- Page 1 LITHIUM IRON PHOSPHATE BATTERY INSTALLATION MANUAL GENERATION 1 Giv-Bat 2.6, Giv-Bat 5.2, Giv-Bat 8.2...
- Page 2 GIV-BAT 2.6 SPECIFICATIONS GIV-BAT 5.2 SPECIFICATIONS SMALL AND COMPACT AGILE AND VERSATILE The perfect starter battery Championing Modular Design The 2.6kWh battery pack is ideal for New Build The 5.2kWh battery pack is our most versatile and Social Housing Projects where smaller storage...
- Page 3 USB Stick** During the summer there is enough capacity to * Expansion bolts quantity varies. 4 included with GIV-BAT 2.6, 6 included with GIV-BAT 5.2 and above. store up to 50% of your daily generated energy ** This may be pre-installed...
- Page 4 Earthing Point Unit Information The Generation 1 batteries are designed to work with a GivEnergy AC Coupled or Hybrid Inverter. The batteries work with renewable generation or import from the grid at off-peak times when prices are lower, and discharge during busier periods when prices are more expensive.
- Page 5 The cardboard packaging is recyclable. Installation Instructions Drill 4 (Giv-Bat 2.6) or 6 (Giv-Bat 5.2 and above) holes at the marked positions, at least 75mm deep. All electrical installations must be carried out by a qualified and registered electrician and in Fix the mounting bracket to the wall using the expansion bolts.
- Page 6 STEP-BY-STEP INSTALLATION For Generation 1 Inverters only For Generation 3 Inverters only A 100A DC circuit breaker must be installed inline between the inverter and battery pack. Only one If multiple Generation 1 batteries are installed, connect output B of the first battery to output A on circuit breaker is required, using the provided cable.
- Page 7 GivEnergy is the main supplier and manufacturer of the product. GivEnergy warrants that your product is (a) of acceptable quality and (b) does not have any latent defects. Battery Description If you suspect something is wrong with the battery, contact GivEnergy on 01377 252 874 or email Master 0, 0, 0, 0 support@givenergy.co.uk.
- Page 8 www.givenergy.co.uk...
