Summary of Contents for Cybernet CyberMed Rx
- Page 2 CyberMed Rx / Rugged X10 User’s Manual FCC-B Radio Frequency Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 3 Safety Instructions Always read the safety instructions carefully. Keep this equipment away from humidity. Lay this equipment on a reliable flat surface before setting it up. The openings on the enclosure are for air convection hence protect the equipment from overheating. DO NOT COVER THE OPENINGS. Confirm the voltage of the power source and adjust accordingly to 110/220V before connecting the equipment to the power inlet.
- Page 4 WEEE Statement (Waste Electrical and Electronic Equipment) The WEEE directive places an obligation on EU-based manufacturers, distributors, retailers and importers to take-back electronics products at the end of their useful life. A sister Directive, ROHS (Restriction of Hazardous Substances) compliments the WEEE Directive by banning the presence of specific hazardous substances in the products at the design phase.
- Page 5 Cleaning the Surface of the All in One PC: ..........26 Troubleshooting ..................27 Appendices ....................29 A - Cybernet Limited Warranty ................30 B - Cybernet’s Recycling Program ................. 35 DOC ID: 16001200 Page | 4...
- Page 6 Direct current Ready to use Getting to know your Tablet This manual refers to both the Medical model known as CyberMed Rx and the Enterprise model known as Rugged X10. Model difference: 1) CyberMed: features a white color unit for medical markets with Antigerm and Medical grade certifications.
- Page 7 CyberMed Rx & Rugged X10 Specifications Display LED panel 10.6” 1920 x 1200 400nits Intel® Broadwell Core™ i7-5650U Intel® Broadwell Core™ i7-5600U Intel® Broadwell Core™ i5-5350U Intel® Broadwell Core™ i5-5300U Intel® Broadwell Celeron® 3765U 1 x DDR3L SO-DIMM sockets, up to 16GB...
- Page 8 Supports Stylus / Digitizer Pen Corning Gorilla Glass 3 Wireless Intel AC7265 supports IEEE802.11ac + BT4.0 Communications 2.0M Camera, front facing Camera 5.0M Camera with flash and auto-focus, rear facing Startek Biometric Fingerprint Reader Biometric Reader Crossmatch 710 Biometric Fingerprint Reader (Option) Castles Technology EZMini II Smart Card Reader Smart Card Reader Identiv FIPS 140-2 Compliant Smart Card Reader (Option)
- Page 9 FSP FSP120-REBN2 IEC 60950-1:2005 (Second Edition) + Am 1:2009 + Am 2:2013 Intended Usage The CyberMed Rx and Rugged X10 is designed for general tablet application for health care environment. It may be used for Radiology, PACS (Picture Archiving Communication Systems), LIS (Lab Information Systems) and Electronic Medical Record purpose.
- Page 10 Read the Manual Please read this manual carefully and remember to keep this manual for future reference. Drivers Please visit https://www.cybernetman.com/en/support/downloads to download the drivers necessary for installation. Note, all of the INF and CAB driver packages are located under the Driver Packages page. Safety Instructions This product has undergone various tests in order to comply with safety standards.
- Page 11 the tablet may result in a fire or electric shock. Also, do not repair the unit on your own. 3. Before suspending the unit, make sure the material used for suspension is sturdy and stable. If not properly suspended, the tablet may fall and cause serious injury to people standing nearby as well as to the unit itself.
- Page 12 Disconnect Device To fully disengage the power to the unit, please ensure the system has been properly shutdown before disconnecting the power cord from the AC inlet. Environmental Factors Operating Temperature: 0°C to 35°C; Non-operating temperature: -20°C to 60°C.
- Page 13 Servicing, Repairing, Maintenance & Safety Checks 1. If the unit is not functioning properly, observe the performance level closely to determine what type of servicing is needed. 2. Do not attempt to repair the tablet on your own. Disassembling the cover exposes users to high voltages and other dangerous conditions.
- Page 14 ISO 7000-0434: Caution, consult ACCOMPANYING DOCUMENTS. ISO 7000-1641: Follow operating instructions or Consult instructions for use. IEC 60417 -5009: ready to use. IEC 60417-5031: Direct current. EU-wide legislation, as implemented in each Member State, requires that waste electrical and electronic products carrying the mark (left) must be disposed of separately from normal house hold waste and follow the “national”...
- Page 15 CyberMed Rx & Rugged X10 Series Overview DOC ID: 16001200 Page | 14...
- Page 16 DOC ID: 16001200 Page | 15...
- Page 17 Front View Item Description Biometric reader – Startek standard. Optional Crossmatch Finger Print FIPS 201 certified and compatible with Imprivata Single Sign-On (SSO). Microphone Analog Microphone Front Camera 2.0 Megapixel Webcam LED indicators for WiFi/Bluetooth, 2D Scanner, and LED Indicators Power.
- Page 18 LED Indicators Symbol Item Description The LED will light up solid green when the tablet is powered on. When the system is in sleep mode (S3), the LED Power will blink green. When the system is powered off (S5) or hibernating (S4), the LED will not light up.
- Page 19 Control Keys Symbol Function Tap to bring up the Start Menu Windows Key Tap and hold for 3 seconds for CTL+ALT+DEL function Volume Up ALT+F11 Volume Down ALT+F10 DOC ID: 16001200 Page | 18...
- Page 20 Back View Item Description Internal USB2.0 port for external modules. Pin Definition: 1: 5V, 2: USB-, 3: USB+, 4: GND Internal USB Port Battery 2 x hot swappable batteries. Rear Camera 5.0 Megapixel camera with flash and auto-focus features. DOC ID: 16001200 Page | 19...
- Page 21 Side View Item Description 2D Scanner Optional 2D scanner. DC Jack 19V DC input. Smart Card Reader Optional Smart Card Reader. Supports Headphone + Microphone CTIA (iPhone) type Audio Jack ear phone. USB 3.0 interfaces supported with 5Gbit/s transfer rate USB3.0 / 900mA output current and compatible with USB2.0 and USB1.1.
- Page 22 Top & Bottom View Item Description Power Button Power on / off button for the tablet. Scanner Power Power on / off button for the optional 2D scanner. When the scanner is powered on, press and hold to Scanner Trigger trigger the scanner.
- Page 23 Then click [Additional power settings]. Select a power plan that suits your personal needs. You may also fine-tune the settings by clicking [Change plan settings]. DOC ID: 16001200 Page | 22...
- Page 24 The Shut Down Menu presents the options of Sleep (S3) & Shut Down (S5) for rapid and easy management of your system power. Waking the System Up The tablet shall be able to wake up from power saving mode in response to a command from any of the following: ...
- Page 25 Battery Information Each Battery provides a multi-level blue LED indicator, allowing the user to press the LED button for real-time battery capacity levels. LED indicator guide: 1x LED ON – 1~20% charge remaining 2x LED ON – 21~40% charge remaining 3x LED ON –...
- Page 26 BIOS Setup The AMI BIOS provides a Setup utility program for specifying the system configurations and settings. The BIOS ROM of the system stores the Setup utility. When you turn on the computer, the AMI BIOS is immediately activated. Pressing the <DEL> key allows you to enter the Setup utility.
- Page 27 Below are the approved disinfectants. The disinfectants have been validated on both housing and the touch glass. To prevent potential damage to the computers, please use the disinfectants listed below. Should you have any questions, please contact Cybernet. Cleaner Brand Viraguard®...
- Page 28 Troubleshooting Display problems: If the screen is blank, make sure that: When I turn on the - The batteries are connected or the AC adapter is tablet, nothing appears connected to the tablet and the power cord is plugged into on the screen.
- Page 29 Incorrect character Check that the Operating System or application programs appears on the screen. are installed or configured correctly. If they are installed and configured correctly, have the tablet serviced. Sound problem No sounds can be heard Make sure that: from the speaker, even - The Mute function is off.
- Page 30 Appendices DOC ID: 16001200 Page | 29...
- Page 31 A - Cybernet Limited Warranty What the warranty covers Cybernet warrants its products to be free from defects in material and workmanship during the warranty period. If a product proves to be defective in material or workmanship during the warranty period, Cybernet will, at its sole option, repair or replace the product with a similar product.
- Page 32 B - Desktop Docking Station Dimensions Ports Item Description 10/100/Gigabit LAN, supports Wake on LAN and PXE. DC Jack 19V DC input. DOC ID: 16001200 Page | 31...
- Page 33 2 x USB 2.0 The USB interface supports Plug and USB2.0 Play. 500mA output current. RS-232 RS-232 serial port. HDMI HDMI output, maximum resolution 4096x2304 @ 24 Hz Security lock slot to prevent the docking station from Security Lock being moved. Tested load of up to 25kg. 2x battery charging ports with LED indicators.
- Page 34 C - VESA Docking Station Dimensions DOC ID: 16001200 Page | 33...
- Page 35 Ports Item Description DC Jack 19V DC input. 10/100/Gigabit LAN, supports Wake on LAN and PXE. 2 x USB 2.0 The USB interface supports Plug and USB2.0 Play. 500mA output current. RS-232 RS-232 serial port. HDMI HDMI output, maximum resolution 4096x2304 @ 24 Hz Security lock slot to prevent the docking station from Security Lock being moved.
- Page 36 D - Cybernet’s Recycling Program Corporate Headquarters UK & European Inquiries Cybernet Manufacturing Cybernet Europe 5 Holland #6, Groveland Business Centre Irvine, California 92618 Boundary Way Free: (888) 834-4577 Hemel Hempstead, HP2 7TE Phone: (949) 600-8000 United Kingdom Fax: (949) 600-8013 Phone: +44.845.539.1200...
