SAJ eManager-C1 Pro Quick Installation Manual page 7

5. Tighten the nut back to the cable gland COM1.
6. Connect the grounding cable
Insert the grounding cable through the POWER AC_IN cable gland at the bottom of the eManager box.
1. Prepare an OT terminal.
a
Callout Description
a Cable
d Hydraulic pilers
2. Locate the grounding bolt. Install the OT terminal to the bolt and tighten it by using the hexagon flange nut.
V0.0
b
Callout Description
b Heat shrink tubing
e Heat gun
Callout Description
a OT grounding terminal
b Hexagon flange nut
c
Callout Description
c OT terminal
/ /
7
d
b
a
