- Page 1 U200 Series User Manual 5G Wi-Fi6 CPE Rout U200 Series User Manual V2.0 Be Honest & Do Best Your Trustworthy Smart Industrial IoT Partner pusr.com...
-
Page 2: Table Of Contents
3.2. AC management ......................错误！未定义书签。 3.2.1. AP list ........................错误！未定义书签。 3.2.2. AP settings ......................错误！未定义书签。 3.2.3. AP information ....................错误！未定义书签。 3.3. AC management via PUSR cloud ................错误！未定义书签。 3.3.1. AP import ......................错误！未定义书签。 3.3.2. AP list ........................错误！未定义书签。 3.3.3. AP settings ......................错误！未定义书签。... - Page 3 U200 Series User Manual 3.8. Software upgrading ....................错误！未定义书签。 3.8.1. Firmware upgrading ....................... - 20 - 3.8.2. Backup ............................- 21 - 3.8.3. Time & Date ..........................- 21 - 3.8.4. Reboot ............................- 22 - 3.8.5. Reset to factory setting ......................- 22 - 3.9.
-
Page 4: Introduction
Multiple Ethernet ports: 1*gigabit WAN/LAN(configurable) port, 3*gigabit LAN ports, connect more Ethernet devices. Automated failover/failback back up among Ethernet, Cellular and Wi-Fi. Support connect to PUSR cloud to to achieve centralized device management and remote monitoring Support WPA3 encryption to protect your data. 1.3. Specification... - Page 5 U200 Series User Manual 5G NRSA/NSA: LTE FDD: n1/n2/n3/n5/n7/n8/n12/n13/n14 B1/B2/B3/B4/B5/B7/B8/B12/ /n18/n20/n25/n26/n28/n29/n30/ B13/B14/B18/B19/B20/B25/ n38/n40/n41/n48/n66/n70/n71/n B26/B28/B66/B71 75/n76/n77/n78/n79 LTE TDD: LTE FDD: B38/B39/B40/B41 Frequency B1/B2/B3/B4/B5/B7/B8/B12/B13/ WCDMA:B1/B2/B4/B5/B6/B8 Bands B14/B17/B18/B19/B20/B25/B26/B /B19 28/B29/ B30/B32/B66/B71 LTE TDD: B34/B38/B39/B40/B41/B42/B43/B WCDMA:B1/B2/B4/B5/B8/B19 5G SA Sub-6: LTE-FDD:Max.150Mbps Max. 2.4 Gbps (DL)/Max. 900 Mbps (DL)/Max.
- Page 6 U200 Series User Manual 3* Gigabit LAN(RJ45), auto MDI/MDIX Standard 12V/2A Power Power Average: 600mA/12V supply Consumption Max: 1100mA/12V Connector DC socket 5.5*2.1 Dimension 180*90.73*90.93 Housing ABS Material Installation Desktop, Physical character Operating 0℃~+55℃ istics Temperature Weight 493.1g 493.1g 493.1g...
- Page 7 U200 Series User Manual 1.4. Button & Indicator Item Description Reset button Press and hold for 5-15s to reset to factory settings. After power on: on Power Not powered on: Off Abnormal power on: off WiFi enabled: always on WiFi...
-
Page 8: Get Started
U200 Series User Manual Figure 1. Dimension of U200s 2. Get Started 2.1. Hardware interface introduction 2.2. Quick test 2.2.1. Login setting page Connect PC to the LAN port of the AP controller, and set the IP to static IP, such as 192.168.1.101. The IP should be on the same network segment as the AP device. -
Page 9: Brief Introduce Of The Webpage
The left column is divided into 9 menu pages: System status, mobile network, Internet settings, WLAN settings, LAN settings, Login settings, client list, upgrade and system log. There are three auxiliary options in the upper right corner: PUSR cloud, Luci, language, as shown in the following figure. -
Page 10: Configuration And Parameter Details
U200 Series User Manual 3. Configuration and parameter details 3.1. System status This interface displays the basic information of the router, including 4 major blocks: system information, WAN port information, LAN port information, WLAN information. The specific information is shown in the figure below. -
Page 11: Network Settings
U200 Series User Manual Figure 6. Mobile network 3.3. Network settings On this page, users can set the network-dependent parameters of the CPE: Mode selecting, Ethernet settings, WAN settings, Wireless connect and other options. 3.3.1. Mode selecting There are 2 modes that can be selected: Router mode and AP mode. -
Page 12: Wan Settings
U200 Series User Manual Figure 7. Mode settings 3.3.2. Ports status checking In this function block, users can implement WAN/LAN switching, and can monitor whether the Ethernet port is connected to a device. [Set lan/lan]: checked means set all 4 ports to LAN port. - Page 13 U200 Series User Manual 3.3.4. Wireless connect Click <SCAN>, it will display the Wi-Fi SSID nearby, check the needed SSID, enter the password, select the needed frequency, check “Turn on”， then click “Apply”. Note: In repeater mode, the LAN IP and the WAN IP should be in the different network segment, or the terminal devices can not access to the Internet.
- Page 14 U200 Series User Manual 3.3.5. 5G AT To get information or settings of 5G module via sending AT command. 3.3.6. 5G NR Settings of 5G module. Items Description Default value 5G OnOff Turn on/Turn off 5G NR. Cellular AUTO(5G/4G/3G) IPv4v6: If the SIM card supports IPv4 and IPv 6 together, please select this option.
-
Page 15: Wlan Settings
U200 Series User Manual Authentication method: PAPCHAP: support PAP and CHAP authentication protocol both. Auth Type PAP: Select PAP authentication type. PAPCHAP CHAP: Select CHAP authentication type. None: There is no need of authentication. The APN information which is based on the SIM card... - Page 16 U200 Series User Manual Wi-Fi enable Turn on / turn off the Wi-Fi function. Turn on / turn off the SSID. After enabling this function, users will not be Hiding SSID able to detect the SSID. Turn on: STAs connected to this AP cannot access each other.
-
Page 17: Lan Network Settings
U200 Series User Manual Country CN/US Channel Select different countries, corresponding to different channel information. auto IEEE 802.11 802.11ax/ac/ (n/a) /a 802.11ax HT Mode 20M/40M/80M/160M 160M WPA3 Enable WPA3 enhanced encryption protocol. Not checked Encryption 80211r Turn on / turn off 802.11r protocol. -
Page 18: Login Settings
U200 Series User Manual After enabling DHCP, the U200 can assign IP addresses to terminal devices. The IP addresses start from the “initial value” and can be DHCP service allocated up to the “maximum number“set. Only available in ROUTER mode 3.6. - Page 19 U200 Series User Manual IP Binding: Enter the IP address and MAC address of the device that needs to be bound, then click on <Add>. Click on <Refresh> to view the devices that have already been bound. Black/white list: Black List: when in blacklist control mode, the CPE refused the WiFi/wireless connection from the device in black list.
-
Page 20: System Configuration
[Date/Time], [Restart], [Restore Factory Settings] and [VLAN]. 3.8.1. Firmware upgrading Select firmware file-> Click upgrade, U200 series device support upgrading firmware in local or online. Upgrade firmware in local: choose the firmware file and click update to upgrade the new firmware. -
Page 21: Backup
U200 Series User Manual Figure 10. Update online 3.8.2. Backup/Restore configuration This function is used to back up the current parameters of U200 device, and it also allows the import of previously saved parameters, making it convenient for users to configure settings. -
Page 22: Reboot
U200 Series User Manual 3.8.4. Reboot Reboot the CPE device. 3.8.5. Reset to factory setting Reset to factory settings. 3.8.6. VLAN When the VLAN ID is set, only packets with the same VLAN ID are allowed to pass through the CPE device. -
Page 23: System Log
U200 Series User Manual 3.9. System log To check the system log. 4. PUSR cloud management U200 series device support centralized management such as configured the CPE, check the operation status of the CPE via PUSR cloud. Login website: mp.usriot.com pusr.com... - Page 24 U200 Series User Manual Figure 11. Click DM 4.1. Add U200 device in DM platform 1> Add U200 using SN and MAC. Users can get the SN and MAC on the back label or on the GUI of the U200.
- Page 25 U200 Series User Manual 2> Add CPE device successfully. Note: The CPE must get access to the Internet to get online on the DM platform. Figure 14. Get online Figure 15. Internet status of CPE 4.2. Check the details of the CPE Click the gateway name, and navigate to the details page.
- Page 26 U200 Series User Manual Figure 16. Access to configuration page Figure 17. Login page 4.3. Firmware upgrading via PUSR Cloud U200s supports upgrading firmware via PUSR cloud remotely. pusr.com - 26 -...
-
Page 27: Warranty
U200 Series User Manual Users can also upgrade firmware in the following picture. 5. Warranty 6. Contact Us Jinan USR IOT Technology Limited Address : Floor 12 and 13, CEIBS Alumni Industrial Building, No. 3 Road of Maolingshan, Lixia District, Jinan, Shandong, China Official website:https://www.pusr.com... -
Page 28: Revision History
U200 Series User Manual this document or in connection with the sale of USR IoT products. EXCEPT AS SET FORTH IN THE TERMS AND CONDITIONS AS SPECIFIED IN THE LICENSE AGREEMENT FOR THIS PRODUCT, USR IoT AND/OR ITS AFFILIATES ASSUME NO LIABILITY WHATSOEVER AND DISCLAIMS ANY EXPRESS, IMPLIED OR STATUTORY WARRANTY RELATING TO ITS PRODUCTS INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR NON‐INFRINGEMENT. - Page 29 U200 Series User Manual Official Website: www.pusr.com Official Shop: shop.usriot.com Technical Support: h.usriot.com Inquiry Email: inquiry@usriot.com Skype & WhatsApp: +86 13405313834 关注有人微信公众号 登录商城快速下单 Product Catalog Facebook Youtube Click to view more: & & pusr.com...
