SAJ eManager Quick Manual

eManager
Quick Guide
Product Documentation
eManager eManager-Pro
Suppo features of: Suppo features of:
· ·
PVs
PVs
·
·
ESSs ESSs
· ·
Devices with d contacts
Devices with d contacts
(such as heat pump)
(such as heat pump)
·
RCR (for Germany)
·
DRM (for Australia)
SAFETY
Before installing the equipment, read the
product information and all the safety
instructions in the user manual carefully and
obse e the appropriate rules and regulations
of the count or region where you install the
equipment.
CAUTION:
ONLY quali ed and trained electricians who
have read and fully understood all safety
regulations contained in this manual can
install, maintain, and repair the equipment.
Access to the equipment is secured by the
means of a tool, lock and key, or others.
The product warranty does not cover
equipment damage caused by failure to
follow the installation and usage guidelines
speci ed in this document and user manual.
You can scan the above QR code to view the
user manual. The information in the product
documentation is subject to change without
notice.
1
Package Contents
eManager
eMana ger
x1 x1
RST
COM
LAN
x1
x1 x2 x1
(Optional)
Document x2
Pro-Mate
x1
x1
x1 x1
2
Dimension
18.6 mm 66.5 mm 17.6 mm
58.0 mm
3
Installing the Equipment
eManager
2
eMana ger
1
RST
COM
LAN
eManager-Pro
AC-DC module (optional)
2
4
3
1
● Ensure that the AC distribution box has a surge protective
device con gured.
● Install the eManager, Pro-Mate module (optional), and AC-DC
power supply module (optional) on the DIN 35-mm standard
guide rails in the AC distribution box.
● Use a tool to lock the AC distribution box.
4
Preparing Cables
Internal CT connection (current ≤ 63A)
Inverter
RS485
AC_OUT
Home
loads
Antenna
eManager
DO
FE
Router
L1-IN L2-IN L3-IN N-IN
AC_IN
DO
Main circuit breaker
Devices with
dry contacts
Devices with
Grid
dry contacts
A
AC_IN, AC_OUT
16mm² 6-16mm²
A B
10-13 mm
150 -160 mm
RJ45 pin
FE
1 2 3 4 5 6 7 8 1 8
T-568B
(Fast
Ethernet)
0.12-0.2 mm²
Best: 0.2 mm²
External CT connection (current >63A)
CT ratio: N x 50 A/50 mA (integer N ≥ 2)
Inverter
RS485
Antenna
eManager
CT
Home
loads
FE
Router
L1-IN L2-IN L3-IN N-IN
AC_IN
Main circuit breaker
Grid
B
RS485, 12V_IN, DO, DI CT
8-10 mm 0.2-1.5 mm² 8-10 mm 0.2-1.5 mm²
Best: 0.5 mm² Best: 0.5 mm²
15 mm 15 mm
Antenna
1 2 3 4 5 6
7 8
The antenna is provided in the
accesso bag. For signal enhancement,
Ethernet connection is recommended.
