Page 1: Table Of Contents
Table of Contents Regulatory Information ..............3 Description of Warning Symbols ..........3 Safety Notices ................4 Preface ..................6 Warranty and Service ..............6 1. Getting Started ................ 8 1.1 Package Contents ............. 8 1.2 Introducing the TV ............. 9 1.3 Features ................ - Page 2 Table of Contents 4. Troubleshooting ..............30 5. Support Timing ..............31 6. Specifications ................ 32 7. Dissembling the stand base ............ 33 8. Using the Cable Organizer ............. 34...
-
Page 3: Regulatory Information
Directive 2006/95/EC on the harmonization of the laws of Member States relating to electrical equipment for use within certain voltage limits. Hannspree cannot accept responsibility for any failure to satisfy the requirements resulting from a non-recommended modification of the device. -
Page 4: Safety Notices
Safety Notices Installation Safety Notes Location Avoid allowing the TV to get prolonged exposure to sunlight or other strong sources of heat. Leave sufficient distance between the TV and the wall to provide enough space for the emission of heat. WARNING To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. - Page 5 Notes: • The LCD TV is for entertainment use only and visual display tasks are excluded. • This device uses a VGA connector to connect to a PC. To reduce the influence of main frequency on the source signal, use a VGA monitor cable with ferrite shield.
-
Page 6: Preface
The information in this manual is subject to change without notice. To the extent allowed by applicable law, Hannspree, Inc. (“Hannspree”) shall not be liable for direct, indirect, special, exemplary, incidental or consequential damages arising from any defect or omission in this manual, even if advised of the possibility of such damages in advance. - Page 7 Hannspree. The TV described in this manual may include copyrighted software of Hannspree (or other third parties). Hannspree (or other third parties) preserves the exclusive rights for copyrighted software, such as the right to distribute or reproduce the copyrighted software.
-
Page 8: Getting Started
Getting Started Package Contents Make sure the following components are included in the box. Please contact Hannspree Customer Service immediately if anything is missing or damaged. • • User’s manual • Quick start guide • Warranty card • Power cord •... -
Page 9: Introducing The Tv
Introducing the TV You can watch SECAM/ PAL/ DVB-T broadcast, cable, or digital television channels, Component and easily connect a VCR, STB or DVD player to the SCART, HDTV ( AV (Composite), and HDMI input ports (location of these ports depends on model). You can also use the TV as a monitor for your PC by connecting it through the VGA port. -
Page 10: Control Panel
Control Panel Description Button Function Power Press to turn the TV on or off. Input source INPUT Press to select the proper input source. Press to turn the on-screen display (OSD) Menu MENU menu on / off. Press to increase the program number or Program select move upward to the previous item on the OSD menu. - Page 11 Description Connector Function Connect to earphones or external Earphone Output speakers with built-in amplifier. Component/ Connect to an external device, such as a L -AUDIO- R CVBS Inputs VCR, STB, or a DVD player. (Audio) Component Connect to an external device, such as a Inputs (Video) VCR, STB, or a DVD player.
-
Page 12: Remote Control
Description Connector Function CI SLOT Connect to a CI device. Connect a HDMI equipment or an HDMI- HDMI 1 Input DVI adapter cable to devices such as a DVD player or set-top box. HDMI 1 Connect a HDMI equipment or an HDMI- HDMI 2 Input DVI adapter cable to devices such as a DVD player or set-top box. - Page 13 Description Icon Function Use to select a program directly. Press 0-9 to Keypad enter the program numbers (press 1 and 0 for program 10). Press to display the programs contained. Pro.List Pro.LIST LAST Last Press to return to the last channel selected. 1.
- Page 14 Description Icon Function Press to change the multi sound selection of Dual sound the TV channel. Select Press P to increase the program number. program Press P to decrease the program number. Red, Green, Press the colored buttons to perform specific Yellow, Blue tasks in the OSD menu or teletext mode.
- Page 15 Description Icon Function Press continuously to toggle through all the Picture Mode picture setting: Vivid, Soft, User, Standard. Press to open favorite list menu and press FAV. Favorite to select channels. Press OK to go to channel the selected channel. FREEZE Press to pause a video frame on-screen.
-
Page 16: Inserting The Remote Control Batteries
Inserting the Remote Control Batteries 1 Open the battery compartment cover at the back of the remote control (A). 2 Insert the batteries paying attention to the polarity markings inside the battery compartment (B). 3 Replace the battery compartment cover (C). - Page 17 CAUTION • If the remote control is not used for a long period, remove the batteries and store them properly. • Handle damaged or leaking batteries carefully, and wash hands with soap if they come in contact with leaked chemical fluids. •...
-
Page 18: Setting Up Your Tv
Setting up your TV Power Connection 1 Connect the power cord to the AC IN input jack on the rear of the TV. 2 Insert the plug at the other end of the power cord into a power outlet. Rear Connections See the illustration and table below for device connection instructions. - Page 19 Connector Notes / Instructions • The VGA and audio cables are optional. AUDIO In HDMI 1 • The HDMI cable is optional. • When the HDMI to HDMI cable is connected, HDMI 2 connecting the audio cable is not necessary. HDMI 3 However it’s necessary to do so if a HDMI to DVI cable is connected.
-
Page 20: Using The Tv
Using the TV 2.3.1 Turning the TV On and Off 1 Press on the control panel or remote control. The power LED indicator on the TV changes from red to green, indicating that the TV is on. 2 Press again. The power LED changes from green to red, indicating that the TV is off. -
Page 21: Adjusting On-Screen Display (Osd) Settings
Adjusting On-Screen Display (OSD) Settings The On-Screen Display (OSD) menu system provides a quick and simple method to adjust the TV settings. The OSD menu can be accessed conveniently through the buttons on the remote control. Before going into details of each OSD option, you may get acquainted with the placement of the OSD system:. -
Page 22: Osd Setting Menus
OSD Setting Menus Follow the instructions indicated on the down side of the OSD Function Menu. Press P on the control panel or arrow keys to scroll through the menus, VOL on the control panel or the arrow key to select an item, or MENU to exit the OSD menu. -
Page 23: Adjusting Sound Settings
• The Advanced Video can be used to adjust the Auto Config, Horizontal, Vertical, Phase, Clock, and Resolution settings for PC mode. Picture Brightness Contrast Sound Colour Temperature Cool Features Advanced Video Parental Enter Select Exit Menu Note: The options available on the OSD may vary depending on the input signal source. -
Page 24: Adjusting Tv Settings
• The SPDIF Delay can be adjusted by pressing to move the scales from 0 to 250. • The AVL can be set to On or Off. • The Type can be set to Normal, Hard of Hearing, or Audio Description. •... - Page 25 • Select Channel Scan to activate the automatic TV channel search. Picture Picture Channel Scan Update Scan Sound Sound Status:Scanning... Single RF Scan Analog Channels: 0 Digital Channels: 0 Analog Manual Scan Features Channel Skip Features Channel Sort Parental Parental Channel Edit Decoder Analog Ch Fine Tune...
- Page 26 • Select the Channel Sort to change the order of the channel list. • The Channel Edit allows you to adjust the detailed items, including Channel Number, Channel Name, Frequency, Colour System, and Sound System for each channel. Picture Picture Analog ---- Transmitter...
-
Page 27: Adjusting Features Settings
Adjusting Features Settings Press MENU to enter the OSD Main Menu screen. Picture Menu Language Picture Format Stereo Sound Press to select the Features menu. Time Subitile Press to enter the Features menu. Features Teletext Language Common Interface Parental Reset Default Press to select an item. - Page 28 • The Picture Format selections include Auto, Normal, Zoom1, Zoom2, Full, Subtitle, Native, and Wide. Please see below for details. Auto Normal Zoom1 Zoom2 Full Subtitle Native Wide Note: The options available on the OSD may vary depending on the input signal source.
-
Page 29: Adjusting Parental Settings
Adjusting Parental Settings Press INPUT and select TV as the signal type. Picture Channel Block Press MENU to enter the OSD Main Menu Parental Guidance Sound Input Block screen. Set Password Features Clear All Press to select the Parental menu. Parental Press to enter the Parental menu. -
Page 30: Troubleshooting
Troubleshooting Situation Solution • Connect the power cord properly. • Check if the power LED is on or not. • Press on the control panel or remote control. No picture and sound. • Press Input to cycle through connected video sources. •... -
Page 31: Support Timing
Support Timing PC Mode Support Timing SJ25DMAB Horizontal Freq. Vertical Freq. Pixel Clock SJ19DMAB SJ28DMBB Mode Resolution (KHz) (Hz) (MHz) SJ22DMAB SJ32DMBB SJ42DMBB 640 x 480 31.469 59.94 25.175 640 x 480 37.861 72.809 31.5 640 x 480 37.5 31.5 720 x 400 31.469... -
Page 32: Specifications
Specifications Model No. SJ19DMAB SJ22DMAB SJ25DMAB SJ28DMBB SJ32DMBB SJ42DMBB DISPLAY Aspect Ratio 16:9 16:9 16:9 16:10 16:9 16:9 Resolution 1366 x 768 1366 x 768 1920 x 1080 1920 x 1200 1920 x 1080 1920 x 1080 Bulgarian, Croatian, Czech, Danish, Dutch, English, Finnish, French, Ukrainian,... -
Page 33: Dissembling The Stand Base
*Installing the LCD TV requires special skill that should only be performed by qualified service personnel. Customers should not attempt to do the work themselves. Hannspree bears no responsibility for improper mounting or mounting that results in accident or injury. You can ask a qualified service personnel about... -
Page 34: Using The Cable Organizer
Using the Cable Organizer Route the cables through the cable clamp as shown:...
