- Page 1 INSTRUCTION MANUAL Solid Top Chest Freezer MWF9007 MWF9010GR MWF9013GR MWF9016GR Please read this user’s manual thoroughly before using. Keep this manual handy for further reference. Email: warranty@atosausa.com Toll Free: 1-800-683-8660 (USA) 1-855-885-6518 (Canada)
-
Page 2: Warranty Information
Warranty Information One YEAR WARRANTY All claims for parts or labor must be made directly through Atosa. All claims must include: model number of the unit. the serial number. proof of purchase, date of installation. and all pertinent information supporting the alleged defect. In case of compressor replacement under warranty. - Page 3 EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF. Outside U.S. and Canada: This warranty does nor apply to areas ourside the continent of the United States. Atosa is not responsible for any warranty claims made on products sold or used in such areas.
-
Page 4: Product Information
The operating temperature for frozen food maintenance is: ■ Between -8°F and -1°F at room temperature of 109°F and 60% RD. --Technical Specification Model MWF9007 MWF9010GR MWF9016GR Rated Electric 115v, 60Hz, 1.0A 115v, 60Hz, 1.5A 115v, 60Hz, 2.6A Refrigrant(Ounces) R600a / 1.90... -
Page 5: Installation Instruction
Installation Instruction --Unpacking and Handling The freezer is in the package of cardboard box with foam boards protect when it arrives at user’s place. The freezer must be transported and handled with care to avoid posing a hazard to persons or property. Never place a freezer on its side or turn it upside down as this may damage or impair operation of the refrigerated unit. -
Page 6: Door Handle Installation
--Door handle Installation Model MWF9010GR, MWF9013GR and MWF9016GR have extension door handle, it need to be installed at field when the freezer is located in the user place, the door handle parts are packed in a bag inside cabinet when freezer arrive at user location. -
Page 7: Maintenance Instruction
Maintenance Instruction --Care and Cleaning The freezer should be cleaned periodically; generally clean it every 30-45 days. Unplug before cleaning and use a soft cloth with a solution of warm water and mild soap to scrub inside and outside of the cabinet. -
Page 8: Technical Service Information
Service Part No MWFP901 Door for MWF9007 MWFP902 Door for MWF9010GR MWFP903 Door for MWF9013GR MWFP904 Door for MWF9016GR MWFP905 Door Gasket for MWF9007 MWFP906 Door Gasket for MWF9010GR MWFP907 Door Gasket for MWF9013GR MWFP908 Door Gasket for MWF9016GR MWFP909 Control Panel... - Page 9 Continue part list No in explode view Description Service Part No MWFP910 Compressor for MWF9007 Compressor for MWF9010GR MWFP911 &9013GR Compressor for MWF9016GR MWFP912 MWFP913 Thermostat MWFP914 Filter Compressor apartment MWFP915 Cover(9007) Compressor apartment MWFP916 Cover(9010GR above) MWFP917 Outter Drain plug...
- Page 10 --Electric Connection Diagram MWF9007 Diagram MWF9010GR/9013GR/9016GR Diagram...
-
Page 11: Troubleshooting
--TroubleShooting Problem or Concern Possible Cause Common Solution The plug isn’t connected to the Replug it. The indicator is not on. socket really. The compressor doses not start. no power Connect the socket with power. The indicator is on ,but the compressor doesn’t work and The power voltage is＜98V.
