SERVICE MANUAL
STEREO CASSETTE PLAYER
• This Service Manual contains information about the difference between HS-PS11/12/13/14
(YU) and HS-PS211(Y). If requiring other information,see Service Manual of HS-PS211(Y),
(S/M Code No. 09-00B-438-1R1).
HS-PS11
HS-PS12
HS-PS13
HS-PS14
BASIC TAPE MECHANISM : 4ZM-2 P17NC
S/M Code No. 09-00C-438-1S1
YU
YU
YU
YU
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Aiwa HS-PS11
Summary of Contents for Aiwa HS-PS11
- Page 1 SERVICE MANUAL BASIC TAPE MECHANISM : 4ZM-2 P17NC STEREO CASSETTE PLAYER • This Service Manual contains information about the difference between HS-PS11/12/13/14 (YU) and HS-PS211(Y). If requiring other information,see Service Manual of HS-PS211(Y), (S/M Code No. 09-00B-438-1R1). S/M Code No. 09-00C-438-1S1...
-
Page 2: Specifications
SPECIFICATIONS Maximum output: 15 mW + 15 mW (EIAJ 32 ohms) Power source: DC 3 V using two R6 (size AA) batteries Maximum outside dimensions: 91.5 (W) x 116.5 (H) x 33.0 (D) mm in.) (excluding projecting parts and control) Weight: Approx.109 g (3.8 oz) (excluding batteries) •... -
Page 3: Electrical Main Parts List
ELECTRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION 87-A21-684-040 C-IC,TA2145AF MAIN C.B 87-012-277-080 C-CAP,U 1800P-50 K B 87-012-277-080 C-CAP,U 1800P-50 K B 87-012-284-080 C-CAP,U 6800P-50 K B 87-012-284-080 C-CAP,U 6800P-50 K B 87-015-674-040 CAP,E 22-6.3 M 7L SRA 87-015-674-040 CAP,E 22-6.3 M 7L SRA 87-012-277-080... - Page 4 WIRING (MAIN / FRONT) – 4 –...
- Page 5 SCHEMATIC DIAGRAM (MAIN / FRONT) – 5 –...
-
Page 6: Mechanical Exploded View
MECHANICAL EXPLODED VIEW 1 / 1 – 6 – – 6 –... -
Page 7: Mechanical Parts List
MECHANICAL PARTS LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION 1 8B-HKA-037-010 PANEL,SBASS LGRE<[GL]PS12> 1 8B-HKA-038-010 PANEL,SBASS ORN<[D]PS13> 1 8B-HKA-039-010 PANEL,SBASS V10<[V]PS14> 1 8B-HKA-051-010 PANEL,SBASS ABLU<[LA]PS11> 2 8B-HRL-006-010 KNOB,SL SBASS 3 86-HRM-205-010 SPR-T,CLICK 4 8B-HKA-056-010 LID,CASS PS11<[LA]PS11> 4 8B-HKA-057-010 LID,CASS PS12<[GL]PS12>... - Page 8 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 2000068 9630472 0251431 Printed in Singapore...
