Summary of Contents for Nextech QC8063
- Page 1 QC8063 4K Outdoor Trail Camera Instruction Manual...
-
Page 2: Table Of Contents
CONTENTS CONTENTS Before First Use ....................... 3 Box Contents ........................3 Product Diagram ......................4 Quick Start Guide ......................6 Using The Camera ......................8 Connecting The Camera To A Computer ............16 SPecifications ......................... 17 Troubleshooting ......................18 Maintenance ........................22 Warranty Information ....................24... -
Page 3: Before First Use
BEFORE FIRST USE Prior to using your product, please read all the safety and operating instructions thoroughly. Please ensure you follow the steps below before using the product. We recommend you keep the original packaging for storing the product when not in use. Please pay close attention to the section entitled Important Safety and General Instructions. -
Page 4: Product Diagram
PRODUCT DIAGRAM... - Page 5 • The monitor is switched on only in SETUP mode for changing menu settings or viewing existing photos. • A TF memory card must be inserted into the memory card slot to save photos (not included). • The mode switch allows you to select from three operating modes: OFF, SETUP, and ON.
-
Page 6: Quick Start Guide
View Screen Indicators QUICK START GUIDE... - Page 7 Open the battery cover to install 8 AA batteries. Energizer Lithium batteries are recommended (batteries not included). Alkaline batteries may be used, but their lifespan will be shorter. Rechargeable batteries are not recommended. Ensure the batteries are installed with the correct polarity (+/-). To install a new SD card of up to 128GB, it's recommended to use high-speed cards (Class 10 or above) if you plan to record video clips.
-
Page 8: Using The Camera
USING THE CAMERA Before setting up the camera for surveillance, it must be configured for its intended purpose. This can be done using the SETUP mode. In this mode, you can adjust settings, capture photos and videos, and review existing photos. The mode switch is located at the bottom edge on the left side of the interior. - Page 9 Sequence Options: 1 shot / 2 shots / 3 shots Select the number of photos to be taken in succession when the camera is triggered in Photo mode. Be mindful of the Interval parameter for optimal performance. Video Resolution Options: 4K / 2K / 1080FHD / 720P Choose the desired video resolution.
- Page 10 On / Off Low / Medium / High Capture, Video, Capture + Video • Capture: Used for taking photos. • Video: Used for recording videos. • Capture + Video: Enables the camera to take both photos and videos in sequence. The camera captures a photo first and then records a video. Operate Interval Default: 30 seconds (adjustable from 5 seconds to 30 minutes).
- Page 11 As soon as the "On" setting is confirmed by pressing the OK button, you can set the interval time for taking photos or recording videos. In this mode, the PIR function is disabled, and the camera takes photos or records videos at the set interval time. Timer: On / Off Select "ON"...
- Page 12 Economy Mode: On / Off When enabled, files captured at night under low battery conditions will result in completely black images. Enable or disable the sound feedback for button presses and alerts. PIR Sensitivity: High / Medium / Low High: Maximum PIR sensitivity with the farthest detection range. Medium: Moderate PIR sensitivity with an average detection range.
- Page 13 Serial ID Set: On / Off Select "ON" to assign a unique name to the camera, which will be displayed in the photo watermark. Language Choose your preferred menu language. Available options include English, German, French, Spanish, Chinese, and more. Version Check the current software version of the camera.
- Page 14 This process helps you determine the best position for aligning the camera. The LED lights up only in SETUP mode when one of the sensors detects movement. The LEDs do not light up in Live mode. To avoid false triggers and unnecessary photos, we recommend: •...
- Page 15 Night recording with Infrared LEDs During night recording, the infrared LEDs (IR LEDs) on the front of the Wildlife Camera provide the necessary light for capturing photos. The camera uses IR LEDs with a long wavelength to minimize visible red light, ensuring discreet operation.
-
Page 16: Connecting The Camera To A Computer
CONNECTING THE CAMERA TO A COMPUTER and videos. 1. Connect the Camera: Use the supplied USB cable to connect the Wildlife Camera to your computer. 2. Automatic USB Mode: The camera will automatically switch to USB mode, regardless of the mode selected on the mode switch. -
Page 17: Specifications
SPECIFICATIONS... -
Page 18: Troubleshooting
TROUBLESHOOTING Unable to Turn On the Camera? • Check Battery Installation: Ensure all four batteries are installed in the battery compartment, filling all spaces with no gaps. • Battery Recommendation: Use Energizer Lithium AA batteries for optimal performance. • Verify Polarity: Confirm the batteries are installed correctly, with the negative (flat) end in contact with the spring side of each slot. - Page 19 Potential Hardware Issues: • If the problem continues, the issue may be due to an electronic component malfunction. • In such cases, contact customer service for assistance. Experiencing shorter-than-expected battery life with your trail camera can result from several factors. Here's how to address them: 1.
- Page 20 Experiencing issues with still photo and video quality on your trail camera can stem from various factors. Here's a comprehensive guide to troubleshoot common problems: 1. Night Photos or Videos Appear Too Dark • Battery Check: Ensure the battery power is sufficient. The flash may cease to operate when battery levels are low, resulting in darker images.
- Page 21 Why are subjects missing in photos? Check PIR Sensitivity Settings • Adjust the PIR SENSITIVITY parameter in the SETUP menu. • Use HIGH for warm temperatures, LOW for cold weather, and MEDIUM for variable conditions. Avoid Heat Sources Place the camera in an area without heat sources in its line of sight. Avoid Water Reflection Position the camera over ground instead of near water to prevent false captures.
-
Page 22: Maintenance
MAINTENANCE Maintenance • Avoid using corrosive cleaners like methylated spirits or thinners to clean the camera housing or accessories. • When needed, clean components with a soft, dry cloth. Storage • Remove the batteries from the camera if it will not be used for an extended period and store them separately. -
Page 24: Warranty Information
WARRANTY INFORMATION Our product is guaranteed to be free from manufacturing defects for a period of 12 Months. If your product becomes defective during this period, Electus Distribution will repair, replace, or refund where a product is faulty; or not fit for intended purpose. This warranty will not cover modified product;...
