HCC & HCC-FPUP
HYDRAWISE READY CONTROLLER QUICK START GUIDE
The Most Complete
Wi-Fi Irrigation Control System
HCC
Wi-Fi
Settings
Zones
Status

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hydrawise HCC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hunter Hydrawise HCC

  • Page 1 HCC & HCC-FPUP HYDRAWISE READY CONTROLLER QUICK START GUIDE Wi-Fi Settings Zones Status The Most Complete Wi-Fi Irrigation Control System...
  • Page 2: Table Of Contents

    Table of Contents Thank You for Purchasing a Hydrawise Ready Irrigation Controller Mount Your Controller Install Your Controller Wiring Your Controller Earth Ground Connection (Lightning Protection) 120 VAC Connections 230 VAC Connections Power Module Terminals Retrofit Your ICC or ICC2 Controller to a Hydrawise Ready Controller Configure Your Controller Offline Basics of Your Touchscreen Controller Home Screen Navigation...
  • Page 3: Thank You For Purchasing A Hydrawise Ready Irrigation Controller

    Visit hydrawise.com to get started. network router. Need more helpful information on your product? Find tips on installation, controller programming, and more. SCAN for help hunter.help/Hydrawise hunterindustries.com...
  • Page 4: Mount Your Controller

    Mount Your Controller Plastic Cabinet Metal Cabinet ➊ ➋ ➊ ➋ ➌ ➌ Plastic and Metal Controllers Remove controller door and control panel for easier access. Use enclosed hole template to mark and drill mounting holes. Leave enough room to open the door. Allow for screw anchors if necessary. Install top center screw first, and leave the screw head ¼"...
  • Page 5: Install Your Controller

    Install Your Controller Plastic Cabinet Metal Cabinet ➊ ➊ Plastic and Metal Controllers Secure the controller in place by installing screws in the remaining holes from inside the cabinet. Replace control panel and door. hunterindustries.com...
  • Page 6: Wiring Your Controller

    Wiring Your Controller Earth Ground Connection (Lightning Protection) Insert copper wire from earth ground hardware, and tighten the screw in front. Minimum 10 AWG (5mm wire to earth ground hardware. Add copper-clad steel ground rods and/or plates sufficient to achieve 10Ω or less resistance at a minimum 8' (2.5 m) away from controller Important: Required for all metal and stainless steel configurations.
  • Page 7: 120 Vac Connections

    Wiring Your Controller Wire Block: 120 V Wire Nut: 120 V Wire Block: 230 V Wire Nut: 230 V ➊ ➋ ➌ ➍ ➊ ➋ ➌ ➍ ➊ ➊ ➋ ➋ ➌ ➌ ➍ ➍ ➎ ➏ ➐ ➐ ➏ ➎...
  • Page 8: Power Module Terminals

    Wiring Your Irrigation System ⑩ ⑪ ⑫ ⑦ P/MV ⑧ SEN 1 SEN 2 SEN C ⑨ 24VAC 24VAC ➊ ➋ ➌ ➍ ➎ ➏ Power Module Terminals ➊ Green Ground ➍ White Sensor Common ➐ Common ⑩ White Sensor Common ➋...
  • Page 9: Retrofit Your Icc Or Icc2 Controller To A Hydrawise Ready Controller

    Retrofit Your ICC or ICC2 Controller to a Hydrawise Ready Controller ICC or ICC2 Controllers Important: Turn off AC power at the source, and verify that it is off. Disconnect the facepack ribbon cable. ➊ Remove and replace the ICC or ICC2 facepack with the HCC Hydrawise-ready facepack.
  • Page 10 Retrofit Your ICC or ICC2 Controller to a Hydrawise Ready Controller ICC or ICC2 Controllers Remove all wiring from the ICC or ICC2 power module. ➊ Remove and replace power module by rotating the locking lever up, then insert the new power module and rotate the locking lever down.
  • Page 11: Configure Your Controller Offline

    Configure Your Controller Offline Configure Your Controller Offline Connection Wizard From the Connection Wizard screen, touch Configure Offline. Tap OK to Welcome to Hydrawise! move on to the next step. Enter in today’s date if it hasn’t already been set or if it is incorrect. Enter To con gure your controller via our app, you will today’s time if it hasn’t already been set or if it is incorrect.
  • Page 12: Basics Of Your Touchscreen Controller

    Basics of Your Touchscreen Controller Home Screen Navigation ① Touch to view all zones. ② Touch to change controller settings. ③ Touch to view controller status information. ➊ ➋ ④ Go to previous screen (changes not saved). Settings ⑤ Go to Home screen (changes not saved). ➅...
  • Page 13: Connect Your Controller To The Internet

    Connect Your Controller to the Internet Using the Connection Wizard Wireless Settings From Home screen touch Settings button then the Wireless button. Select your wireless network from the list shown on the controller display Status ➋ Connecting to Hydrawise... and press the Confirm button on screen. Enter your wireless password and press the OK button on keyboard.
  • Page 14: Notices

    Certificate of Conformity to European Directives This equipment has been tested and found to comply with the limits Hunter Industries declares that the irrigation controller Model for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 15: Innovation, Science And Economic Development Canada (Ised) Compliance Notice

    Notices Innovation, Science and Economic Development Canada Wi-Fi Module Information (ISED) Compliance Notice Radio module: Microchip Technology Inc. (model number ATWINC-1500-MR210UB) This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: This device may not cause interference, and This device must accept any interference, including interference...
  • Page 16 HUNTER INDUSTRIES | Built on Innovation® 1940 Diamond Street, San Marcos, CA 92078 USA hunterindustries.com © 2024 Hunter Industries™. Hunter, the Hunter logo, and other marks are trademarks of Hunter Industries, registered in the U.S. and certain other countries. Please recycle.
