SERVICE MANUAL
STEREO CASSETTE PLAYER
Maximum output:
Power source:
Maximum dimensions:
Weight
• Design and specifications are subject to change without notice.
HS-PS162
BASIC TAPE MECHANISM :
SPECIFICATIONS
15 mW + 15 mW (EIAJ/32Ω)
4 mW + 4 mW (EIAJ/16Ω)<Y1>
DC 3V using two R6 (size AA) dry cell batteries,
AC house current using the optional AC adaptor
Aiwa AC-D302<YH>
116.6 (W) X 92.0 (H) X 34.3 (D) mm (4
Approx.110g (3.9 oz) (excluding batteries)
S/M Code No. 09-991-401-6O1
YU,Y1,YH,YJ
4ZM-2 P1NC2
4ZM-2 P6NC2
4ZM-2 P3NC2
5
5
3
/
x 3
/
x 1
/
in.)
8
8
8
Advertisement
Table of Contents
Related Manuals for Aiwa HS-PS162 YU
Summary of Contents for Aiwa HS-PS162 YU
- Page 1 4 mW + 4 mW (EIAJ/16Ω)<Y1> Power source: DC 3V using two R6 (size AA) dry cell batteries, AC house current using the optional AC adaptor Aiwa AC-D302<YH> Maximum dimensions: 116.6 (W) X 92.0 (H) X 34.3 (D) mm (4 in.) Weight Approx.110g (3.9 oz) (excluding batteries)
-
Page 2: Electrical Main Parts List
ELECTRICAL MAIN PARTS LIST DESCRIPTION REF. NO. PART NO. KANRI REF. NO. PART NO. KANRI DESCRIPTION 87-A21-144-040 IC,TA2069AF DIODE 87-020-339-080 CHIP DIODE,1SS226 MAIN C.B 87-010-181-080 C-CAP,S 1800-50 K B 87-010-181-080 C-CAP,S 1800-50 K B 87-010-189-080 C-CAP,S 8200-50 K B 87-010-189-080 C-CAP,S 8200-50 K B 87-015-676-040 CAP,E 47-6.3... -
Page 3: Practical Service Figure
ADJUSTMENT <DECK> PRACTICAL SERVICE FIGURE 1. Tape Speed Adjustment Settings : • Test tape : TTA–100(TAPE CENTER) Tape speed : 3000Hz ± 50Hz • Test point : PHONES JACK (J1) Wow & flutter : Less than 0.5% (RMS) • Adjustment location : SFR1 Take-up torque : 40g-cm (FWD/RVS) - Page 4 WIRING (MAIN)
-
Page 5: Schematic Diagram (Main)
SCHEMATIC DIAGRAM (MAIN) -
Page 6: Mechanical Exploded View
MECHANICAL PARTS LIST MECHANICAL EXPLODED VIEW REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 8Z-HKB-002-010 PANEL,CASS<YU,YH,YJ> 8Z-HKB-030-010 PANEL,CASS YZ<EXCEPT YU,YH,YJ> 8Z-HKB-001-010 LID,CASS<YU> 8Z-HKB-008-010 LID,CASS LBLU<[LL]Y1> 8Z-HKB-005-010 LID,CASS LGRE<[GL]Y1B,[GL]Y1>... - Page 7 SPRING APPLICATION POSITION (4ZM-2 P1NC2) 84-ZM2-225-010 84-ZM2-226-010 SPR-T,AUTO FIND SPR-C,CLUTCH 84-ZM2-228-010 SPR-C,BT 84-ZM2-224-010 SPR-T,FF LOCK 84-ZM2-222-010 SPR-T,PLAY 84-ZM2-227-010 84-ZM2-223-010 SPR-C,AZIMUTH SPR-T,REW STOP...
- Page 8 SPRING APPLICATION POSITION (4ZM-2 P6NC2) 84-ZM2-225-010 84-ZM2-226-510 SPR-T,AUTO FIND SPR-C,CLUTCH 84-ZM2-228-210 SPR-C,BT 84-ZM2-224-110 SPR-T,FF LOCK 84-ZM2-222-110 SPR-T,PLAY 84-ZM2-227-310 84-ZM2-223-110 SPR-C,AZIMUTH SPR-T,REW STOP...
- Page 9 SPRING APPLICATION POSITION (4ZM-2 P3NC2) 84-ZM2-225-010 84-ZM2-226-010 SPR-T,AUTO FIND SPR-C,CLUTCH 84-ZM2-228-010 SPR-C,BT 84-ZM2-224-010 SPR-T,FF LOCK 84-ZM2-222-010 SPR-T,PLAY 84-ZM2-227-010 84-ZM2-223-010 SPR-C,AZIMUTH SPR-T,REW STOP...
- Page 10 TAPE MECHANISM EXPLODED VIEW (4ZM-2 P1NC2) FRAME,CENTER...
- Page 11 TAPE MECHANISM PARTS LIST (4ZM-2 P1NC2) DESCRIPTION REF. NO. PART NO. KANRI REF. NO. PART NO. KANRI DESCRIPTION 84-ZM2-002-01K LEVER,PLAY 84-ZM2-211-01K GEAR,CONNECT 84-ZM2-222-010 SPR-T,PLAY 84-ZM2-005-01K LEVER,STOP 84-ZM2-004-01K LEVER,REW 84-ZM2-003-01K LEVER,FF 84-ZM2-223-010 SPR-T,REW STOP 84-ZM2-232-010 BELT,MAIN 84-ZM2-214-01K FLY-WHL,P 10 84-ZM2-230-010 CAPSTAN,P 1.8-25 11 84-ZM2-220-01K BRG,P 12 84-ZM2-210-01K...
- Page 12 TAPE MECHANISM EXPLODED VIEW (4ZM-2 P6NC2) FRAME,CENTER SHAFT REEL FELT,CLUTCH CAPSTAN,1.8-23.3...
- Page 13 TAPE MECHANISM PARTS LIST (4ZM-2 P6NC2) DESCRIPTION REF. NO. PART NO. KANRI REF. NO. PART NO. KANRI DESCRIPTION 84-ZM2-244-010 BELT,MAIN Y 84-ZM2-220-110 BRG,P 84-ZM2-211-010 GEAR,CONNECT 84-ZM2-216-210 REEL TABLE,R 84-ZM2-223-110 SPR-T,REW STOP 84-ZM2-034-010 LEVER,REW W 84-ZM2-224-110 SPR-T,FF LOCK 84-ZM2-033-010 LEVER,FF W 84-ZM2-207-310 LEVER,AUTO 10 84-ZM2-035-010...
- Page 14 TAPE MECHANISM EXPLODED VIEW (4ZM-2 P3NC2) FRAME,CENTER...
-
Page 15: Accessories / Package List
TAPE MECHANISM PARTS LIST (4ZM-2 P3NC2) DESCRIPTION REF. NO. PART NO. KANRI REF. NO. PART NO. KANRI DESCRIPTION 84-ZM2-012-010 LEVER,PLAY G 84-ZM2-211-01K GEAR,CONNECT 84-ZM2-222-010 SPR-T,PLAY 84-ZM2-015-010 LEVER,STOP G 84-ZM2-014-010 LEVER,REW G 84-ZM2-013-010 LEVER,FF G 84-ZM2-223-010 SPR-T,REW STOP 84-ZM2-232-010 BELT,MAIN 84-ZM2-221-010 FLY-WHL,P2 84-ZM2-230-010 CAPSTAN,P 1.8-25... - Page 16 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 Printed in Singapore 9820527 9630472 931261...
