APPROVAL:
ECO-198
Part Number Legend – PD2035-290XXX*-YYY
YYY -> Power Output
•
o 009 for 8.5W
o 008 for 7.5W
o 007 for 6.5W
*XXX digits denote product branding
2801 E. Camelback Rd. Ste. #180
Phoenix, AZ 85016
jupiteresearch.com
DOCUMENT NO:
CDS – PD2035-290XXXX-YYY
Luster Power Supply
Jupiter PN(s):
See part number legend
Electrical Specifications
Battery Cell Capacity
Power Output (±0.5W)
Max. Current Output
Resistance
Charging Current
Activation Time
User Interface
Cartridge Attachment
Activation
Notification
Low Battery Notification
Charging Indication
VER:
1.1
EFFECTIVE DATE:
04/15/2020
PAGE 1 OF 3
350 mAh
Standard power is 8.5W:
6.5W and 7.5W options
available upon request
3.0 A
0.8 – 1.5 Ω
Maximum 500 mA
0 – 10 seconds;
Other time durations
available by request
Magnetic
Breath Actuated
LED
LED flashes 10 times
LED is on during
charging, flashes 20X
and turns off when fully
charged, and flashes 3X
when disconnected
from power.
Advertisement
Related Manuals for Jupiter PD2035-290007 Series
Summary of Contents for Jupiter PD2035-290007 Series
- Page 1 DOCUMENT NO: CDS – PD2035-290XXXX-YYY VER: EFFECTIVE DATE: Luster Power Supply 04/15/2020 APPROVAL: ECO-198 Jupiter PN(s): See part number legend PAGE 1 OF 3 Electrical Specifications Battery Cell Capacity 350 mAh Power Output (±0.5W) Standard power is 8.5W: 6.5W and 7.5W options available upon request Max.
- Page 2 Storage Humidity: Li-ion batteries; section 38.3. Humidity 35% to 70% Jupiter power supplies are not required classified Dangerous Goods when packaged Compatibility properly for transport by sea, air, or ground due to their small capacity The Luster Power Supply uses a Magnetic CCELL and containment within the device.
- Page 3 DOCUMENT NO: CDS – PD2035-290XXXX-YYY VER: EFFECTIVE DATE: Luster Power Supply 04/15/2020 APPROVAL: ECO-198 Jupiter PN(s): See part number legend PAGE 3 OF 3 User Guide Assembly Guide to setup and use of device. and User Guide Plug atomizer into battery.
