PLEASE RETAIN THIS GUIDE FOR FUTURE REFERENCE
Please read this user guide carefully when you assemble, install, operate, and
maintain your stove.
If you have any more questions, please contact your local dealer.
Item Code
I500
I700
Ecosy+ Stoves of Hampshire
www.ecosystoves.co.uk
USER GUIDE
Nominal Heat
output
5.0kW
6.9kW
Energy
Dimension (W*D*H)
Index
A+
489*346*641mm
A
639*345*483mm
Weight
81kg
97kg
Advertisement
Table of Contents
Related Manuals for Ecosy+ I500
Summary of Contents for Ecosy+ I500
- Page 1 Please read this user guide carefully when you assemble, install, operate, and maintain your stove. If you have any more questions, please contact your local dealer. Nominal Heat Energy Item Code Dimension (W*D*H) Weight output Index I500 5.0kW 489*346*641mm 81kg I700 6.9kW 639*345*483mm 97kg Ecosy+ Stoves of Hampshire www.ecosystoves.co.uk...
-
Page 2: The Clean Air Act 1993 And Smoke Control Areas
I500, we recommend blocking the secondary/tertiary air controller at 23.5cm. This results in a minimum opening of 0.5 cm*.For the I700,we recommend blocking the secondary/tertiary air controller at 31cm. -
Page 3: Unpacking Your Stove
chamber is made of ceramic bricks. Furthermore, the stove is equipped with a baffle plate made of vermiculite and steel. The combustion chamber and the baffle plate of the production models can be made of either ceramic bricks or vermiculite plates. Air supply is regulated by two controllers positioned below the loading door;... - Page 4 trim and stove separately. (5) Re-attach trim to outer shell. (4)Remove Pull outward to separate them from outer shell. (6)Slide outer shell/ trim assembly into the (7)Slide the stove into the fitted outer shell. cavity/recess, ensuring the back of the trim is flush withthe front of the recess.
-
Page 5: Installation Instructions
(8)Open the stove door,remove baffle plate(s) and pull the flue collar and flue down on top of the stove. Secure in place from the inside of the stove using the screws provided. 3. Installation Instructions It is important that all local regulations, including those referring to national and European Standards need to be complied with when installing the appliance. -
Page 6: Burning Coal
Avoid overloading your appliance as this may cause damage to the product and cause unstable burn ◆ conditions. 3.1.2.1 Burning Coal The Air-wash/secondary air lever (The control to the right) – This should be left partially open, to ◆ allow the air-wash system to keep the glass clean Primary air control lever (The control to the left) - When burning coal, the stove should be mainly ◆... -
Page 7: Air Controls
3.6. Dampers/ controls left open Operation with the air controls or appliance dampers open can cause excess smoke. The appliance must not be operated with air controls, appliance dampers or door left open except as directed in the instructions. 4. Operating Instructions Operation with the door open can cause excess smoke. -
Page 8: Burning Wood
Model Maximum Length - mm Maximum Diameter - mm I500 I700 stove is suitable for use with wood, coal and solid fuels. Note that the inset stove has been recommended for use in Smoke Control Area when burning wood logs. The inset stoves can be used in Smoke Control Areas when burning authorized solid fuels. -
Page 9: Maintenance
Warning! The stove will remain HOT after the fire has been extinguished. 4.10. Safety Notes for your guidance This appliance is NOT suitable for use in a shared flue. This appliance should NEVER be operated with the doors open. NEVER clean the glass when the stove is hot. ALWAYS use stove glass cleaner, which is available from DIY and stove retailers, only when the stove is cool. -
Page 10: Troubleshooting
5.2. Baffle plate Remove and clean the baffle plate once a month to avoid soot or fly ash. Block the flue ways and produce dangerous fume emission. 5.3. Fireproof glass Use a proprietary glass cleaner to clean the glass when cool. Any material that may damage the glass should not be used to clean the panel. - Page 11 Second, always dispose of items in a way that is as sustainable as possible and that is in line with the current environmental protection, reprocessing/recycling and disposal technology. 7.Technical Drawings and Performance Date I500 inset Stove I500 Wood Fuel Smokeless Fuel Nominal Heat Output 5.0 kW...
- Page 12 I500 Inset stove I700 Wood Fuel Smokeless Fuel Nominal Heat Output 6.9 kW 6.8kW Net Efficiency 75.80% 78.50% Seasonal Efficiency 66.80% 69.50% PM at 13% O2 29 mg/m3 25 mg/m3 OGC at 13% O2 56 mg/m3 15 mg/m3 CO at 13% O2 0.06 vol%...
- Page 13 Room heater burning solid fuel without supply Product Type of hot water in accordance with EN 13229:2001 Product model designation I500 inset Stove, Serial No. - Room heater burning solid fuel without supply Intended use of hot water Manufactured by Manufacturer’s autho rised...
- Page 14 Harmonized Technical EN 13229:2001 specification: Performance – Wood Essential characteristics Performance - Ancit Fire Safety:- Reaction to fire Rear = 400mm Clearance distances to Sides = 300mm combustible materials Ceiling = NPD Risk of burning fuel PASS falling out Emission of CO = 0.09% CO=0.08% combustion products...
- Page 15 report Ref: EZKA/2021-3/00031-1 Declared performance:- Harmonized Technical EN 13229:2001 specification: Performance – Wood Essential characteristics Performance - Ancit Fire Safety:- Reaction to fire Rear = 400mm Clearance distances to Sides = 200mm combustible materials Ceiling = NPD Risk of burning fuel falling out PASS Emission of combustion products CO = 0.06%...
- Page 16 this will be requested if a claim is started. If this is not provided upon request, we will not be able to escalate your claim. The guarantee will begin from the sale date on the invoice and we do not cover any cost incurred when removing faulty appliances or installing new ones, even if it has been proven that the stove is faulty.
- Page 17 possible. If your glass is crazed it does not need changing and is safe to use. Ecosy+ stoves Ecosy+ Stoves of Hampshire www.ecosystoves.co.uk...
