APPROVAL:
ECO-312
Description: All-in-one disposable vape pen, top-fill cartridge design
Features:
•
CCELL Technology atomizer (T35-EVO) – heating element embedded in porous ceramic
•
Battery Capacity: 280mAh
•
Preheat and child-resistant button
•
0.5ml and 1ml options available at the same size
•
Clog-free dual air vents
•
Breath actuated
•
USB-C charging
•
Food-grade mouthpiece
•
Medical-grade stainless steel center post
2801 E. Camelback Rd. Ste. #180
Phoenix, AZ 85016
jupiteresearch.com
DOCUMENT NO:
CDS- LX3928-7nnXXXX-
Voca Pro
Jupiter PN(s):
*All dimensions in mm
YYYZZZ-F
Multiple–view PN Legend
VER:
1.1
EFFECTIVE
DATE:
10/06/2023
PAGE 1 OF 5
Advertisement
Related Manuals for Jupiter Voca Pro
Summary of Contents for Jupiter Voca Pro
- Page 1 DOCUMENT NO: CDS- LX3928-7nnXXXX- VER: YYYZZZ-F EFFECTIVE DATE: Voca Pro 10/06/2023 APPROVAL: ECO-312 Jupiter PN(s): Multiple–view PN Legend PAGE 1 OF 5 *All dimensions in mm Description: All-in-one disposable vape pen, top-fill cartridge design Features: • CCELL Technology atomizer (T35-EVO) – heating element embedded in porous ceramic •...
- Page 2 DOCUMENT NO: CDS- LX3928-7nnXXXX- VER: YYYZZZ-F EFFECTIVE DATE: Voca Pro 10/06/2023 APPROVAL: ECO-312 Jupiter PN(s): Multiple–view PN Legend PAGE 2 OF 5 • Available for customization Specifications Internal Volume Gross 0.5 mL 1.0 mL Max. fill volume 0.5 mL 1.0 mL Weight, empty with Mouthpiece 26.3 g...
- Page 3 2 times and turns off. Custom over-vaping protection times are available upon request. Li-ion Battery Cells Jupiter power supplies are not required to be classified as Dangerous Goods when packaged properly for transport by sea, air, or ground due to their small capacity and containment within the device.
- Page 4 Cells are not accessible to the user without permanent damage to the unit. Voca Pro Filling Instructions Failure to follow these instructions may result in device leakage or poor performance. Voca Devise Filling and Assembly Instructions Insert a filling needle into the space between the airway and the outer wall of the reservoir.
- Page 5 DOCUMENT NO: CDS- LX3928-7nnXXXX- VER: YYYZZZ-F EFFECTIVE DATE: Voca Pro 10/06/2023 APPROVAL: ECO-312 Jupiter PN(s): Multiple–view PN Legend PAGE 5 OF 5 Pre-Loaded Filling Instructions • Recommended Closure Force (50pcs) o 1124.04IbF - 2248.09IbF (5000N-10000N) For Technical Assistance please contact us at: CS@JupiterResearch.com...
