- Page 1 Pre-installation Manual HDX NewsSpeed...
- Page 3 Pre-installation Manual HDX NewsSpeed T11397 Edition AB, March 2016 This manual has part No 10076649...
- Page 4 This manual is published by: GLUNZ & JENSEN A/S Selandia Park 1 DK-4100 Ringsted Denmark Phone:+45 57 68 81 81 E-mail: gjhq@glunz-jensen.com Internet: www.glunz-jensen.com Copyright © 2014 by GLUNZ & JENSEN A/S. Pre-installation Manual - HDX NewsSpeed 1448...
-
Page 5: Part 0: Introduction
Introduction Part 0: Introduction Reservations This manual was written and illustrated using the best possible information • available at the time of publication. Any differences between this manual and the equipment reflect improvements • introduced after the publication of the manual. Changes, technical inaccuracies and typographic errors will be corrected in •... -
Page 6: Table Of Contents
Introduction Table of contents Table of contents Part 0: Introduction ........0-3 Reservations . -
Page 7: Part 1: Transportation
Transportation When the processor arrives Part 1: Transportation When the processor arrives Storing the processor before installation The crated processor will usually be delivered some time before the arrival of the Service Technician. In which case you should prepare an appropriate place indoors to store the crated processor. -
Page 8: Checking The Crate For Damage
Transportation Transporting the processor Preheat section Width (W) 151 cm (59.4") Length (L) 118 cm (46.4") Height (H) 75 cm (29.5") Weight, crated 245 kg (540.1 lb) (+/- 5%) Weight, without crate 170 kg (374.8 lb) Checking the crate for damage Check if the crate is damaged at the time of delivery. -
Page 9: Transporting The Processor
Transportation Transporting the processor Transporting the processor Lifting the crate To lift the crate, at least a forklift truck or two persons and a hand powered pallet mover are required. " Please note that you can only insert the forks of the forklift truck or pallet mover from the side as illustrated below. -
Page 10: Available Width For Transport
Transportation Transporting the processor Available width for transport Depending on the width of the door(s) through which the processor has to be transported to the installation site, the Service Technician may have to perform the actions described in the table below: If width of door is …... -
Page 11: Part 2: Installation Requirements
Installation requirements Cleaning facilities Part 2: Installation requirements Cleaning facilities It is essential to have easy access to a sink and a water tap with hot water where rollers, guides, and brushes can be washed. Minimum recommended size of the sink 150 x 40 cm (60 x 16") Space requirements Free space around the machine... -
Page 12: Water Supply And Drains
Installation requirements Water supply and drains Water supply and drains Processor Water supply 3/4" male T11372 Developer Developer overflow drain Gum section overflow Prepare the installation site for water supply and drain connections according to the illustration above. Please also refer to the processor dimensions described earlier in this document. -
Page 13: Drains
Installation requirements Environmental requirements Drains All drain hoses must have a positive fall from the processor to the drain. Never lead drain hoses from the developer section into a drain, as most developer solutions are strong pollutants. It is also illegal to empty these types of chemicals into the public sewer system. -
Page 14: Electrical Requirements
Installation requirements Electrical requirements Electrical requirements Electrical installation must conform to local regulations and guidelines. Main power connection The main power connection is made in the processor's field-wiring box located on the left side of the processor as shown in the illustration below. Main power Main switch connection... -
Page 15: Electrical Specifications
Installation requirements Electrical specifications The processor is Class 1 equipment. Therefore, the processor must be connected to earth to avoid electrical shocks. Please be aware of double pole/neutral fusing. Electrical specifications Installation requirements for power supply " Specifications on the equipment’s name plate is the actual input current and will thus not be identical to below mentioned. - Page 16 Installation requirements Electrical specifications Above mentioned power consumption measured with the following settings: · Stream feed · Max. plate width · Pre-heat 120°C · Dev. temp. 24°C · Dryer temp. 45°C · Speed 1,8 m/min. · Ambient temp. approx. 24°C Pre-installation Manual - HDX NewsSpeed 1448...
-
Page 17: Part 3: Pre-Installation Check List
Pre-installation check list Part 3: Pre-installation check list Please ask the customer to answer the following questions in order to ensure a trouble-free installation of the processor: 1. Delivery of the crate and transport to the installation site YES NO A. - Page 18 Pre-installation check list 3. Water supply and drain YES NO A. Capacity of air condition/ventilation adequate with regard to BTU as specified on page 2-5? B. Can a hose ¾" BSP be connected to the water supply tap? C. Is there a large sink (with hot water) for cleaning the equipment? D.
