- Page 1 Version Last updated 12/06/2024 ADDRESS CONTACT Ecosy+ Telephone: + 44 1256 830099 Unit 24, Folly Farm, Ramsdell Email: trade@ecosystoves.co.uk Tadley, Hampshire RG26 5RJ United Kingdom Brought to you by...
-
Page 2: Table Of Contents
Phone: 01256 830099 Unit 22 (Office) and Unit 26 CONTENTS WELCOME ........................................3 SAFETY ........................................... 3 TECHNICAL INFORMATION .................................... 4 ASSEMBLY ........................................6 HEARTH .......................................... 6 AIR SUPPLY / VENTILATION / CHIMNEY DRAW .............................. 8 AIR CONTROL ......................................... 9 FUEL OVERLOADING..................................... 10 SMOKE FREE ZONES ..................................... -
Page 3: Welcome
Stove. please take the time to have a read through the attached manual. The Elk is a premium stove, made from extremely thick cast iron Yours Truly, and steel. It also boasts some of the lowest emissions of any stove... -
Page 4: Technical Information
Phone: 01256 830099 Unit 22 (Office) and Unit 26 TECHNICAL INFORMATION: ELK STOVE Defra Approved Nominal Output Efficiency 83.9 DIN Plus Dust (at 13% O2) Mean NOX (at 13% O2) Mean CnHm (at 13% O2) Mean CO emissions 0.006 Hearth Temperature... - Page 5 Phone: 01256 830099 Unit 22 (Office) and Unit 26 ecosystoves.co.uk + 44 1256 830099 trade@ecosystoves.co.uk...
-
Page 6: Assembly
Your stove is fully built and almost ready to go. All you need to is attach the legs and flue collar. FLUE OUTLET The Elk has a top and rear flue outlet and will arrive with a set of threads. When securing the flue collar or blanking plate, ensure the screws are pinched up and not over- tightened. - Page 7 Phone: 01256 830099 Unit 22 (Office) and Unit 26 ecosystoves.co.uk + 44 1256 830099 trade@ecosystoves.co.uk...
-
Page 8: Air Supply / Ventilation / Chimney Draw
Phone: 01256 830099 Unit 22 (Office) and Unit 26 AIR SUPPLY / VENTILATION / CHIMNEY DRAW Your stove will require a constant air supply and should not be used at the same time and in the same room/space as extractor fans or any device which may draw air supply away from the stove. -
Page 9: Air Control
Phone: 01256 830099 Unit 22 (Office) and Unit 26 AIR CONTROL The Rock range has 3 separate air controls. Primary Air: This is the dial on the left hand side of the stove, as you are looking it. This is just below the base lip of the fire. When turning this to the right, air is flowing in and turning it to the left air is restricted. -
Page 10: Fuel Overloading
Phone: 01256 830099 Unit 22 (Office) and Unit 26 When you light the fire, you will want all vents fully open and in most cases the door ajar slightly. However, this will depend on how well the chimney is drawing. When the fire is established to some degree the door can be closed and the vents gradually closed. If you close the vent down too early, before the fire is established, it could go out and/or increase smoke output. -
Page 11: Smoke Free Zones
The Elk range has been recommended as suitable for use in smoke control areas when burning seasoned wood logs. Each appliance has been factory fitted with a screw that prevents the full closure of the vent. If you are not in a smoke free zone, or have not installed the appliance onto a 5”... - Page 12 Phone: 01256 830099 Unit 22 (Office) and Unit 26 ecosystoves.co.uk + 44 1256 830099 trade@ecosystoves.co.uk...
-
Page 13: Fuel
Phone: 01256 830099 Unit 22 (Office) and Unit 26 Please note the following advice on minimising smoke emissions: FUEL WOOD All types of wood are suitable provided they are well seasoned, UNTREATED, and have a moisture level be- tween 12% and 20%. For soft woods, typically they will need to have been left in suitable storage for 9+ months for the moisture to evaporate. -
Page 14: Lighting My Stove
Phone: 01256 830099 Unit 22 (Office) and Unit 26 LIGHTING MY STOVE Prior to lighting the fire for the first time, ensure that • Installation and building work is complete. • The chimney is suitable and sound and has been swept and free from obstruction. •... - Page 15 Phone: 01256 830099 Unit 22 (Office) and Unit 26 TIPS Getting heat into the chamber is very important. A hot chamber will increase the stoves efficiency and make refueling the fire very easy. If the temperature in the stove is too low, the glass will begin to go black and excess smoke will be produced. Often the key to a hot firebox is the burning of quality dry fuel.
-
Page 16: Cleaning And Maintenance
Phone: 01256 830099 Unit 22 (Office) and Unit 26 CLEANING AND MAINTENANCE When cold, the inside of the stove should be given a regular sweep out. The flue and flue pipe will require cleaning with a suitable chimney brush, to minimise build- up of soot and tar . Your chimney will also require periodic sweeping. -
Page 17: Guarantee
Phone: 01256 830099 Unit 22 (Office) and Unit 26 GUARANTEE The main body of your stove is guaranteed for 7 years. Incorrect use or installation not carried out by a registered HETAS installer will void the guarantee. The only exceptions will be if the install has been signed off by your local authority or suitably qualified Oftec installer. -
Page 18: Broken Fire Bricks
Phone: 01256 830099 Unit 22 (Office) and Unit 26 BROKEN FIRE BRICKS It is common for vermiculite bricks to break. They are fully heat resistant but can be quite fragile. The most common bricks to break are the base and back bricks as these take the brunt of abuse. To ensure the longevity of your fire bricks, please ensure that you gently place fuel in the fire and do not over stack fuel. -
Page 19: Broken / Crazed Glass
Phone: 01256 830099 Unit 22 (Office) and Unit 26 BROKEN / CRAZED GLASS The glass used in all fires is fully approved heat resistant ceramic glass. This glass will not break through heat but can easily break if struck with a log or similarly hard object. This is why the glass is not covered by any manufacturer of stoves. Common causes for glass breakages are customers closing the door when a log is still sticking out. -
Page 20: Energy Efficiency
Phone: 01256 830099 Unit 22 (Office) and Unit 26 ENERGY EFFICIENCY ecosystoves.co.uk + 44 1256 830099 trade@ecosystoves.co.uk... - Page 21 Phone: 01256 830099 Unit 22 (Office) and Unit 26 1. Elk Brass Handle 2. Door 3. Glass 4. Right Fire Brick 5. Upper Grate Section 6. Back Brick Set 7. Primary Baffle Plate 8. Secondary Baffle Plate 9. Stoves Body 10.
