- Page 1 INSTRUCTION MANUAL MILK COOLER Please read the user’s manual before you use this product. If you request unnecessary services, you may waste money. Thus, fix simple troubles by yourself which you have found...
-
Page 2: Table Of Contents
Content 1. Preface ..................... 2 2. Use of the equipment ............... 6 3. Technical features ................6 4. Operation ....................6 5. Handling ....................7 6. Installation procedure ..............7 7. Connecting to the main power supply ........7 8. Maintenance instructions ..............9 9. -
Page 3: Preface
Preface PLEASE READ INSTRUCTIONS BEFORE USING THIS APPLIANCE. IMPORTANT SAFETY INSTRUCTION To reduce the risk of fire, electric shock, or injury to persons when using your product, basic safety precautions should be followed,including the following. This appliance must be properly installed and located in ... - Page 4 Connect to properly grounded outlets only. Avoid the use of extension cords. Do not run cord under carpeting, runners or the like. Arrange cord away from traffic area and where it will not create a tripping hazard. Always unplug appliance when not in use and before cleaning, ...
- Page 5 This equipment is intended for the storage and display of packaged products only. WARNING: Keep clear of obstruction all ventilation openings in the appliance enclosure or in the structure for building-in. WARNING: Do not use mechanical devices or other means to ...
- Page 6 operator procedures and instructions maintenance operation The manual is to be considered an integral part of the refrigerator and should be stored in a safe place for father consult to permit a good working life of the refrigerator. The appliance is intended for commercial use only.
-
Page 7: Use Of The Equipment
2. Use of the equipment The refrigerator is for reserving fresh perishable food products with a built-in refrigerated unit. The operating temperature for refrigeration is: Between 33 degrees Fahrenheit and 45 degrees Fahrenheit at room temperature of 109 degrees Fahrenheit and 60%RH. 3. -
Page 8: Handling
5. Handling ▲The refrigerator arrive in PET film and packed in cardboard box on a wood pallet. ▲The refrigerator must be transported and handled with care to avoid posing a hazard to persons or property. ▲Never place a refrigerator with an in-built refrigerated unit on its side or turn it upside down as this may damage or impair operation of the refrigerated unit. -
Page 9: Connecting Steps
▲ This operation must be carried out by professionally and qualified persons. ▲ The refrigerator are supplied complete with a power supply cable for the connection to the main power supply. A thermomagnetic circuit breaker (not supplied) must be installed between the mains power point and the power supply cable of the refrigerator. -
Page 10: Maintenance Instructions
▲ Check that the refrigerator is in order as demonstrated by the pilotlight incorporated in the main switch coming on Maintenance instructions The smooth operation and life of the equipment are mainly determined by correct and regular maintenance. Cleaning: Regular cleaning of the refrigerator unit is strongly recommendedeach month. -
Page 11: Technical Service
☆ Check that the plug is inserted properly in the socket ☆ Check that the switch on/off ☆ Check that the mains voltage powers the plug Refrigerator temperature go up: ☆ Unit to near to a heat source ☆ Condenser dirty or close ▲... -
Page 12: Configuration Sketch Map
11. Configuration Sketch Map 1. Microcomputer controller 2. CASTER 3. Water connection box 4. Power adapter 5. Evaporator 6. Compressor 7. Condenser fan 8. Condenserr 9. Evaporator fan Operating Instruction 1. New upright air-cooling refrigerator should be opened and ventilate it before it is in use. After that, users should use warm water clean its inside. - Page 13 controller works as: if the temperature increases and reaches set point plus differential the compressor is started and then turned off when the temperature reaches the set point value again. 3. Microcomputer Controller Operation Instruction: 4. Microcomputer panel sketch map, meanings of running indicator light and LED showing.
- Page 14 6. How to see the point . Push and immediately release the key, the set point will be showed; Push and immediately release the key or wait about 5s to return to normal visualisation. 7. How to change the setpoint . Push the SET key for more than 2 seconds to change the Set point value;...
- Page 15 Alarm signalling . Mess. Cause Outputs Compressor output according to “P1” Room probe failure “Cy”e“Cn” “P2” Evaporator probe failure Defrost end is timed Maximum temperature “HA” Outputs unchanged alarm Minimum temperature “LA” Outputs unchanged alarm “EA” External alarm Outputs unchanged “CA”...
- Page 16 Tab.1 normal operation start function icon blink Compressor request request defrost request output on output off alarm no alarm RTC fitted and RTC not fitted or ON if RTC enabled,at least 1 time disabled,not even 1 time clock fitted band set band set Table of functions activated by the buttons-models S,X,Y,C Tab.2...
- Page 17 Setting the set point(desired temperature) ▲ press SET for 1s the set value will start flashing after a few moments; ▲ increase or decrease the value using UP or DOWN; ▲ press SET to confirm the new value. Switching the device ON/OFF ▲Press UP for more than 3s.
-
Page 18: Technical Parameters
Technical Parameters MILK COOLER AMC-5801 3.0 +33~+45 R290 58×32×47 AMC-5802 3.0 +33~+45 R290 58×34×47 AMC-4901 3.0 +33~+45 R290 49×32×47 3.0 +33~+45 R290 49×34×47... - Page 19 Warning Please hold the door handle with both hands. Open/close the door evenly. DO NOT release the door until it is completely opened/closed. CAUTION: To prevent damage to the equipment and bodily injury, do not drop/slam the door.
-
Page 20: Official Approval And Rules
OFFICIAL APPROVAL AND RULES CONFORMS TO UL STD.471 CERTIFIED TO CSA STD.C22.2 NO.120 CONFORMS TO NSF/ANSI STD. 7 R10001001205 version number 20240116...
