- Page 1 REVERSE OSMOSIS WATER FILTRATION SYSTEM S Series Thank you for choosing Stokk water filtration system. For any inquiries, please feel free to reach us via email support@stokkfilter.com WWW.STOKKFILTER.COM...
-
Page 2: Table Of Contents
CONTENT PREPARATION INSTALLATION OPERATION CARE & MAINTENANCE TROUBLESHOOTING WARRANTY CUSTOMER SUPPORT... -
Page 3: Preparation
PREPARATION The following instructions must be followed when using the product to prevent injury and property damage. Any incorrect operation due to disregard of instructions may cause harm or damage. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 4: Product Specifications
In order to run the When not in use for an and machine longevity, machine smoothly, use extended period, shut off regularly clean and replace Stokk filters and the water source and the filters. accessories. power supply and store the machine properly. -
Page 5: Package Contents
RS1-RO600 metal ions (arsenic, lead), bacteria, 12-24 months chemical residues, microorganisms, Reverse Osmosis and organic compounds (trichloro- Membrane methane, carbon tetrachloride). Search "stokk+filter model" on amazon.com to purchase the correct replacement filter. support@stokkfilter.com www.stokkfilter.com +1(866)-387-8668 (Mon-Fri 10�00-14�00 EST) -
Page 6: System Features
Check each item against the parts list to ensure nothing is missing or damaged during shipping. If any parts are cracked or broken, do not proceed with the installation; instead, contact Stokk customer service at support@stokkfilter.com. Familiarize yourself with all components for a swift installation. -
Page 7: Parts Description
PARTS DESCRIPTION Parts List RO Faucet * 1 Set Feed Water Adapter 3/8" and 1/2" * 1 Quick-Connect Drain Saddle 1/4" * 1 Set RO System * 1 Set Fitting 1/4" * 1 White PE Pure Water Blue PE Feed Water Tubing 1/4"... - Page 8 RO System Description Front PPC Filter Filtering Indicator RO Filter Reset Button RO Filter Life Indicator PPC Filter Flush Button Life Indicator Feed Water Port Pure Water Port Waste Water Port...
-
Page 9: Installation Tips
INSTALLATION TIPS How To Operate The Tubing Connecting Tubing: · Insert the tubing into the fitting until it reaches the marked full insert point (Figure ①). Ensure complete insertion to avoid leaks. · Once fully inserted, attach the blue lock clip to secure the tubing in place. Note: If the tubing is too long, trim it to the appropriate length using a sharp utility knife or scissors. -
Page 10: Installation Steps
How To Drill A Hole For The Ro Faucet (Optional) Please remember to wear safety goggles to protect your eyes while drilling. · Select an appropriate drill bit based on the material of your sink or countertop. · Place the positioning stickers provided on the sink or countertop and drill holes according to the dimensions indicated on the sticker. - Page 11 Step 1. Install The Feed Water Adapter (3/8" or 1/2") Note: Ensure the feed water adapter is closed before installation. ·Turn off the water supply and open the kitchen faucet to release all water pressure. · Place a towel under the water pipe and disconnect the cold-water pipe from the cold-water supply valve.
- Page 12 Step 2. Install the RO Faucet Note: If your kitchen sink or countertop does not have a hole, you will need to drill a 1/2" hole. Refer to the "How to Drill a Hole for the RO Faucet" instructions. · Insert the faucet stem into the hole on the countertop. ·...
- Page 13 Step 3. Install the Drain Saddle · Affix the foam sealing strip onto the front plate of the drain saddle, ensuring proper hole alignment (see Figure ⑥). · Choose a convenient location on the drainage pipe and drill a 1/4" hole (see Figure ⑦).
- Page 14 Step 4. Connect Water Tubings Note:If the supplied pipes are too long, cut them evenly to ensure a complete fit into the connectors. Ensure all water tubing connections are fully inserted to prevent leaks. ·Remove the dust plug before connecting the hose. ·Connect the blue Feed Water Tubing: Insert both ends of the blue tubing into the feed water adapter and the "Feed Water"...
- Page 15 ·Connect the red Waste Water Tubing: Insert the other end of the red tubing into the "Waste Water" port of the water system, securing it with a lock clip. Lock Clip Waste Water Drain Saddle Tubing "Waste Water" port Waste Water Tubing Step 5.
-
Page 16: Control Panel
OPERATION CONTROL PANEL Water Purification Indicator Lights up blue when the water system is purifying water and turns off when the water purification is completing. RO Filter Life Indicator Lights up blue under normal conditions. Replace new RO filter and reset the filter when the indicator lights up red. PPC Filter Life Indicator Lights up blue under normal conditions. -
Page 17: Water Dispensing
WATER DISPENSING · Turn on the RO faucet at any time to dispense healthy and tasty pure water. FLUSHING System Cleaning Note: Clean the whole system at least 30 minutes before first use, after replace- ment of filters, or if the machine has been inactive for an extended period. ·... - Page 18 Step 1. Replace the Filter · ·Unplug the water system. Put a dry towel under the water system before replacing the filter. ·Pull out the filter handle and turn counterclockwise to remove it. ·Insert the new filter in the correct position, turn clockwise until you feel a click. Note: You can safely dispose of the exhausted filters.
-
Page 19: Care & Maintenance
CARE & MAINTENANCE · If the water system has not been used for more than two days, turn on the faucet for 3 minutes before using it. · If you plan not to use the water system for more than one week, turn on the RO faucet, shut off the cold-water valve, and disconnect the power. -
Page 20: Troubleshooting
TROUBLESHOOTING Problem Possible Cause Solution The machine ·The power under sink is off. ·Check and turn on the cannot be ·The power outlet is damaged. power under the sink. powered on after ·The hardware is damaged. ·Try another power outlet. pluged in. - Page 21 Problem Possible Cause Solution Water leakage ·Connections are not firm. ·Check all joints, fittings of machine. and tubing connections to locate the leakage. Make sure the filters are well installed. There is odor or ·Incorrect tubing installation. ·Make sure the waste water bubbles in the ·The machine is being used tubing is not connected with...
-
Page 22: Faq
Q: Why did I receive a new water purifier with droplets in the package? A: Each filter undergoes individual examination for filtration reliability using air pressure. Additionally, the entire filtration system is inspected with sterile water to guarantee optimal performance. Any remaining droplets may not be completely drained during shipping and are harmless. -
Page 23: Warranty
WARRANTY TERMS & POLICY We warrant the highest quality in material, craftsmanship, and service for all our products, effective from the date of purchase throughout the warranty period. Defective products due to manufacturer flaws will be replaced based on eligibility. Refunds are available within the first 30 days of purchase and are applicable only to the original purchaser. -
Page 24: Customer Support
CUSTOMER SUPPORT If you have any questions or concerns about your new product, please contact our helpful Customer Support Team. support@stokkfilter.com www.stokkfilter.com www.facebook.com/stokkfilter... - Page 25 W WW.STO K K FI LTER.CO M facebook.com/stokkfilter support@stokkfilter.com Jin Fang Technology (Hong Kong) Limited Unit 616, 6/f, Kam Teem Ind Bldg, 135 Connaught Rd West, Sai Wan, Hong Kong +1(866)-387-8668 (Mon-Fri 10�00-14�00 EST)
