- Page 1 LITHIUM IRON PHOSPHATE (LFP) BATTERY INSTALLATION MANUAL GIV-BAT-3.4-HV, GIV-BAT-10.2-HV, GIV-BAT-13.6-HV, GIV-BAT-17.0-HV, GIV-BAT-20.4-HV AUS V 1.0 | OCT 2024...
-
Page 2: Specifications
STACKABLE BATTERY Customised power, to your property Our stackable battery is designed to work alongside the GivEnergy 3-Phase Hybrid Inverter. High voltage BMS allows for greater charge and discharge power running at a lower current, providing higher efficiency than our lesser voltage range. -
Page 3: Box Contents
GIV-BAT-13.6-HV (13.6kWh) The model and specification of the battery’s nameplate match the order specifications Item Item If any damaged or missing parts are found, please contact GivEnergy on 1300 GIVENERGY (1300 448 363) Battery Battery or email Giv-Bat HV Kit... -
Page 4: System Appearance
DC breaker manufacturer. · Weight Restrictions: Do not place heavy items on top of the product. If you suspect something is wrong with the battery, contact GivEnergy on 1300 GIVENERGY (1300 448 363) or email info.aus@givenergy.com. I I I I... - Page 5 SAFETY AND INSTALLATION BATTERY TERMINAL INTRODUCTION Battery Terminal Introductions Do not use the battery if there are any deformities, such as bulging or leakages Do not puncture the battery Do not throw the battery or use forceful impact Do not attempt to repair the battery yourself (please call your Approved Installer) The battery must be installed vertically, never install horizontally, avoid tilting the unit Terminal Description Do not install in direct sunlight...
-
Page 6: Product Handling
This guide provides step-by-step instructions for the proper handling, transportation, and unpacking of the GivEnergy stackable batteries. It also includes guidelines for dealing with packaging damage should it occur during transit. Please follow these instructions carefully to ensure the safety of the product and the installer. - Page 7 Pallet presentation Safe transport in installer vehicles The GivEnergy stackable batteries is presented on pallets When transporting the batteries in an installer’s vehicle, use proper securing methods, such as straps or cargo nets, to prevent movement and damage during transit...
- Page 8 Remember, proper handling and care during the transportation and unpacking process are essential to Installation ensure the safe and effi cient installation of your GivEnergy stackable batteries. If you have any questions or concerns, don’t hesitate to contact the supplier or manufacturer for assistance.
-
Page 9: Installation Environment
INSTALLATION ENVIRONMENT INSTALLATION ENVIRONMENT Basic installation requirements There must be adequate clearance around the batteries to allow for heat dissipation. The diagram The ambient temperature for the installation of the battery system should be above - 10℃ , below 50℃ , and below illustrates the space required around the inverter. - Page 10 STEP-BY-STEP INSTALLATION STEP-BY-STEP INSTALLATION Place the base plate down as close to the wall as possible. The base plate needs to be flush to Use the template/positioning part to mark holes for the 2 bolts for the HV box. the wall. Cut out the skirting board if in the way. Drill two holes at the marked points to suit the fixings.
-
Page 11: Ground Connection
CONNECTING THE BATTERY TO THE INVERTER GROUND CONNECTION Connect the cable to the battery and the other end to the inverter. Ensure that the grommeted Ground wiring end of the cable is the inverter end. Push the plug until there is a click, lock in place using the red tab. -
Page 12: Battery Cables
GROUND CONNECTION BATTERY CABLES Multiple battery parallel wiring diagram One type of cables exist for connection to the stackable battery: Plug to plug battery cable (Built in comms cable) Instructions on how to install the cable are also on the plug itself. Battery Inverter IMPORTANT... - Page 13 Wait for the relays to start up To download a fully illustrated guide, please visit our Knowledge Base at www.givenergy.co.uk Make sure that the battery has a green status Note: If commissioning is incomplete, leave the battery off to avoid it going flat. Without The battery indicator on the inverter should light up commissioning, the system may not operate correctly.
- Page 14 Use a multimeter to ensure the equipment is completely uncharged. • The equipment should be repaired by GivEnergy Staff and it is strictly forbidden for maintenance staff to open b. Equipment Cleaning equipment on their own.
- Page 15 DIP SWITCHES AND STATUS INDICATORS PARAMETER AND MODEL COMPARISON TABLE Status indicators GIV-BAT GIV-BAT GIV-BAT GIV-BAT GIV-BAT Parameter type 3.4-HV 10.8-HV 13.6-HV 17.0-HV 20.4-HV Height above ground (L) 220mm 575mm 725mm 875mm 1025mm High Voltage (UH) 87.6Vd.c 262.8Vd.c 350.4Vd.c 438.0Vd.c 525.6Vd.c Low Voltage (UL) 67.2Vd.c...
- Page 16 Either sign into the online portal at https://portal.givenergy.cloud, or the GivEnergy app with your GivEnergy Engineer login. If you are a first time user, and you do not have an account or Engineer login, please consult your supplier to get this set up.
- Page 17 Please contact us in time if there are any conditions that could not be explained in the manual. GivEnergy Australia Pty Ltd Phone: +61 1300 GIVENERGY (1300 448 363) Email: info.aus@givenergy.com Address: ‘Level 1, 1 Queens Road, Melbourne, VIC 3004 Alternatively, visit our troubleshooting guide on the knowledge base at www.givenergy.co.uk. FUNDAMENTALS Appendix...
- Page 18 Details of Manufacturer or Importer Aluminum 7429-90-5 5-10 7440-02-0 GivEnergy Australia Pty Ltd Level 1, 1 Queens Road, SECTION 4 – First Aid Measures Melbourne VIC 3004 Australia After eye contact: Flush eyes with plenty of water for at least 15 minutes, occasionally lifting the upper and lower eyelids.
- Page 19 MSDS MSDS SECTION 6 – Accidental Release Measures SECTION 9 – Physical and Chemical Properties Information on basic physical and chemical properties Personal precautions, protective equipment and emergency procedures: Appearance White If the battery is released, remove personnel from area until fumes dissipate. Provide maximum ventilation to Odour clear out hazardous gases.
- Page 20 12 November 2024 Document Number: SDS001 SECTION 13 – Disposal Considerations Document Title: GIV-BAT-3.4-HV Battery Module SDS Version Number: Product disposal recommendation Observe local, state and federal laws and regulation. Packaging disposal recommendation Disposal must be made according to official regulations.
- Page 21 Work with the best in the energy management business GivEnergy HQ GivEnergy Australia Pty Osprey House, Brymbo Rd Level 1, 1 Queens Road Newcastle-under-Lyme Melbourne ST5 9HX 3004 Victoria www.givenergy.co.uk 1300 GIVENERGY (1300 448 363)
