PUSR USR-G805 User Manual

Dual sim4g router
Hide thumbs

Advertisement

Quick Links

Download this manual
USR-G805 User Manual
Dual SIM 4G Router
User Manual
(Cost effective)
USR-G805s-42, USR-G805s-G
V2.0
Be Honest & Do Best
Your Trustworthy Smart Industrial IoT Partner
pusr.com
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the USR-G805 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PUSR USR-G805

Summary of Contents for PUSR USR-G805

  • Page 1 USR-G805 User Manual Dual SIM 4G Router User Manual (Cost effective) USR-G805s-42, USR-G805s-G V2.0 Be Honest & Do Best Your Trustworthy Smart Industrial IoT Partner pusr.com...

  • Page 2: Table Of Contents

    USR-G805 User Manual Content 1. Introduction ..............................- 6 - 1.1. Features ..............................- 6 - 1.2. Parameters table ........................... - 6 - 1.3. Indicator introduction ..........................- 8 - 1.4. Dimension ..............................- 8 - 2. Get Started ...............................- 9 - 2.1.
  • Page 3 USR-G805 User Manual 4.3.4. Mobile information ........................- 26 - 4.4. Network failover ..........................- 27 - 4.5. WLAN AP .............................. - 28 - 4.5.1. Basic settings ..........................- 28 - 4.5.2. Client information ........................- 29 - 4.6. WLAN STA .............................- 29 - 4.6.1.
  • Page 4 6.4.2. Whitelist settings ........................- 52 - 7. Additional services ............................- 53 - 7.1. PUSR Cloud ............................- 53 - 7.1.1. Add USR-G805s on PUSR Cloud ....................- 53 - 7.1.2. Gateway Information ........................- 55 - 7.1.3. Remote access ..........................- 56 - 7.1.4.
  • Page 5 USR-G805 User Manual 8.2.17. AT+PLANG ..........................- 67 - 8.2.18. AT+UPTIME ..........................- 68 - 8.2.19. AT+WANINFO ..........................- 68 - 8.2.20. AT+DIALINFO ..........................- 69 - 8.2.21. AT+LANINFO ..........................- 69 - 8.2.22. AT+WANN ..........................- 70 - 8.2.23. AT+LANN ...........................- 70 - 8.2.24.

  • Page 6: Introduction

    Supports firewall, NAT, DMZ, port forwarding, access restriction, etc. to ensure data security. Cooperating with PUSR service, it can realize centralized management of remote equipment and improve operation and maintenance efficiency. Supports mainstream VPN: PPTP, L2TP, Ipsec, GRE and enhanced OpenVPN.
  • Page 7 USR-G805 User Manual Maximum Transmission LTE-FDD (Mbps) :150 (DL)/50 (UL) Data Rate LTE-TDD (Mbps):130 (DL)/30 (UL) Antennas 1 × SMA-K Connectors (Center PIN: SMA Female) SIM Slot 2 x (3 V/1.8 V) Nano-SIM(4FF) Push-push type slot Ethernet Interface 2 x WAN ports, RJ45, 10/100 Mbps, the WAN2 port can be configure as LAN port, supports auto MDI/MDIX crossover, Ethernet Isolation 1.5 KV...

  • Page 8: Indicator Introduction

    USR-G805 User Manual Security Access Control, DMZ, Port Forwarding, SYN-Flood Protection, Filtering (IP& MAC & Domain) Management Web UI, PUSR cloud Reliability WAN Failover, Dual SIM Backup Certificate In progress CE, *FCC, *WEEE, RoHS, *RCM, *WPC 1.3. Indicator introduction USR-G805s provides 3 indicators in total, the specific description is as follows.

  • Page 9: Get Started

    USR-G805 User Manual Figure 1. Dimension of USR-G805s 2. Get Started 2.1. Login router Power on the G805s router, connect PC to USR-G805s via LAN port or via Wi-Fi, users can login router via Chrome or the other browser. The default network parameters are shown in the following table: Table 3.

  • Page 10: Brief Introduction Of The Webpage

    Status：Mainly display device name, firmware version, running status, and routes etc. Service: Mainly some additional functions, including dynamic DNS, GPS (GPS version), PUSR cloud. VPN: Configuration of VPN, such as PPTP, L2TP and OpenVPN. Network: In this interface, there are many categories related to network connection. Users can set parameters such as WAN port, LAN port and cellular network.

  • Page 11: Status & System

    USR-G805 User Manual Figure 3. Status webpage 3. Status & System 3.1. Status Users can get the basic information of USR-G805s, such as firmware version, running time, IPv4 WAN status, routes list, and information about DHCP client. 3.2. System (Hostname) In this page, users can modify the hostname, the default is USR-G805s.

  • Page 12: Administration Password

    USR-G805 User Manual Figure 4. Hostname page 3.3. Administration password This password is used when users login the built-in webpage. The default login password is root. Users can modify it in this page for secure login. Figure 5. Administration password pusr.com...

  • Page 13: Reboot Timer (Timed Restart Function)

    USR-G805 User Manual 3.4. Reboot timer (Timed restart function) Users can realize the periodic restart of the router through parameter setting. It can be restarted on a daily, weekly, or monthly basis. Timed restart can regularly clear the operation cache to improve the stability of the router operation.

  • Page 14: Http Port

    USR-G805 User Manual Figure 7. NTP Settings 3.6. HTTP port The port of logging in the webpage, default is 80, users can modify it in this page. Figure 8. HTTP port 3.7. System log Local log Users can view the log information and download the log information in this page.
  • Page 15 USR-G805 User Manual Application log level: Debug, Info, Notice, Warning, Error, Critical, Alert and Emergency. Figure 9. Local system log Remote log The remote service IP is 0.0.0.0, it means the remote log function is disabled. Users can change the remote service IP and port.

  • Page 16: Backup/Upgrade

    USR-G805 User Manual 3.8. Backup/Upgrade Download backup: Click "Generate archive" to download a tar archive of the current configuration files. Restore backup: Click “Browse” to select the backup archive file (Downloaded backup file), and then upload the backup file. Reset to defaults: Click this button, the USR-G805s will restore to factory default settings.

  • Page 17: Network Introduction

    USR-G805 User Manual 4. Network introduction 4.1. WAN interface For USR-G805s device, it supports multiple WAN interface: 4G connectivity, STA connectivity and wired WAN connectivity. 4G connectivity: this router support connect to base station both in IPv6 and IPv4, in the following picture, it’s WAN6_4G(IPv6) and WAN_4G(IPv4).
  • Page 18 USR-G805 User Manual Figure 14. DHCP Client of WAN interface Static address Mode In this mode, uses can set the IP address of USR-G805s. Figure 15. Static IP of WAN interface Table 4. Detail parameters of WAN interface Items Description IPv4 address Should be on the same network segment as the LAN IP of the upper-level router.

  • Page 19: Lan Interface

    USR-G805 User Manual IPv4 broadcast The broadcast address is calculated from the IP address and subnet mask. Use custom DNS servers User-defined. PPPoE Mode Fill in the correct username and password given by the operator. Figure 16. PPPoE Mode 4.2. LAN interface 4.2.1.

  • Page 20: Vlan Enable

    USR-G805 User Manual Figure 17. LAN interface Figure 18. Settings of LAN interface 4.2.2. VLAN enable USR-G805s supports VLAN function, multiple network ports can be divided into different network segments. If needed, users can enable it manually. pusr.com - 20 -...

  • Page 21: Wan/Lan Switching

    USR-G805 User Manual Note:  VLAN division is disabled by default. If this function is enabled, the IP address of the LAN1 port is automatically changed to 192.168.1.1, the IP address of LAN2 is changed to 192.168.2.1, and so on.
  • Page 22 USR-G805 User Manual If the using SIM card support IPv4 and IPv6, then it can get both IPv4 IP and IPv6 IP like the following figure. For LAN port, the router can assign IPv6 IP to the LAN device, it also need the LAN device support IPv6 protocol.

  • Page 23: Cellular Network

    USR-G805 User Manual 4.3. Cellular network 4.3.1. Configuration 4.3.1.1. SIM switching For USR-G805s, it supports dual sim single standby mode, and can get 4G connectivity according to user’s settings. There are 3 mode for user to choose: master standby mode, mutual standby mode and manual mode.

  • Page 24: Sim1 Configuration

    USR-G805 User Manual Items Description Link Detection Enable Whether to enable the link detection function. By default, it’s not enabled. Interval The time interval between two consecutive pings. Range: 1-86400 s, It’s 10 seconds by default. Max Ping Tries The maximum number of attempts to ping.

  • Page 25: Sim1/Sim2 Configuration

    USR-G805 User Manual SIM1: Prioritize using SIM1 to dial up and connect to the Internet. SIM2: Prioritize using SIM2 to dial up and connect to the Internet. Sim Card Switch Enable: Enable automatic SIM switching. Enable Disable: Disable automatic SIM switching.

  • Page 26: Mobile Information

    USR-G805 User Manual Table 6. Parameters description of SIM card Items Description Default APN Name The SIM card operator provides this parameter. Auto check Username The SIM card operator provides this parameter. None Password The SIM card operator provides this parameter.

  • Page 27: Network Failover

    USR-G805 User Manual Figure 21. Information of cellular network For USR-G805 device, it supports display the input/output rate of 30 seconds and 5 minutes. 4.4. Network failover In this interface, users can choose network priority. The default is to use the WAN port network first.

  • Page 28: Wlan Ap

    USR-G805 User Manual Figure 22. Network switch page 4.5. WLAN AP 4.5.1. Basic settings Users can set Wi-Fi related information on this page. Figure 23. AP settings Table 7. Parameters description of Wi-Fi interface Items Description Default Enable To choose whether to enable the Wi-Fi function.

  • Page 29: Client Information

    USR-G805 User Manual Hide SSID To choose whether to hide the SSID. Disable If the SSID is hidden, the user cannot search for the Wi-Fi name on the mobile phone or PC. Users can connect to Wi-Fi by manually entering the SSID.
  • Page 30 USR-G805 User Manual Figure 25. STA settings The steps to connect to the upper-level routers: 1>Click “Scan” button， 2> Click the drop-down button of SSID, the available Wi-Fi network is displayed. Users can select the Wi-Fi network or enter the Wi-Fi name to connect to.

  • Page 31: Ap Information

    USR-G805 User Manual 4.6.2. AP information If the USR-G805s connect to upper-level Wi-Fi successfully, the information will be displayed in this page. Figure 27. The AP information 4.7. DHCP introduction On this page, users can assign static IP addresses to specific network devices and define device hostnames.

  • Page 32: Routing Table

    USR-G805 User Manual Note: Up to 100 static router rules can be added. Figure 29. Static routing rule Table 8. Parameters description of static routing Items Description Default Interface Network interface of the target network. Target Destination network address. IPv4 A netmask is used to divide an IP address into sub-networks (subnets).

  • Page 33: Network Diagnostics

    USR-G805 User Manual Figure 30. Routing table checking 4.9. Network diagnostics USR-G805s provides online diagnostic functions, including Ping tools, routing analysis tools, and DNS viewing tools. Figure 31. Network diagnostics pusr.com - 33 -...

  • Page 34: Tcp Dump

    USR-G805 User Manual Table 9. Description of diagnostic types Items Description Default value Ping Users can ping a specific IP address directly on the router 8.8.8.8 side. Traceroute Routing analysis tool, which can obtain the routing path 8.8.8.8 passed when accessing an address.
  • Page 35 USR-G805 User Manual Figure 32. PPTP VPN settings Table 10. Parameter details of PPTP VPN Items Description Default PPTP Client Whether to enable PPTP client. Disable Server Address Set PPTP server IP or domain name. 192.168.0.2 Interface Select the interface according to different networking methods.

  • Page 36: L2Tp Client

    USR-G805 User Manual VPN server. Extra option Append pppd parameters, non-professionals, prohibited None operation. Enable Static Users need to enter static IP manually if this option is enabled. Disabled Tunnel IP Address Default Gateway Force all client generated traffic through the tunnel, except WAN Disabled protocol is PPPOE.

  • Page 37: Ipsec Vpn

    USR-G805 User Manual L2TP Client Turns the L2TP client on or off. Server Address Set L2TP server IP or domain name. 192.168.0.2 Interface Select the interface according to different networking methods. auto Username/ Password Username used for authentication to the PPTP server. They are 192.168.55.0...
  • Page 38 USR-G805 User Manual Items Description Default IPSec enable Whether to enable IPSec VON Disable Interface Select the interface according to different networking methods. auto Peer Address Set L2TP server IP or domain name. 192.168.0.2 Negotiation Method Main and aggressive are supported...

  • Page 39: Openvpn

    USR-G805 User Manual Local Identifier It can be IP address or @domain, @client 0-29 characters can be set. Peer Identifier It can be IP address or @domain, @server 0-29 characters can be set. Encryption 3DES, AES-128, AES-192, AES-256 are supported...

  • Page 40: Openvpn Client

    USR-G805 User Manual Figure 34. Edit OpenVPN settings 5.4.1. OpenVPN client USR-G805s supports import .ovpn config file and PKCS#12 cert-file. Say goodbye to complex parameter settings. After importing the ovpn file, users just need to config the username and password.
  • Page 41 USR-G805 User Manual Figure 36. Enable traditional OpenVPN settings Figure 37. Upload certificate file pusr.com - 41 -...

  • Page 42: Openvpn Server

    USR-G805 User Manual 5.4.2. OpenVPN server Figure 38. OpenVPN server settings 5.5. GRE Items Description Default Whether to enable GRE VPN. Disable Interface Name The name of GRE VPN tunnel gre_gre1 Interface auto Peer WAN IP Remote GRE WAN IP address 192.168.0.10...

  • Page 43: Firewall

    USR-G805 User Manual Peer Tunnel IP Remote GRE tunnel IP address 10.10.10.1 Peer Subnet Remote IP/Mask 192.168.55.0/24 Local Tunnel IP Local GRE tunnel IP address 10.10.10.2 Whether NAT is required for data passing through GRE interfaces Enabled Set the TTL parameters(1~255)

  • Page 44: Port Forward

    USR-G805 User Manual Masquerading: IP masquerading automatically, which is meaningful for the WAN port and 4G port, the masquerading for IP when access the external. MSS clamping: Limit the large of the MSS, generally it is 1460. The first rule: The input, output, and forward packet from LAN to WAN is accept by default.

  • Page 45: Dmz Function

    USR-G805 User Manual address Internal port Users can set a single port or a range of ports, like 8000-9000. None Note: It’s DMZ function when external port and internal port are empty. Figure 40. Port forwards settings 6.2.2. DMZ function DMZ function is a physical or logical subnet that separates a local area network (LAN) from other untrusted networks -- usually, the public internet.

  • Page 46: Traffic Rules

    USR-G805 User Manual Figure 41. DMZ settings 6.3. Traffic rules The Traffic Rules tab is a crucial feature of a firewall functionality that allows you to set rules to filter and control network traffic moving through the device. In essence, traffic rules determine which firewall rules will be applied to packets traveling through the network.

  • Page 47: Open Ports On Router

    USR-G805 User Manual The rule will apply only to hosts that match MAC addresses specified in this field. Leave empty to make the rule skip MAC address matching. Source IP IP address or network segment used by connecting hosts. Source port IP address or network segment used by connecting hosts.

  • Page 48: Add New Forward Rule

    USR-G805 User Manual below is an example of the Open ports on device section and the table below provides information on the fields contained in that section. Table 14. Parameter details Items Description Default Name The name of the rule， user defined.

  • Page 49: Source Nat

    USR-G805 User Manual Figure 44. Add new forward rules 6.3.3. Source NAT Source NAT (SNAT) is a form of masquerading used to change a packet's source address and/or port number to a static, user-defined value. SNAT is performed in the POSTROUTING chain, just before a packet leaves the device.
  • Page 50 USR-G805 User Manual Figure 45. Settings of SourceNAT Users need to fill in the basic information before clicking the “Add and edit” button, it will redirect you to the rule's configuration page. Figure 46. Detail settings of SourceNAT Table 17. Parameter details of Source NAT...

  • Page 51: Access Restrictions

    USR-G805 User Manual Protocol Specifies to which protocols the rule should apply, including TCP+UDP, TCP, TCP+UDP UDP, ICMP. Source zone Matches traffic originated from the specified zone. Source IP Mathes traffic originated from specified IP address or network segment. Source port Mathes traffic originated from specified port number.

  • Page 52: Blacklist Settings

    USR-G805 User Manual 6.4.1. Blacklist settings First, select the blacklist, enter the name of the rule and the prohibited domain address, and then click Add, and the added rules will be displayed in the list. Click Apply and the rules take effect immediately. Devices connected to the router will not be able to access the domain address just added.

  • Page 53: Additional Services

    USR-G805 User Manual Figure 49. Add whitelist rules 7. Additional services 7.1. PUSR Cloud 7.1.1. Add USR-G805s on PUSR Cloud PUSR platform login address: https://mp.usriot.com/. On USR-G805s side, users need enable the PUSR cloud first. pusr.com - 53 -...
  • Page 54 USR-G805 User Manual Figure 50. Enable the PUSR function of G805s On PUSR cloud side, users can add USR-G805s on PUSR platform and monitor the status of USR-G805s. Figure 51. Add device on PUSR cloud pusr.com - 54 -...

  • Page 55: Gateway Information

    USR-G805 User Manual Figure 52. Enter the information of USR-G805s Figure 53. Online status 7.1.2. Gateway Information Click “Gateway Name”, it will guide you to a new page showing the detail of the USR-G805s. pusr.com - 55 -...

  • Page 56: Remote Access

    Users can also send AT command to query parameters of USR-G805s Figure 55. Parameters query and config 7.1.3. Remote access After the USR-G805s is launched on the PUSR platform, you can remotely log in to the built-in webpage through pusr.com - 56 -...

  • Page 57: Firmware Upgrade

    USR-G805 User Manual the PUSR platform to view and modify parameters. Figure 56. Login configuration page Figure 57. Login page 7.1.4. Firmware upgrade Users can also upgrade firmware via PUSR platform. pusr.com - 57 -...

  • Page 58: Alarm Settings

    USR-G805 User Manual Figure 58. Firmware upgrade function 7.1.5. Alarm settings Add alarm trigger type, for USR-G805s, we add “Gateway monitoring trigger”. Figure 59. Add alarm trigger type Add alarm contacts and verify email. pusr.com - 58 -...
  • Page 59 USR-G805 User Manual Figure 60. Add alarm contacts Add alarm configuration Figure 61. Add alarm configuration Check the alarm email: Power off the USR-G805s pusr.com - 59 -...

  • Page 60: Ddns

    USR-G805 User Manual 7.2. DDNS It’s disabled by default. Figure 62. DDNS function 7.3. SSH function This function is in developing. 7.4. SNMPD The G805s supports the Simple Network Management Protocol (SNMP) service. You can use SNMP to remotely view device information and monitor device status without going to the site one by one. The device supports SNMP version V2C and V3.

  • Page 61: Sms

    USR-G805 User Manual Items Description Default Enable SNMP Whether to enable SNMP. Disable username The name assigned to an SNMP user user auth type Auth or auth-enc auth auth mode SHA or MD5 auth passwd The encryption password used as the encryption private key...

  • Page 62: Sms Sending

    USR-G805 User Manual 7.5.2. SMS sending This router support sending message to specified number, and can also record the sent message and received message content on the page, so users can check the pusr.com - 62 -...

  • Page 63: At Command

    USR-G805 User Manual 8. AT Command 8.1. AT command set Number Name Function Test AT command available AT+R Restart the device Factory data reset AT+CLEAR AT+VER Query firmware version Query current device wan port MAC AT+MAC AT+APN Query or set 4G APN information...

  • Page 64: Description Of At Command

    USR-G805 User Manual AT+WANN Query WAN Port Configuration Query LAN port configuration AT+LANN AT+LAN Query/Set LAN Port Configuration AT+PING Execute ping command Query default routing using NIC AT+NETSTATUS AT+ALYSIMSWITCH Query/Switch Operators AT+DUALSIMMODE Query/set the switch mode and active SIM card 8.2.

  • Page 65: At+Mac

    USR-G805 User Manual inquire AT+VER +VER:<ver> not have parameter ver: Current software version number This command executes correctly and returns the current explain software version number. 8.2.5. AT+MAC name AT+MAC function Query WAN port MAC inquire AT+MAC +MAC:<mac> not have...

  • Page 66: At+Csq

    USR-G805 User Manual 8.2.8. AT+CSQ name AT+CSQ function Query Device 4G Signal Strength inquire AT+CSQ +CSQ:<csq> not have parameter csq: cellular signal value explain not have 8.2.9. AT+CPIN name AT+CPIN function Query SIM card status inquire AT+CPIN +CPIN:<cpin> not have...

  • Page 67: At+Sysinfo

    USR-G805 User Manual explain 8.2.13. AT+SYSINFO name AT+SYSINFO function Query SYSINFO information inquire AT+SYSINFO +SYSINFO:<ops_operate>,<ops_net_type> not have parameter ops_operate: operator information ops_net_type: network mode explain 8.2.14. AT+CELLULAR name AT+CELLULAR function Query resident network mode inquire AT+CELLULAR +CELLULAR:<ops_net_type> not have parameter...

  • Page 68: At+Uptime

    USR-G805 User Manual function Query web landing language inquire AT+PLANG +PLANG:<plang> AT+PLANG=<pl ang> OK parameter plang:zh_cn/en zn_cn: Chinese en: English explain 8.2.18. AT+UPTIME name AT+UPTIME function Query system runtime inquire AT+UPTIME +UPTIME:<time> not have parameter time explain 8.2.19. AT+WANINFO name...

  • Page 69: At+Dialinfo

    USR-G805 User Manual 8.2.20. AT+DIALINFO name AT+DIALINFO function Query 4G network card information inquire AT+DIALINFO +DIALINFO:<mac>|<ip>|<mask>|<rx_packets>|<tr_packets>< rx_b ytes>|<tx_bytes> not have parameter Mac:4G MAC ip:4G IP card mask:4GNIC subnet maskrx_ packets: number of packets received tr_packets: number packets sent rx_bytes: receive...

  • Page 70: At+Wann

    USR-G805 User Manual 8.2.22. AT+WANN name AT+WANN function Query WAN Port Configuration inquire AT+WANN +WANN:<type>,<ip>,<mask>,<gateway> not have parameter type:WANport protocol typeip:WANIP mask:WAN subnet mask gateway:WAN gateway explain 8.2.23. AT+LANN name AT+LANN function Query LAN port configuration inquire AT+LANN +LANN:<ip>,<mask> not have...

  • Page 71: At+Netstatus

    USR-G805 User Manual function Execute ping command inquire not have AT+PING=<ip> PING IP(IP): 56 data bytes parameter ip:IP or domain name, cannot be null, invalidpingparameter,e.g. -c1 invalid Limitations [1-200) Note: Parameters can only be associated with IP or domain names explain 8.2.26.

  • Page 72: Contact Us

    USR-G805 User Manual AT+DUALSIMMODE=<dualsim_mode>[,<sim_fixed>] parameter dualsim_mode: Master:Master standby mode Mutual:Mutual standby mode Manual: Manual mode sim_fixed： sim1: sim1 is active sim2: sim2 is active explain 9. Contact Us Jinan USR IOT Technology Limited Address : Floor 12 and 13, CEIBS Alumni Industrial Building, No. 3 Road of Maolingshan, Lixia District, Jinan, Shandong, China Official website: https://www.pusr.com...
  • Page 73 USR-G805 User Manual THE POSSIBILITY OF SUCH DAMAGES. USR IoT and/or its affiliates make no representations or warranties with respect to the accuracy or completeness of the contents of this document and reserves the right to make changes to specifications and product descriptions at any time without notice. USR IoT and/or its affiliates do not make any commitment to update the information contained in this document.
  • Page 74 USR-G805 User Manual Official Website: www.pusr.com Official Shop: shop.usriot.com Technical Support: h.usriot.com Inquiry Email: inquiry@usriot.com Skype & WhatsApp: +86 13405313834 关注有人微信公众号 登录商城快速下单 Product Catalog Facebook Youtube Click to view more: & & pusr.com...
