GivEnergy 3HY 6.0 Installation Manual

Generation 3 | 3-phase + stackable battery

Advertisement

Quick Links

GENERATION 3 | 3-PHASE + STACKABLE BATTERY
INSTALLATION MANUAL
3HY 6.0, 3HY 8.0, 3HY 10.0, 3HY 11.0
10.2 HV, 13.6 HV, 17.0 HV, 20.4 HV
V 1.0 09/23

Advertisement

loading
Need help?

Need help?

Do you have a question about the 3HY 6.0 and is the answer not in the manual?

Questions and answers

Summary of Contents for GivEnergy 3HY 6.0

  • Page 1 GENERATION 3 | 3-PHASE + STACKABLE BATTERY INSTALLATION MANUAL 3HY 6.0, 3HY 8.0, 3HY 10.0, 3HY 11.0 10.2 HV, 13.6 HV, 17.0 HV, 20.4 HV V 1.0 09/23...
  • Page 2 Before installation, the following tools are required: Hybrid Inverter Item Item Name The 3-phase GivEnergy Hybrid Inverter is a battery inverter and solar inverter in one unit, meaning Drill that the battery is AC and DC coupled. Suitable drill bit for wall and fixings...
  • Page 3 The model and specification of the inverter’s nameplate match the order specifications If any damaged or missing parts are found, please contact GivEnergy on 01377 252 874 or email support@givenergy.co.uk immediately. Returns must be provided in original or equivalent packaging. The...
  • Page 4 SAFETY AND INSTALLATION Safety Instructions Item Item Name Extra care and attention must be taken when installing and maintaining any GivEnergy equipment. Power Flow Direction Indicators The system is capable of retaining a high voltage, even when disconnected. Battery connection point...
  • Page 5 Only GivEnergy supplied battery cables must be used Note: Take into consideration that batteries may be added at a later date. To allow for this, hang Only GivEnergy batteries should be connected to our inverters the inverter higher to ensure there is enough space.
  • Page 6 STEP-BY-STEP INSTALLATION Drill 5 holes at the marked positions, at least 75mm deep. Fix the mounting bracket to the wall using Insert the 2 x M4 safety locking screws on the left and right side to prevent the inverter from being 5 x M6x50 expansion bolts.
  • Page 7 CLEARANCE AND MAINTENANCE To connect the AC connector: Space Clearance a. Connect the cables to their respective connection ports There must be adequate clearance around the inverter to allow for heat dissipation. The diagram b. Cut a hole in the cable grommet below illustrates the space required around the inverter.
  • Page 8 CONNECTIONS OVERVIEW COMMUNICATION CONNECTIONS Dip Switches Item Item Name Battery connection point PV Input x 2 Built-in WiFi aerial ON OFF Communication and LAN Connectors EPS Connection AC Connection DC Input Isolation Switch Cable Clamps Dipswitch WiFi IP65 Cable Entry Glands Communication/network ports METER DEBUG485...
  • Page 9 This output must be protected as close to the inverter as possible, with a double pole 30mA RCD rated at up to 20A. 3HY 6.0 - minimum 4mm² - 16mm² There are four approved methods to connect to the EPS, please refer to the EPS Connection Guide on our Knowledge Base for more information.
  • Page 10 Our stackable battery is designed to work alongside the GivEnergy 3-Phase Hybrid Inverter. For further information, please refer to the meter guide on the Knowledge Base. High voltage BMS allows for greater charge and...
  • Page 11 The model and specification of the battery’s nameplate match the order specifications Item Item If any damaged or missing parts are found, please contact GivEnergy on 01377 252 874 or email Battery Battery support@givenergy.co.uk immediately. Returns must be provided in original or equivalent packaging. The...
  • Page 12 Extra care and attention must be taken when installing and maintaining any GivEnergy equipment. ON/OFF Switch The system is capable of lethal voltages, even when disconnected HV Box If you suspect something is wrong with the battery, contact GivEnergy on 01377 252 874 or email Rotary Isolator support@givenergy.co.uk. Battery packs...
  • Page 13 STEP-BY-STEP INSTALLATION STEP-BY-STEP INSTALLATION Place the base plate down as close to the wall as possible. The base plate needs to be flush to Use the template/positioning part to mark holes for the 2 bolts for the HV box. the wall. Cut out the skirting board if in the way. Drill two holes at the marked points to suit the fixings.
  • Page 14 CONNECTING THE BATTERY TO THE INVERTER BATTERY CABLES One type of cables exist for connection to the stackable battery: Connect the cable to the battery and the other end to the inverter. Ensure that the grommeted end of the cable is the inverter end. Push the plug until there is a click, lock in place using the red Plug to plug battery cable tab.
  • Page 15 Wait for the relays to start up To download a fully illustrated guide, please visit our Knowledge Base at www.givenergy.co.uk Make sure that the battery has a green status Note: If commissioning is incomplete, leave the battery off to avoid it going flat. Without The battery indicator on the inverter should light up commissioning, the system may not operate correctly.
  • Page 16 CLEARANCE AND MAINTENANCE DIP SWITCHES AND STATUS INDICATORS Space Clearance Status indicators There must be adequate clearance around the batteries to allow for heat dissipation. The diagram below illustrates the space required around the inverter. 300mm 300mm 300mm 300mm What does the STATUS light mean? Shut down 300mm 300mm...
  • Page 17 PARAMETER AND MODEL COMPARISON TABLE DECOMMISSIONING A SYSTEM Uninstalling the Inverter GIV-BAT GIV-BAT GIV-BAT GIV-BAT Parameter type 10.8-HV 13.6-HV 17.0-HV 20.4-HV Follow the shut-down procedure Height above ground (L) 575mm 725mm 875mm 1025mm Remove all connections and cables from the inverter High Voltage (UH) 262.8Vd.c 350.4Vd.c...
  • Page 18 3-Phase 11.0 12 years 12 years If you have any questions, please contact GivEnergy on 01377 252 874 or email support@givenergy.co.uk. Alternatively, visit our troubleshooting guide on the knowledge base at www.givenergy.co.uk. Stackable Battery | HV 10.2/ 13.6/ 17.0/ 20.4...
  • Page 19 SCAN ME TO ACCESS ALL AVAILABLE RESOURCES...
