- Page 1 TR934N85C User Manual Tumble Dryer USER MANUAL...
-
Page 2: Table Of Contents
9. DAILY USE......................21 10. HINTS AND TIPS....................24 11. CARE AND CLEANING..................26 12. TROUBLESHOOTING..................28 13. TECHNICAL DATA................... 31 14. QUICK GUIDE....................33 15. PRODUCT INFORMATION SHEET IN REFERENCE TO E.U. REGULATION 1369/2017....................... 35 16. ENVIRONMENTAL CONCERNS..............36 My AEG Care app... -
Page 3: Customer Care And Service
ENGLISH FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it. -
Page 4: Children And Vulnerable People Safety
1.1 Children and vulnerable people safety WARNING! Risk of suffocation, injury or permanent disability. This appliance can be used by children aged from 8 • years and above and persons with reduced physical, sensory or mental capabilities or lack of experience... - Page 5 ENGLISH houses and other similar accommodation where such use does not exceed (average) domestic usage levels. Do not change the specification of this appliance. • If the tumble dryer is put on top of a washing machine, • use the stacking kit. The stacking kit, available from your authorized vendor, can be used only with the appliance specified in the instructions supplied with the accessory.
- Page 6 WARNING: In the appliance enclosure or in the built - • in structure, keep ventilation opening clear of obstruction. WARNING: Do not damage the refrigerant circuit. • If the mains power supply cable is damaged, it must • be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons to avoid an electrical hazard.
-
Page 7: Safety Instructions
ENGLISH 2. SAFETY INSTRUCTIONS 2.1 Installation to a grounding connection in the building. • Make sure that the parameters on the rating plate are compatible with the Warning: Risk of fire / Flammable electrical ratings of the mains power materials. supply. -
Page 8: Internal Lighting
2.4 Internal lighting tight. The damage of the system can cause a leakage. WARNING! 2.7 Service Risk of injury. • To repair the appliance contact the • Visible LED radiation, do not look Authorised Service Centre. directly into the beam. -
Page 9: Product Description
ENGLISH 3. PRODUCT DESCRIPTION Water container Airflow slots Control panel Condenser lid Internal lighting Condenser cover Appliance door Adjustable feet Filter Rating plate and QR Code For ease of loading laundry or ease of installation the door is reversible (see the separate leaflet). -
Page 10: Control Panel
4. CONTROL PANEL Programmes Start/Pause button Programme dial SyncDry button Favourite programmes Options Display auto-off function On/Off button with Finish In button Remote Start button 4.1 Display Symbol on the display Symbol description cycle time indication... -
Page 11: Wi-Fi - Connectivity Setup
ENGLISH Symbol on the display Symbol description maximum load finish in selection (up to 24h) wireless connection remote control APP notification to check + Anti Crease option on child lock on laundry dryness: iron dry, cupboard dry, extra dry Time Dry option on drain the water container indicator: clean the filter... -
Page 12: Wireless Connection Configuration
Access Point is open for around 3 minutes. • Scan the QR code with the built-in 4. Configure the My AEG Care app on camera app to download the My AEG your smart device and follow the on... -
Page 13: Remote Start
5.6 Wi-Fi Always On but it is also possible to start a drying program remotely. The Wi-Fi Always On function can be activated only via My AEG Care app. Remote Start This feature keeps the appliance connected to the network even when the... -
Page 14: Programmes
My AEG Care and you will be able to choose a drying programme that suits your needs most. Programme names are subject to change depending on market requirements without notice. The My AEG Care app will give you a complete description of each programme. Sportswear Pillow Silk... - Page 15 ENGLISH Programme Load Properties / Fabric mark Blended garments containing mostly Synthetics 4,0 kg synthetic fibres like polyester, polya‐ mide, etc. Recommended for generic delicate Delicates 2,0 kg fabrics such as viscose, rayon, acryl‐ ic and their blends. Gently dries for machine and hand-washable wool‐ lens.
- Page 16 Programme Load Properties / Fabric mark Dries and sanitizes your garments and other items maintaining the tem‐ perature above 60°C over time, re‐ moving 99.9% of bacteria and viru‐ 5,0 kg Hygiene Note: This cycle should only be used for wet items.
-
Page 17: Consumption Data
ENGLISH Options Dryness + Anti Time Dry Silent Programme Level Crease Bedlinen XL Outdoor Hygiene Duvet Down Jackets 1) Aside from the programme, you can set one or more options at the same time. 2) Set by default 3) See chapter OPTIONS: Time Dry on Wool programme Consumption data Energy consump‐... -
Page 18: Options
7. OPTIONS 7.1 Dryness Level 7.3 + Anti Crease Extends up to 120 minutes the anti- This option helps to achieve requested crease phase (30 minutes) at the end of laundry dryness. You can select the level the drying cycle. After drying phase drum... -
Page 19: Favourite Programmes
Once the washing programme has come to an end, the washing machine transfers the programme data via the home router Wi-Fi to the AEG Cloud, as well as to your tumble dryer. In order to use the SyncDry function, the AEG tumble... -
Page 20: Before First Use
8. BEFORE FIRST USE Working compressor. Rear drum locks are removed automatically when dryer is activated for the first Brrrr time. Possible to hear some noise. To unlock the rear drum locks: 1. Switch on the appliance. 2. Set any programme. -
Page 21: Daily Use
ENGLISH 9. DAILY USE 9.1 Preparing the laundry • Always set the programme suitable for the type of laundry. Very often the clothes after • Do not put light and dark colours washing cycle are kneaded together. and tangled altogether. •... -
Page 22: Setting A Programme
9.6 Setting a programme 1. Pull open the appliance door. 2. Load the laundry one item at a time. 3. Close the appliance door. 9.4 Turning on the appliance Use the programme dial to set the programme. The approximate programme duration appears on the display. -
Page 23: Child Lock Option Activation
ENGLISH You can activate the child lock option: After setting a drying programme, the icon lights up on the display • before you touch the Start/Pause if the programme supports it. button - the appliance cannot start • after you touch the Start/Pause Touching the Start/Pause button, the button - programs and option ProSense starts the laundry load... -
Page 24: Programme End
9.12 Programme end 2. Open the appliance door. 3. Remove the laundry. Clean the filter and drain the 4. Close the appliance door. water container after each Possible causes of unsatisfactory drying drying cycle. (See chapter results: CARE AND CLEANING.) •... -
Page 25: Deactivating The Tank Indicator
ENGLISH Crease buttons at the same time for moment it is first switched on. The actual approximately 2 seconds. operating time of the cycles is shown (does not include pauses or delayed start In case of Wi-Fi network time). connected machines a To visualise this value, proceed as ProSense bars animation is follows:... -
Page 26: Care And Cleaning
11. CARE AND CLEANING 11.1 Cleaning the filter Filter At the end of each cycle the symbol comes on the display and you must clean the filter. The filter collects the lint during the drying cycle. To achieve the best drying... -
Page 27: Cleaning The Condenser
ENGLISH 2. Open the condenser cover. 2. Pull the plastic connection out and drain the water into a basin or equivalent receptacle. 3. Turn the lever to unlock the condenser lid. 3. Push the plastic connection back in and place the water container back into position. -
Page 28: Troubleshooting
11.5 Cleaning the control 7. Turn the lever until it clicks into position. panel and housing 8. Put the filter back. Use a standard neutral soap detergent to 11.4 Cleaning the drum clean the control panel and housing. Use a moist cloth to clean. Dry the WARNING! cleaned surfaces with a soft cloth. - Page 29 ENGLISH Error code Possible cause Remedy The mains supply is unstable. When the appliance is showing EH0, please wait until main supply is stable than press start. If the ap‐ pliance pause the cycle without any indication then press the cycle start.
- Page 30 Problem Possible cause Remedy The filter is not locked into posi‐ Put the filter in the correct position. The loading tion. door does not Laundry is trapped between the Remove trapped items and close close door and the seal.
-
Page 31: Technical Data
Move the router closer to the appli‐ ance through ance. Equip your home network the My AEG with wireless range extender. Care application Do not use at the same time micro‐ does not work wave oven and remote control. - Page 32 Maximum load volume 8,0 kg Voltage 230 V Frequency 50 Hz Sound power level 64 dB Total power 700 W Energy efficiency class A+++ Energy consumption on the standard cotton 1,47 kWh programme with the full load. Energy consumption on the standard cotton 0,83 kWh programme with the partial load.
-
Page 33: Quick Guide
ENGLISH 14. QUICK GUIDE 14.1 Daily use 1. Push the On/Off button to turn on the 4. Touch the Start/Pause button. appliance. 5. The appliance starts. 2. Use the programme dial to set the programme. 3. To activate or deactivate an option touch the relevant button or 2 buttons combination. - Page 34 14.3 Programme Programme Load Properties / Fabric mark Designed for routine drying of what you wash without MixDry 5,0 kg sorting. Dries evenly clothes made of cotton, cotton- synthetic blends and synthetic. Cotton fabrics programme designed for maximum en‐...
-
Page 35: Product Information Sheet In Reference To E.u. Regulation 1369/2017
ENGLISH 15. PRODUCT INFORMATION SHEET IN REFERENCE TO E.U. REGULATION 1369/2017 Product Information Sheet Trade Mark Model TR934N85C PNC916099353 Rated capacity in kg Air vented or condenser tumble dryer Condenser Energy efficiency class A+++ Energy consumption in kWh per year, based on 160 drying cy‐... -
Page 36: Environmental Concerns
Average condensation efficiency of the standard cotton pro‐ gramme at partial load as a percentage Weighted condensation efficiency for the 'standard cotton pro‐ gramme at full and partial load' Sound power level in dB Built in appliance Y/N The information given in the chart above is compliant with the EU Commission regulation 392/2012 implementing directive 2009/125/EC. - Page 40 My AEG Care app The software in this product contains components that are based on free and open source software. AEG gratefully acknowledges the contributions of the open software and robotics communities to the development project. To access the source code of these free and open source software components whose license conditions require publishing, and to see their full copyright information and applicable license terms, please visit: http://aeg.opensoftwarerepository.com (folder NIUS)
