wallas 3009 Operation Manual

OPERATION GUIDE
3 0 0 9 A D V A N C E D C O N T R O L P A N E L
Please Refer to Manual for Full Operation and Maintenance Instructions at wallas.com
DIGITAL PANEL LEGEND
Main Menu Bar
1
Manual Mode
Settings
Temp Sensor (must be wired)
Device Info
Device Stats
Clear Lock
Temp Unit (C°/F°)
Connections
Altitude
Power Level 1 - 6
2
Stove Status
3
Start/Stop Icon
4
Info Bar
5
Power On/Off
Combustion
Info
Lock
Stove power %
S t o v e s 6 0 0 D & 1 2 0 0 D
BUTTONS
Select
Button
Left Arrow
Right Arrow
Move cursor
left or up Move cursor
right or down
1200D
Cooking area
Stewing area
SCAN FOR MANUALS
600D 1200D
IGNITION
To start, use the Arrow Buttons to
move the orange selection square
to the white Start/Stop Icon and
press the Select Button. Confirm
the selection by holding the Select
Button down for 3 seconds (safety
feature). White icon turns orange.
Starting will appear on the screen.
The light orange combustion light
will light up when the burner flame
has been ignited and the
combustion has stabilized (in about
5 min). Stove will be fully
operational about 10 min later.
POWER LEVEL SETTING
Use the Arrow Buttons (left or
right) to move the orange
selection square to the Main
Menu Bar. Press Select Button to
activate the Main Menu Bar. Use
Arrow Buttons to choose the
Manual Mode and press the
Select Button to select.
Use the Arrow Buttons to move
the orange selection square to
the Power Level and press
Select Button (picture 2).
Press Arrow Buttons to set the
desired power level (1-6).
