Technical Support and E-Warranty Certificate www.vevor.com/support PORTABLE DIESEL&GASOLINE TANK USER MANUAL We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
Page 2
This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.
SAFETY INSTRUCTION AND PRECAUTIONS WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Part List GENERAL: All transfer units come standard with an Auto shut-off gun and all pumps feature a duty cycle for 30 minutes of continuous dispensing,all pumps also contain an internal bypass that allows for the pump to operate for up to a maximum of three minutes when the f i l l i n g nozzle shuts off without damaging the pump or motor.
GUN: Trigger filling nozzle with automatic shut-off and hose swivel. DELIVERY HOSE; 4mx3/4 inch Diesel Delivery hose supplied. FILTRATION: Suction foot screen filter PUMPS: Power Motor Duty Internal Motor Internal Volts Open Flow Power Cord Output Cycle Bypass Speed Fuse 4m with 140W 12V DC 40L/min...
Page 5
Warning! Prior to installing or using the Diesel unit all operators must have read and fully understand the contents of this instruction manual as well as all other manuals supplied,and the safety decal fitted to the Diesel/gasoline unit Warning! Never allow inadequately trained person to install or operate the Diesel /gasoline unit.
Warning! Any spillage shall be cleaned up immediately and the materials used in the clean-up shall be disposed of safely and in accordance with any legal regulations and codes of practice that apply to the safe use,storage and disposal of Diesel/gasoline Warning! Ensure that the electrical lead(s)are always in good condition and the wire is not exposed through the plastic coating.Do not allow the lead to become tightly knotted,crushed...
clips on the battery.If you intend to extend the cable or add a plug,make sure it is of sufficient capacity 7Amps FILLING THE DIESEL UNIT; Ensure that the tank is supported on an even base capable of taking the weight.No Special equipment is required for filling the tank,however when the lid has been removed from the tank take care not to introduce contaminants into the tank via the filler neck and ensure that the lid is kept free of contaminating particles while filling.
Trouble shoot TROUBLE SHOOTING GUIDE Problem Solution ·Ensure battery wires are connected to battery properly.Red Pump does not operate Clip to +ve ·Check Fuse(7A)under plastic pump switch cover is intact. ·Remove pump end cover,connect power to White &Black wires to test To Test &Repair if Pump ·If motor still does not operate,remove 3 x head cover bolts &...
Page 9
·Remove gun from hose &re-test,Run the hose into the tank To Test &Repair if the filling neck while checking Pumps running but low ·If flow improves,check hole in the end of the nozzle for or nil flow from nozzle blockage ·Replace gun as required ·Check red alligator clip fitted to positive terminal,black to negative.If it is the wrong way around the pump runs...
WARNING: Changes or modifications to this product not expressly approved by the party.responsible for compliance could void the user's authority to operate the product. Note: This product has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules, These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 12
Technical Support and E-Warranty Certificate www.vevor.com/support...
