Summary of Contents for Aiwa HS-PS120 D
- Page 1 HS-PS120 SERVICE MANUAL STEREO CASSETTE PLAYER BASIC TAPE MECHANISM : TN–8S–118 MODEL CODE : 88HKK-0137 S/M Code No. 09-991-402-5R1...
- Page 3 87-A20-855-040 1C C-IC, TA2069F MAIN C.B. 87-010-501-040 0E CAP, E 47-4 M5L SRE 87-010-501-040 0E CAP, E 47-4 M5L SRE 87-A10-177-010 0E CAP,CER 1500P-50 K B 87-A10-177-010 0E CAP,CER 1500P-50 M D 87-010-490-040 0E CAP, ELECT 0.1-50 87-010-490-040 0E CAP, ELECT 0.1-50 87-015-676-040 0E CAP, E 47-6.3 7L 87-018-209-080 0E CAP, TC U 0.1-50V 87-A10-489-040 0E CAP,E 220-4 7L SR...
-
Page 5: Schematic Diagram - 1 (Main)
SCHEMATIC DIAGRAM - 1 (MAIN) - Page 6 MAIN C.B VOLUME PHONES SFR1 Tape speed : 3000Hz ± 90Hz Wow & flutter : Less than 0.5% (R.M.S) Take-up torque : 27 ~ 60g-cm (FWD) F.F torque : 60g-cm REW torque : More than 55g-cm Back tension : 1.5 ~ 5.5g-cm (FWD) S/N Ratio : More than 43dB (PB, DC) Distortion :...
- Page 7 88-HKK-001-010 -- LID,CASS 83-HRJ-202-010 0E T-SP,CLICK 88-HKK-004-010 -- PANEL,CASS 81-HK9-208-210 0E SPR-P,CASS A 88-HKK-002-010 -- FRAME,CENTER 88-HRK-010-010 -- BTN,STOP 88-HRK-009-010 -- BTN,FF 88-HRK-008-010 -- BTN,REW 88-HRK-007-010 -- BTN,PLAY 10 88-HKK-203-010 -- HLDR,JACK 11 88-HKK-204-010 -- SHAFT,CALKING 12 88-HKK-201-010 -- BAT-CONTACT,+ 13 88-HKK-202-010 -- BAT-CONTACT,- 14 88-HKK-006-010 -- LID,BATT 15 88-HKK-003-010 -- CABI,REAR...
- Page 8 SCREW CAMERA 2-4.3 SCREW 2-2 HEAD SP PINCH ROLLER SP TAPE GUIDE HEAD HEAD PANEL PANEL SP REEL FEATHER MOTOR PULLEY BASE S T GEAR STOP BUTTON LEVER R GEAR T GEAR LUG PLATE PLATE ASSY REW BUTTON LEVER FF BUTTON R REEL CAMERA LEVER...
- Page 9 S2-010-098-800 2C TN-8S 118 S1-903-073-010 1C PINCH ROLLER ASSY S1-908-043-010 1E TAKE UP REEL ASSY S1-908-053-030 1F FLYWHEEL ASSY S1-908-050-080 1C MAIN BELT S6-401-011-630 1B LEAF SW MSW-1541TA(SW1) 87-045-351-019 1F MOTOR BDH3B09(M1) S6-202-010-910 1H HEAD MS25P-BK007(PH) 84-447-019-310 0E CLIP,BELT 87-B30-123-010 1H HEADPHONE,HP-M006(T) 88-HKK-901-010 1B IB,D-C...
