Summary of Contents for Cybernet G15
-
Page 2: Fcc-B Radio Frequency Interference Statement
CyberMed / iOne / IPC G15 User’s Manual FCC-B Radio Frequency Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 3: Safety Instructions
Safety Instructions Always read the safety instructions carefully. Keep this equipment away from humidity. Lay this equipment on a reliable flat surface before setting it up. The openings on the enclosure are for air convection hence protect the equipment from overheating. DO NOT COVER THE OPENINGS. Confirm the voltage of the power source and adjust accordingly to 110/220V before connecting the equipment to the power inlet. -
Page 4: Consignes De Sécurité
Consignes de sécurité Lisez toujours attentivement les consignes de sécurité. Gardez cet équipement à l'abri de l'humidité. Posez cet équipement sur une surface plane fiable avant de l'installer. Les ouvertures sur l’enceinte sont destinées à la convection d’air et protègent équipement de surchauffe. -
Page 5: Weee Statement
WEEE Statement (Waste Electrical and Electronic Equipment) The WEEE directive places an obligation on EU-based manufacturers, distributors, retailers and importers to take-back electronics products at the end of their useful life. A sister Directive, ROHS (Restriction of Hazardous Substances) compliments the WEEE Directive by banning the presence of specific hazardous substances in the products at the design phase. -
Page 6: Table Of Contents
Consignes de sécurité ................3 WEEE Statement ..................4 Getting to know your All in One PC ............7 Introduction ....................7 CyberMed / iOne / IPC G15 Specifications ..........8 Power Information ..................9 Intended Use ................... 10 Unpacking ....................11 Drivers ..................... - Page 7 Troubleshooting ..................25 Appendices ..................... 27 A - Cybernet Limited Warranty ................27 B - Cybernet’s Recycling Program ................. 28 DOC ID: 16002000 Rev1.0...
-
Page 8: Getting To Know Your All In One Pc
Ready to use Getting to know your All in One PC This manual refers to both the Medical model known as CyberMed G15 / S15 the Enterprise model known as iOne G15 / S15, and the Industrial model known as IPC... -
Page 9: Cybermed / Ione / Ipc G15 Specifications
CyberMed / iOne / IPC G15 Specifications LCD panel 15.6” 1920 x 1080, 350nits / 500nits (Optional) Display Intel® Core™ i3-1115G4@12W Intel® Core™ i5-1135G7@12W Intel® Core™ i5-1145G7 / 1145G7E Intel® Core™ i7-1185G7 / 1185G7E 2 x DDR4 SO-DIMM sockets, up to 64GB... -
Page 10: Power Information
Wireless Intel AX210 support IEEE802.11 a/b/g/n/ac/ax + BT5.2 Communications Camera Full HD web camera (Optional) Optional internal backup battery with 7 hours of runtime Battery Charging time: 7 hours Windows 11 / 10 / IoT / Pro Operating System Linux Operating Environment Ambient Temperature: 0°C ~ 35°C (operating). -
Page 11: Intended Use
Intended Use The CyberMed G15 is designed for general pc application for health care environment. It may be used for Radiology, PACS (Picture Archiving Communication Systems), LIS (Lab Information Systems) and Electronic Medical Record purpose. It shall not be used for life-supporting system. -
Page 12: Unpacking
Unpacking After opening the carton, please check carefully to see if there are any damages or missing parts. Read the Manual Please read this manual carefully and remember to keep this manual for future reference. Drivers Please visit https://www.cybernetman.com/en/support/downloads to download the drivers necessary for installation. -
Page 13: Transporting & Placement
2. If the G15 does fall to the ground, immediately turn the power off and disconnect cords. Then contact an authorized service personnel for repairs. Continual use of the G15 may result in a fire or electric shock. Also, do not repair the unit on your own. -
Page 14: Disconnect Device
The G15 uses 19V DC output from an adapter. Connect the unit to a power source with the same numerical value as indicated. Please use only the power cord provided by the dealer to ensure safety and EMC compliance. -
Page 15: Ventilation Spacing
1. If the unit is not functioning properly, observe the performance level closely to determine what type of servicing is needed. 2. Do not attempt to repair the G15 on your own. Disassembling the cover exposes users to high voltages and other dangerous conditions. Notify and request a qualified authorized service personnel for servicing the unit. - Page 16 ISO 7000-0434: Caution, consult ACCOMPANYING DOCUMENTS. ISO 7000-1641: Follow operating instructions or Consult instructions for use. IEC 60417 -5009: ready to use. IEC 60417-5031: Direct current. EU-wide legislation, as implemented in each Member State, requires that waste electrical and electronic products carrying the mark (left) must be disposed of separately from normal house hold waste and follow the “national”...
-
Page 17: Cybermed & Ione G15 Series Overview
CyberMed & iOne G15 Series Overview DOC ID: 16002000 Rev1.0... -
Page 18: Bottom View
Bottom View Item Description Power button Main power ON/OFF button. DC IN 19V input with 72 /120Watt adapter. RS232/RS422/RS485 is selectable at pin 9. 0/5V is selectable in the BIOS menu (100mA max). LAN1 Intel I225LM 10M/100M/1G/2.5 Gigabit LAN, supports Wake on LAN, PXE Boot, and Intel AMT. -
Page 19: Front Button Description
Front Button description Item Description Power Button Main power ON/OFF button. Press and hold for 1 second to trigger power button action. Privacy Button Press once to enter privacy mode, which will disable display and touch function until the privacy button is pressed again. -
Page 20: Power Management
Power management has the potential to save significant amounts of electricity as well as deliver environmental benefits. To be energy efficient, turn off your display or set the G15 to sleep mode after a period of user inactivity. Power Management in Windows OS Right click the start button, and select [Power Options]. - Page 21 Select a power plan that suits your personal needs. You may also fine-tune the settings by clicking [Change plan settings]. The Shut Down Menu presents the options of Sleep (S3) & Shut Down (S5) for rapid and easy management of your system power. DOC ID: 16002000 Rev1.0...
-
Page 22: Waking The System Up
Turn off the display after 15 minutes. Initiate Sleep after 30 minutes. Waking the System Up The G15 can be woken up from power saving mode in response to a command from any of the following: the power button, ... -
Page 23: Power Save Settings For Windows
Change from “Balanced” mode to “Power saver” mode Installing the Cable Cover Cybernet provides a cable cover for easy cable management. Before installation, please remove the two screws as shown below. Next, install all of the cables, and secure the cable management cover using the provided fasteners. -
Page 24: Bios Setup
BIOS Setup The AMI BIOS provides a Setup utility program for specifying the system configurations and settings. The BIOS ROM of the system stores the Setup utility. When you turn on the computer, the AMI BIOS is immediately activated. Pressing the <DEL> key allows you to enter the Setup utility. -
Page 25: Cleaning The Surface Of The All In One Pc
Below are the approved disinfectants. The disinfectants have been validated on both housing and the touch glass. To prevent potential damage to the computers, please use the disinfectants listed below. Should you have any questions, please contact Cybernet. Cleaner Brand Viraguard®... -
Page 26: Troubleshooting
Display problems: If the screen is blank, make sure that: When I turn on the G15, - The AC adapter is connected to the G15 and the power nothing appears on the cord is plugged into a working electrical outlet. - Page 27 The screen is blank. Check the following: - Check the screen brightness setting. - If the G15 is in sleep mode, press the power button to resume the G15. - If the problem persists, refer to the solution in the following problem "the screen is unreadable or distorted."...
-
Page 28: Appendices
A - Cybernet Limited Warranty What the warranty covers Cybernet warrants its products to be free from defects in material and workmanship during the warranty period. If a product proves to be defective in material or workmanship during the warranty period, Cybernet will, at its sole option, repair or replace the product with a similar product. -
Page 29: B - Cybernet's Recycling Program
B - Cybernet’s Recycling Program Corporate Headquarters UK & European Inquiries Cybernet Manufacturing Cybernet EMEA Limited 5 Holland Unit 3 Station Approach Irvine, California 92618 Wendover, Bucks HP22 6BN Free: (888) 834-4577 United Kingdom Phone: (949) 600-8000 Phone: +44.0300.124.6600 Fax: (949) 600-8013 www.cybernetemea.com...
