Advanced User Guide
EN
CT2-D371-A
© CANON INC. 2025

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EOS R50 V and is the answer not in the manual?

Questions and answers

Related Manuals for Canon EOS R50 V

Summary of Contents for Canon EOS R50 V

  • Page 1 Advanced User Guide CT2-D371-A © CANON INC. 2025...

  • Page 2: Table Of Contents

    Contents Introduction..........10 Package Contents.
  • Page 3 Creative Zone movie modes........107 Movie Auto Exposure......... . . 109 Movie Shutter-Priority AE.
  • Page 4 Sound Recording..........181 Exposure Compensation.
  • Page 5 Display During HDMI Connection....... . . Canon Log HDMI Output Range........342 Retain Creative Assist Data.
  • Page 6 Using the Self-Timer......... . . Remote Control Shooting.
  • Page 7 Connecting to EOS Utility........564 Uploading Images to image.canon....... . . 574 Advanced Connections.
  • Page 8 Date/Time/Zone..........696 Language.
  • Page 9 Trademarks and Licensing........830...

  • Page 10: Introduction

    After shooting, play images back and check whether they have been properly recorded. If the camera or memory card is faulty and images cannot be recorded or transferred to a computer, Canon cannot be held liable for any loss or inconvenience caused. Copyrights...

  • Page 11: Package Contents

    ) can be downloaded from the Canon website. Caution When you need Lens Instruction Manuals, download them from the Canon website Lens Instruction Manuals (PDF files) are for lenses sold separately, and when a lens kit is purchased, some accessories included with the lens may not match...

  • Page 12: Supplemental Information

    Supplemental Information Refer to the following website for information on lenses compatible with camera features, and for supplemental information about the camera. https://cam.start.canon/H001/...

  • Page 13: Compatible Accessories

    Compatible Accessories Check the following website for details on compatible accessories. https://cam.start.canon/H002/...

  • Page 14: Instruction Manuals

    Be sure to read before use. Advanced User Guide Complete instructions are provided in this Advanced User Guide. For the latest Advanced User Guide, refer to the following website. https://cam.start.canon/C021/ Lens Instruction Manuals View or download from the following website. https://cam.start.canon/...

  • Page 15: Quick Start Guide

    Quick Start Guide Insert the battery ( Upon purchase, charge the battery to start using ( Insert the card ( Insert the card with the label facing the front of the camera until it clicks into place.

  • Page 16: Attach The Lens

    Attach the lens ( Align the red mount index on the lens with the red mount index on the camera to attach the lens. Set the power switch to < > ( Flip out the screen ( When the language setting screen is displayed, see Language. When the date/time/zone setting screen is displayed, see Date/Time/ Zone.

  • Page 17: Recording Movies

    Recording movies Set the Mode dial to < >. Focus on the subject ( By default, [ : Movie Servo AF] is set to [Enable] so that the camera always keeps focusing (...
  • Page 18 Record the movie ( Press the movie shooting button (on the top or front) to start recording a movie. You can also start recording a movie by tapping [ ] on the screen. REC] (1) is displayed in the upper right while movie recording is in progress, and a red frame appears around the screen.

  • Page 19: Shooting Still Photos

    Review the recorded movie ( Press the < > button. Press < > twice. Shooting still photos Set the Mode dial to < >. Tap the shooting mode icon.

  • Page 20: Take The Picture

    Select [ Focus on the subject ( A tracking frame [ ] for AF appears over any face detected. Press the shutter button halfway, and the camera will focus on the subject. Take the picture ( Press the shutter button completely to take the picture.
  • Page 21 Review the picture. The image just captured will be displayed for approx. 2 sec. on the screen. To display the image again, press the < > button (...

  • Page 22: About This Guide

    About This Guide Icons in This Guide Basic Assumptions for Operating Instructions Icons in This Guide > Indicates the Main dial. < Indicates the Quick control dial. < > < > < > Indicates the direction to press the cross keys (< >).
  • Page 23 Basic Assumptions for Operating Instructions Before following any instructions, make sure the power switch is set to < > ( and the Multi-function lock feature is off ( It is assumed that all the menu settings and Custom Functions are set to their defaults. Illustrations in this guide show the camera with the RF-S14-30mm F4-6.3 IS STM PZ lens attached as an example.

  • Page 24: Compatible Cards

    Compatible Cards The following cards can be used with the camera regardless of capacity. If the card is new or was previously formatted (initialized) by another camera or computer, format the card with this camera ( SD/SDHC/SDXC memory cards * UHS-II and UHS-I cards compatible Cards That Can Record Movies When recording movies, use a card with ample performance (fast enough writing and reading speeds) for the movie recording size (...

  • Page 25: Safety Instructions

    Safety Instructions Be sure to read these instructions in order to operate the product safely. Follow these instructions to prevent injury or harm to the operator of the product or others. WARNING: Denotes the risk of serious injury or death. Keep the product out of the reach of young children.
  • Page 26 Observe the following instructions when using commercially available batteries or provided battery packs. • Use batteries/battery packs only with their specified product. • Do not heat batteries/battery packs or expose them to fire. • Do not charge batteries/battery packs using non-authorized battery chargers. •...
  • Page 27 CAUTION: Follow the cautions below. Otherwise physical injury or property damage may result. Do not fire the flash near the eyes. It may hurt the eyes. Do not look at the screen or through the viewfinder (on products with a viewfinder) for extended periods.
  • Page 28 After movie recording or repeated continuous shooting over an extended period, do not touch the screen storage compartment (A), which may be hot. This may cause burns. The camera and memory cards may become hotter when [ : Auto pwr off temp.] is set to [High].

  • Page 29: Handling Precautions

    The camera is not waterproof and cannot be used underwater. If the camera gets wet, contact a Canon Service Center immediately. Wipe off any water droplets with a dry and clean cloth. If the camera has been exposed to salty air, wipe it with a clean, well-wrung wet cloth.
  • Page 30 Attach the lens cap to prevent direct sunlight and other light from entering the lens when you are not shooting. Screen The following does not affect images captured by the camera. Although the screen is produced under extremely high-precision manufacturing conditions and more than 99.99% of the pixels meet design specifications, 0.01% or fewer pixels may be defective or appear as red or black dots.
  • Page 31 Lens After detaching the lens from the camera, put down the lens with the rear end up and attach the rear lens cap to avoid scratching the lens surface and electrical contacts (1).
  • Page 32 Besides dust entering the camera from outside, in rare cases, lubricant from the camera's internal parts may adhere to the front of the sensor. If smudges are visible on images, have the sensor cleaned by a nearest Canon Service Center.

  • Page 33: Part Names

    Part Names Attaching the Strap...
  • Page 34 Shutter button/movie shooting button Zoom lever During shooting: <W> Wide-angle/<T> Telephoto During playback: < > Index/< > Magnify AF-assist beam/red-eye reduction/self-timer/remote control lamp RF lens mount index Image sensor Grip Contacts Lens mount Microphone (10) Speaker (11) Strap mount (12) Tally lamp (13) Terminal cover...
  • Page 35 (10) (11) (12) (13) (14) (18) (15) (19) (16) (20) (17) (21) (22) (25) (23) (24)
  • Page 36 Multi-function shoe < > Playback button < > Menu button Screen Mode dial < > 1/stream/movie-photo playback toggle button <LOCK> Multi-function lock button Strap mount < > Power switch (10) < > Main dial (11) Serial number (body number) (12) <...

  • Page 37: Mode Dial

    Mode Dial The Mode dial is divided into Basic and Creative zones for movies and a zone for still photo shooting. (1) Basic Zone movie modes Simply press the movie shooting button and the camera sets everything to suit the subject or scene for shooting.
  • Page 38 (2) Creative Zone movie modes ( Record movies with your preferred exposure or other settings. To select a recording mode for < > or < >, tap an icon in the upper left of the screen. < >: Slow/fast motion movies S&F movie auto exposure S&F movie shutter-priority AE S&F movie aperture-priority AE...
  • Page 39 (3) < >: Still photo shooting ( In Basic Zone modes, the camera determines optimal settings for the subject or scene. In Creative Zone modes, you can shoot with your preferred exposure or other settings. To select a shooting mode, tap an icon in the upper left of the screen. Basic Zone Scene Intelligent Auto Self portrait...
  • Page 40 Battery Charger LC-E17 Charger for Battery Pack LP-E17 ( Power plug Charge lamp Full-charge lamp Battery slot Battery Charger LC-E17E Charger for Battery Pack LP-E17 ( Power cord socket Charge lamp Full-charge lamp Battery slot Power cord...

  • Page 41: Attaching The Strap

    Attaching the Strap Pass the end of the strap through the strap mount from the bottom, then pass it through the strap buckle as shown. Pull the strap to take up any slack and make sure the strap will not loosen from the buckle.

  • Page 42: Software/Apps

    For JPEG/TIFF upscaling, applying deep learning. Requires a paid subscription. Picture Style Editor Enables you to edit existing Picture Styles or create and save original Picture Style files. Canon XF Utility For transferring movie files to a computer, as well as playback and still photo extraction. Smartphone apps...
  • Page 43 Download the software. Connect to the internet from a computer and access the following Canon website. https://cam.start.canon/ Depending on the software, you may need to enter the camera's serial number. The serial number is written on the camera body.
  • Page 44 Installing Smartphone Apps Always install the latest version. Apps can be installed from Google Play or App Store. You can also access Google Play and App Store from the following Canon website. https://cam.start.canon/...
  • Page 45 Software Instruction Manuals Check the following website for software instruction manuals. https://cam.start.canon/...

  • Page 46: Preparation And Basic Operations

    Preparation and Basic Operations This chapter describes preparatory steps before you start shooting and the basic camera operations. • Charging the Battery • Inserting/Removing the Battery and Card • Using the Screen • Turning on the Power • Attaching and Detaching RF/RF-S Lenses •...

  • Page 47: Charging The Battery

    Charging the Battery Detach the protective cover provided with the battery. Fully insert the battery into the charger. Do the opposite to remove the battery.
  • Page 48 Charge the battery. LC-E17 Flip out the charger prongs as shown and plug the charger into a power outlet. LC-E17E Connect the power cord to the charger and insert the plug into a power outlet. Charging starts automatically and the charge lamp (1) lights up in orange.
  • Page 49 Charge the battery on the day before or on the day it is to be used. Charged batteries gradually lose their charge, even when they are not used. After charging the battery, remove it and disconnect the charger from the power outlet.

  • Page 50: Inserting/Removing The Battery And Card

    Inserting/Removing the Battery and Card Insertion Formatting the Card Removal Insert a fully charged Battery Pack LP-E17 and card in the camera. The captured images are recorded onto the card. Insertion Slide the card/battery compartment cover lock and open the cover. Insert the battery.
  • Page 51 Insert the card. Insert the card with the label facing the front of the camera until it clicks into place. Caution Make sure the card's write-protect switch (1) is set upward to enable writing and erasing. Close the cover. Press the cover closed, then slide the card/battery compartment cover lock to lock it.

  • Page 52: Formatting The Card

    Formatting the Card If a card is new or was previously formatted (initialized) by another camera or computer, format the card with this camera (...
  • Page 53 Removal Slide the card/battery compartment cover lock and open the cover. Set the power switch to < >. Make sure the access lamp (1) is off before opening the card/ battery compartment cover. If [Saving...] is displayed on the screen, close the cover. Removing the battery.
  • Page 54 Remove the card. Gently push in the card, then let it go to eject. Pull the card straight out, then close the cover. Caution Do not remove cards immediately after a red [ ] icon is displayed as you are shooting. Cards may be hot, due to high internal camera temperature. Set the power switch to <...
  • Page 55 Caution When the access lamp is lit or blinking, it indicates that images are being written to, read from, or erased from the card, or data is being transferred. Do not open the card/battery compartment cover. To avoid corrupting image data or damaging cards or the camera, never do any of the following while the access lamp is lit or blinking.

  • Page 56: Using The Screen

    Using the Screen You can change the direction and angle of the screen. Flip out the screen. Rotate the screen. When the screen is out, you can tilt it up or down or rotate it to face the subject. Indicated angles are only approximate. Face it toward you.
  • Page 57 Caution Avoid forcing the screen into position as you rotate it, which puts undue pressure on the hinge. When a cable is connected to a camera terminal, the rotation angle range of the flipped-out screen will be limited. Note Keep the screen closed and facing the camera body when the camera is not in use. You can protect the screen.

  • Page 58: Turning On The Power

    Turning on the Power Setting the Display Language Setting the Date, Time, and Time Zone Connecting the Camera to a Smartphone Battery Level Indicator < > The camera turns on. < > The camera is turned off and does not function. Set the power switch to this position when not using the camera.

  • Page 59: Setting The Date, Time, And Time Zone

    Setting the Date, Time, and Time Zone Set the Date/Time/Zone if the [Date/Time/Zone] setting screen appears. Connecting the Camera to a Smartphone Instructions for connecting to a smartphone are displayed if you select [OK] when the setup screen appears (...

  • Page 60: Battery Level Indicator

    Battery Level Indicator When the power switch is set to < >, the battery level will be indicated. Battery level is sufficient. Battery level is low, but the camera can still be used. Battery will be exhausted soon (blinks). Charge the battery. Note Doing any of the following will exhaust the battery faster: •...

  • Page 61: Attaching And Detaching Rf/Rf-S Lenses

    Attaching and Detaching RF/RF-S Lenses Attaching a Lens Detaching a Lens Caution Do not look at the sun directly through any lens. Doing so may cause loss of vision. When attaching or detaching a lens, set the camera's power switch to < >.

  • Page 62: Attaching A Lens

    Attaching a Lens Remove the caps. Remove the rear lens cap (1) and body cap (2) by turning them as shown by the arrows. Attach the lens. Align the red mount index on the lens with the red mount index on the camera and turn the lens as shown by the arrow until it clicks into place.
  • Page 63 Set the focus mode to < >. < > stands for autofocus. < > stands for manual focus. Autofocus is disabled. For RF lenses without a focus mode switch Set [ : Focus mode] to [AF]. For RF lenses with a focus mode switch Set the lens focus mode switch to <...

  • Page 64: Detaching A Lens

    Detaching a Lens While pressing the lens release button, turn the lens as shown by the arrow. Turn the lens until it stops, then detach it. Attach the rear lens cap to the lens you removed.

  • Page 65: Attaching And Detaching Ef/Ef-S Lenses

    Attaching and Detaching EF/EF-S Lenses Attaching a Lens Detaching a Lens All EF and EF-S lenses can be used by attaching an optional Mount Adapter EF-EOS R. The camera cannot be used with EF-M lenses. Attaching a Lens Remove the caps. Remove the rear lens cap (1) and body cap (2) by turning them as shown by the arrows.
  • Page 66 Attach the lens to the adapter. Align the red or white mount index on the lens with the corresponding mount index on the adapter and turn the lens as shown by the arrow until it clicks into place. (3) Red index (4) White index Attach the adapter to the camera.
  • Page 67 Set the lens's focus mode switch to < >. < > stands for autofocus. < > stands for manual focus. Autofocus is disabled. Remove the front lens cap.
  • Page 68 Detaching a Lens While pressing the lens release button, turn the adapter as shown by the arrow. Turn the lens until it stops, then detach it. Detach the lens from the adapter. Hold down the lens release lever on the adapter and turn the lens counterclockwise.

  • Page 69: Multi-Function Shoe

    For details, refer to the accessory's Instruction Manual. Use of accessories not designed for a multi-function shoe requires Multi-Function Shoe Adapter AD-E1, sold separately. For details, refer to the Canon website (...
  • Page 70 Attaching the shoe cover After removing accessories from the multi-function shoe, reattach the shoe cover to protect the contacts from dust and water. Slide the shoe cover all the way in by pressing the part labeled (B) in the figure, as shown.

  • Page 71: Basic Operations

    Basic Operations Holding the Camera Zoom Lever Movie Shooting Button Shutter Button < > Main Dial < > Quick Control Dial < > Multi-Function Lock Button < > Info Button < > Control Ring < > 1/Stream/Movie-Photo Playback Toggle Button <...

  • Page 72: Holding The Camera

    Holding the Camera Viewing the screen as you shoot As you shoot, you can tilt the screen to adjust it. For details, see Using the Screen. (1) Normal angle (2) Low angle (3) High angle...

  • Page 73: Zoom Lever

    Zoom Lever You can zoom with the zoom lever when using a power zoom lens. The following operations are also available. • Digital zooming ( • Switching between menu tabs • Magnifying/reducing images during playback Note You can zoom faster or slower with power zoom lenses by pressing the lever more or less (...
  • Page 74 Movie Shooting Button Press the movie shooting button (A or B) to start recording a movie. Press it again to stop recording. Note Movie shooting button A functions as a shutter button in still photo shooting.
  • Page 75 Shutter Button The shutter button has two steps. You can press the shutter button halfway. Then you can further press the shutter button completely. Pressing halfway This activates autofocusing and the automatic exposure system that sets the shutter speed and aperture value. The exposure value (shutter speed and aperture value) is displayed on the screen for 8 sec.
  • Page 76 Note The camera will still pause before taking a picture if you press the shutter button completely without pressing it halfway first, or if you press the shutter button halfway and immediately press it completely. Even during menu display or image playback, you can return to shooting standby by pressing the shutter button halfway.
  • Page 77 < > Main Dial (1) After pressing a button, turn the < > dial. Press a button such as < >, then turn the < > dial. If you press the shutter button halfway, the camera will go back to shooting standby. Used for operations such as setting the ISO speed.
  • Page 78 < > Quick Control Dial (1) After pressing a button, turn the < > dial. Press a button such as <WB>, then turn the < > dial. If you press the shutter button halfway, the camera will go back to shooting standby. (2) Only turn the <...
  • Page 79 (3) After pressing a button, press the < >< >< >< > keys. Press < > or < >, then press the < >< >or < >< > keys to set menu or Quick Control features. Note The operations in (1) and (3) can be performed even when controls are locked with the Multi-function lock (...
  • Page 80 < > Multi-Function Lock Button Configuring [ : Multi function lock] ( ) and pressing the < > button prevents settings from being changed by accidentally touching the Main dial, Quick control dial, control ring, or touch-screen panel. Press the < >...

  • Page 81: Info Button

    < > Info Button Each press of the < > button changes the information shown.

  • Page 82: Control Ring

    < > Control Ring By default, exposure compensation can be set in Creative Zone modes by turning the control ring of RF lenses or mount adapters while pressing the shutter button halfway. Otherwise, you can assign a different function to the control ring by configuring [ ] in [ Customize dials/control ring] ( Caution : Focus/control ring] must be set when using lenses that have a combination...

  • Page 83: Toggle Button

    < > 1/Stream/Movie-Photo Playback Toggle Button Press during movie recording to access the streaming settings screen ( ). Press during playback to switch between movie and still photo playback.
  • Page 84 < / > 2/AF Start/Send Images to Smartphone Button Press during movie recording to activate autofocus (except in Basic Zone movie modes). Pressing this button in still photo shooting is equivalent to pressing the shutter button halfway (except in basic shooting). Press during playback to access the setting screen for sending images to a smartphone (...
  • Page 85 < > 3/Color Mode/Image Search Button Press during movie recording or still photo shooting to access the color mode selection screen ( ). Press during playback to display images found using the current search conditions.

  • Page 86: Menu Operations And Settings

    Menu Operations and Settings Creative Zone Menu Screen Basic Zone Menu Screen Menu Setting Procedure Dimmed Menu Items < > button Screen < > button < >Quick control dial/cross keys < > button < > Main dial...
  • Page 87 Creative Zone Menu Screen Main tabs Secondary tabs Secondary tab name Menu items : Shooting : Autofocus : Playback : Communication functions : Set-up (10) : Control customization (11) : Custom Functions (12) : My Menu (13) Menu settings...
  • Page 88 Basic Zone Menu Screen * In Basic Zone modes, some tabs and menu items are not displayed.

  • Page 89: Menu Setting Procedure

    Menu Setting Procedure Display the menu screen. Press the < > button to display the menu screen. Select a tab. Press the < > button to switch between main tabs (groups of functions). You can also switch tabs with the zoom lever. Turn the <...
  • Page 90 Select an option. Turn the < > dial to select an option. The current setting is indicated in blue. Set an option. Press < > to set it. Exit the setting. Press the < > button to return to shooting standby. Note The description of menu functions hereafter assumes that you have pressed the <...
  • Page 91 Dimmed Menu Items Ex: When [Digital zoom: On] is set Dimmed menu items cannot be set. The menu item is dimmed if another function setting is overriding it. You can see the overriding function by selecting the dimmed menu item and pressing <...

  • Page 92: Quick Control

    Quick Control You can directly and intuitively select and set the settings displayed. Press < > ( Select a setting item and set your preferred option. Movie recording Still photo shooting Turn the < > dial to select an option. Turn the <...
  • Page 93 Note You can select the position of the Quick Control screen as displayed in movie recording modes (...

  • Page 94: Touch-Screen Operation

    Touch-Screen Operation Tapping Dragging Shooting with the Touch Shutter Tapping Sample screen (Quick Control) Use your finger to tap (touch briefly and then remove your finger from) the screen. For example, when you tap [ ], the Quick Control screen appears. By tapping [ you can return to the preceding screen.
  • Page 95 Dragging Sample screen (Menu screen) Slide your finger while touching the screen.

  • Page 96: Shooting With The Touch Shutter

    Shooting with the Touch Shutter Just by tapping the screen, you can focus and take the picture automatically. Enable the Touch Shutter. Tap [ ] on the screen. Each time you tap the icon, it will toggle between [ ] and [ ] (Touch Shutter: Enable) The camera will focus on the spot you tap, then the picture will be taken.
  • Page 97 Tap the screen to shoot. Tap the face or subject on the screen. On the point you tap, the camera focuses (Touch AF) using your specified AF Area. When [ ] is set, the AF point turns green when focus is achieved, then the picture is taken automatically.

  • Page 98: Movie Recording Modes

    Movie Recording Modes This chapter describes how to use Basic and Creative zone movie modes on the Mode dial. In Basic Zone movie modes, simply press the shutter button to start recording, and all features will be set automatically. Basic Zone movie modes •...

  • Page 99: A+>: Fully Automatic Recording (Scene Intelligent Auto)

    <A+>: Fully Automatic Recording (Scene Intelligent Auto) Scene Icons The camera detects the type of scene and sets all settings accordingly. The detected scene type is indicated in the upper left of the screen. For icon details, see Scene Icons. Set the Mode dial to <...
  • Page 100 Record the movie. Press the movie shooting button (on the top or front) to start recording a movie. You can also start recording by tapping [ ] on the screen While the movie is being recorded, [ REC] (1) is displayed, the screen is outlined in red, and the tally lamp is lit.

  • Page 101: Scene Icons

    Scene Icons In < > recording mode, the camera detects the type of scene and configures all settings accordingly. The detected scene type is indicated in the upper left of the screen. For icon details, see Scene Icons.

  • Page 102: Scn>: Special Scene Recording

    <SCN>: Special Scene Recording • Smooth Skin Movie • Movie for Close-Up Demos • Movie IS Mode Selecting a shooting mode according to the subject and scene automatically sets the features that are suitable for shooting. * < > stands for Special Scene. Set the Mode dial to <...
  • Page 103 Select a shooting mode. • [ ]: Smooth skin movie • [ ]: Movie for close-up demos • [ ]: Movie IS mode...

  • Page 104: Smooth Skin Movie

    Smooth Skin Movie Image processing makes skin look smoother. On the Quick Control screen, you can set the level of the [Smooth skin effect] and [AF for close-up demos], etc. Shooting tips Focus on the face. Focus by moving closer to or farther from the subject's face, so that the AF point [ appears on it.

  • Page 105: Movie For Close-Up Demos

    Movie for Close-Up Demos Subjects near the camera can be given priority for focusing. This is useful for demonstrations, product reviews, or similar situations. Adjust the brightness or other settings on the Quick Control screen. Caution No AF points are displayed. Subjects cannot be selected manually.

  • Page 106: Movie Is Mode

    Movie IS Mode Enables movie recording with reduced camera shake. Adjust the brightness or other settings on the Quick Control screen. Note Control by the camera will ensure effective exposure tracking if brightness changes greatly between scenes, as when you switch between shooting people and scenery.

  • Page 107: Creative Zone Movie Modes

    Creative Zone movie modes • Movie Auto Exposure • Movie Shutter-Priority AE • Movie Aperture-Priority AE • Movie Manual Exposure • Slow/Fast Motion Recording • Custom Recording Modes Set the Mode dial to < > or < >. Tap the shooting mode icon.
  • Page 108 Select a shooting mode. < >: Advanced movies • [ ]: Movie auto exposure • [ ]: Movie shutter-priority AE • [ ]: Movie aperture-priority AE • [ ]: Movie manual exposure < >: Slow/fast motion recording • [ ]: S&F movie auto exposure •...

  • Page 109: Movie Auto Exposure

    Movie Auto Exposure Exposure is controlled automatically to suit the brightness. Focus on the subject. By default, [ : Movie Servo AF] is set to [Enable] so that the camera always keeps focusing ( By default, pressing the < > button focuses using your specified AF area.
  • Page 110 Record the movie. Press the movie shooting button (on the top or front) to start recording a movie. You can also start recording by tapping [ ] on the screen REC] (1) is displayed in the upper right while movie recording is in progress, and a red frame appears around the screen.

  • Page 111: Movie Shutter-Priority Ae

    Movie Shutter-Priority AE You can set your preferred shutter speed for movie recording. ISO speed and aperture values are set automatically to suit the brightness and obtain standard exposure. Set the shutter speed (1). Set it by looking at the screen as you turn the < >...

  • Page 112: Movie Aperture-Priority Ae

    Movie Aperture-Priority AE You can set your preferred aperture value for movie recording. ISO speed and shutter speed are set automatically to suit the brightness and obtain standard exposure. Set the aperture value (1). Set it by looking at the screen as you turn the < >...

  • Page 113: Movie Manual Exposure

    Movie Manual Exposure You can set your preferred shutter speed, aperture value, and ISO speed for movie recording. Set the shutter speed, aperture value, and ISO speed. Press the shutter button halfway and check the exposure level indicator. Turn the < >...
  • Page 114 Caution During movie recording, avoid changing the shutter speed, aperture value, or ISO speed, which may record changes in the exposure or create more noise at high ISO speeds. When recording a movie of a moving subject, a shutter speed of approx. 1/25 sec. to 1/125 sec.

  • Page 115: Slow/Fast Motion Recording

    Slow/Fast Motion Recording S&F Recording Mode Movies captured using slow or fast motion recording are played back in slow or fast motion. Sound is not recorded. Set the slow or fast motion speed (playback speed) in [ : Movie rec. size]. Select [ : Movie rec.
  • Page 116 Select a playback frame rate. • Turn the < > dial to switch tabs. • Use the < >< > keys to select an item. • Playback speed is shown in the upper right. Press < >. S&F Recording Mode ]: S&F movie auto exposure Exposure is controlled automatically to suit the brightness.

  • Page 117: Custom Recording Modes

    Custom Recording Modes You can record using the camera function settings assigned to [ : Custom shooting mode (C1-C3)] ( < >, < >, and < > on the Mode dial correspond to [C. shooting mode: C1], [C. shooting mode: C2], and [C. shooting mode: C3].

  • Page 118: Still Photo Shooting Mode

    Still Photo Shooting Mode This chapter describes how to use [Still photo mode] on the Mode dial. In Basic modes, simply compose the shot and press the shutter button, and all features will be set automatically. • Setting the Shooting Mode Advanced shooting •...

  • Page 119: Setting The Shooting Mode

    Setting the Shooting Mode Set the Mode dial to < >. Tap the shooting mode icon.
  • Page 120 Select a shooting mode. (1) Creative Zone Set your preferred exposure or other settings for the subject or scene. • [P]: Program AE • [Tv]: Shutter-priority AE • [Av]: Aperture-priority AE • [M]: Manual exposure • [B]: Bulb exposure (2) Basic Zone The camera sets everything to suit the subject or scene.

  • Page 121: P: Program Ae

    P: Program AE The camera automatically sets the shutter speed and aperture value to suit subject brightness. * [P] stands for Program. * AE stands for Auto Exposure. Focus on the subject. The shutter speed and aperture value are set automatically. Check the display and shoot.
  • Page 122 Note Differences between [P] and [ ] modes ] mode limits available functions and sets the AF area, metering mode, and many other functions automatically. [P] mode only sets the shutter speed and aperture value automatically, and you can freely set the AF area, metering mode, and other functions.

  • Page 123: Tv: Shutter-Priority Ae

    Tv: Shutter-Priority AE In this mode, you set the shutter speed and the camera automatically sets the aperture value to obtain the standard exposure matching the brightness of the subject. A faster shutter speed can freeze the action of a moving subject. A slower shutter speed can create a blurred effect, giving the impression of motion.
  • Page 124 Check the display and shoot. As long as the aperture value is not blinking, the standard exposure will be obtained. Caution If the lowest aperture value blinks, it indicates underexposure. Turn the < > dial to set a slower shutter speed until the aperture value stops blinking or set a higher ISO speed.

  • Page 125: Av: Aperture-Priority Ae

    Av: Aperture-Priority AE Depth-of-Field Preview In this mode, you set the desired aperture value and the camera sets the shutter speed automatically to obtain the standard exposure matching the subject brightness. A higher f/ number (smaller aperture hole) will make more of the foreground and background fall within acceptable focus.
  • Page 126 Focus on the subject. Press the shutter button halfway. The shutter speed is set automatically. Check the display and shoot. As long as the shutter speed is not blinking, the standard exposure will be obtained. Caution If a slow shutter speed blinks, it indicates underexposure. Turn the < >...

  • Page 127: Depth-Of-Field Preview

    Note Aperture value display The higher the value, the smaller the aperture opening will be. The aperture value displayed varies depending on the lens. If no lens is attached to the camera, “F00” will be displayed for the aperture. Depth-of-Field Preview The aperture changes only at the moment you shoot, and it remains open at other times.

  • Page 128: M: Manual Exposure

    M: Manual Exposure Exposure Compensation with ISO Auto In this mode, you set both the shutter speed and aperture value as desired. To determine the exposure, refer to the exposure level indicator or use a commercially available exposure meter. * [M] stands for Manual. Set the ISO speed ( Press the <...
  • Page 129 Set the exposure and take the picture. Check the exposure level indicator and set the desired shutter speed and aperture value. Exposure Compensation with ISO Auto If the ISO speed is set to [AUTO] for manual exposure shooting, you can set exposure compensation ( ) as follows: Tap the exposure level indicator...

  • Page 130: Exposure Lock (Ae Lock)

    Exposure Lock (AE Lock) Effect of AE Lock You can lock the exposure when you want to set the focus and exposure separately or when you will take multiple shots at the same exposure setting. Lock the exposure by pressing the button assigned to AE lock, then recompose and take the picture.
  • Page 131 Note For details on assigning AE lock, see Customize Buttons for Shooting. AE lock is not possible with bulb exposures. Effect of AE Lock AF Point Selection Metering Mode Selection Automatic Selection Manual Selection Exposure centered on the AF point in Exposure centered on the selected AF focus is locked.

  • Page 132: B: Bulb Exposure

    B: Bulb Exposure In this mode, the shutter stays open as long as you hold down the shutter button completely, and closes when you let go of the shutter button. Use bulb exposures for night scenes, fireworks, astrophotography, and other subjects requiring long exposures. Set the desired aperture value.

  • Page 133: A+: Fully Automatic Shooting (Scene Intelligent Auto)

    A+: Fully Automatic Shooting (Scene Intelligent Auto) Shooting Moving Subjects Scene Icons Adjusting Settings Creative Assist In [ ] mode, the camera analyzes the scene and sets optimal settings automatically. Subject movement is also detected, so that the camera can keep subjects in focus ( Aim the camera at what you will shoot (the subject).
  • Page 134 Focus on the subject. Press the shutter button halfway to focus. You can also focus by tapping a person's face or other subject on the screen. Under low light, the AF-assist beam ( ) is automatically activated if needed. Once the subject is in focus, that AF point turns green and the camera beeps (One-Shot AF).
  • Page 135 Note AF operation (One-Shot AF or Servo AF) is set automatically when you press the shutter button halfway. Even when automatically set to One-Shot AF, the camera will switch to Servo AF if subject motion is detected while you are pressing the shutter button halfway.

  • Page 136: Shooting Moving Subjects

    Shooting Moving Subjects Pressing the shutter button halfway tracks moving subjects to keep them in focus. Keep the subject on the screen as you hold down the shutter button halfway, and at the decisive moment, press the shutter button completely.

  • Page 137: Scene Icons

    Scene Icons The camera detects the scene type and sets everything automatically to suit the scene. An icon representing the detected scene appears in the upper left of the screen (...

  • Page 138: Adjusting Settings

    Adjusting Settings By tapping icons on the screen, you can adjust settings for drive mode, image quality, Touch Shutter, and Creative Assist.
  • Page 139 Creative Assist You can shoot with your preferred effects applied. Press < >. Select an effect. Select an effect with the < > dial and press < >. Select the effect level and other details. Set with the < > dial and press < >.

  • Page 140: Saving Effects

    Creative Assist effects ] Preset Select one of the preset effects. Note that [Saturation], [Color tone 1], and [Color tone 2] are not available with [B&W]. ] Background blur Adjust background blur. Choose higher values to make backgrounds sharper. To blur the background, choose lower values.

  • Page 141: Self Portrait

    Self Portrait Shoot with settings optimized for shots of yourself. Rotate the screen around to face you. Shooting tips Set the brightness and smooth skin effect. [Brightness] and [Smooth skin effect] can be set in a range of five levels. In [Background], you can adjust the level of background blurring.

  • Page 142: Portrait

    Portrait Blurs the background to make the person you shoot stand out, while also softening skin tones and hair. Shooting tips Select the location where the distance between the subject and the background is the farthest. The further the distance between the subject and background, the more blurred the background will look.

  • Page 143: Smooth Skin

    Smooth Skin Image processing makes skin look smoother. Shooting tips Enable the camera to detect faces. When the camera detects the main subject to which the smooth skin effect will be applied, the frame is displayed on the subject's face. For more effective skin smoothing, you can move closer to or farther from the subject so that the frame is displayed on the subject's face.

  • Page 144: Panoramic Shot

    Panoramic Shot The panorama is created by combining shots captured in continuous shooting as you move the camera in one direction while pressing the shutter button completely. Choose a shooting direction. Tap [ ] in the lower right to choose the shooting direction. An arrow is displayed showing the direction to move the camera.
  • Page 145 > mode images, use a computer or other device to reduce panorama images if you will print them from a memory card inserted in a Canon printer. If panoramas are not compatible with certain software or online services, try resizing them on a computer.

  • Page 146: Food

    Food A good choice for culinary photography. Also reduces the reddish tinge from tungsten lights or similar light sources. Shooting tips Change the color tone. [Color tone] can be adjusted. After pressing < >, set toward [Warm tone] (red) to increase the reddish tinge of food, or set toward [Cool tone] (blue) to reduce an excessive red tinge.

  • Page 147: Handheld Night Scene

    Handheld Night Scene For handheld night shooting without a tripod or similar equipment. Shooting tips Hold the camera steady. Keep your elbows close to your body to hold the camera steady ( ). In this mode, four shots are aligned and merged into a single image, but if there is significant misalignment in any of the four shots due to camera shake, they may not align properly in the final image.

  • Page 148: Shooting And Recording

    Shooting and Recording This chapter describes shooting and recording and introduces menu settings on the shooting [ ] tab. To switch between movie recording and still photo shooting, use the Mode dial ( Caution After switching between movie recording and still photo shooting, check the camera settings again before shooting.
  • Page 149 • Reverse Display • Auto Power Off Temperature • Standby: Low Resolution • Display During HDMI Connection • Canon Log HDMI Output Range • General Movie Recording Still photo shooting • Still Photo Image Quality • Dual Pixel RAW •...
  • Page 150 • Dust Delete Data Acquisition • Focus Bracketing • Drive Mode • Interval Timer Shooting • Silent Shutter Function • Shutter Mode • Enabling Shutter Release Without a Card • Image Stabilizer (IS Mode) • Review Duration • High-Speed Display •...

  • Page 151: Tab Menus: Movie Recording

    Tab Menus: Movie Recording Information Display (Movie Recording) Shooting mode/Image quality/size Shooting mode Movie rec. size Movie rec. format Digital zoom Sound-rec. settings Sound recording Audio format Audio settings Audio Status...
  • Page 152 Exposure Exposure comp. ISO speed settings Av 1/8-stop incr. Auto slow shutter Detect priority AE while AF Color/tone/Dynamic range Color mode Clarity HDR shooting (PQ) Auto Lighting Optimizer Highlight tone priority...
  • Page 153 White balance/Quality correction White balance Custom White Balance WB correction Lens aberration correction High ISO speed NR Various shooting/Shutter control Time-lapse movie Cinema view Movie self-timer...
  • Page 154 Assist shooting Tally lamp IS (Image Stabilizer) mode Auto level Assist shooting Metadata Time code HDR/C.Log View Assist. False color set. Zebra settings...
  • Page 155 Assist shooting Shooting info. disp. Rotate shoot info disp Quick Ctrl screen Quick Control customization Reverse display Assist shooting/HDMI Auto pwr off temp. Standby: Low res. HDMI display HDMI output range for C. Log...
  • Page 156 Information Display (Movie Recording) For details on the icons on the movie recording screen, see Information Display. Caution The remaining time displayed for movie recording is only a guideline. Movie recording may stop before the initially displayed recording time elapses if the red [ ] icon appears due to high internal camera temperature during recording (...

  • Page 157: Tab Menus: Still Photo Shooting

    Tab Menus: Still Photo Shooting Shooting mode/Image quality/size Shooting mode Image quality Dual Pixel RAW Still img aspect ratio Digital tele-conv Exposure Exposure comp. ISO speed settings Anti-flicker shoot. External Speedlite control Metering mode Detect priority AE while AF...
  • Page 158 Color/tone/Dynamic range Color mode Clarity HDR shooting (PQ) HDR Mode Auto Lighting Optimizer Highlight tone priority White balance/Quality correction White balance Custom White Balance WB correction Lens aberration correction Long exp. noise reduction High ISO speed NR Dust Delete Data...

  • Page 159: Shutter Control

    Various shooting Focus bracketing Shutter control Drive mode Interval timer Silent shutter function Shutter mode Release shutter without card...
  • Page 160 Assist shooting IS (Image Stabilizer) mode Review duration High speed display Display simulation HDR/C.Log View Assist. Assist shooting Shooting info. disp. Quick Control customization Display frame rate setting Reverse display Auto pwr off temp. Note In [ ] mode, [Retain Creative Assist data] is displayed (...

  • Page 161: Movie Recording Size

    Movie Recording Size 4K Movie Recording Image Area Cards That Can Record Movies Movie Files Exceeding 4 GB Total Movie Recording Time and File Size Per Minute Movie Recording Time Limit You can set the resolution, frame rate, and compression method in [ : Movie rec.

  • Page 162: Compression Method

    Frame rate (fps: frames per second) ] 119.9 fps/[ ] 59.94 fps/[ ] 29.97 fps For areas where the TV system is NTSC (North America, Japan, South Korea, Mexico, etc.). ] 100.00 fps/[ ] 50.00 fps/[ ] 25.00 fps For areas where the TV system is PAL (Europe, Russia, China, Australia, etc.). ] 23.98 fps Mainly for cinematic purposes.

  • Page 163: Movie Recording

    4K Movie Recording Recording 4K movies requires a stable card with a fast writing speed. For details, see Cards That Can Record Movies. 4K movie recording greatly increases the processing load, which may increase the internal camera temperature faster or higher than for regular movies. If a white ] or red [ ] icon appears during movie recording, the card may be hot, so stop recording the movie and let the camera cool down before removing...

  • Page 164: Image Area

    Image Area For details on the image area at various resolutions, see the specifications ( Caution Recording with Movie digital IS ( ) crops the image around the center of the screen.
  • Page 165 Cards That Can Record Movies For details on cards that can record at each movie recording size, see Estimated recording time, video bit rate, file size, and card performance requirements. Test cards by recording a few movies to make sure they can record correctly at your specified size ( Caution Before recording 4K movies, format cards by selecting [Low level format] in [ :...
  • Page 166 Movie Files Exceeding 4 GB Individual movie files exceeding 4 GB cannot be recorded to SD cards. With SDHC cards, once the movie file size reaches 4 GB, a new movie file is created automatically. During playback, these files are automatically played consecutively. With SDXC cards, individual movies are recorded as a single file, even if they exceed 4 Caution When importing movie files exceeding 4 GB to a computer, use either EOS Utility...
  • Page 167 Total Movie Recording Time and File Size Per Minute Estimated recording time, movie bit rate, file size, and card performance requirements.

  • Page 168: High Frame Rate

    Movie Recording Time Limit For details on the maximum recording time per movie, see the specifications ( Recording stops automatically when the maximum time is reached. Caution The camera's internal temperature may rise and less recording time may be available after extended movie playback/Live View display. High Frame Rate High Frame Rate movie recording at 119.9/100.0 fps is available in [ ], [...

  • Page 169: Movie Recording Format

    Movie Recording Format XF-HEVC S and XF-AVC S Movies You can specify the format of movie files recorded. Select [ : Movie rec. format] ( Select an option.
  • Page 170 XF-HEVC S and XF-AVC S Movies XF-HEVC S and XF-AVC S movies are in original Canon video formats that are extensions of H.265/HEVC and MPEG-4 AVC/H.264, respectively. These formats maintain image quality while offering high data compression. Brightness, Movie Hue,...

  • Page 171: Still Photo Image Quality

    Still Photo Image Quality RAW Images Guide to Image Quality Settings Maximum Burst for Continuous Shooting You can select the pixel count and the image quality. JPEG/HEIF image quality options are as follows: . For RAW images, you can specify as the image quality.

  • Page 172: Raw Images

    RAW images captured by this camera. If a previous version of DPP Ver. 4.x is installed on your computer, obtain and install the latest version of DPP from the Canon website to update it ( ), which will overwrite the previous version.
  • Page 173 Guide to Image Quality Settings Still photo file size / Number of shots available / Maximum burst for continuous shooting for details on file size, number of shots available, maximum burst, and other estimated values.
  • Page 174 Maximum Burst for Continuous Shooting The estimated maximum burst is shown on the upper left of the shooting screen. Note If the maximum burst is displayed as “99”, it indicates that you can shoot 99 or more shots continuously. Fewer shots are available for a value of 98 or lower, and when [BUSY] is displayed on the screen, internal memory is full and shooting will stop temporarily.

  • Page 175: Dual Pixel Raw

    Dual Pixel RAW Shooting images with this feature enabled produces special Dual Pixel RAW images containing dual pixel information from the image sensor. This is called Dual Pixel RAW shooting. When processing these images in Digital Photo Professional software for EOS cameras, you can take advantage of the dual pixel data to fine-tune apparent resolution (using depth information), shift the camera viewpoint slightly, and reduce ghosting.
  • Page 176 Caution Startup takes longer when the power switch is set to <ON> or the camera resumes operation from auto power off. Continuous shooting speed is slower when you shoot with Dual Pixel RAW ( Maximum burst is also lower. ] and [ ] drive modes are not available.

  • Page 177: Still Image Aspect Ratio

    Still Image Aspect Ratio You can change the image's aspect ratio. Select [ : Still img aspect ratio] ( Set the aspect ratio. Select an aspect ratio. JPEG images The images will be recorded with the set aspect ratio. RAW Images The images will always be recorded in the [3:2] aspect ratio.

  • Page 178: Digital Zoom

    Digital Zoom With the recording size set to [ ] (NTSC) or [ ] (PAL), you can shoot with approx. 1–10× digital zoom. Select [ : Digital zoom] ( Select an option. Select [Enable], then press < >. Press the < >...
  • Page 179 Caution Using a tripod to prevent camera shake is recommended. Maximum ISO speed is ISO 12800. A magnified view is not available. Since Movie digital zoom processes the image digitally, the image will look grainier at higher magnifications. Noise, dots of light, etc. may also become noticeable. Also see “Shooting Conditions That Make Focusing Difficult”...

  • Page 180: Digital Tele-Converter

    Digital Tele-Converter Shooting magnification can be increased beyond lens magnification by enlarging the center of the image area. Select [ : Digital tele-conv] ( Select a shooting magnification. Shooting magnification is not adjusted when [Off] is selected. Caution Higher shooting magnification results in lower image quality. Not available when RAW image quality is selected.

  • Page 181: Sound Recording

    Sound Recording Sound Recording Audio Format Audio Settings Recording Mode Recording Level Wind Filter Audio Noise Reduction Attenuator Microphone Directionality Audio Status Sound Recording Select [On] for sound recording during movie recording. The built-in microphone is used for recording unless you use microphones that are external or designed for the multi-function shoe.
  • Page 182 Select an option. Set the recording level and other settings as needed in [ : Audio settings] ( Caution Microphones may pick up sounds from Wi-Fi operations. For best results, avoid using wireless features when recording. Make sure any output plugs of external microphones are fully inserted in the camera.
  • Page 183 Four-channel recording The camera supports four-channel sound recording. Four-channel recording can include combinations of the following sources. Microphone designed for a multi-function shoe (2 channels) + built-in microphone (2 channels) Microphone designed for a multi-function shoe (2 channels) + external microphone (2 channels) External microphone (2 channels) + external microphone (2 channels) Built-in microphone (2 channels) + built-in microphone (2 channels)

  • Page 184: Audio Format

    Audio Format You can choose the audio format used for sound in movie recording. Select [ : Audio format] ( Select an option. Caution Selecting [LPCM/24bit/4CH] enables four-channel sound recording (with multiple microphones). Selecting [AAC/16bit/2CH] restricts recording to two channels (with a single microphone).

  • Page 185: Audio Settings

    Audio Settings Configure microphones for sound recording in these settings. When using microphones that are external or designed for a multi-function shoe, also refer to the microphone instruction manual. Select [ : Audio settings] ( Select the device to use. Built-in microphone For configuring settings for the built-in microphone.
  • Page 186 Set the item. When set to [Built-in microphone] When set to [External microphone] When set to [Hot shoe input] Available setting items vary depending on the microphone used. Caution Sound recording is momentarily paused to reduce noise when [Recording mode], [Rec.

  • Page 187: Recording Mode

    Recording Mode Auto The sound-recording level is adjusted automatically. Auto level control will take effect automatically in response to the sound level. Manual You can adjust the sound-recording level as needed. Adjust the level in [Rec. level]. Caution Do not change the [Recording mode] settings when listening with headphones. This may cause sudden loud output that may hurt your ears.

  • Page 188: Recording Level

    Recording Level Available when [Recording mode] is set to [Manual]. To adjust the sound-recording level, turn the < > dial while watching the level meter. Look at the peak hold indicator, and adjust so that the level meter sometimes lights up on the right of the “12”...

  • Page 189: Wind Filter

    Wind Filter Available when using the built-in microphone or multi-function shoe microphones that are compatible with wind filters. Set to [Auto] to reduce audio distortion in windy outdoor scenes. When the wind filter function takes effect, part of the low bass sounds will also be reduced.
  • Page 190 Audio Noise Reduction When recording with the built-in microphone, this feature reduces mechanical lens sounds caused by autofocusing, as well as white noise. Disable Disables audio noise reduction. Enable Enables audio noise reduction. High Reduces audio noise more than with [Enable]. Caution Audio quality may be different when set to [Enable] than when set to [Disable].
  • Page 191 Attenuator As a function that suppresses sound distortion caused by loud noises during recording, the attenuator can be enabled or disabled when using microphones designed for a multi- function shoe. For details, refer to the microphone instruction manual.

  • Page 192: Microphone Directionality

    Microphone Directionality Available when using multi-function shoe microphones for which directivity can be switched. For details, refer to the microphone instruction manual.

  • Page 193: Audio Status

    Audio Status Indicates audio status such as the active microphone and the headphone volume. Select [ : Audio Status] ( Check the details as needed. Note [Monitor CH] indicates channels set in [Shoot. monitor CH] for [Headphones] in [ : Audio monitor].

  • Page 194: Exposure Compensation

    Exposure Compensation You can set exposure compensation toward the positive or negative side to brighten or darken images relative to the standard exposure determined by the camera. Exposure compensation is available in these shooting modes. Movie recording: [ Still photo shooting: [P] [Tv] [Av] [M] To adjust exposure compensation when using Live View, press the shutter button halfway and turn the <...

  • Page 195: Movie Iso Speed Settings

    Movie ISO Speed Settings Max for Auto Max for Auto In [ ] or [ ] mode, you can set the ISO speed manually. You can also select ISO Auto. Tap the ISO speed display. Set the ISO speed. Turn the < >...
  • Page 196 ISO speed guide Low ISO speeds reduce image noise but may increase the risk of camera shake and subject blur or reduce the area in focus (shallower depth of field), in some shooting conditions. High ISO speeds enable low-light shooting, a larger area in focus (deeper depth of field), and longer flash range but may increase image noise.
  • Page 197 Select the ISO speed. Select the ISO speed, then press < >. Max for Auto You can set the maximum limit for ISO Auto in 4K time-lapse/Full HD time-lapse movie recording in [ ], [ ], or [ ] mode or in [ ] mode with ISO Auto.
  • Page 198 Select the ISO speed. Select the ISO speed, then press < >.

  • Page 199: Still Photo Iso Speed Settings

    Still Photo ISO Speed Settings Maximum [AUTO] ISO Speed Set the ISO speed to suit the ambient light level. In Basic Zone modes, ISO speed is set automatically. Tap the ISO speed display. Set the ISO speed. Turn the < >...
  • Page 200 High ISO speeds enable low-light shooting, a larger area in focus (deeper depth of field), and longer flash range but may increase image noise. Note Can also be set on the [ISO speed] screen in [ ISO speed settings]. Caution Image noise (such as graininess, dots of light, or banding), irregular colors, or color shift may be noticeable at high ISO speeds, in high temperatures, or with long exposures.
  • Page 201 Maximum [AUTO] ISO Speed For ISO [AUTO], you can set the maximum ISO speed limit. Select [ ISO speed settings] ( Select [Max for Auto]. Select [Max for Auto], then press < >. Select the ISO speed. Select the ISO speed, then press < >.

  • Page 202: Movie Av In 1/8-Stop Increments

    Movie Av in 1/8-Stop Increments Aperture values can be set in 1/8-stop increments for movie recording with RF lenses. Available in [ ], [ ], [ ], or [ ] recording mode. Select [ Av 1/8-stop incr.] ( Select an option.

  • Page 203: Movie Auto Slow Shutter

    Movie Auto Slow Shutter You can choose whether to record movies that are brighter and less affected by image noise than when set to [Disable] by automatically slowing the shutter speed under low light. Available in [ ] or [ ] recording mode.

  • Page 204: Anti-Flicker Shooting

    Anti-Flicker Shooting Uneven exposure and color may appear in continuous shooting at fast shutter speeds under flickering light sources such as fluorescent lights, due to uneven vertical exposure. Anti- flicker shooting enables you to take pictures when exposure and colors are less affected by flickering.
  • Page 205 Caution When [Enable] is set and you shoot under a flickering light source, the shutter- release time lag may become longer. Also, the continuous shooting speed may become slower, and the shooting interval may become irregular. Flicker at a frequency other than 100 Hz or 120 Hz cannot be detected. Also, if the flickering frequency of the light source changes during continuous shooting, effects of the flicker cannot be reduced.

  • Page 206: Metering Mode

    Metering Mode Four methods (metering modes) to measure the subject's brightness are provided. Normally, evaluative metering is recommended. In Basic Zone modes, evaluative metering is set automatically. Select [ : Metering mode] ( Select an option. : Evaluative metering General-purpose metering mode suited even for backlit subjects. The camera adjusts the exposure automatically to suit the scene.

  • Page 207: Ae For Priority Subjects During Af

    AE for Priority Subjects During AF Performs metering for subjects detected based on the [ : Subject to detect] setting. Select [ : Detect priority AE while AF] ( Select an option. [Enable]: Metering is based on the AF point or AF area where the subject was detected.

  • Page 208: Color Mode

    Color Mode Picture Style Color Filter Custom Picture You can set your preferred movie or still photo image characteristics from the Picture Style, Color Filter, or Custom Picture menu. Select [ : Color mode] ( Select an option. Select [INFO] to access the corresponding menu. Picture Style By selecting a preset Picture Style, you can obtain effective image characteristics.
  • Page 209 Picture Style Characteristics Auto The color tone will be adjusted automatically to suit the scene. The colors will look vivid for blue skies, greenery and sunsets, particularly in nature, outdoor, and sunset scenes. Note If the desired color tone is not obtained with [Auto], use another Picture Style. Standard The image looks vivid, sharp, and crisp.
  • Page 210 Symbols Icons on the Picture Style selection screen represent [Strength], [Fineness], and [Threshold] for [Sharpness] as well as [Contrast] and other parameters. The numbers indicate the values for these settings specified for the respective Picture Style. Sharpness Strength Fineness Threshold Contrast Saturation Color tone...
  • Page 211 Picture Style Customization You can customize any Picture Style by changing it from the default settings. For details on customizing [Monochrome], see Monochrome Adjustment. Select [ : Color mode] ( Select [Picture Style]. Select a Picture Style, then press the <INFO> button. Select a Picture Style.
  • Page 212 Select an option. Select an option, then press < >. For details on settings and effects, see Settings and Effects. Set the effect level. Adjust the effect level, then press < >. Press the < > button to save the adjusted setting and return to the Picture Style selection screen.
  • Page 213 Note For movie recording, [Fineness] and [Threshold] for [Sharpness] cannot be set (not displayed). By selecting [Default set.] in step 3, you can restore the parameter settings of the respective Picture Style to the defaults. To shoot with the Picture Style you adjusted, first select the adjusted Picture Style, then shoot.
  • Page 214 Filter Sample Effects N:None Normal black-and-white image with no filter effects. Ye:Yellow Blue sky will look more natural, and white clouds will look crisper. Or:Orange The blue sky will look slightly darker. The sunset will look more brilliant. R:Red The blue sky will look quite dark. Fall leaves will look crisper and brighter. Skin tones and lips will appear muted.
  • Page 215 Select [Picture Style]. Select a Picture Style, then press the <INFO> button. Select [User Def. *]. Select [User Def. *], then press the <INFO> button. Press < >. With [Picture Style] selected, press < >.
  • Page 216 Select a base Picture Style. Select the base Picture Style, then press < >. Select an option. Select an option, then press < >.
  • Page 217 Set the effect level. Adjust the effect level, then press < >. For details, see Picture Style Customization. Press the < > button to save the adjusted setting and return to the Picture Style selection screen. The base Picture Style will be indicated on the right of [User Def. *]. Blue style names in [User Def.

  • Page 218: Color Filter

    Color Filter You can add effects to images by selecting preset filters. Select [ : Color mode] ( Select [Color filter]. Select a color filter.
  • Page 219 Filter Effect Recommended Scenes Matte with teal shadows and StoryTeal&Orange amber highlights High-contrast daytime scenes and other Matte with a magenta filter effect scenes with contrast, such as well-lit StoryMagenta overall rooms Matte with a blue filter effect StoryBlue overall Teal shadows and amber Scenes with contrast that include some PaleTeal&Orange...
  • Page 220 Custom Picture Custom picture files on the camera enable you to adjust color tones in movie recording by applying a combination of settings (gamma/color space, color matrix, and look files), mainly in preparation for post-production processing. You can select a custom picture file to record movies with your preferred image characteristics.

  • Page 221: Selecting Custom Picture Files

    Selecting custom picture files Select [ : Color mode] ( Select [Custom Picture]. Select [Custom Picture], then press the <INFO> button. Select [Select File].
  • Page 222 C1: Canon Canon 709 / Suitable for display on BT.709 Neutral BT.709 compliant-monitors Also suitable without post- processing Uses Canon Log 3 gamma; post- C2: Canon Canon Log 3 / processing required Neutral Log 3 C.Gamut Retains Canon Log characteristics...
  • Page 223 Editing custom pictures You can edit settings of the selected custom picture file. Select [ : Color mode] ( Select [Custom Picture]. Select [Custom Picture], then press the <INFO> button. Select [Edit File]. To edit a protected ([ ]) custom picture file, select [Unprotect] by [Protect] to enable editing.
  • Page 224 Edit the settings as needed. Select a setting to edit, then adjust it on the screen displayed ( To save an edited custom picture file with a new name, select [Rename] and enter a name. To reset editing, select [Reset], then select the custom picture file to reset.
  • Page 225 Gamma with a wide dynamic range that is also Canon 709 suitable without post-processing Suitable for viewing on BT.709 compliant-monitors Color space developed by Canon based on image sensor characteristics, covering a wider color C.Gamut gamut than that of BT.2020...
  • Page 226 Color equivalent to “traditional color” in ITU-R Vivid BT.2390 Black Black level adjustment Not available with [Gamma/Color Space] set to [Canon Log 3] Increases or decreases the black level. Higher Master –50 to +50 values brighten dark image areas but decrease Pedestal contrast.
  • Page 227 Black Gamma Lower gamma curve correction, for dark image areas Raises or lowers the black part of the gamma curve in the following ranges Available with [Gamma/Color Space] set to [BT.709 Standard] (1) Output (2) Input (3) Point (4) Level (5) Range Level –50 to +50...
  • Page 228 Knee Compression of bright image areas to prevent clipped highlights Available with [Gamma/Color Space] set to [BT.709 Standard] (1) Output (2) Input Slope Point Adjustment with each setting is enabled when set Activate On, Off to [On] Slope –35 to +50 Adjusts the slope above the knee point Point 50 to 109...
  • Page 229 Sharpness Sharpness adjustment Increases or decreases the level of edge Level –10 to +50 sharpness Sets the center frequency for edge enhancement Detail –8 to +8 Higher values increase the frequency, sharpening Frequency images Sets the contrast threshold between edges and surrounding image areas, which determines edge Coring –30 to +50...
  • Page 230 Color Correction Settings to correct image areas with certain color characteristics Areas for correction are detected accordingly With the settings configured, areas not detected are displayed in neutral colors (except when adjusting [Area A Revision Level], [Area B Revision Level], [Area A Revision Phase], and [Area B Revision Phase]) Specifies areas (A or B) for color correction Area A is corrected when set to [Area A] Select Area...
  • Page 231 Checking custom picture settings You can review custom picture file settings from the [Custom Picture] menu. Select [ : Color mode] ( Select [Custom Picture]. Select [Custom Picture], then press the <INFO> button. On the [Custom Picture] screen, select [Status]. Check the settings.
  • Page 232 Saving and loading custom picture files Edited custom picture files can be saved to a card and used with other cameras of the same model. Select a custom picture file to save ( On the [Custom Picture] screen, select [Save File].
  • Page 233 Using look files You can register 17- or 33-grid 3D LUT files in .cube format from the Blackmagic Design application DaVinci Resolve as look files in custom picture files to adjust the color tone of movies you record.
  • Page 234 Registering look files Before you begin, the look file to register should be copied to a card. Load the card in the camera. Select a custom picture file ( Select [Edit File]. To edit a protected ([ ]) custom picture file, select [Unprotect] by [Protect] to enable editing.
  • Page 235 Select [Register]. Look files on the card are listed. Select a look file. After applying the look file, select the gamma/color space. Select [OK]. Caution The following look files are not compatible. • Input range outside a range of 0–1 in the header (“LUT_3D_INPUT_RANGE”) •...
  • Page 236 Using look files for color adjustment You can use registered look files for color adjustment. On the [Edit File] screen, select [Look File]. Select [On]. To disable color adjustment based on look files, select [Off]. Removing look files Select a custom picture file ( Select [Edit File].
  • Page 237 Select [OK]. Canon Log image quality With Canon Log, skies, white walls, and similar subjects may be affected by noise or uneven gradation, exposure, or colors, depending on the subject or shooting conditions. Banding or noise may also be noticeable in dark image areas.

  • Page 238: Clarity

    Clarity You can adjust image clarity, as determined by the contrast of image edges. Set toward the negative end to make images look softer or toward the positive end for a sharper appearance. Select [ : Clarity] ( Set the effect level. Caution Setting clarity may darken or lighten the areas around boundaries in high-contrast images.

  • Page 239: Hdr Shooting (Pq)

    HDR Shooting (PQ) HDR shooting (PQ)] enables you to capture HDR images conforming to the PQ specification (referring to the input signal gamma curve for HDR image display) defined in ITU-R BT.2100 and SMPTE ST.2084. Note Captured as HEIF or RAW images. For optimal viewing, use an HDR display device.

  • Page 240: Hdr Mode

    HDR Mode You can shoot still photos with clipped highlights and shadows reduced for a high dynamic range of tones even in high-contrast scenes. HDR shooting is effective for landscape and still-life shots. HDR shooting enhances gradation in dark image areas by merging three images deliberately captured at different exposures (standard, underexposed, and overexposed) to produce an HDR image that compensates for loss of detail in dark image areas.
  • Page 241 Set [Limit max brightness] (only with [ HDR shooting (PQ)] set to [HDR PQ]). With [Disable], maximum brightness is not limited. Recommended when you will review images on a monitor supporting display at brightnesses exceeding 1000 nits. With [1000 nits], maximum brightness is limited to approx. 1000 nits. Set [Continuous HDR].
  • Page 242 Set [Auto Image Align]. For handheld shooting, select [Enable]. When using a tripod, select [Disable]. Take the picture. When you press the shutter button completely, three consecutive images will be captured, and the HDR image will be recorded to the card.
  • Page 243 Caution Expanded ISO speeds (H) are not available in HDR shooting. The flash will not fire during HDR shooting. RAW image quality cannot be set. In HDR shooting, three images are captured with settings such as shutter speed automatically adjusted. For this reason, even in [Tv] or [M] mode, the shutter speed and ISO speed will change, relative to your specified speed.

  • Page 244: Auto Lighting Optimizer

    Auto Lighting Optimizer Brightness and contrast can be corrected automatically if shots look dark or contrast is too low or high. Select [ : Auto Lighting Optimizer] ( Set a correction option. Caution Noise may increase and apparent resolution may change, under some shooting conditions.

  • Page 245: Highlight Tone Priority

    Highlight Tone Priority You can reduce overexposed, clipped highlights. Select [ : Highlight tone priority] ( Set an option. [Enable]: Improves gradation in highlights. The gradation between the grays and highlights becomes smoother. [Enhanced]: Reduces overexposed highlights even more than [Enable], under some shooting conditions.

  • Page 246: White Balance

    White Balance White Balance ] Auto White Balance ] Custom White Balance ] Color Temperature White balance (WB) is for making the white areas look white. Normally, the Auto [ (Ambience priority) or [ ] (White priority) setting will obtain the correct white balance. If natural-looking colors cannot be obtained with Auto, you can select the white balance to match the light source or set it manually by shooting a white object.
  • Page 247 (Approx.) Display Mode Color Temperature (K: Kelvin) Auto (Ambience priority) 3000–7000 Auto (White priority) Daylight 5200 Shade 7000 Cloudy, twilight, sunset 6000 Tungsten light 3200 White fluorescent light 4000 When using Flash Automatically set* Custom 2000–10000 Color temperature 2500–10000 * Applicable with Speedlites having a color temperature transmission function. Otherwise, it will be fixed to approx.
  • Page 248 White Balance The human eye adapts to changes in lighting so that white objects look white under all kinds of lighting. Cameras determine white from the color temperature of lighting and, based on this, apply image processing to make color tones look natural in your shots.

  • Page 249: Auto White Balance

    ] Auto White Balance With [ ] (Ambience priority), you can slightly increase the intensity of the image's warm color cast when shooting a tungsten-light scene. If you select [ ] (White priority), you can reduce the intensity of the image's warm color cast.

  • Page 250: Custom White Balance

    ] Custom White Balance With custom white balance, you can manually set the white balance for the specific light source of the shooting location. Make sure to perform this procedure under the light source at the actual location of the shoot. Registration from an image on a card Shoot a white object.
  • Page 251 Import the white balance data. Use the < >< > keys to select the image captured in step 1, then press < >. Select [OK] to import the data. Select [ : White balance] ( Select [...
  • Page 252 Shooting and registering white balances Press < >. Select a white balance setting. Press the < >< > keys for selection. Select [Shoot to set WB]. Turn the < > dial to select [ ], then press the < > button.
  • Page 253 Shoot a white object. Aim the camera at a plain white object, so that white fills the screen. Set the camera to manual focus ( ) and shoot so that the white object has standard exposure. The custom white balance is registered to the camera. Caution Correct white balance may not be obtained if the exposure of your image differs greatly from standard exposure.

  • Page 254: Color Temperature

    ] Color Temperature A value can be set representing the white balance color temperature. Select [ : White balance] ( Select a color temperature. Set the color temperature. Turn the < > dial to set a color temperature, then press < >.

  • Page 255: White Balance Correction

    White Balance Correction White Balance Correction You can correct the white balance that is set. This adjustment will have the same effect as using a commercially available color temperature conversion filter or color compensating filter. White Balance Correction Select [ : WB correction] (...
  • Page 256 Set the white balance correction. Sample setting: A2, G1 Press the < > keys to move the [■] mark on the screen to your preferred position. B is for blue, A for amber, M for magenta, and G for green. White balance is corrected in the direction you move the mark.

  • Page 257: Lens Aberration Correction

    Lens Aberration Correction Peripheral Illumination Correction Distortion Correction Focus Breathing Correction Digital Lens Optimizer Chromatic Aberration Correction Diffraction Correction Vignetting, image distortion, and other issues may be caused by lens optical characteristics. The camera can compensate for these phenomena by using [Lens aberration correction]. Select [ : Lens aberration correction] ( Select an option.

  • Page 258: Peripheral Illumination Correction

    Select a setting. Confirm that the name of the attached lens and [Correction data available] are displayed. If [Correction data not available] or [ ] is displayed, see Digital Lens Optimizer. Peripheral Illumination Correction Vignetting (dark image corners) can be corrected. Caution Depending on shooting conditions, noise may appear on the image periphery.

  • Page 259: Distortion Correction

    Distortion Correction Distortion (image warping) can be corrected. Caution Specifying distortion correction may subtly change the angle of view, resulting in images that are cropped a little and seem slightly less sharp. The amount of image cropped may vary between still photos and movies. Note With RF lenses, distortion correction during movie recording is supported.
  • Page 260 Movies with abrupt changes to the angle of view may be recorded if you move the focusing distance range switch during recording. Correction artifacts may occur, depending on the lens and shooting conditions. For details on lenses compatible with this feature, visit the Canon website (...
  • Page 261 Digital Lens Optimizer Various aberrations from lens optical characteristics can be corrected, along with diffraction and low-pass filter-induced loss of resolution. If [Correction data not available] or [ ] is displayed by [Digital Lens Optimizer], you can use EOS Utility to add the lens correction data to the camera. For details, refer to the EOS Utility Instruction Manual.

  • Page 262: Chromatic Aberration Correction

    Chromatic Aberration Correction Chromatic aberration (color fringing around subjects) can be corrected. Note [Chromatic aberr corr] is not displayed when [Digital Lens Optimizer] is set to [Standard] or [High].
  • Page 263 General precautions for lens aberration correction Lens aberration correction cannot be applied to existing JPEG/HEIF images. When using a non-Canon lens, setting the corrections to [Disable] is recommended even if [Correction data available] is displayed. Magnifying the periphery of the image may display parts of the image that will not be recorded.
  • Page 264 Note General notes for lens aberration correction Effects of lens aberration correction vary by lens and shooting conditions. Also, the effect may be difficult to discern depending on the lens used, shooting conditions, etc. If the correction is difficult to discern, magnifying and checking the image after shooting is recommended.

  • Page 265: Long Exposure Noise Reduction

    Long Exposure Noise Reduction Noise such as dots of light or banding that tends to occur in long exposures at shutter speeds of one sec. or slower can be reduced. Select [ : Long exp. noise reduction] ( Set a reduction option. Auto For images exposed for 1 sec.

  • Page 266: High Iso Speed Noise Reduction

    High ISO Speed Noise Reduction You can reduce the image noise generated. This function is especially effective when shooting at high ISO speeds. When shooting at low ISO speeds, the noise in the darker parts of the image (shadow areas) can further be reduced. Select [ : High ISO speed NR] ( Set the level.

  • Page 267: Dust Delete Data Acquisition

    Dust Delete Data Acquisition Preparation Dust Delete Data Appending Dust Delete Data used to erase dust spots can be appended to images. The Dust Delete Data is used by Digital Photo Professional (EOS software) to erase the dust spots automatically. Preparation Use an RF or EF lens.
  • Page 268 Shoot a plain white object. Shoot with a plain white object (such as a new sheet of white paper) filling the screen, at a distance of 20–30 cm (0.7–1.0 ft.). Since the image will not be saved, the data can still be obtained even if there is no card in the camera.
  • Page 269 Dust Delete Data Appending The camera will append the Dust Delete Data obtained to all shots from now on. Acquiring Dust Delete Data before shooting is recommended. For details about using Digital Photo Professional (EOS software) to erase dust spots automatically, refer to the Digital Photo Professional Instruction Manual.

  • Page 270: Time-Lapse Movies

    Time-Lapse Movies Still photos captured at your specified interval can be automatically combined to create a time-lapse movie. A time-lapse movie shows how a subject changes in a much shorter period of time than the actual time it took. It is effective for a fixed-point observation of changing scenery, growing plants, celestial motion, etc.
  • Page 271 Set the shooting interval. Refer to [ : Time required] (1) and [ : Playback time] (2) as you set it. Press < > to set < >. Use the < >< > keys to set a value, then press < >.
  • Page 272 Set the number of shots. Refer to [ : Time required] and [ : Playback time] as you set the number. Select the digit. Press < > to set < >. Use the < >< > keys to set a value, then press < >.
  • Page 273 Set [Auto exposure]. Fixed 1st frame When taking the first shot, metering is performed to set the exposure automatically to match the brightness. The exposure setting for the first shot will be applied to subsequent shots. Other shooting-related settings for the first shot will also be applied for subsequent shots. Each frame Metering is also performed for each subsequent shot to set the exposure automatically to match the brightness.
  • Page 274 Set [Screen auto off]. Disable Even during time-lapse movie recording, the image will be displayed. (The screen turns off only at the time of shooting.) Note that the screen will turn off when approx. 30 min. elapse after the shooting started. Enable The screen will turn off when approx.
  • Page 275 Set [Beep per taken]. Set to [0] to prevent the camera from beeping for each shot. Check the settings. Time required (1) Indicates the time required to shoot the set number of shots with the set interval. If it exceeds 24 hours, “*** days” will be displayed. Playback time (2) Indicates the movie recording time (equivalent to the time required for playback).
  • Page 276 Take a test shot. Press the < > button and double-check the Time required (1) and Interval (2) shown on the screen. As in still photo shooting, set the exposure and shooting functions, then press the < > button to focus. Press the movie shooting button to take a test shot, which is recorded to the card as a still photo.
  • Page 277 Note Test shots are captured in JPEG quality. You can set the maximum limit for Auto ISO in [ ], [ ], and ] mode or in [ ] mode with ISO Auto, in the [ Max for Auto] option of [ ISO speed settings] ( If you have set [Half-press] in [ : Shutter btn function for...
  • Page 278 Record the time-lapse movie. Press the shutter button completely to start recording the time- lapse movie. AF will not work during time-lapse movie recording. A recording icon “●” is displayed on the screen as the time-lapse movie is recorded. When the set number of shots are taken, the time-lapse movie recording ends.
  • Page 279 Caution Do not point the camera toward an intense light source, such as the sun or an intense artificial light source. Doing so may damage the image sensor or the camera's internal components. Time-lapse movies cannot be recorded when the camera is connected to a computer with the interface cable, or when an HDMI cable is connected.
  • Page 280 Set [ : Time-lapse movie] to [Disable] if you will connect the camera to a computer with the interface cable and use EOS Utility (EOS software). Options other than [Disable] will prevent the camera from communicating with the computer. Image stabilization is not applied in time-lapse movie recording. Time-lapse movie shooting ends if the power switch is set to <...

  • Page 281: Cinema View

    Cinema View You can record movies with a cinematic angle of view and frame rate. Select [ : Cinema view] ( Select [On]. Movies are recorded with a 2.35:1 CinemaScope angle of view. During recording, black bars are displayed on the top and bottom of the screen, which is 16:9.

  • Page 282: Movie Self-Timer

    Movie Self-Timer Movie recording can be started by the self-timer. Select [ : Movie self-timer] ( Select an option. Record the movie. After you press the movie shooting button or tap [ ], the camera beeps and displays the number of seconds left before recording. Note To cancel the self-timer, either tap the screen or press <...

  • Page 283: Focus Bracketing

    Focus Bracketing Focus bracketing enables continuous shooting with the focal distance changed automatically after each shot. These images enable you to create a single image in focus over a deep depth of field. Compositing is also possible using an application that supports depth compositing, such as Digital Photo Professional (EOS software).
  • Page 284 Set [Focus increment]. Specify how much to shift the focus. This amount is automatically adjusted to suit the aperture value at the time of shooting. Larger aperture values increase the focus shift and make focus bracketing cover a wider range under the same focus increment and number of shots.
  • Page 285 Set [Depth composite]. Select [Enable] for in-camera depth compositing. The depth- composited image is saved. Select [Disable] if you prefer not to perform in-camera depth compositing. Only captured images are saved. Caution Depth-composited images are saved as JPEGs. image quality is not available. Settings are adjusted so that the resulting image is Set [Crop depth comp.].
  • Page 286 Shooting with a wider angle of view is recommended. After depth compositing, you can crop the image if necessary. For details on lenses compatible with this feature, visit the Canon website ( Suitable [Focus increment] settings vary by subject. An unsuitable [Focus increment] setting may cause unevenness in composite images, or shooting may take more time because more shots are taken.
  • Page 287 Note Consider using a tripod, wireless remote control (sold separately, ), or other means of securing the camera. For best results, set the aperture value in a range of f/5.6–11 before shooting. Details such as shutter speed, aperture value, and ISO speed are determined by conditions for the first shot.

  • Page 288: Drive Mode

    Drive Mode You can select drive mode options from the menu. For details, see “Selecting the Drive Mode” ( Select [ : Drive mode] ( Select an option.

  • Page 289: Interval Timer Shooting

    Interval Timer Shooting With the interval timer, you can set the shooting interval and number of shots, so that the camera takes individual shots repeatedly according to your interval until your specified number of shots are taken. Select [ : Interval timer] ( Select [Enable].
  • Page 290 Set the shooting interval and number of shots. Select an option to set (hours : minutes : seconds / number of shots). Press < > to display [ ]. Set the desired number, then press < >. (Returns to [ Interval Can be set in a range of [00:00:01]–[99:59:59].
  • Page 291 Take the picture. First shot is taken and shooting continues according to the interval timer settings. During interval timer shooting, [ ] will blink. After the set number of shots are taken, the interval timer shooting will stop and be automatically canceled. Note Using a tripod is recommended.
  • Page 292 Caution Do not point the camera toward an intense light source, such as the sun or an intense artificial light source. Doing so may damage the image sensor or the camera's internal components. In < > focus mode, the camera will not shoot unless subjects are in focus. Consider setting the mode to manual focus and focusing manually before shooting.

  • Page 293: Silent Shutter Function

    Silent Shutter Function Limits shutter release sounds and operating sounds, and disables firing and illumination of flash units and other light sources. The silent shutter function restricts settings as follows. Shutter release sound, focused beep: restricted to headphone output Touch sounds, self-timer sounds: not produced Anti-flicker shooting: [Disable] Long exposure noise reduction: [Disable] Shutter mode: [Electronic...

  • Page 294: Shutter Mode

    Shutter Mode You can choose the method of shutter release. Select [ : Shutter mode] ( Select an option. Elec. 1st-curtain Electronic Enables reduced sound and vibration from shutter operations, compared to electronic first-curtain. Recommended when shooting with the aperture of a bright lens wide open.
  • Page 295 : Silent shutter function] to [On] sets the shutter mode to [Electronic Zooming during continuous shooting may cause changes in exposure even at the same f/number. For details, refer to the Canon website ( Precautions when set to [Electronic The continuous shooting speed may become slower depending on the shooting conditions.

  • Page 296: Enabling Shutter Release Without A Card

    Enabling Shutter Release Without a Card Set to [Disable] to avoid shooting unless there are cards in the camera. Select [ : Release shutter without card] ( Select [Disable].

  • Page 297: Tally Lamp

    Tally Lamp The tally lamp lights up or blinks to indicate camera status. Select [ : Tally lamp] ( Select an option. When set to [On], the tally lamp lights up or blinks as follows. Movie recording in progress • Cannot record movies, due to a low battery level or insufficient card free space Blinking rapidly •...

  • Page 298: Image Stabilizer (Is Mode)

    Image Stabilizer (IS Mode) Image stabilization reduces camera shake during movie recording and still photo shooting. The available features differ during movie recording and still photo shooting. Select [ : IS (Image Stabilizer) mode] ( Select and set the item. IS mode (movies/still photos) Activates image stabilization using lens IS.
  • Page 299 Caution [IS mode] is not available for lenses with an IS switch ([ : IS (Image Stabilizer) mode] cannot be used in still photo shooting). Use the IS switch on the lens instead. Movie Digital IS Stabilization by Movie digital IS may be less effective at some movie recording sizes.

  • Page 300: Movie Auto Level

    Movie Auto Level Auto leveling helps keep movies straight during recording. Caution Set [ Digital IS] in [ : IS (Image Stabilizer) mode] to [Off]. Select [ Auto level] ( Select an option.

  • Page 301: Metadata

    Metadata Embedding Custom Picture Files Custom picture files can be embedded in movie files by setting [Add File] to [On] when function] in [ : Custom Picture] is set to [On]. Embedding Custom Picture Files Select [ : Metadata] ( Select an option.

  • Page 302: Time Code

    Time Code Count Up Start Time Setting Movie Recording Count Movie Play Count HDMI Drop Frame Time codes record the time automatically as movies are recorded. Time codes always record elapsed hours, minutes, seconds, and frames. They are mainly used when movies are edited.
  • Page 303 Count Up Rec run The time code advances only during movie recording. Time codes in each movie file recorded continue from the last time code in the previous file. Free run The time code keeps advancing, even when you are not recording. Caution When set to [Free run], time codes will be affected by any changes to settings for time, zone, or daylight saving time (...
  • Page 304 Start Time Setting You can set the initial time of the time code. Manual input setting Enables you to set any starting hour, minute, second, and frame. Reset Resets the time set with [Manual input setting] or [Set to camera time] to “00:00:00.” or “00:00:00:”...
  • Page 305 Movie Recording Count You can select how time is displayed on the movie recording screen. Rec time During recording standby, displays the available recording time. During recording, displays the time that has elapsed since movie recording began (1). Time code Displays the time code during movie recording (2).
  • Page 306 Movie Play Count You can select how time is displayed on the movie playback screen. Rec time Displays the recording or playback time during movie playback. Time code Displays the time code during movie playback. Note Time codes are always added to movie files, regardless of the [Movie rec count] setting.
  • Page 307 HDMI Time code Time codes can be added to movies as you record them to an external device via HDMI. • Off No time code is added to HDMI video output. • On Time codes are added to HDMI video output. When [On] is set, [Rec Command] is displayed.

  • Page 308: Drop Frame

    Drop Frame The time code's frame count will cause a discrepancy between the actual time and the time code if the frame rate is set to (119.9 fps), (59.94 fps), or (29.97 fps). The discrepancy is corrected automatically when [Enable] is set. Enable Corrects the discrepancy automatically by skipping time code numbers (DF: drop frame).

  • Page 309: Review Duration

    Review Duration To keep the image displayed immediately after you shoot, set to [Hold], and if you prefer not to have the image displayed, set to [Off]. Select [ : Review duration] ( Set a time option. Note When [Hold] is set, images are displayed as long as the time set in the [Screen off] option of [ : Power saving].

  • Page 310: High-Speed Display

    High-Speed Display High-speed display that switches between each shot and the live image is available when shooting in [ ] (high-speed continuous shooting) drive mode and [Elec. 1st-curtain] shutter mode. Select [ High speed display] ( Select an option. Select [Enable] for display that switches between each shot and the live image.

  • Page 311: Display Simulation

    Display Simulation With display simulation, display of image brightness and depth of field more closely matches the actual brightness (exposure) of your shots. Select [ : Display simulation] ( Select an option. Exposure+DOF ( Image brightness and depth of field as displayed closely matches the actual brightness (exposure) of your shots.
  • Page 312 Caution Notes on [Exposure+DOF] Display may flicker at some shutter speeds. With EF lenses, this setting may increase the shutter-release time lag. The depth of field shown is only a guideline. For more precise indication of the depth of field, press the button assigned to depth-of-field preview ( [Exposure+DOF] is not available with some lenses.

  • Page 313: Hdr/C. Log View Assist

    View Assist Display Conditions HDR shooting (PQ)] is set to [HDR PQ] [Gamma/Color Space] in [ : Custom Picture] is set as follows • Canon Log 3 / C.Gamut • PQ / BT.2020 • HLG / BT.2020 * HLG stands for Hybrid Log-Gamma.
  • Page 314 View Assist Display Settings Select [ HDR/C.Log View Assist.] ( Select screen or viewfinder display. Use View Assist display on the screen. HDMI Use view-assisted display on non-HDR display devices connected via HDMI.
  • Page 315 Select an option. For the screen On (BT.709 during When the camera is set to [HDR PQ], converted images are displayed that resemble how the images would look on an HDR display device. Image display with a custom picture applied involves basic conversion to a standard gamma/color space.

  • Page 316: False Color Settings

    False Color Settings False Color Display Color-coded display in six colors based on the brightness level is shown on the screen during movie recording. This can help you adjust the exposure. Select [ : False color set.] ( Select [False color]. Select [On].

  • Page 317: False Color Display

    The following features are not available when the camera is set to use false colors. • Color Filter • Cinema View • Time-Lapse Movies • Auto Lighting Optimizer • Zebra display • View Assist for HDR/Canon Log • HDR Movie Mode • MF peaking...

  • Page 318: Zebra Settings

    Zebra Settings To help you adjust exposure before or during movie recording, you can display a striped pattern over or around image areas of a specified brightness. Select [ : Zebra settings] ( Select [Zebra]. Select [On]. Select [Zebra pattern]. [Zebra 1]: Displays left-slanting stripes around areas of the specified brightness.
  • Page 319 Set the level. Zebra 1 level Zebra 2 level Set with the < >< > keys. Note The maximum brightness value does not reach 100% when HDR-PQ is set. Note that the maximum brightness value varies depending on [ : Highlight tone priority] and [ : Picture Style] settings.

  • Page 320: Shooting Information Display

    Shooting Information Display Customizing Information on the Screen Grid Histogram Electronic Level Size Card Free Space (%) Display Lens Information Display Recording Emphasis Aspect Marker Clearing Settings You can customize the details and screens of information shown on the camera when you shoot.
  • Page 321 Select screens. Press the < >< > keys to select screens of information to show on the camera. For information you prefer not to display, press < > to clear the checkmark [ ]. To edit the screen, press the < >...
  • Page 322 Grid A grid can be displayed on the screen. Select [ : Shooting info. disp.] ( Select [Grid display]. Select an option.
  • Page 323 Histogram You can select the content and display size of the histogram. Select [ : Shooting info. disp.] ( Select [Histogram disp]. Select an option. Select the content ([Brightness] or [RGB]) and display size ([Large] or [Small]).
  • Page 324 Electronic Level Size You can select the display size of the electronic level. Select [ : Shooting info. disp.] ( Select [Electronic level size].
  • Page 325 Card Free Space (%) Display You can display card free space on the screen. Select [ : Shooting info. disp.] ( Select [Card free space (%) display]. Select [On]. Note During still photo shooting or when writing to cards, the number of available shots is shown instead of the free space.

  • Page 326: Lens Information Display

    Lens Information Display You can display information about the lens in use. Select [ : Shooting info. disp.] ( Select [Lens info display]. Select an option. Focus distance disp You can display focus distance when using RF lenses. In focus distance display, you can select the timing and unit of measurement.
  • Page 327 Recording Emphasis Select [ : Shooting info. disp.] ( Select [Recording emphasis]. Select an option. Screen edges are lit in red while movie recording is in progress. No frame is displayed to call attention to recording in progress.
  • Page 328 Aspect Marker If you will change the image aspect ratio when editing the recorded movie, you can display aspect markers on the movie recording screen (during standby and recording) to be aware of the final angle of view after editing. Select [ : Shooting info.

  • Page 329: Clearing Settings

    Clearing Settings Select [ : Shooting info. disp.] ( Select [Reset]. Select [OK].

  • Page 330: Auto Rotate Movie Shooting Info Display

    Auto Rotate Movie Shooting Info Display You can automatically rotate information on the screen when holding the camera vertically in movie recording. Select [ : Rotate shoot info disp] ( Select an option.

  • Page 331: Quick Control Screen

    Quick Control Screen You can change the Quick Control ( ) views available during movie recording. Select [ : Quick Ctrl screen] ( Select the view to display. Turn the < > dial to select Quick Control display options. For items you prefer not to display, press < >...

  • Page 332: Customizing Quick Controls

    Customizing Quick Controls Resetting the Custom Quick Control Screen or Clearing All Items Quick Control items and the layout are customizable. Select [ : Customize Quick Controls] ( Select [Edit layout]. Select items to remove. Use the < > dial or < >...
  • Page 333 Select items to add. Use the < > dial or < > keys to select an item to add, then press < >. To change the layout, press the < > button. Change the layout. Press the < >< > keys to select an item to move, then press <...
  • Page 334 Select [Save and exit]. Review the screen. Press < > to check the screen with your settings applied. Resetting the Custom Quick Control Screen or Clearing All Items Select [Reset settings] to restore the default Quick Control screen items and layout. Select [Clear all items] to remove all items from the layout, so that the Quick Control screen is not displayed even when <...

  • Page 335: Display Frame Rate

    Display Frame Rate You can set the display frame rate for the shooting screen in still photo shooting. Choose whether to conserve battery power or use a high frame rate for display. Select [ Display frame rate setting] ( Select an option. When set to [Smooth] By pressing the <...
  • Page 336 Caution Shooting under low light with [Suppress lower frame rate] set for shooting screen display may affect performance as follows. • Faster battery consumption • Fewer shots available • Lower image display brightness • Difficulty in autofocusing • Lower metering precision •...

  • Page 337: Reverse Display

    Reverse Display A mirror image can be displayed when you shoot with the screen rotated toward the subject (toward the front of the camera). Select [ : Reverse display] ( Select [On]. Select [Off] if you prefer not to reverse display when the screen is facing the subject.

  • Page 338: Auto Power Off Temperature

    Auto Power Off Temperature You can set the maximum camera body temperature at which the camera automatically turns off. Setting this level higher than the standard temperature can extend the available shooting time by removing some operating restrictions. Select [ : Auto pwr off temp.] ( Select [High].

  • Page 339: Standby: Low Resolution

    Standby: Low Resolution Set to [On] to conserve battery power and control the rise of camera temperature during standby. As a result, it may enable you to record movies over a longer period. Select [ : Standby: Low res.] ( Select an option.

  • Page 340: Display During Hdmi Connection

    Display During HDMI Connection You can specify how movies are displayed as they are recorded via HDMI to an external device. Movie output itself corresponds to the [Movie rec. size] setting. The default setting is [ Select [ : HDMI display] ( Select an option.
  • Page 341 Caution Card recording is not performed with [HDMI display] set to [ ]. Camera menus and image playback are only displayed on the screen connected via HDMI. The HDMI output resolution and frame rate are automatically adjusted to suit the movie recording size.

  • Page 342: Canon Log Hdmi Output Range

    Canon Log HDMI Output Range You can select the output range of video signals output via an HDMI connection. Select [ : HDMI output range for C. Log] ( Select an option. Prioritize Full Range Full-range output is used whenever possible. Note that the output range will be automatically adjusted to suit display specifications.

  • Page 343: Retain Creative Assist Data

    Retain Creative Assist Data By storing Creative Assist settings used in [ ] mode, you can skip the step of selecting the effect again in subsequent shooting. Select [ : Retain Creative Assist data]. Select [Enable].

  • Page 344: General Movie Recording

    General Movie Recording Warning Indicator Display in Movie Recording General Movie Recording Precautions Warning Indicator Display in Movie Recording A 10-level indicator (1) is displayed during movie recording in case of excessive internal camera temperature. As the internal temperature rises, the level on the indicator extends to the right. How fast the level increases will depend on shooting conditions.
  • Page 345 A message is displayed if you continue to record while the icon is flashing, and the camera automatically turns off. Subsequent recording To keep recording under the same settings, leave the camera off and let it cool down a while. Note that the camera may overheat again after you resume recording.
  • Page 346 General Movie Recording Precautions Caution Precautions for movie recording Do not point the camera toward an intense light source, such as the sun or an intense artificial light source. Doing so may damage the image sensor or the camera's internal components. If you record something that has fine detail, moire or false colors may result.
  • Page 347 If you use a card with a slow writing speed, an indicator may appear on the right of the screen during movie recording. The indicator shows how much data has not yet been written to the card (remaining capacity of the internal buffer memory), and it increases more quickly the slower the card is.

  • Page 348: General Still Photo Shooting

    General Still Photo Shooting Information Display in Still Photo Shooting General Still Photo Shooting Precautions Information Display in Still Photo Shooting For details on the icons displayed for still photo shooting, see Information Display. Note White display of the [ ] icon indicates that your shots will be about as bright as the image displayed.
  • Page 349 General Still Photo Shooting Precautions Caution Do not point the camera toward an intense light source, such as the sun or an intense artificial light source. Doing so may damage the image sensor or the camera's internal components. Image quality When you shoot at high ISO speeds, noise (such as dots of light and banding) may become noticeable.
  • Page 350 Under low light, bright [ : Screen brightness] settings may cause noise or irregular colors in images. However, the noise or irregular colors will not be recorded in the captured image. When you magnify the image, the image sharpness may look more pronounced than in the actual image.

  • Page 351: Shooting With Speedlites

    Shooting with Speedlites EL/EX Series Speedlites for EOS Cameras Canon Speedlites Other Than the EL/EX Series Non-Canon Flash Units Quick Flash Group Control FE Memory Function EL/EX Series Speedlites for EOS Cameras Features of EL/EX series Speedlites (sold separately) can be used in flash photography with the camera.
  • Page 352 Note You can also set flash exposure compensation in [Flash function settings] in [ External Speedlite control] ( The camera can turn on certain Speedlites automatically when the camera is turned on. For details, refer to the instruction manual of Speedlites that support this feature.
  • Page 353 Canon Speedlites Other Than the EL/EX Series With an EZ/E/EG/ML/TL series Speedlite set to A-TTL or TTL autoflash mode, the flash can be fired at full output only. Set the camera's shooting mode to [Av] or [M] and adjust the aperture value before shooting.

  • Page 354: Sync Speed

    Non-Canon Flash Units Sync speed The camera can synchronize with non-Canon compact flash units at up to 1/250 sec. With large studio flash units, the flash duration is longer than that of a compact flash unit and varies depending on the model. Before shooting, confirm that flash sync is performed correctly by taking some test shots at a sync speed of approx.
  • Page 355 Quick Flash Group Control As you view the shooting screen in wireless multi-flash photography, you can configure the settings for each flash group by pressing the button assigned to [Quick flash group control] in [ : Customize buttons for shooting]. This example is based on assigning the <...
  • Page 356 FE Memory Function You can set the flash output captured in [ETTL] flash mode as the flash output for [M] flash mode by pressing the button assigned to [ETTL M] in [ : Customize buttons for shooting]. This example is based on assigning the < >...

  • Page 357: Flash Photography Settings

    Flash Photography Settings Flash Firing E-TTL Balance E-TTL II Flash Metering Continuous Flash Control Slow Synchro Flash Function Settings Flash Custom Function Settings Clearing Flash Function Settings/Clearing All Speedlite Custom Functions Functions of EL/EX series Speedlites compatible with flash function settings can be set via a camera menu screen.

  • Page 358: Flash Firing

    Select an option. Flash Firing To enable flash photography, set to [Enable]. To enable only the AF-assist beam of the Speedlite, set to [Disable].
  • Page 359 E-TTL Balance You can set your preferred appearance (balance) for flash shots. This setting enables you to adjust the ratio of ambient light to Speedlite light output. Set the balance to [Ambience priority] to lower the proportion of flash output and uses ambient light to produce lifelike shots with a natural mood.
  • Page 360 E-TTL II Flash Metering Set to [Eval (FacePrty)] for flash metering suitable for shots of people. Set to [Evaluative] for flash metering that emphasizes firing in continuous shooting. If [Average] is set, the flash exposure will be averaged for the entire metered scene. Note Depending on the scene, flash exposure compensation may be necessary.
  • Page 361 Continuous Flash Control Set to [E-TTL each shot] to perform flash metering for each shot. Set to [E-TTL 1st shot] to perform flash metering for only the first shot before continuous shooting. The flash output level for the first shot is applied to all subsequent shots.

  • Page 362: Slow Synchro

    Slow Synchro You can set the flash-sync speed for flash photography in [P] or [Av] mode. Note that the maximum flash synchronization speed is 1/250 seconds. 1/250-30sec. auto The flash sync speed is set automatically within a range of 1/250 sec. to 30 sec. to suit the scene's brightness.

  • Page 363: Flash Function Settings

    Flash Function Settings The information displayed on the screen, position of display, and available options vary depending on the Speedlite model, its Custom Function settings, the flash mode, and other factors. For details on the Speedlite's functions, refer to the Speedlite's Instruction Manual. Sample display Flash mode Wireless functions/...

  • Page 364: Flash Mode

    Flash mode You can select the flash mode to suit your desired flash photography. [E-TTL II flash metering] is the standard mode of EL/EX series Speedlites for automatic flash photography. [Manual flash] is for setting the Speedlite's [Flash output level] yourself. Regarding other flash modes, refer to the Instruction Manual of a Speedlite compatible with the respective flash mode.

  • Page 365: Wireless Functions

    Wireless functions You can use radio or optical wireless transmission to shoot with wireless multiple-flash lighting. For details on wireless flash, refer to the Instruction Manual of a Speedlite compatible with wireless flash photography. Firing ratio control (RATIO) With a macro flash, you can set the firing ratio control. For details on firing ratio control, refer to the Instruction Manual of the macro flash.

  • Page 366: Shutter Synchronization

    Shutter synchronization Normally, set this to [First-curtain synchronization] so that the flash fires immediately after the shooting starts. Set to [Second-curtain synchronization] and use low shutter speeds for natural-looking shots of subject motion trails, such as car headlights. Set to [High-speed synchronization] for flash photography at higher shutter speeds than the maximum flash sync shutter speed.

  • Page 367: Flash Exposure Bracketing

    Flash exposure bracketing Speedlites equipped with flash exposure bracketing (FEB) can change the external flash output automatically as three shots are taken at once.
  • Page 368 Flash Custom Function Settings For details on the Speedlite's Custom Functions, refer to the Instruction Manual of the Speedlite. Select [Flash C.Fn settings]. Set the desired functions. Select the number. Select an option. Caution With an EL/EX series Speedlite, the Speedlite will always fire at full output if the [Flash metering mode] Custom Function is set to [1:TTL] (autoflash).
  • Page 369 Clearing Flash Function Settings/Clearing All Speedlite Custom Functions Select [Clear settings]. Select the settings to be cleared. Select [Clear flash settings] or [Clear all Speedlite C.Fn's]. Select [OK] on the confirmation screen to clear all flash settings or Flash Custom Function settings.

  • Page 370: Af/Drive

    AF/Drive This chapter describes autofocus operation and drive modes and introduces menu settings on the AF [ ] tab. to the right of titles indicates functions only available in Creative Zone modes. Note < > stands for autofocus. < > stands for manual focus. •...

  • Page 371: Tab Menus: Af (Movie Recording)

    Tab Menus: AF (Movie Recording) AF operation/area Movie Servo AF AF area Focus mode Subject detection Subject to detect Eye detection Register people priority Switching tracked subjects...
  • Page 372 Servo AF character. Movie Servo AF speed Movie Servo AF track sens. Customized controls Limit subject to detect L/R eye detection...
  • Page 373 MF related MF peaking settings Focus guide Lens electronic MF...

  • Page 374: Tab Menus: Af (Still Photos)

    Tab Menus: AF (Still Photos) AF operation/area AF operation AF area Whole area tracking Servo AF Focus mode Subject detection Subject to detect Eye detection Register people priority Switching tracked subjects...
  • Page 375 Customize AF operation Preview AF AF-assist beam firing Customized controls Limit subject to detect L/R eye detection...
  • Page 376 MF related MF peaking settings Focus guide Lens electronic MF...

  • Page 377: Af Operation

    AF Operation One-Shot AF for Still Subjects Servo AF for Moving Subjects AI Focus AF for Automatic AF Mode Switching You can select the AF operation characteristics to suit the shooting conditions or subject. Set the focus mode to AF. For RF lenses without a focus mode switch Set [ : Focus mode] to [AF].
  • Page 378 Select [ : AF operation] ( Select an option. Note If focus is not achieved, the AF point will turn orange. When using One-Shot AF, either recompose the shot and try to focus again or see “Shooting Conditions That Make Focusing Difficult” ( With Servo AF, the camera shoots even when subjects are not in focus.

  • Page 379: One-Shot Af For Still Subjects

    One-Shot AF for Still Subjects This AF operation is suited for still subjects. When you press the shutter button halfway, the camera will focus only once. When focus is achieved, the AF point will turn green and the beeper will sound. The focus remains locked while you hold down the shutter button halfway, allowing you to recompose the image before taking the picture.
  • Page 380 Press the shutter button completely to take the picture.
  • Page 381 Servo AF for Moving Subjects This AF operation is suited for moving subjects. While you hold down the shutter button halfway, the camera will keep focusing on the subject continuously. When focus is achieved, the AF point will turn blue. The beeper will not sound even when focus is achieved.

  • Page 382: Ai Focus Af For Automatic Af Mode Switching

    AI Focus AF for Automatic AF Mode Switching The AF mode is automatically switched from [One-Shot AF] to [Servo AF] based on subject status while you are pressing the shutter button halfway or shooting continuously.

  • Page 383: Movie Servo Af

    Movie Servo AF Subject Detection AF With this function enabled, the camera focuses on the subject continuously during movie recording. Set the Mode dial to < >, < >, < >, or < >. Select [ : Movie Servo AF].
  • Page 384 Select [Enable]. Enable • By default, pressing the < > button focuses using your specified AF area. • By default, pressing the shutter button halfway starts metering. • To keep the focus at a specific position, or if you prefer not to record mechanical sounds from the lens, you can temporarily stop Movie Servo AF by tapping [ ] in the lower left of the screen.
  • Page 385 Caution Precautions when set to [Movie Servo AF: Enable] Autofocusing when recording with Canon Log or at frame rates of 100 fps or higher may be more difficult for subjects under low light, or for low-contrast subjects. Difficulty in autofocusing can be reduced by shooting near maximum aperture or using a bright lens.
  • Page 386 Detect. only Movie Servo AF is only used for subjects set in [ : Subject to detect]. Movie Servo AF stops if no subject is detected.

  • Page 387: Selecting The Af Area

    Selecting the AF Area AF Area Selecting the AF Area Whole Area Tracking Servo AF Subject to Detect Eye Detection Switching Tracked Subjects Tracking with a Button Focus Mode Manually Setting AF Points Magnified View AF Shooting Tips Shooting Conditions That Make Focusing Difficult AF Range...
  • Page 388 AF Area AF area operation is as follows. Screens shown here are displayed when you press the button assigned to [AF area] in [ : Customize buttons for shooting]. : Spot AF The camera focuses in a narrower area than 1-point AF. : 1-point AF The camera focuses using a single AF point [...
  • Page 389 : Expand AF area: Focuses using one AF point [ ] and the AF area outlined here in blue. Effective for moving subjects, which are difficult to track with 1-point AF. Focusing on your preferred subject is easier than with Flexible Zone AF. When Servo AF is used, first you will focus using an AF point [ : Expand AF area: Around Focuses using one AF point [...
  • Page 390 : Flexible Zone AF 1 By default, a square Zone AF frame is set. : Flexible Zone AF 2 By default, a vertical rectangular Zone AF frame is set.
  • Page 391 : Flexible Zone AF 3 By default, a horizontal rectangular Zone AF frame is set. With Flexible Zone AF 1–3, you can freely set the size of the Zone AF frame ( Uses auto selection AF in Zone AF frames to cover a larger area than Expand AF area, which makes focusing easier than with 1-point AF/Expand AF area and effective for moving subjects.
  • Page 392 Selecting the AF Area You can select the AF area to suit the shooting conditions or subject. Select [ : AF area] ( Select the AF area. Note You can also set the AF area by pressing < >, using the < >...
  • Page 393 Whole Area Tracking Servo AF You can set whether to switch to whole-area subject tracking during Servo AF (while the shutter button is pressed halfway with [ : AF operation] set to [Servo AF]). Select [ : Whole area tracking Servo AF] ( Select an option.
  • Page 394 Subject to Detect You can specify conditions for automatic selection of the main subject to track. Selecting an option other than [None] will display a tracking frame [ ] for the main subject detected. The tracking frame will move to track subjects that start moving. You can shoot with the subject's eyes in focus by setting [ : Eye detection] to an option other than [Disable] (...
  • Page 395 None The camera determines the main subject automatically from how you compose shots, without detecting subjects. Tracking frames are not displayed. Caution The following kinds of subjects may not be detected. • Extremely small or large • Too bright or dark •...
  • Page 396 Manually selecting a subject for focus Check the tracking frame. Aim the camera at the subject. An AF point (or Zone AF frame) appears on the screen if you have set [ : AF area] to an option other than [Whole area AF]. In this case, aim the AF point over the subject.
  • Page 397 Focus and shoot/record. A tracking frame is displayed (in green for One-Shot AF or blue for Servo AF) when you press the shutter button halfway, and the camera beeps (only for One-Shot AF). An orange tracking frame indicates that the camera could not focus on subjects.
  • Page 398 Caution Tapping the screen to focus will focus with [One-Shot AF], regardless of the AF operation setting. If the subject's face is significantly out of focus, face detection will not be possible. Adjust the focus manually ( ) so that the face can be detected, then perform AF. AF may not detect subjects or people's faces at the edges of the screen.
  • Page 399 Eye Detection You can shoot with the eyes of people or animals in focus. Select [ : Eye detection] ( Select an option. Disable Eye detection is not performed. Auto The eye for AF operation is selected automatically after eye detection. Right eye/Left eye Gives priority to the selected eye for AF, after eye detection.
  • Page 400 Aim the camera at the subject. A tracking frame is displayed around their eye. To choose an eye to focus on when [ : AF area] is set to [Whole area AF], either tap the screen or use < >. As you use < >, the tracking frame changes again to [ You can also tap the screen to choose an eye, when [...
  • Page 401 Switching Tracked Subjects You can specify how easily the camera switches AF points to track subjects. Initial priority Tracks the subject initially determined for AF, to the extent possible. On subject Tracks the subject initially determined for AF, to the extent possible. Switches to other subjects if the camera can no longer determine if the tracked subject is the main subject.
  • Page 402 Tracking with a Button You can press a button assigned to [Start/stop whole area AF tracking] and [AF point selection] in [ : Customize buttons for shooting] to track subjects with a tracking frame ]. This example is based on assigning [Start/stop whole area AF tracking] to the <...
  • Page 403 Press the < > button. The tracking frame changes to [ ], which locks on to that subject for tracking and follows the subject within the screen if it moves. To cancel tracking, press the < > button again. To choose a subject to focus on when multiple subjects can be detected, press the <...

  • Page 404: Focus Mode

    Focus Mode You can set how the camera focuses. Select [ : Focus mode] ( Select an option. The camera operates in autofocus mode. The camera operates in manual focus mode. Note You can also switch between [AF] and [MF] when the shooting screen is displayed by pressing the <...
  • Page 405 Manually Setting AF Points You can manually set AF points by pressing the button assigned to [AF point selection] in : Customize buttons for shooting]. This example is based on assigning the < > button. Check the AF point. An AF point (1) is displayed. Move the AF point.
  • Page 406 Focus and shoot/record. Aim the AF point over the subject and press the shutter button halfway. Once the subject is in focus, the AF point changes color (to green for One-Shot AF or blue for Servo AF) and the camera beeps (only for One-Shot AF).

  • Page 407: Magnified View

    Magnified View To check the focus, you can magnify display by approx. 5× or 10× by tapping [ Magnification is centered on the tracking frame when the tracking frame is white (as an active frame) after subject detection. Magnification is centered on the AF point (in the center of the screen) when subjects are detected and the tracking frame is gray, or when subjects cannot be detected.
  • Page 408 AF Shooting Tips Even when focus is achieved, pressing the shutter button halfway will focus again. Image brightness may change before and after autofocusing. Depending on the subject and shooting conditions, it may take longer to focus, or the continuous shooting speed may decrease. If the light source changes as you shoot, the screen may flicker, and focusing may be difficult.
  • Page 409 Shooting Conditions That Make Focusing Difficult Subject with low-contrast such as the blue sky, solid-color flat surfaces or when highlight or shadow details are clipped. Subjects in low light. Stripes and other patterns where there is contrast only in the horizontal direction. Subjects with repetitive patterns (Example: Skyscraper windows, computer keyboards, etc.).
  • Page 410 AF Range The available autofocus range varies depending on the lens used and settings such as aspect ratio, movie recording size, and Movie digital IS.

  • Page 411: Manual Focus

    Manual Focus Setting MF Peaking (Outline Emphasis) Focus Guide If focusing is not possible with autofocus, you can magnify the image and focus manually. Set the focus mode to < >. For RF lenses without a focus mode switch Set [ : Focus mode] to [MF].
  • Page 412 For RF lenses with a focus mode switch Set the lens focus mode switch to < >. Magnify the image. Tapping [ ] changes the screen as follows. Move the magnified area. Use the < > keys to move the magnified area into position for focusing.
  • Page 413 Focus manually. While looking at the magnified image, turn the lens focusing ring to focus. After focusing, tap [ ] to return to the normal view. Note In magnified view, the exposure is locked. Even when focusing manually, you can use Touch Shutter to shoot.
  • Page 414 Setting MF Peaking (Outline Emphasis) Edges of subjects in focus can be displayed in color to make focusing easier. You can set the outline color and adjust the sensitivity (level) of edge detection. Select [ : MF peaking settings] ( Select [Peaking].
  • Page 415 Note Peaking display shown on the screen is not recorded in images.
  • Page 416 Focus Guide Setting [ : Focus guide] to [On] provides a guide frame that shows which direction to adjust focus and the extent of adjustment needed. Select [ : Focus guide] ( Select [On]. To display the guide frame on the face of the person detected as the main subject, set [ : Subject to detect] to an option other than [None].
  • Page 417 The guide frame indicates the current position in focus and adjustment amount as follows. Much adjustment needed toward infinity Slight adjustment needed toward infinity In focus Slight adjustment needed toward close range Much adjustment needed toward close range...
  • Page 418 Adjustment information not detected Caution Under difficult shooting conditions for AF ( ), the guide frame may not be displayed correctly. Higher aperture values are more likely to prevent correct guide frame display. No AF points are displayed while the guide frame is displayed. The guide frame is not displayed in these situations.

  • Page 419: Registering People To Prioritize

    When using this feature, be aware of the need to protect personal information and comply with privacy regulations, as by asking people for their consent before registering their information. Canon cannot be held liable for any personal information issues arising from use of this feature.

  • Page 420: Registering Faces

    Registering Faces Registering people by taking their picture Select [ : Register people priority] ( Select [Photograph people and register].
  • Page 421 Aim the frame over the face of a person to register, then take their picture. Shoot under ample light with the subject facing you. Ask subjects to pose with a natural facial expression before you shoot. For best results, ask subjects to take off any hats, masks, sunglasses, or other coverings before you take their picture.
  • Page 422 Registering people from images on the card JPEG or HEIF images can be used. Process any RAW images you will use into JPEGs before saving them to the card. Caution With the following images, detection may be less accurate, and it may not be possible to register faces.
  • Page 423 Switch to playback. Press < >. Select a face. For pictures that show more than one person, you can use the < >< > dials or < > keys to move the orange frame over the face to register. Press < >.
  • Page 424 Select [OK]. After the following screen appears, you can register another person's face. Display when registered faces are detected A white frame with [ ] appears on any registered faces that are detected on the shooting screen. Note that [ ] is not displayed when One-Shot AF or Servo AF is used.
  • Page 425 Note When [ : Subject to detect] is set to an option other than [People], priority is given to the subject specified in that setting.
  • Page 426 Changing or Removing the Priority of Registered People You can change detection priority by rearranging registered people. You can also remove registered people. Changing detection priority Select [Change/del. priority of reg. people]. Select the face of a registered person. Select with the < >...
  • Page 427 Change the priority. Move with the < > dial or < > keys, then press < >. When finished changing priority, press the < > button. Removing registered people Select the face of a registered person. Select with the < >...
  • Page 428 Select [OK]. Press the < > button to exit.
  • Page 429 Enabling Detection of Registered People's Faces Select [Register people priority]. Select [Enable].
  • Page 430 Clearing All Registered People Delete all registered information before disposing of the camera or transferring ownership. Select [Delete all registered people]. Press < >.
  • Page 431 Select [OK]. Press < >.
  • Page 432 Saving and Loading Registered Data Registered face data can be saved to a card. Registered data saved by a EOS R50 V camera can also be loaded from a card. Select [Save/load registered data on card].
  • Page 433 Select [Save registration data on card]. Select [Save registration data on card] to save the camera's registered data to the card. To rename the registered data file before saving it, press the < > button on the following screen. To load registered data from the card and overwrite existing data on the camera, select [Load from card (overwrite)].

  • Page 434: Customizing Af Functions

    * Lenses supporting slow focus transition during movie recording USM and STM lenses released in and after 2009 are compatible. For details, refer to the Canon website ( Caution With certain lenses, even if you adjust the AF speed, the speed may not change.
  • Page 435 Movie Servo AF tracking sensitivity You can adjust the tracking sensitivity (to one of seven levels), which affects responsiveness if the subject strays from the AF point during Movie Servo AF, as when interfering objects move across AF points or when you pan. This function is available when [ : Movie Servo AF] is set to [Enable].

  • Page 436: Af-Assist Beam Firing

    [Customize AF operation] Preview AF This function keeps subjects generally in focus. The camera is ready to focus immediately when you press the shutter button halfway. Select [ : Preview AF] ( Select [Enable]. Caution Fewer shots are available when set to [Enable], because the lens is driven continuously and battery power is consumed.
  • Page 437 Select an option. [ON] Enable Enables firing of the AF-assist beam, when needed. [OFF] Disable Disables firing of the AF-assist beam. Set if you prefer not to fire the AF-assist beam. Caution Speedlite AF-assist beam firing is disabled when the Speedlite's [ : AF-assist beam firing] Custom Function is set to [Disable].
  • Page 438 [Customized controls] Limit subject to detect You can limit the available setting options in [ : Subject to detect] to your preferred options. Select an option to exclude and press < > to clear [ ]. Select [OK] to register the setting.
  • Page 439 Caution The [ ] mark cannot be cleared from all items at the same time. Note An asterisk to the right of [ : L/R eye detection] indicates that the default setting has been modified.
  • Page 440 [MF related] Lens electronic MF For lenses equipped with electronic manual focusing, you can specify how manual focus adjustment is used with One-Shot AF. ] Disable after One-Shot After the AF operation, manual focusing adjustment is disabled. ] One-Shot→enabled You can manually adjust the focus after the AF operation if you keep holding down the shutter button halfway.
  • Page 441 Note For details on your lens's manual focus specifications, refer to the Lens Instruction Manual.

  • Page 442: Selecting The Drive Mode

    Selecting the Drive Mode Single and continuous drive modes are provided. You can select the drive mode suiting the scene or subject. Press the < > key ( With an image displayed, press the < > key. Select the drive mode item. Turn the <...
  • Page 443 ] High-speed continuous shooting When you hold down the shutter button completely, you can shoot continuously as described below while you keep holding it down, based on the [ : Shutter mode] setting. • [Elec. 1st-curtain]: max. approx. 7.6 shots/sec. •...
  • Page 444 Continuous shooting speed with Servo AF may be slower depending on subject conditions or the lens used. Visit the Canon website for details on lenses supporting the maximum continuous shooting speed ( Continuous shooting will be slower under flickering light when set to [Electronic ].

  • Page 445: Using The Self-Timer

    Using the Self-Timer Use the self-timer when you want to be in the picture such as a commemorative photograph. Press the < > key ( With an image displayed, press the < > key. Select the drive mode item. Turn the < >...
  • Page 446 Take the picture. Focus on the subject, then press the shutter button completely. To check operation, look at the self-timer lamp, listen for beeps, or watch the countdown in seconds on the screen. Self-timer lamp blinking accelerates and the camera beeps quickly approx.

  • Page 447: Remote Control Shooting

    Remote Control Shooting Wireless Remote Control BR-E1 You can shoot remotely by using an optional Wireless Remote Control BR-E1, which pairs via Bluetooth. Wireless Remote Control BR-E1 You can shoot remotely up to approx. 5 meters/16.4 feet from the camera. First, pair the camera and BR-E1 ( For operating instructions, refer to the BR-E1 instruction manual.

  • Page 448: Customizing Operation

    Customizing Operation Adjusting the Zone AF Frame Size This section describes ways to customize AF operation. You can also use a combination of customized settings. Adjusting the Zone AF Frame Size You can resize the Zone AF frame displayed for Flexible Zone AF 1–3. Press <...
  • Page 449 Press the < > button. Adjust the Zone AF frame size. Use the < > keys to adjust the Zone AF frame size, then press < >. To restore the default setting, press the < > button.

  • Page 450: Playback

    Playback This chapter covers topics related to playback—playing back captured still photos and movies—and introduces menu settings on the playback [ ] tab. Caution Normal display or configuration on this camera may not be possible for images captured on other cameras, or images from this camera that have been edited or renamed on a computer.

  • Page 451: Tab Menus: Playback

    Tab Menus: Playback File operation Protect images Erase images Rotate stills Change mov rotate info Rating Print order Image processing Creative Assist Resize Cropping HEIF→JPEG conversion...

  • Page 452: Playback Method

    Playback method Slide show Set image search conditions View from last seen Various settings Playback information display AF point disp. Playback grid Movie play count...

  • Page 453: Image Playback

    Image Playback Single-Image Display Shooting Information Display Touch Playback Single-Image Display Switch to playback. Press the < > button. The last image captured or played back is displayed. Browse images. Turn the < > dial to browse images. Movies and still photos are displayed one after another regardless of which was captured first.
  • Page 454 No information Basic information display Shooting information display Exit image playback. Press the < > button to exit image playback and return to shooting standby. Note Lines indicating the image area are shown on RAW images captured with [ : Still img aspect ratio] set to [1:1], [4:3], or [16:9] ( If the search conditions are set with [ : Set image search conditions] (...
  • Page 455 Shooting Information Display With the shooting information screen displayed ( ), you can press the < > button to switch to other information. You can also customize the information displayed, in [ Playback information display] (...

  • Page 456: Touch Playback

    Touch Playback The camera features a touch-screen panel that you can touch to control playback. Supported touch operations are like those used with smartphones and similar devices. First, press the < > button to prepare for touch playback. Browse images Jump display Index display...
  • Page 457 Magnified view Note You can also magnify display by double-tapping with one finger.

  • Page 458: Magnified Image Display

    Magnified Image Display Magnify the image. During image playback, press the zoom lever toward < >. Display switches to a magnified view. The magnified area position (1) will be displayed in the lower right of the screen. Each press of the zoom lever toward < >...
  • Page 459 Scroll the image. Use the < > keys to scroll around the magnified image. To cancel the magnified view, press the < > button or tap [...

  • Page 460: Index Display (Multiple-Image Display)

    Index Display (Multiple-Image Display) Switch to the index display. During image playback, press the zoom lever toward < >. The 4-image index display will appear. The selected image is highlighted with an orange frame. Press the zoom lever further toward the <...
  • Page 462 Browse images. Press the < > keys to move the orange frame for image selection. Press < > in the index display to display the selected image in the single-image display.

  • Page 463: Movie Playback

    Movie Playback Switch to playback. Press the < > button. Select a movie. Turn the < > dial to select a movie to play. In single-image display, the [ ] icon displayed in the upper left of the screen indicates a movie. In index display, perforations at the left edge of a thumbnail indicate a movie.
  • Page 464 In the single-image display, press < >. Select [ The movie will start playing back. Sound is played through the speaker (1). You can pause playback and display the movie playback panel by pressing < >. Press it again to resume the playback. Press the <...
  • Page 465 Movie playback panel Item Playback Operations Skips backward approx. 1 sec. each time you press the < > key. Skip backward Holding the < > key down will rewind the movie. Previous frame Displays the previous frame each time you turn the < >...
  • Page 466 Controls not on the previous screen are as follows. Item Playback Operations Displays the editing screen ( Edit Adjust the slow motion speed by turning the < > dial. The slow Slow motion motion speed is indicated in the upper right of the screen. Available when you play 4K movies.

  • Page 467: Editing A Movie's First And Last Scenes

    Editing a Movie's First and Last Scenes You can edit out the first and last scenes of a movie in approx. 1-sec. increments. Pause movie playback. The movie playback panel will appear. Press the < > button, then select [...
  • Page 468 Specify the part to be edited out. Select either [ ] (cut beginning) or [ ] (cut end). Press the < >< > keys to go back or forward one frame. Each turn of the < > dial goes back or forward one frame. After deciding which part to edit out, press <...
  • Page 469 Save. Select [ ] (1). The save screen will appear. To save it as a new file, select [New file], or to save it and overwrite the original movie file, select [Overwrite]. You can compress the file and save it as a separate file when [ ] (2) is displayed.

  • Page 470: 4K Movie Frame Grab

    4K Movie Frame Grab From 4K movies, you can select individual frames to save as JPEG or HEIF still images. This is referred to as “frame grabbing.” Select a 4K movie. Turn the < > dial to make a selection. On the shooting information screen ( ), 4K movies are labeled with ] icons.
  • Page 471 Select a frame to grab. Use the movie playback panel to select the frame to grab as a still image. For movie playback panel instructions, see Movie playback panel. Press the < > button, then select [ Save. Select [OK] to save the current frame as a JPEG still image. HEIF images are saved if you grab frames from movies recorded with HDR shooting (PQ)] set to [HDR PQ].
  • Page 472 Select the image to display. Select [View original movie] or [View extracted still image]. Caution Frame grabbing is not possible from the following 4K movies. • Movies recorded with other cameras Frame grabbing is not possible while the camera is connected to a computer.

  • Page 473: Playback On A Tv Set

    Playback on a TV Set By connecting the camera to a television with a commercially available HDMI cable, you can play back the captured still photos and movies on the television. If the image does not appear on the TV screen, confirm that [ : System frequency] is correctly set to [59.94Hz:NTSC] or [50.00Hz:PAL] (depending on the video system of your television).
  • Page 474 Press the < > button. Images are now displayed on the television, with nothing displayed on the camera screen. The images will automatically be displayed at the optimum resolution matching the connected television. Caution Adjust movie sound volume with the television. The sound volume cannot be adjusted with the camera.

  • Page 475: Protecting Images

    Protecting Images Protecting Individual Images Specifying the Range of Images to Protect Protecting All Images in a Folder or on a Card You can protect important images from being accidentally erased. Caution If you format the card ( ), the protected images will also be erased. Note Once an image is protected, it cannot be erased by the camera's erase function.
  • Page 476 Select the image to protect. Turn the < > dial to select an image to protect. Protect the image. Press < > to protect the selected image, after which it will be labeled with a [ ] icon (1) at the top of the screen. To cancel protection and clear the [ ] icon, press <...
  • Page 477 Specifying the Range of Images to Protect While looking at the images in the index display, you can specify the first and last images for a range to protect all the specified images at once. Select [Select range]. Select [Select range] in [ : Protect images].
  • Page 478 Protecting All Images in a Folder or on a Card You can protect all the images in a folder or on a card at once. When you select [All images in folder] or [All images on card] in [ : Protect images], all the images in the folder or on the card will be protected.

  • Page 479: Erasing Images

    Erasing Images Erasing Images Individually Selecting ([ ]) Multiple Images to Erase Together Specifying the Range of Images to Erase Erasing All Images in a Folder or on a Card You can either select and erase unnecessary images individually or erase them in one batch.
  • Page 480 Erase the images. JPEG/HEIF/RAW images or movies Select [Erase]. RAW+JPEG/RAW+HEIF images Select an option. Series of images captured in [ ], [ ], or [ ] drive mode are erased when you select [Erase scene including image] during playback.
  • Page 481 Selecting ([ ]) Multiple Images to Erase Together By adding checkmarks to the images to be erased, you can erase all those images at once. Select [ : Erase images] ( Select [Select and erase images]. Select an image. Turn the < >...
  • Page 482 Erase the images. Select [OK].
  • Page 483 Specifying the Range of Images to Erase While looking at the images in the index display, you can specify the first and last images for a range to erase all the specified images at once. Select [Select range]. Select [Select range] in [ : Erase images].
  • Page 484 Erase the images. Select [OK].
  • Page 485 Erasing All Images in a Folder or on a Card You can erase all the images in a folder or on a card at once. When you select [All images in folder] or [All images on card] in [ : Erase images], all the images in the folder or on the card will be erased.

  • Page 486: Rotating Still Photos

    Rotating Still Photos You can use this feature to rotate the displayed image to the desired orientation. Select [ : Rotate stills] ( Select an image to rotate. Turn the < > dial to select the image. Rotate the image. Each time you press <...
  • Page 487 Note If you set [ : Auto rotate] to [On ) before taking pictures, you need not rotate the image with this function. If the rotated image is not displayed in the rotated orientation during image playback, set [ : Auto rotate] to [On Movies cannot be rotated.

  • Page 488: Changing Movie Orientation Information

    Changing Movie Orientation Information You can manually edit movie playback orientation information (which determines which side is up). Select [ : Change mov rotate info] ( Select a movie. Turn the < > dial to select a movie with orientation information to change.
  • Page 489 Caution Movies are played horizontally on the camera and via HDMI video output, regardless of the [ : Add rotate info] setting ( Movie orientation information of movies recorded with other cameras cannot be edited with this camera.

  • Page 490: Rating Images

    Rating Images Rating Individual Images Rating by Specifying the Range Rating All Images in a Folder or on a Card You can rate images on a scale of 1–5 ( ). This function is called rating. * Rating images can help you organize them. Rating Individual Images Select [ : Rating] (...
  • Page 491 Rate the image. Press < >, and a blue highlight frame will appear as shown in the screen shown above. Use the < >< > keys to select a rating mark and press < >. When you append a rating mark to the image, the number beside the set rating will increase by one.
  • Page 492 Rating by Specifying the Range While looking at the images in the index display, you can specify the first and last images for a range to rate all the specified images at once. Select [Select range]. Select [Select range] in [ : Rating].
  • Page 493 Rate the image. Turn the < > dial to select a rating mark, then select [OK]. All the images in the specified range will be rated (same rating) at once.
  • Page 494 Rating All Images in a Folder or on a Card You can rate all the images in a folder or on a card at once. Under [ : Rating], when you select [All images in folder] or [All images on card], all the images in the folder or on the card will be rated.
  • Page 495 Note Values next to ratings are displayed as [###] if more than 1,000 images have that rating. With [ : Set image search conditions] and [ : Image jump w/ ], you can display only the images given a specific rating.

  • Page 496: Print Ordering (Dpof)

    Print Ordering (DPOF) Print Options Selecting Images for Printing DPOF (Digital Print Order Format) enables you to print images recorded on the card according to your printing instructions such as the image selection, quantity to print, etc. You can print multiple images in one batch or create a print order for a photofinisher. You can set the print settings such as print type, date imprinting, file number imprinting, etc.
  • Page 497 Set the options as desired. Set [Print type], [Date], and [File No.] options. Standard Prints one image on one sheet. Multiple thumbnail images are printed Index Print type on one sheet. Prints both the standard and index Both prints. [On] imprints the recorded date of the captured Date image.
  • Page 498 Caution If you print an image with a large image size using the [Index] or [Both] setting ), the index print may not be printed with certain printers. In this case, resize the image ( ), then print the index print. Even if [Date] and [File No.] are set to [On], the date or file number may not be imprinted, depending on the print type setting and printer.

  • Page 499: Selecting Images For Printing

    Selecting Images for Printing Selecting images Select and specify the images individually. Press the < > button to save the print order to the card. Standard/Both (1) Quantity (2) Total images selected Press < > to print a copy of the displayed image. By pressing the < ><...
  • Page 500 Selecting multiple images Select range Select [Select range] in [Multiple]. Selecting the first and last images of the range marks all the images in the range with a checkmark [ ], and one copy of each image will be specified for printing. All images in a folder Select [Mark all in folder] and select the folder.

  • Page 501: Creative Assist

    Creative Assist You can process RAW images by applying your preferred effects and saving as JPEGs. Select [ : Creative Assist] ( Select an image. Turn the < > dial to select images to process, then press < >.
  • Page 502 Select an effect. Use the < > dial to select the effect. By selecting [Preset] and pressing < >, you can choose [VIVID], [SOFT], or other preset effects. [AUTO1], [AUTO2], and [AUTO3] are effects recommended by the camera based on image conditions. You can select effects such as [Brightness] or [Contrast] by pressing <...
  • Page 503 To reset the settings, press the < > button and select [OK] after a confirmation message is displayed. To confirm the effect, press the < > button. Select [OK] to save the image.

  • Page 504: Resizing Jpeg/Heif Images

    Resizing JPEG/HEIF Images You can resize a JPEG or HEIF image to reduce the pixel count and save it as a new image. Resizing is available for , , or JPEGs or HEIFs (in sizes except ), including those captured in RAW+JPEG and RAW+HEIF shooting. Note that resizing is not available for images, RAW images, or frame-grab images from 4K movies.
  • Page 505 Save. Select [OK] to save the resized image. Check the destination folder and image file number, then select [OK]. To resize another image, repeat steps 2 to 4.

  • Page 506: Cropping Jpeg/Heif Images

    Cropping JPEG/HEIF Images You can crop a captured JPEG or HEIF image and save it separately. RAW images and frame-grab images from 4K movies cannot be cropped. Select [ : Cropping] ( Select an image. Turn the < > dial to select the image to crop. Press <...
  • Page 507 Set the cropping frame. The image area within the cropping frame will be cropped. Resizing the cropping frame size Operate the zoom lever to resize the cropping frame. The smaller the cropping frame, the more magnified the cropped image will look. Correcting tilt You can correct image tilt by ±10°.
  • Page 508 Check a preview of the cropped image. Turn the < > dial to select [ ], then press < >. The image area to crop is displayed. Save. Turn the < > dial to select [ ], then press < >.

  • Page 509: Converting Heif To Jpeg

    Converting HEIF to JPEG You can convert HEIF images captured in HDR shooting and save them as JPEG images. Converting Individual Images Specifying the Range of Images to Convert Caution Some scenes may look different after conversion if the original and converted images are compared.
  • Page 510 Select an image. Turn the < > dial to select the HEIF image, then press < >. To select other images, repeat step 3. Press the < > button to convert to JPEG. Save. Select [OK] to save the JPEG image. If there are other images for conversion, select [Yes].
  • Page 511 Specifying the Range of Images to Convert Select [Select range]. Specify the range of images. Select the first image (start point). Next, select the last image (end point). A checkmark [ ] will be appended to all the images within the range between first and last images.
  • Page 512 Save. Select [OK] to save the JPEG image. If there are other images for conversion, select [Yes]. Select the images to use for display. Select [Original image] or [Processed img.]. Your selected image is displayed.

  • Page 513: Slide Show

    Slide Show You can play back the images on the card as an automatic slide show. Specify the images to be played back. To play back all the images on the card, go to step 2. If you want to specify the images to be played back in the slide show, filter the images with [ : Set image search conditions] ( Select [...
  • Page 514 Set the playback as desired. Select [Set up]. Display time Repeat Set the [Display time] and [Repeat] (repeated playback) settings for the still photos. After completing the settings, press the < > button.
  • Page 515 Start the slide show. Select [Start]. After [Loading image...] is displayed, the slide show will start. All movies are played first, followed by all still photos. Exit the slide show. To exit the slide show and return to the setting screen, press the <...

  • Page 516: Setting Image Search Conditions

    Setting Image Search Conditions Clearing the Search Conditions You can filter image display according to your search conditions. After setting the image search conditions, you can play back and display only the found images. You can also protect, rate, play a slide show, erase, and apply other operations to filtered images. Select [ : Set image search conditions] ( Set the search conditions.
  • Page 517 Apply the search conditions. Read the message displayed, then select [OK]. The search condition is applied. Display the found images. Press the < > button. Only the images that match the set conditions (filtered) will be played back. When the images are filtered for display, the screen will have an outer yellow frame (2).
  • Page 518 Note Search conditions may be cleared after operations involving camera power or card changes and editing, adding, or erasing images. Auto power off time may be extended while the [ : Set image search conditions] screen is displayed. Clearing the Search Conditions Access the screen in step 2, then press the <...

  • Page 519: Resuming From Previous Playback

    Resuming from Previous Playback Select [ : View from last seen] ( Select an option. [Enable]: Playback resumes from the last image displayed (unless you have just finished shooting). [Disable]: Playback resumes from your most recent shot whenever the camera is restarted.

  • Page 520: Customizing Playback Information Display

    Customizing Playback Information Display Histogram You can specify screens and accompanying information displayed during image playback. Select [ : Playback information display] ( Add a checkmark [ ] next to the number of screens to display. Turn the < > dial and select the number. Press <...
  • Page 521 Histogram The histograms show signal levels across the tonal range. Brightness display (for checking the general exposure level and overall gradation) and RGB display (for checking saturation and gradation of red, green, and blue) are available. You can switch the histogram displayed by pressing the <...

  • Page 522: [Brightness] Display

    [Brightness] display This histogram is a graph showing the distribution of the image's brightness level, with the horizontal axis indicating the brightness level (darker on the left and brighter on the right) and the vertical axis indicating the pixel count at each brightness level. The more pixels there are toward the left, the darker the image, and the more pixels there are toward the right, the brighter the image.

  • Page 523: [Rgb] Display

    [RGB] display This histogram is a graph showing the distribution of each primary color's brightness level in the image (RGB or red, green, and blue), with the horizontal axis indicating the color's brightness level (darker on the left and brighter on the right) and the vertical axis indicating the pixel count at each color brightness level.

  • Page 524: Af Point Display

    AF Point Display You can display the AF points that were used to focus, which will be outlined in red on the playback screen. Select [ : AF point disp.] ( Select [Enable].

  • Page 525: Playback Grid

    Playback Grid You can display a grid over still photos shown in single-image display on the playback screen. This function is convenient for checking the image's vertical or horizontal tilt as well as composition. Select [ : Playback grid] ( Select an option.

  • Page 526: Movie Play Count

    Movie Play Count You can select how time is displayed on the movie playback screen. Select [ : Movie play count] ( Select an option. Rec time Displays the recording or playback time during movie playback. Time code Displays the time code during movie playback.
  • Page 527 Note Time codes are always added to movie files, regardless of the [Movie rec count] setting. The [Movie play count] setting in [ : Time code] is linked to the [ : Movie play count], so that these settings always match. The “frame”...

  • Page 528: Communication Functions

    Caution Important Note that Canon cannot be held liable for any loss or damage caused by erroneous wireless communication settings when using the camera. In addition, Canon cannot be held liable for any other loss or damage caused by use of the camera.
  • Page 529 • Wireless Communication Status...

  • Page 530: Tab Menus: Communication Functions

    Tab Menus: Communication Functions Network function Connect to smartphone(tablet) Connect to Wireless Remote Connect to EOS Utility Upload to image.canon Advanced connection Live streaming USB (UVC/UAC) streaming HDMI streaming Camera Connect streaming Live Switcher Mobile streaming...

  • Page 531: Network Settings

    Network function Airplane mode Wi-Fi settings Bluetooth settings Camera name GPS settings Error details Network settings Reset communication settings Choose USB connection app Caution Some menu items cannot be configured while the camera is connected to computers or other devices via an interface cable. The Wi-Fi connection will be terminated if you set the camera power to <...

  • Page 532: Connecting To A Smartphone Or Tablet

    Connecting to a Smartphone or Tablet Preparing the Smartphone Bluetooth Pairing and Wi-Fi Connection to Smartphones Main Functions of Camera Connect Maintaining a Wi-Fi Connection When the Camera Is Off Editing/Deleting Devices for Connections Reconnecting Using Connection Information Automatic Image Transfer to a Smartphone as You Shoot Sending Images to a Smartphone from the Camera You can do the following after pairing the camera with a smartphone.
  • Page 533 Preparing the Smartphone Turning on Bluetooth and Wi-Fi on a Smartphone Turn on Bluetooth and Wi-Fi from the smartphone settings screen. Note that pairing with the camera is not possible from the smartphone's Bluetooth settings screen. Installing Camera Connect on a Smartphone The dedicated app Camera Connect (free of charge) must be installed on the smartphone on which Android or iOS is installed.
  • Page 534 Bluetooth Pairing and Wi-Fi Connection to Smartphones Select [ Connect to smartphone(tablet)] ( Select [Add a device to connect to]. When automatically transferring images to a smartphone during shooting, set [Send to smartphone after shot] (...
  • Page 535 Select [OK]. This screen is not displayed if [Wi-Fi settings] and [Bluetooth settings] are already set to [Enable]. A message is displayed if the camera is already paired with another device. Select [OK] to end the current Bluetooth connection. Press < >.
  • Page 536 Start pairing. Press < > to start pairing. If Camera Connect is not installed, use the smartphone to scan the QR code on the screen, go to Google Play or App Store to install Camera Connect, then press < > to start pairing. Start Camera Connect.
  • Page 537 Establish a Bluetooth connection. When a message appears on the smartphone, use the smartphone as indicated. Press < >.
  • Page 538 Complete the connection process. Press < >. The name of the connected device is displayed. Caution The camera cannot be connected to two or more devices at the same time via Bluetooth. To switch to a different smartphone for the Bluetooth connection, see Reconnecting via Wi-Fi/Bluetooth.
  • Page 539 Tap a Camera Connect function. For details on Camera Connect functions, see Main Functions of Camera Connect. Tap a Camera Connect function to initiate a Wi-Fi connection. Confirm that the devices are connected via Wi-Fi. After a Wi-Fi connection is established, the camera screen switches to shooting standby.
  • Page 540 [ Communicating] screen Send to smartphone after shot Images can be transferred to a smartphone automatically ( Confirm Wi-Fi settings You can check setting details. Error details After any Wi-Fi connection errors, you can check the error details ( Disconnect Terminates the Wi-Fi connection.

  • Page 541: Auto Transfer

    Main Functions of Camera Connect Images on camera Images can be browsed, deleted, or rated. Images can be saved on a smartphone. Effects can be applied to RAW images and saved to a smartphone. Remote live view shooting Enables remote shooting as you view a live image on the smartphone. Auto transfer Enables camera and app setting adjustment for automatic transfer of your shots ( Bluetooth remote controller...
  • Page 542 Maintaining a Wi-Fi Connection When the Camera Is Off You can use a smartphone to browse images on the camera or perform other operations even when the camera is off, as long as it is paired to the smartphone via Bluetooth. If you prefer not to stay connected to the camera via Wi-Fi/Bluetooth when it is off, either set : Airplane mode] to [On] or set [ : Bluetooth settings] to [Disable].
  • Page 543 Editing/Deleting Devices for Connections Before editing or deleting connection settings for other devices, end the Wi-Fi connection. Select [ Connect to smartphone(tablet)] ( Select [Edit/delete device]. Select the intended device. Select an option.
  • Page 544 Changing device nicknames You can change the nickname of devices the camera connects to. Deleting connection information You can delete the connection information.
  • Page 545 Reconnecting Using Connection Information The configured connection information can be used to connect again. Select [ Connect to smartphone(tablet)] ( Select the device for the connection. Select the connection option in the list of past connections. Follow the on-screen instructions to connect the camera to the device.
  • Page 546 Automatic Image Transfer to a Smartphone as You Shoot Your shots can be automatically sent to a smartphone. Before following these steps, make sure that the camera and smartphone Wi-Fi connection is terminated. Select [ Connect to smartphone(tablet)] ( Select [Send to smartphone after shot]. Set [Auto send] to [Enable].

  • Page 547: Sending Images To A Smartphone From The Camera

    Sending Images to a Smartphone from the Camera You can use the camera to send images to a smartphone connected via Wi-Fi. Displaying the menu screen Switch to playback. Press < >. Select [Send images to smartphone]. If you perform this step while connected via Bluetooth, a message is displayed requesting you to establish a Wi-Fi connection.
  • Page 548 Browse images. Turn the < > dial to select images to send, then press < >. Images can be selected by touch from index display ( Press < >. The menu is displayed.
  • Page 549 Setting the quality to send Select [Quality to send]. You can select the image quality of the movies to send. Note When sending multiple movies, you can change the [Quality to send] on the confirmation screen before sending. Selecting compression for movies applies to all movies sent at that time. However, the following movie formats are not compressed.
  • Page 550 Setting the size of images to send Select [Size to send]. Select the image size to send. Note When sending multiple images, you can also change [Size to send] as needed on the confirmation screen before sending. Selecting the reduced size for still photos applies to all still photos sent at that time. Note that size still photos are not reduced.
  • Page 551 Sending the current image Select [Send img shown]. Press < > with [Send img shown] selected to immediately send the image.
  • Page 552 Selecting and sending images Select [Send selected]. Select images to send. Turn the < > dial to select images to send, then press < >. To switch to selecting images from 3-image display, press the zoom lever toward < >. To return to single-image display, press the zoom lever toward <...
  • Page 553 Select [Send].
  • Page 554 Sending a selected range of images Select [Send range]. Specify the range of images. Select the first image (start point). Next, select the last image (end point). A checkmark [ ] will be appended to all the images within the range between first and last images.
  • Page 555 Select an option. You can change the [Quality to send] ( ) and [Size to send] ( Select [Send].
  • Page 556 Sending all images on a card Select [Send all card]. Select an option. You can change the [Quality to send] ( ) and [Size to send] ( Select [Send].
  • Page 557 Sending images found by searching Send all the images that match the search conditions set in [ : Set image search conditions] at once. For details on [ : Set image search conditions], see Setting Image Search Conditions. Select [Send all found]. Select an option.
  • Page 558 Ending image transfer Press the < > button on the image transfer screen. To end the Wi-Fi connection, select [Disconnect] on the [ Communicating] screen. Caution During the image transfer operation, a picture cannot be taken even if the camera's shutter button is pressed.

  • Page 559: Connecting To A Wireless Remote Control

    Connecting to a Wireless Remote Control Deleting Connection Information Reconnecting Using Connection Information This camera can also be connected to Wireless Remote Control BR-E1 (sold separately, via Bluetooth for remote control shooting. Select [ Connect to Wireless Remote] ( Select [Add a device to connect to].
  • Page 560 Select [OK]. This screen is not displayed if the Bluetooth setting is already set to [Enable]. A message is displayed if the camera is already paired with another device. Select [OK] to end the current Bluetooth connection. Pair the devices. When the screen shown above appears, press and hold the <W>...
  • Page 561 Set up the camera for remote control shooting. For instructions after the pairing is complete, refer to the BR-E1's Instruction Manual. Caution Bluetooth connections consume battery power even after the camera's auto power off is activated. Note When you will not use Bluetooth, setting [ : Bluetooth settings] to [Disable] is recommended (...
  • Page 562 Deleting Connection Information You can delete the connection information. Pairing information for any connected BR-E1 units will be deleted. Select [ Connect to Wireless Remote] ( Select [Delete connection information]. Select [OK].
  • Page 563 Reconnecting Using Connection Information When paired via Bluetooth with another device, the camera can use the connection information to reconnect. Select [ Connect to Wireless Remote] ( Select the device. Press < >.

  • Page 564: Connecting To Eos Utility

    Connecting to EOS Utility Operating the Camera Using EOS Utility Editing/Deleting Devices for Connections Reconnecting Using Connection Information This section describes how to connect the camera to a computer via Wi-Fi and perform camera operations using EOS software or other dedicated software. Install the latest version of software on the computer before setting up a Wi-Fi connection ( For computer operating instructions, refer to the computer user manual.
  • Page 565 Select [Add a device to connect to]. Check the SSID (network name) and password. Check the SSID (1) and Password (2) displayed on the camera screen. To switch networks, press the < > button. For instructions on configuring communication functions, see Basic Communication Settings.
  • Page 566 Steps on the computer (1) Select the SSID, then enter the password. Computer's screen (sample) On the computer's network setting screen, select the SSID checked in step 4 in Steps on the camera (1). For the password, enter the password checked in step 4 in Steps on the camera (1).
  • Page 567 Steps on the camera (2) Select [OK]. The following message is displayed. “******” represents the last six digits of the MAC address of the camera to be connected.
  • Page 568 Steps on the computer (2) Start EOS Utility. In EOS Utility, click [Pairing over Wi-Fi/LAN]. If a firewall-related message is displayed, select [Yes]. Click [Connect]. Select the camera to connect to, then click [Connect].
  • Page 569 Steps on the camera (3) Establish a Wi-Fi connection. Select [OK]. The [ Communicating] screen is displayed on the camera ( The Wi-Fi connection to a computer is now complete. Operate the camera using EOS Utility on the computer. To reconnect via Wi-Fi, see Reconnecting via Wi-Fi/Bluetooth.
  • Page 570 Communicating] screen Confirm Wi-Fi settings You can check setting details for Wi-Fi connections ( Error details After any Wi-Fi connection errors, you can check the error details ( Disconnect Terminates the Wi-Fi connection. Caution If the Wi-Fi connection is terminated while recording a movie with remote shooting, the following will occur.
  • Page 571 Editing/Deleting Devices for Connections Before editing or deleting connection settings for other devices, end the Wi-Fi connection. Select [ Connect to EOS Utility] ( Select [Edit/delete device]. Select the intended device. Select an option.
  • Page 572 Changing device nicknames You can change the nickname of devices the camera connects to. Deleting connection information You can delete the connection information.
  • Page 573 Reconnecting Using Connection Information The configured connection information can be used to connect again. Select [ Connect to EOS Utility] ( Select the device for the connection. Select the connection option in the list of past connections. Follow the on-screen instructions to connect the camera to the device.

  • Page 574: Uploading Images To Image.canon

    Link the camera to image.canon to send images directly from the camera. A smartphone with a browser and internet connection is required. For instructions on how to use image.canon services and details on countries and regions where it is available, visit the image.canon site (https://image.canon/).
  • Page 575 Select [OK]. Scan the QR code with the dedicated app. Select [OK]. Establish a Wi-Fi connection. For instructions on configuring communication functions, see Basic Communication Settings.
  • Page 576 Confirm that the number is displayed in the dedicated app. Select [OK]. Set up automatic image transfer. [When charging battery (high power)]: Auto send starts when the camera is off and connected to a power source to charge it over USB. Note that auto send will start after the camera has been charged for a while if the remaining capacity is initially low.
  • Page 577 The [ ] icon changes to [ Check the dedicated app. Confirm that the camera model name is registered in the dedicated app. Note Uploaded images are stored at image.canon for 30 days at the original image size, without storage limitations.
  • Page 578 [Upload to image.canon] screen Auto send You can change the auto send settings. Movie(s) to send You can select the type of movies uploaded. Still image(s) to send You can select the type of still photos uploaded. Switch network You can change the settings for Wi-Fi connections.

  • Page 579: Advanced Connections

    Advanced Connections Connecting to a Smartphone or Tablet Using Camera Control API (CCAPI) Connecting to a Smartphone or Tablet You can establish a direct Wi-Fi connection with a smartphone and use Camera Connect to control the camera. Select [ : Advanced connection] ( Select [OK].
  • Page 580 Select [Add a device to connect to]. When automatically transferring images to a smartphone during shooting, set [Send to smartphone after shot] ( Start searching for access points. To start searching if Camera Connect is already installed on the smartphone, press < >.
  • Page 581 Start Camera Connect and tap the camera name. Select [OK]. The [Communicating] screen is displayed on the camera (...
  • Page 582 [Communicating] screen Confirm Wi-Fi settings You can check setting details. Error details After any Wi-Fi connection errors, you can check the error details ( Disconnect Terminates the Wi-Fi connection.
  • Page 583 Before using an application or other product applying the Camera Control API (CCAPI),* prepare the camera for CCAPI control by connecting it to the smartphone, tablet, or computer you will use. * Camera Control API is an HTTP-based application programming interface for controlling Canon cameras over a network. Accessing the setting screen...

  • Page 584: Setting A Port Number

    Setting a port number Select an option. Port no. (HTTP) The HTTP port number can be changed as needed. Port no. (HTTPS) The HTTPS port number can be changed as needed. HTTPS Set to [Disable] when using HTTP. Configuring user authentication Select [User authentic.].
  • Page 585 Select use of user authentication. If you have selected [Enable], enter the [User name] and [Password] in [Edit account]. Select [Edit account]. Set the user name. Press < > to access the virtual keyboard ( ), then enter the user name.

  • Page 586: Configuring The Connection

    Set the password. Press < > to access the virtual keyboard ( ), then enter the password. After input, select [OK]. Configuring the connection Select [Connect]. Select [Add with wizard]. To configure connection details, select [Add manually].
  • Page 587 Establish a Wi-Fi connection. Connect to an access point via Wi-Fi. For instructions on configuring communication functions, see Basic Communication Settings. Set the user name. Press < > to access the virtual keyboard ( ), then enter the user name. Select [OK] to go to the next screen.
  • Page 588 Establish a Wi-Fi connection. When the screen above appears on the camera, use the smartphone, computer, or other device to access the indicated URL from the application developed for camera control. Display of the screen above on the camera indicates that a connection has been established.

  • Page 589: Changing Settings

    [Communicating] screen The following operations are available from the [Communicating] screen. Confirm Wi-Fi settings You can check setting details. Error details After any Wi-Fi connection errors, you can check the error details ( Disconnect Terminates the connection. Changing settings You can change the settings when the camera is not connected. Check/edit connections Check or edit connection settings.
  • Page 590 Select the intended device. Select items to check or change. Wireless LAN (or Wired) When wireless LAN settings have been configured, you can change the SSID (network name) and details such as the connection method, security, and type of encryption. TCP/IPv4 You can change the TCP/IPv4 settings.

  • Page 591: Auto Connect

    Auto connect Selecting [Enable] will automatically establish a connection the next time the camera starts up after you turn it off.

  • Page 592: Usb (Uvc/Uac) Streaming

    USB (UVC/UAC) Streaming Enabling Power Over USB Setting the Streaming Size Setting Up AF for Close-Up Demos Select this option if you will use UVC/UAC-compatible applications over a USB connection to a computer or other device. Switch to movie recording ( Select [ USB (UVC/UAC) streaming] ( Select [OK].
  • Page 593 Start the application on the device. Check video input on the connected device. [LIVE] is displayed on the shooting screen while video is displayed by the application. Caution Consider using power over USB or a household power outlet accessory (sold separately) when using the camera over extended periods.
  • Page 594 Enabling Power Over USB By enabling power over USB, you can power the camera from a computer or other device. Complete this setting after connecting the devices via USB. Tap [ ] on the shooting screen. The menu is displayed. Select [Power over USB].
  • Page 595 1.5 A at 5V DC. Use a USB cable that conforms to USB Power Delivery specifications. We recommend using a genuine Canon product (Interface Cable IFC-100U). The remaining battery level may decline when power is supplied to the camera. To...
  • Page 596 Setting the Streaming Size You can set the streaming size. Complete this setting after connecting the devices via USB. Tap [ ] on the shooting screen. The menu is displayed. Select [Streaming size]. Select [ The menu is displayed. Select [Streaming size].
  • Page 597 Change the setting as needed. Select [OK], and after a message is displayed, disconnect the USB cable and redo the [ USB (UVC/UAC) streaming] setting ( Caution Cannot be set while streaming is in progress. ] and [ ] are not available with [Power over USB] set to [On] or with [Shooting mode] set to [Smooth skin movie].
  • Page 598 Setting Up AF for Close-Up Demos With [AF for close-up demos] set to [On], the camera focuses on nearby subjects, which enables you to shoot with any face in front of the camera in focus. In this case, the tracking frame is not displayed.
  • Page 599 Caution No AF points are displayed. Subjects cannot be selected manually.

  • Page 600: Hdmi Streamin

    HDMI Streaming Select this option if you will stream over an HDMI connection with an HDMI-compatible device. Switch to movie recording ( Select [ HDMI streaming] ( Select [OK]. Connect the camera to the other device with a HDMI cable. Start the application on the device.
  • Page 601 Caution Audio output is LPCM/16bit/2CH (channels 1 and 2), even with [ : Audio format] set to [LPCM/24bit/4CH]. Consider using power over USB or a household power outlet accessory (sold separately) when using the camera over extended periods. The remaining battery level may decline when power is supplied to the camera. To avoid running out of battery power, use a fully charged battery.

  • Page 602: Camera Connect Streaming

    Camera Connect Streaming Pairing with a Smartphone via Bluetooth Setting Up Streaming Editing/Deleting Devices for Connections Reconnecting Using Connection Information Select this option if you will stream with Camera Connect on a paired smartphone. Check the streaming requirements and terms of service in advance on the streaming site. Pairing with a Smartphone via Bluetooth Switch to movie recording ( Select [...
  • Page 603 Select [OK]. Press < >. Select [OK]. This screen is not displayed if the Bluetooth setting is already set to [Enable].
  • Page 604 Select [Add a device to connect to]. A message is displayed if the camera is already paired with another device. Select [OK] to end the current Bluetooth connection. Press < >.
  • Page 605 Start pairing. Press < > to start pairing. If Camera Connect is not installed, use the smartphone to scan the QR code on the screen, go to Google Play or App Store to install Camera Connect, then press < > to start pairing. Start Camera Connect.
  • Page 606 Complete the connection process. Press < >. When a message appears on the smartphone, use the smartphone as indicated. The name of the connected device is displayed. Press the < > button.
  • Page 607 Setting Up Streaming Select [ Camera Connect streaming] ( Select [OK]. Set up the communication functions. For instructions on configuring communication functions, see Basic Communication Settings.
  • Page 608 Complete the streaming settings in Camera Connect. Select the streaming platform you will use, then configure the settings accordingly. You can enter a URL on the screen to select a streaming site. Set the streaming quality, based on your communication environment. Start streaming.
  • Page 609 Once the camera becomes hot, ] appears on the screen as a warning. Note that Canon is in no way responsible for third-party services. No image is recorded to the card during streaming (but a card must be in the camera).
  • Page 610 Editing/Deleting Devices for Connections Select [ Connect to smartphone(tablet)] ( Select [Edit/delete device]. Select the device to connect. Select an option. Changing device nicknames You can change the nickname of devices the camera connects to.
  • Page 611 Deleting connection information You can delete the connection information.
  • Page 612 Reconnecting Using Connection Information The configured connection information can be used to connect again. Select [ Camera Connect streaming] ( Select [OK]. Complete the streaming settings in Camera Connect.

  • Page 613: Live Switcher Mobile Streaming

    Live Switcher Mobile Streaming Connecting the Camera and Smartphone via Wi-Fi Editing/Deleting Devices for Connections Reconnecting Using Connection Information Select this option if you will stream with Live Switcher Mobile on a smartphone over a Wi-Fi connection. Check the streaming requirements and terms of service in advance on the streaming site. Connecting the Camera and Smartphone via Wi-Fi Switch to movie recording ( Select [...
  • Page 614 Select [OK]. Select [Connect]. Select [Add a device to connect to].
  • Page 615 Set up the communication functions. For instructions on configuring communication functions, see Basic Communication Settings. This screen is not displayed if the camera is already connected to the smartphone. Check the SSID. In Live Switcher Mobile, select the camera for the connection. Select [OK].
  • Page 616 No image is recorded to the card during streaming (but a card must be in the camera). Note that Canon is in no way responsible for third-party services. Test streaming in advance to make sure that the image is straight and in the correct orientation, and adjust the orientation as needed.
  • Page 617 Editing/Deleting Devices for Connections Select [ Live Switcher Mobile streaming] ( Select [OK]. Select [Connect]. Select [Edit/delete device].
  • Page 618 Select the device to connect. Select an option. Changing device nicknames You can change the nickname of devices the camera connects to. Deleting connection information You can delete the connection information.
  • Page 619 Reconnecting Using Connection Information The configured connection information can be used to connect again. Select [ Live Switcher Mobile streaming] ( Select [OK]. Select [Connect]. Select the device.
  • Page 620 Check the access point. To switch networks, press the < > button. For instructions on configuring communication functions, see Basic Communication Settings. Start Live Switcher Mobile.

  • Page 621: Basic Communication Settings

    Basic Communication Settings Checking the Type of Access Point Connecting via WPS (PBC Mode) Connecting via WPS (PIN Mode) Connecting Manually to Detected Networks Connecting Manually by Specifying Networks Connecting in Camera Access Point Mode Setting the IP Address...

  • Page 622: Checking The Type Of Access Point

    Checking the Type of Access Point When connecting via an access point, check whether the access point supports WPS*, which simplifies connections between Wi-Fi devices. If you are unsure about WPS compatibility, refer to the access point user manual or other documentation.

  • Page 623: Connecting Via Wps (Pbc Mode)

    Connecting via WPS (PBC Mode) Instructions in this section are continued from Checking the Type of Access Point. This is a connection method used with access points compatible with WPS. In pushbutton connection mode (PBC mode), the camera and access point can be connected simply by pressing the WPS button on the access point.
  • Page 624 Connect to the access point. Press the access point's WPS button. For details on where the button is and how long to press it, refer to the access point user manual. Select [OK] to initiate connection with the access point. The following screen is displayed once the camera is connected to the access point.

  • Page 625: Connecting Via Wps (Pin Mode)

    Connecting via WPS (PIN Mode) Instructions in this section are continued from Checking the Type of Access Point. This is a connection method used with access points compatible with WPS. In PIN code connection mode (PIN mode), an 8-digit identification number indicated on the camera is entered on the access point to establish a connection.
  • Page 626 Enter the PIN code. On the access point, enter the 8-digit PIN code displayed on the camera screen. For instructions on entering PIN codes on the access point, refer to the access point user manual. After entering the PIN code, select [OK] on the camera. Connect to the access point.
  • Page 627 Set the IP address. Go to Setting the IP Address.
  • Page 628 Connecting Manually to Detected Networks Instructions in this section are continued from Checking the Type of Access Point. Connect to an access point by selecting its SSID (or ESS-ID) in a list of active access points nearby. Selecting the access point Select an access point on the [Select a network] screen.
  • Page 629 Entering the access point encryption key Enter the encryption key (password) set on the access point. For details on the encryption key that has been set, refer to the access point's user manual. If the [IP address set.] screen is displayed, go to Setting the IP Address.
  • Page 630 Connecting Manually by Specifying Networks Instructions in this section are continued from Checking the Type of Access Point. Connect to an access point by entering its SSID (or ESS-ID). Entering the SSID Select [Manual settings] on the [Select a network] screen. Enter the SSID (network name).
  • Page 631 Setting the access point authentication method Select the type of security. Select an option and then [OK] to go to the next screen. Entering the access point encryption key Enter the encryption key (password) set on the access point. For details on the encryption key that has been set, refer to the access point's user manual.
  • Page 632 Set the IP address. Go to Setting the IP Address.

  • Page 633: Connecting With Easy Connection

    Connecting in Camera Access Point Mode Camera access point mode is a connection method for directly connecting the camera and other devices via Wi-Fi without using an access point. Two connection methods are available, as follows. Connecting with Easy connection Network settings for camera access point mode are configured automatically.
  • Page 634 Use the other device to connect to the camera. (1) SSID (network name) (2) Encryption key (password) In other device's Wi-Fi settings, select the SSID (network name) shown on the camera screen, then enter the password. Complete the connection settings based on the device to connect to.
  • Page 635 Connecting with Manual connection Network settings for camera access point mode are configured manually. Set [SSID], [Channel setting], and [Encryption settings] on each screen displayed. Select [Manual connection]. Select [OK]. Enter the SSID (network name). Press < > to access the virtual keyboard ( ), then enter the SSID.
  • Page 636 Select a channel setting option. To specify the settings manually, select [Manual setting], then turn the < > dial. Select [OK] to go to the next screen. Select the type of security. Select [OK] to go to the next screen. If you have selected [None], the [IP address setting (IPv4)] screen is displayed ( The same type of security must be set on both the other device and the...
  • Page 637 Enter the password. Press < > to access the virtual keyboard ( ), then enter the password. Select [Auto setting]. Select [OK]. If an error is displayed for [Auto setting], set the IP address manually...
  • Page 638 Use the other device to connect to the camera. (1) SSID (network name) (2) Encryption key (password) Complete connection settings for the communication function.

  • Page 639: Setting The Ip Address Automatically

    Setting the IP Address Select a method of setting the IP address, and then set the IP address on the camera. When IPv6 is used, the camera only connects via IPv6. IPv4 connections are disabled. Setting the IP address automatically Set up the IP address settings automatically.

  • Page 640: Setting The Ip Address Manually

    Setting the IP address manually Set up the IP address settings manually. Note that the items displayed vary depending on the communication function. Select [Manual setting]. Select [OK] to go to the next screen. Select an option to configure. The items displayed vary depending on the communication function. Select an option to access the screen for numerical input.
  • Page 641 Enter the number. Turn the < > dial to switch to other input fields at the top of the screen, and press the < >< > keys to select numbers to enter. Press < > to enter the selected number. To delete the last number entered, select the [ ] button.
  • Page 642 Select an IPv6 option. Select an option and then [OK] to go to the next screen. Select [Enable] to use IPv6. Complete the connection settings based on the device to connect to.

  • Page 643: Reconnecting Via Wi-Fi/Bluetooth

    Reconnecting via Wi-Fi/Bluetooth Connection settings for devices you have connected to via Wi-Fi or Bluetooth are retained on the camera. You can use these settings to reconnect to the same device. Select an option. End any current connections if a message is displayed indicating that communication is in progress or being established with another device.

  • Page 644: Airplane Mode

    Airplane Mode You can temporarily disable Wi-Fi and Bluetooth functions. Select [ : Airplane mode] ( Set to [On]. ] is displayed on the screen. Note ] may not be displayed in still photo shooting, movie recording, or playback, depending on display settings. If it is not displayed, press the < >...

  • Page 645: Wi-Fi Settings

    Wi-Fi Settings Select [ : Wi-Fi settings] ( Select an option. Wi-Fi When the use of electronic devices and wireless devices is prohibited, such as on board airplanes or in hospitals, set it to [Disable]. MAC address You can check the MAC address of the camera. Caution Transferring movies Each movie file is large, and transferring large files over Wi-Fi may take some time.

  • Page 646: Bluetooth Settings

    Bluetooth Settings Select [ : Bluetooth settings] ( Select an option. Bluetooth If you will not use the Bluetooth function, select [Disable]. Bluetooth address You can check the camera's Bluetooth address. Connect to You can check the name and communication status of the paired device.

  • Page 647: Camera Name

    Camera Name You can change the camera name (displayed on smartphones and other cameras) as needed. Select [ : Camera name] ( Change the camera name. Use the virtual keyboard ( ) to enter the camera name. Press the < >...

  • Page 648: Gps Settings

    GPS Settings GPS via Mobile GPS Information Display GPS via Mobile You can use a smartphone to geotag images. Complete these settings after installing the dedicated Camera Connect app ( ) on the smartphone. On the smartphone, activate location services. Establish a Bluetooth connection.
  • Page 649 Select [Enable]. Take the picture. Images are geotagged with the information from the smartphone.

  • Page 650: Gps Information Display

    GPS Information Display You can check the status of smartphone location information acquisition in the GPS connection icon on the screens for still photo shooting or movie recording ( respectively). Gray: Location services are off Blinking: Location information cannot be acquired On: Location information acquired Geotagging images as you shoot Images you shoot while the GPS icon is on are geotagged.
  • Page 651 Caution The smartphone can acquire location information only while it is paired with the camera via Bluetooth. Direction information is not acquired. Acquired location information may not be accurate, depending on traveling conditions or smartphone status. It may take some time to acquire location information from the smartphone after you turn the camera on.

  • Page 652: Error Details

    Error Details You can display details of errors affecting the camera's wireless communication functions. Select [ : Error details] ( Details of errors that have occurred are displayed. For more information on errors, see Responding to Error Messages.

  • Page 653: Responding To Error Messages

    Responding to Error Messages When an error occurs, display the details of the error by following one of the procedures below. Then, eliminate the cause of the error by referring to the examples shown in this chapter. Select [ : Error details]. Select [Error details] on the [Communicating] screen.
  • Page 654 11: Connection target not found In the case of [Connect to smartphone(tablet)], is the app running? • Establish a connection using the app ( In the case of [Connect to EOS Utility], is EOS Utility running? • Start EOS Utility and try to connect again ( Are the camera and the access point set to use the same encryption key for authentication? •...
  • Page 655 Does your network include a router or similar device that serves as a gateway? • If applicable, ask your network administrator for the network gateway address and set it on the camera ( • Make sure that the gateway address setting is correctly entered on all network devices including the camera.
  • Page 656 23: Device with same IP address exists on selected network Is another device on the camera network using the same IP address as the camera? • Change the camera's IP address to avoid using the same address as another device on the network. Otherwise, change the IP address of the device that has a duplicate address.
  • Page 657 64: Cannot connect to wireless LAN terminal Are the camera and the access point set to use the same encryption method? • See the specifications for details on the type of encryption available on the camera If filtering by MAC address is active, is the MAC address of the camera in use registered at the access point? •...
  • Page 658 130: The server is currently busy Please wait a moment and try again The web service is temporarily overloaded. • Try accessing the web service over Wi-Fi again later. 131: Try again An error occurred in the web service Wi-Fi connection. •...
  • Page 659 137: The QR code shown on the camera has expired. Try camera web link setup again. The QR code displayed has expired. • Reconfigure camera web link settings and scan the QR code displayed again on the camera. 161: An error has occurred A streaming error has occurred.

  • Page 660: App Selection For Usb Connections

    Canon app(s) for iPhone Select if you will use an iOS app. For details on the cables required to connect the camera to smartphones, visit the Canon website ( Caution Consider using power over USB or a household power outlet accessory (sold separately) when using the camera over extended periods for [UVC/UAC streaming].

  • Page 661: Resetting Communication Settings

    Resetting Communication Settings All wireless communication settings can be deleted. By deleting the wireless communication settings, you can prevent their information from being exposed when you lend or give your camera to other people. Select [ : Reset communication settings] ( Select [OK].

  • Page 662: Virtual Keyboard Operations

    Virtual Keyboard Operations Input area, for entering text Cursor keys, for moving in the input area Current no. of characters/no. available Keyboard Switch input modes Space Delete a character in the input area Exit input Use the < > dial to move within (1). Use the <...

  • Page 663: Wireless Communication Function Precautions

    Wireless Communication Function Precautions Distance Between the Camera and the Smartphone Installation Location of the Access Point Nearby Electronic Devices Precautions for Using Multiple Cameras If the transmission rate drops, the connection is lost, or other problems occur when using the wireless communication functions, try the following corrective actions.
  • Page 664 Distance Between the Camera and the Smartphone If the camera is too far from the smartphone, a Wi-Fi connection may not be established even when Bluetooth connection is possible. In this case, bring the camera and the smartphone closer together, then establish a Wi-Fi connection. Installation Location of the Access Point When using indoors, install the device in the room where you are using the camera.

  • Page 665: Security

    Security If security settings have not been properly set, the following problems may occur. Transmission monitoring Third parties with malicious intent may monitor wireless LAN transmissions and attempt to acquire the data you are sending. Unauthorized network access Third parties with malicious intent may gain unauthorized access to the network you are using to steal, modify, or destroy information.

  • Page 666: Checking Network Settings

    Checking Network Settings Windows Open the Windows [Command Prompt], then enter ipconfig/all and press the <Enter> key. In addition to the IP address assigned to the computer, the subnet mask, gateway, and DNS server information are also displayed. macOS In macOS, open the [Terminal] application, enter ifconfig -a, and press the <Return> key. The IP address assigned to the computer is indicated in the [enX] item (X: number) next to [inet], in the format “***.***.***.***”.

  • Page 667: Wireless Communication Status

    Wireless Communication Status Wireless communication status can be checked on the screen. Quick Control screen Information display screen during playback (1) Wi-Fi function (2) Wireless signal strength (3) Bluetooth function Screen Communication Status Wi-Fi Function Wireless Signal Strength Wi-Fi: Disable Not Connected Not displayed Wi-Fi: Enable...
  • Page 668 Bluetooth function indicator Bluetooth Function Connection Status Screen Bluetooth Connected Other Than [Disable] Bluetooth Not Connected [Disable] Bluetooth not connected Not displayed...

  • Page 669: Set-Up

    Set-up This chapter describes menu settings on the set-up [ ] tab. to the right of titles indicates functions only available in advanced modes. • Tab Menus: Set-up • Folder Settings • Still Photo File Numbering • Movie Clip Numbering •...

  • Page 670: Tab Menus: Set-Up

    Tab Menus: Set-up File/card setting Folder selection File numbering Clip Number File name Format card Auto rotate rotate info Country/Area/Guidance/Audio settings Date/Time/Zone Language System frequency Feature guide Beep Volume Audio monitor...

  • Page 671: Reset All Settings

    Customize display/Various settings Screen brightness UI magnification HDMI resolution Power saving Reset/All settings Reset camera Custom shooting mode (C1-C3)
  • Page 672 Various settings Battery info. Copyright information Manual/software URL Certification Logo Display Firmware...

  • Page 673: Folder Settings

    Folder Settings Creating a Folder Renaming Folders Selecting a Folder You can create or select the folder for saving still photos. You can also rename folders. Note Movie files are saved in the following folder (with **** indicating the reel number). •...
  • Page 674 Select [OK]. To rename the folder, select [Change folder name].

  • Page 675: Renaming Folders

    Renaming Folders Enter letters and numbers of your choice. You can enter five characters. By selecting [ ], you can change the input mode. Select [ ] to delete a character. Use the < > dial or < > to select a character, then press < >...

  • Page 676: Selecting A Folder

    Selecting a Folder (1) Number of images in folder (2) Lowest file number (3) Folder name (4) Highest file number Select a folder on the folder selection screen. Captured images are stored in your selected folder. Note Folders A folder can contain up to 9999 images (file number 0001–9999). When a folder becomes full, a new folder with the folder number increased by one is created automatically.

  • Page 677: Still Photo File Numbering

    Still Photo File Numbering Continuous Auto Reset Manual Reset Captured still photos saved in a folder are assigned a file number from 0001 to 9999. You can change how the image files are numbered. (Example) (1) File number Select [ : File numbering] (...
  • Page 678 Set the item. Select [Numbering]. Select [Continuous] or [Auto reset]. If you want to reset the file numbering, select [Manual reset] ( Select [OK] to create a new folder, and the file number will start with 0001. Caution If the file number in folder 999 reaches 9999, shooting will not be possible even if the card still has free space.
  • Page 679 Continuous For continuous file numbering regardless of switching cards or creating folders Even after you replace the card or create a new folder, the file numbering continues in sequence up to 9999. This is useful when you want to save images numbered anywhere between 0001 to 9999 on multiple cards or in multiple folders into one folder on a computer.

  • Page 680: Auto Reset

    Auto Reset For restarting file numbering from 0001 after switching cards or creating folders When you replace the card or create a folder, the file numbering restarts from 0001 for the new images saved. This is useful if you want to organize images by cards or folders. If the replacement card or existing folder already contains images recorded previously, the file numbering of the new images may continue from the file numbering of the existing images on the card or in the folder.

  • Page 681: Manual Reset

    Manual Reset For resetting file numbering to 0001 or starting from 0001 in new folders When you reset the file numbering manually, a new folder is created automatically and the file numbering of images saved to that folder starts from 0001. This is useful, for example, if you want to use different folders for the images taken yesterday and the ones taken today.

  • Page 682: Movie Clip Numbering

    Movie Clip Numbering Continuous Auto Reset Recorded movies saved in a folder are assigned a clip number from 001 to 999. You can change how clips are numbered. (Example) (1) Clip number Select [ : Clip Number] ( Set the item. Select [Continuous] or [Auto reset].
  • Page 683 Continuous For continuous file numbering regardless of switching cards Clip numbering is continuous up to 999, even if you replace a card. This is useful when movies numbered between 001 to 999 on multiple cards will be saved in a single folder on a computer, for example.
  • Page 684 Auto Reset For restarting clip numbering from 001 after switching cards Clip numbering is reset to 001 if you replace a card. This is useful if you want to organize movies by cards. Note that numbering may continue after the number of any existing movies on new cards. If you want to save images with the file numbering starting from 001, use a newly formatted card each time.

  • Page 685: File Naming

    File Naming Registering/Changing Still Photo File Names Movie File Name Settings Registering/Changing Still Photo File Names File names consist of four alphanumeric characters followed by a four-digit file number ( and file extension. You can change the first four alphanumeric characters, which by default are unique for each camera and set when the camera is shipped.
  • Page 686 Enter letters and numbers of your choice. Enter four characters for User setting 1 or three for User setting 2. By selecting [ ], you can change the input mode. Select [ ] to delete a character. Use the < >...
  • Page 687 Select a registered file name. Select [File name], then choose a registered file name. Caution An underscore (“_”) cannot be used as the first character. Note Notes on [User setting2] Shooting after you have selected “*** + image size” (as registered to User setting 2) will add a character representing the current image size to your file name as the fourth character.
  • Page 688 Hour, minute, and second, set automatically based on when recording Recording time began. Two characters, from A to Z and 0 to 9, randomly set for each clip Random component (movie file). User-defined field Five characters, from A to Z and 0 to 9. Default: CANON.
  • Page 689 Configuring movie file names Select [ : File name] ( Select [Movies]. Configure movie file name settings. Camera index Enter two characters of your choice. Set defaults for [Reel Number] and [Clip Number] as needed.
  • Page 690 User defined Enter letters or numbers of your choice. • You can enter five characters. • By selecting [ ], you can change the input mode. • Select [ ] to delete a character. • Use the < > or < >...

  • Page 691: Card Formatting

    Card Formatting If the card is new or was previously formatted (initialized) by another camera or computer, format the card with this camera. Caution When the card is formatted, all images and data on the card will be erased. Even protected images will be erased, so make sure there is nothing you need to keep.

  • Page 692: Low-Level Formatting

    Conditions requiring card formatting The card is new. The card was formatted by a different camera or a computer. The card is full of images or data. A card-related error is displayed ( Low-level formatting Perform low-level formatting if the card's writing or reading speed seems slow or if you want to totally erase the data on the card.

  • Page 693: Auto Rotate

    Auto Rotate You can change the auto rotation setting that straightens images shot in vertical orientation when they are displayed. Select [ : Auto rotate] ( Select an option. Automatically rotates images for display on both the camera and computers. Automatically rotates images only for display on computers.
  • Page 694 Caution Images captured with auto rotation set to [Off] will not rotate during playback even if you later set auto rotation to [On]. Note If a picture is taken while the camera is aimed up or down, automatic rotation to the proper orientation for viewing may not be performed correctly.

  • Page 695: Adding Orientation Information To Movies

    Adding Orientation Information to Movies For movies recorded with the camera held vertically, orientation information indicating which side is up can be added automatically to enable playback in the same orientation on smartphones or other devices. Select [ : Add rotate info] ( Select an option.

  • Page 696: Date/Time/Zone

    Date/Time/Zone When you turn on the power for the first time or if the date/time/zone have been reset, follow these steps to set the time zone first. By setting the time zone first, you can simply adjust this setting as needed in the future and the date/time will be updated to match it.
  • Page 697 Use the < >< > keys to select the zone and then press < >. If your time zone is not listed, press the < > button, then set the difference from UTC in [Time difference]. Use the < >< >...
  • Page 698 Set daylight saving time. Set it as necessary. Select [ ] or [ ] and then press < >. When the daylight saving time is set to [ ], the time set in step 3 will advance by 1 hour. If [ ] is set, the daylight saving time will be canceled and the time will go back by 1 hour.

  • Page 699: Language

    Language Select [ : Language Set the desired language.

  • Page 700: System Frequency

    System Frequency Set the video system of any television used for display. This setting determines the frame rates available when you record movies. Select [ : System frequency] ( Select an option. 59.94Hz:NTSC For areas where the TV system is NTSC (North America, Japan, South Korea, Mexico, etc.).

  • Page 701: Feature Guide

    Feature Guide A brief description of functions and items can be displayed when you set the shooting mode or use Quick Control. Select [ : Feature guide] ( Select an option. Sample screen (1) Feature guide Note To clear a description, either tap it or continue performing operations.

  • Page 702: Beeps

    Beeps Select [ : Beep] ( Select an option. Enable Enables beeping when in focus and during touch control, etc. Disable Disables beeping. Note By default, beeping volume for touch operations is set to [0] (...

  • Page 703: Volume

    Volume The volume of camera sounds is adjustable. Select [ : Volume] ( Select an option. Adjusting the volume Adjust the volume with < >< > keys and then press < >.

  • Page 704: Audio Monitor

    Audio Monitor Headphones HDMI Headphones Adjusting the volume Select [ : Audio monitor] ( Select [Headphones]. Select [Volume].
  • Page 705 Adjust the volume. Turn the < > dial to adjust the volume, then press < >. Caution Make sure any headphone output plugs are fully inserted in the camera. Note You can check sound from the built-in microphone or an external microphone on headphones when [ : Sound recording] is set to [On].
  • Page 706 Select [Audio monitoring]. Select an option. Real-time audio (without NR) Audio output without noise reduction. Recorded audio (NR applied) Audio output with noise reduction. Caution Selecting [Recorded audio (NR applied)] results in audio output that is slightly out of sync with video. Audio in recorded movies is not delayed. Selecting output channels for the headphone terminal You can select the combination of channels for output from the headphone terminal during shooting or playback.
  • Page 707 Select [Headphones]. Select [Shoot. monitor CH] or [Playback monitor CH].
  • Page 708 Select the combination of channels for audio output (L/R). Shoot. monitor CH Playback monitor CH CH1+2 indicates that the signal is a combination of channels 1 and 2. The same applies to CH1+3, CH3+4, and so on. Caution There is no sound from channels 3 and 4 for [Playback monitor CH] when you shoot with [ : Audio format] ( ) set to [AAC/16bit/2CH], because no sound is...
  • Page 709 HDMI Selecting output channels for the HDMI output terminal You can select the combination of channels for output from the HDMI output terminal during shooting or playback. Select [ : Audio monitor] ( Select [HDMI]. Select [Shoot. monitor CH] or [Playback monitor CH].
  • Page 710 Select [CH1/CH2] or [CH3/CH4]. Shoot. monitor CH Playback monitor CH Caution No sound is produced when you play a movie recording with [ : Audio format] ) set to [AAC/16bit/2CH] and [Playback monitor CH] set to [CH3/CH4].

  • Page 711: Screen Brightness

    Screen Brightness Select [ : Screen brightness] ( Make the adjustment. Referring to the gray image, use the < >< > keys to adjust the screen brightness and then press < >. Check the effect on the screen. Note To check the image's exposure, referring to the histogram is recommended (...

  • Page 712: Ui Magnification

    UI Magnification You can magnify menu screens by double-tapping with two fingers. Double-tap again to restore the original display size. Select [ : UI magnification] ( Select [Enable]. Caution Use camera controls when configuring menu functions with the display magnified. Touch-screen operations are not supported.

  • Page 713: Hdmi Resolution

    HDMI Resolution Set the image output resolution used when the camera is connected to a television or external recording device with an HDMI cable. Select [ : HDMI resolution] ( Select an option. Auto The images will automatically be displayed at the optimum resolution matching the connected television.

  • Page 714: Power Saving

    Power Saving You can adjust the timing of when the screen dims, when the screen dims and then turns off, and when the camera turns off after the camera is left idle (Screen dimmer, Screen off, and Auto power off). Select [ : Power saving] ( Select an option.

  • Page 715: Resetting The Camera

    Resetting the Camera The camera's settings for shooting functions and menu functions can be restored to their defaults. Select [ : Reset camera] ( Select an option. Basic settings Restores default settings for camera shooting functions and menu settings. Other settings Settings for individual selected options can be reset.

  • Page 716: Custom Recording Mode (C1-C3)

    Custom Recording Mode (C1–C3) Automatic Update of Registered Settings Canceling Registered Custom Recording Modes In < > mode, you can register current camera settings such as recording, menu, and Custom Function settings as Custom recording modes assigned to [C1] to [C3] modes. Select [ : Custom shooting mode (C1-C3)] ( Select [Register settings].
  • Page 717 Register the desired items. Select the Custom recording mode to register, then select [OK] on the [Register settings] screen. The current camera settings are registered to Custom recording mode Depending on the menu items, setting options changed in other recording modes may not be carried over to the Custom recording mode settings.
  • Page 718 Canceling Registered Custom Recording Modes If you select [Clear settings] in step 2, the settings of each mode can be restored to default settings, as they were before registration. Note You can also change recording and menu settings in Custom recording modes.

  • Page 719: Battery Information

    (Green): Battery recharge performance is slightly degraded. (Red): Purchasing a new battery is recommended. Caution Using a genuine Canon Battery Pack LP-E17 is recommended. If you use batteries that are not genuine Canon products, the camera's full performance may not be attained or malfunction may result.

  • Page 720: Copyright Information

    Copyright Information Checking the Copyright Information Deleting the Copyright Information When you set the copyright information, it will be recorded to the image as Exif information. Caution If the entry for “Author” or “Copyright” is long, it may not be displayed entirely when you select [Display copyright info.].
  • Page 721 Enter text. Use the < > keys to select a character and then press < > to enter it. By selecting [ ], you can change the input mode. Select [ ] to delete a character. Exit the setting. Press the < >...
  • Page 722 Deleting the Copyright Information When you select [Delete copyright information] in step 2, you can delete the [Author] and [Copyright] information.

  • Page 723: Other Information

    Other Information Manual/software URL To download instruction manuals, select [ : Manual/software URL] ( ) and scan the displayed QR code with a smartphone. You can also use a computer to access the website at the URL displayed and download software. Certification Logo Display Select [ : Certification Logo Display] ( ) to display some of the logos of the...

  • Page 724: Control Customization

    Control Customization You can assign frequently used functions to camera buttons or dials according to your preferences for easy operations. • Tab Menus: Control Customization • Control Customization Details...

  • Page 725: Tab Menus: Control Customization

    Tab Menus: Control Customization Customized controls when shooting (movie recording) Customize buttons for shooting Shutter btn function for movies Customize dials/control ring Multi function lock Focus/control ring Camera/ optical zoom speed Lens optical zoom speed Customized controls when shooting (still photo shooting) Customize buttons for shooting Customize dials/control ring Touch Shutter...
  • Page 726 Customized controls when playback Customize buttons for playback Image jump w/ Img jump w/ Customized controls/Reset Touch control Clear all customized controls...
  • Page 727 In Basic Zone modes, the following screens are displayed. Customized controls when shooting (movie recording) Shutter btn function for movies Multi function lock Customized controls when shooting (still photo shooting) Touch Shutter Multi function lock Customized controls when playback Image jump w/...
  • Page 728 Customized controls Touch control...

  • Page 729: Control Customization Details

    Control Customization Details [Customized controls when shooting] [Customized controls when playback] [Customized controls/Reset] You can customize camera features on the [ ] tab to suit your shooting preferences. [Customized controls when shooting] [Customize buttons for shooting] You can assign common shooting functions to camera buttons that are easy for you to use. Different functions, for use when shooting still photos or movies, can be assigned to the same button.
  • Page 730 Select a function to assign. Press < > to set it. You can configure advanced settings for functions labeled with ] in the lower left of the screen by pressing the < > button. Note ]: “AF Stop” or “Lens Function” button on super telephoto lenses with Image Stabilizer.
  • Page 731 Functions available for customization ●: Default ○: Available for customization : Metering and AF start ●* ○ ● ○ ○ : AF stop ○ ○ ○ ● : AF point selection ○ ○ ○ ○ ○ ○ ○ ○ ○ : Direct AF point selection ○...
  • Page 732 : Register people priority ○ ○ ○ ○ ○ ○ ○ ○ ○ : Focus mode ○ ○ ○ ○ ● ○ ○ ○ ○ : Peaking ○ ○ ○ ○ ○ ○ ○ ○ ○ : Focus guide ○ ○...
  • Page 733 Exposure Compensation ●: Default ○: Available for customization : AE lock, AF stop ○ ○ ○ ○ : Metering start* ○ : AE lock ○ ○ ○ ○ : AE lock (while button pressed)* ○ : AE lock/FE lock* ○ ○...
  • Page 734 Image ●: Default ○: Available for customization : Silent shutter function* ○ ○ ○ ○ ○ ○ ○ ○ ○ : Image quality* ○ ○ ○ ○ ○ ○ ○ ○ ○ : One-touch image quality setting* ○ ○ ○ ○...
  • Page 735 : Picture Style ○ ○ ○ ○ ○ ○ ○ ○ ○ : Color filter ○ ○ ○ ○ ○ ○ ○ ○ ○ : Select folder ○ ○ ○ ○ ○ ○ * 1: Cannot be assigned as a function available in movie recording. * 2: Cannot be assigned as a function available in still photo shooting.
  • Page 736 Movies ●: Default ○: Available for customization : False color* ○ ○ ○ ○ ○ ○ ○ ○ ○ : Zebra* ○ ○ ○ ○ ○ ○ ○ ○ ○ : Movie recording* ○ ○ ○ ○ ○ : Pause Movie Servo AF* ○...
  • Page 737 Operation ●: Default ○: Available for customization : Flash function settings* ○ ○ ○ ○ ○ ○ ○ ○ ○ ● : Quick flash group control* ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ : Maximize screen brightness (temp) ○...
  • Page 738 Display frame rate setting* ○ ○ ○ ○ ○ ○ ○ ○ ○ : Wi-Fi/Bluetooth connection ○ ○ ○ ○ ○ ○ ○ ○ ○ : Create folder* ○ ○ ○ ○ ○ ○ ○ ○ ○ : No function (disabled) ○...
  • Page 739 Shutter btn function for movies You can set the functions performed by pressing the shutter button halfway or completely during movie recording. Caution In movie recording, the [ : Shutter btn function for movies] setting overrides any function assigned to the shutter button in [ : Customize buttons for shooting].
  • Page 740 Select an option. [Half-press] options [Fully-press] options With [Fully-press] set to [Start/stop mov rec], you can start/stop movie recording not only with the movie shooting button but also by pressing the shutter button completely, or by using a remote switch (sold separately).
  • Page 741 Customize dials/control ring Frequently used functions can be assigned to the < > and < > dials and < > ring. Select [ : Customize dials/control ring] ( Select a camera control. Select a function to assign. Press < > to set it. Note To clear settings configured with [ : Customize dials/control ring], select [...
  • Page 742 Functions available for dials ●: Default ○: Available for customization Function ○ : Change shutter spd. (hold meter. btn) ○ : Change aperture (hold meter. btn) ○ : Set ISO speed(while holding metering button) ● : Exposure comp. (hold meter. btn) ○...
  • Page 743 Touch Shutter Touch Shutter can be specified. When set to [Enable], [ ] display in the lower left of the shooting screen changes to [ ], and Touch Shutter is enabled. For Touch Shutter instructions, see Shooting with the Touch Shutter.
  • Page 744 Multi function lock Specify camera controls to lock when the Multi-function lock is enabled. This can help prevent accidentally changing settings. Select [ : Multi function lock] ( Select camera controls to lock. Select a camera control and press < >...
  • Page 745 Focus/control ring Menu-based switching of lens focus/control ring functionality. Caution Available when using lenses that have a combination focusing ring/control ring but have no switch to switch between these feature. FOCUS: Use as focus ring The ring works as a focusing ring. CONTROL: Use as control ring The ring works as a control ring.
  • Page 746 Camera/ optical zoom speed You can set the optical zoom speed used when zooming with the zoom lever or a wireless remote control. The zoom speed during shooting standby and during movie recording can be set separately. Zoom speed Set the zoom speed. Fast: Suitable for zooming during shooting standby.
  • Page 747 Zoom speed Set the zoom speed. Fast: Suitable for zooming during shooting standby. Slow: Suitable when you prefer slow zooming, such as during movie recording. Speed level Set a zoom speed level (relative to the zoom speed), to zoom faster or slower depending on how much you turn the zoom ring.
  • Page 748 [Customized controls when playback] Customize buttons for playback You can assign common playback functions to camera buttons that are easy for you to use. Select [ : Customize buttons for playback] ( Select a camera control. To switch to [ : Customize buttons for shooting] ( ), press the <...
  • Page 749 Functions available for customization ●: Default ○: Available for customization Function ○ ○ : Protect ○ ○ : Rating ○ ○ : Erase images ○ ○ : Protect (image jump w/ ○ ○ : Rating (image jump w/ ○ ○ : Cropping ○...
  • Page 750 Image jump w/ To set how the camera jumps through images, you can turn the < > dial on the playback screen in single-image display. Note With [Jump images by the specified number], you can turn the < > dial to select the number of images to jump by.
  • Page 751 Img jump w/ To set how the camera jumps through images, you can turn the < > dial while pressing the button assigned to [ ] on the playback screen in single-image display. Note You can configure this function when assigning [ ] or [ ] to a button in : Customize buttons for playback] (...
  • Page 752 [Customized controls/Reset] Touch control [Sensitive] makes the touch-screen panel more responsive than [Standard]. To disable touch operations, select [Disable]. Caution Precautions for touch-screen panel operations Do not use sharp objects such as fingernails or ballpoint pens for touch operations. Do not use wet fingers for touch operations. If the screen has any moisture or if your fingers are wet, the touch-screen panel may not respond or malfunction may occur.
  • Page 753 Clear all customized controls Selecting [ : Clear all customized controls] clears all control customization settings.

  • Page 754: Custom Functions/My Menu

    Custom Functions/My Menu You can fine-tune camera functions and change the functionality of buttons and dials to suit your shooting preferences. You can also add menu items and Custom Functions that you adjust frequently to My Menu tabs. • Tab Menus: Custom Functions •...

  • Page 755: Tab Menus: Custom Functions

    Tab Menus: Custom Functions Exposure C.Fn ISO expansion Safety shift Other C.Fn/Reset Release shutter w/o lens Retract lens on power off Clear all Custom Func. (C.Fn) Selecting [ : Clear all Custom Func. (C.Fn)] clears all Custom Function settings.

  • Page 756: Custom Function Setting Items

    Custom Function Setting Items Exposure C.Fn Other C.Fn/Reset You can customize camera features on the [ ] tab to suit your shooting preferences. Any settings you change from default values are displayed in blue.
  • Page 757 Exposure C.Fn ISO expansion Makes “H” (equivalent to ISO 51200 in still photo shooting and ISO 25600 in movie recording) available as an ISO speed in manual selection. Note that “H” is not available with : Highlight tone priority] set to [Enable] or [Enhanced]. OFF: Disable ON: Enable Safety shift...
  • Page 758 Other C.Fn/Reset Release shutter w/o lens You can specify whether shooting still photos or movies is possible without a lens attached. OFF: Disable ON: Enable Retract lens on power off You can set whether to retract gear-type STM lenses (such as RF35mm F1.8 Macro IS STM) automatically when the camera's power switch is set to <...

  • Page 759: Tab Menus: My Menu

    Tab Menus: My Menu Add My Menu tab Delete all My Menu tabs Delete all items Menu display...

  • Page 760: Registering My Menu

    Registering My Menu Creating and Adding My Menu Tabs Registering Menu Items on My Menu Tabs My Menu Tab Settings Deleting All My Menu Tabs/Deleting All Items Menu Display Settings On the My Menu tab, you can register menu items and Custom Functions you often adjust.
  • Page 761 Creating and Adding My Menu Tabs Select [Add My Menu tab] ( Select [OK]. You can create up to five My Menu tabs by repeating steps 1 and 2.
  • Page 762 Registering Menu Items on My Menu Tabs Select [MY MENU*: Configure]. Select [Select items to register]. Register the desired items. Select an item, then press < >. Select [OK] on the confirmation screen. You can register up to six items. To return to the screen in step 2, press the <...
  • Page 763 My Menu Tab Settings You can sort and delete items on the menu tab, and rename or delete the menu tab itself. Sort registered items You can change the order of the registered items in My Menu. Select [Sort registered items], select an item to rearrange, then press <...
  • Page 764 Rename tab You can rename the My Menu tab from [MY MENU*]. Select [Rename tab]. Enter text. Use the < > keys to select a character and then press < > to enter it. By selecting [ ], you can change the input mode. Select [ ] to delete a character.
  • Page 765 Deleting All My Menu Tabs/Deleting All Items You can delete all the created My Menu tabs or My Menu items registered on them. Delete all My Menu tabs You can delete all My Menu tabs you created. When you select [Delete all My Menu tabs], all the tabs from [MY MENU1] to [MY MENU5] will be deleted and the [ ] tab will revert to its default.

  • Page 766: Menu Display Settings

    Menu Display Settings You can select [Menu display] to set the menu screen that is to appear first when you press the < > button. Normal display Displays the last displayed menu screen. Display from My Menu tab Displays with the [ ] tab selected.

  • Page 767: Reference

    Reference This chapter provides reference information on camera features. • Importing Images to a Computer • Importing Images to a Smartphone • Using a USB Power Adapter to Charge/Power the Camera • Troubleshooting Guide • Error Codes • Information Display •...

  • Page 768: Importing Images To A Computer

    Importing Images to a Computer Connecting to a Computer with an Interface Cable Using a Card Reader Connecting to a Computer via Wi-Fi You can use EOS software to import images from the camera to a computer. Connecting to a Computer with an Interface Cable Install EOS Utility ( In [ : Choose USB connection app], select [Photo Import/Remote...
  • Page 769 Caution With a Wi-Fi connection established, the camera cannot communicate with the computer even if they are connected with an interface cable.

  • Page 770: Using A Card Reader

    Using a Card Reader You can use a card reader to import images to a computer. Install Digital Photo Professional ( Insert the card into the card reader. Use Digital Photo Professional to import the images. Refer to the Digital Photo Professional Instruction Manual. Note When using a card reader instead of EOS software to transfer images from the camera to a computer, copy the folders on the card (DCIM and XFVC) to the...

  • Page 771: Connecting To A Computer Via Wi-Fi

    Connecting to a Computer via Wi-Fi You can connect the camera to the computer via Wi-Fi and import images to the computer...

  • Page 772: Importing Images To A Smartphone

    When using AD-P1, refer to the instruction manual included with AD-P1. Use of a Canon USB cable (Interface Cable IFC-100U or IFC-400U) is recommended when connecting Android smartphones. For details on USB cables used to connect iPhones, visit the Canon...
  • Page 773 Using Camera Connect Install Camera Connect on the smartphone and start it. For details on installing Camera Connect, see “Installing Camera Connect on a Smartphone” ( Turn the camera on. Tap [Images on camera]. Select images displayed to import them to the smartphone.
  • Page 774 Using Smartphone Features Turn the camera on. Use the smartphone to import images. Android smartphones: Use Camera Connect to import images ( iPhones: Start the Photos app, then import images from the card.

  • Page 775: Using A Usb Power Adapter To Charge/Power The Camera

    Using a USB Power Adapter to Charge/Power the Camera Using USB Power Adapter PD-E2 (sold separately), you can charge Battery Pack LP-E17 without removing it from the camera. The camera can also be powered. Charging Connect the USB power adapter. With the camera power switch set to <...

  • Page 776: Supplying Power

    Connect the power cord. Connect the power cord to the USB power adapter and plug the other end into a power outlet. Charging begins, and the access lamp (1) is lit in green. When charging is finished, the access lamp turns off. Supplying power To power the camera without charging batteries, set the camera power switch to <...
  • Page 777 If the problem persists, take the camera to the nearest Canon Service Center. The charging time required and the amount charged vary depending on ambient temperature and remaining capacity.

  • Page 778: Troubleshooting Guide

    (1) there is a problem with the battery charger or battery, or (2) communication with a non-Canon battery has failed. In the case of (1), unplug the charger's power plug from the power outlet, reattach the battery, wait a few minutes, and then reconnect the power plug to the power outlet.
  • Page 779 In this case, unplug the power cord, reattach the battery, and wait a few minutes before plugging it in again. If the problem persists, take the camera to the nearest Canon Service Center. If batteries are hot or cold, the access lamp blinks in green and a protective circuit stops charging.
  • Page 780 [Battery communication error. Does this battery/ do these batteries display the Canon logo?] is displayed. Do not use any battery packs other than a genuine Canon Battery Pack LP-E17. Remove and install the battery again ( If the electrical contacts are dirty, use a soft cloth to clean them.
  • Page 781 Shooting-related problems The lens cannot be attached. To attach EF or EF-S lenses, you will need a mount adapter. The camera cannot be used with EF-M lenses ( No images can be shot or recorded. Make sure the card is properly inserted ( Slide the card's write-protect switch to the Write/Erase setting ( If the card is full, replace the card or delete unnecessary images to make space Shooting is not possible if the AF point turns orange when you attempt to focus.
  • Page 782 / Maximum burst for continuous shooting is based on the standard Canon test card, and the actual maximum burst is higher for cards with faster writing speeds. For this reason, estimated maximum burst may differ from actual maximum burst.
  • Page 783 Expanded ISO speeds cannot be selected for still photo shooting. Set [ : ISO expansion] to [Enable] ( Check the [ISO speed] setting in [ ISO speed settings]. Expanded ISO speeds (H) are not available when [ : Highlight tone priority] is set to [Enable] or [Enhanced], even with [ : ISO expansion] set to [Enable].
  • Page 784 The Speedlite always fires at full output. Flash units other than EL/EX series Speedlites used in autoflash mode always fire at full output ( The flash always fires at full output when [Flash metering mode] in external flash Custom Function settings is set to [1:TTL] (autoflash) ( External flash exposure compensation cannot be set.
  • Page 785 The ISO speed cannot be set for movie recording. ISO speed is set automatically in [ ]/< >/< > recording mode. In [ ] mode, you can manually set the ISO speed ( The minimum speed in the ISO speed range is ISO 200 when [ : Highlight tone priority] is set to [Enable] or [Enhanced].
  • Page 786 The subject looks distorted during movie recording. If you move the camera to the left or right (panning) or shoot a moving subject, the image may look distorted. The problem may be more noticeable in time-lapse movie recording. Sound is not recorded in movies. Sound is not recorded in S&F recording.
  • Page 787 Problems with wireless features Cannot pair with a smartphone. Use a smartphone compliant with Bluetooth Specification Version 4.1 or later. Turn on Bluetooth from the smartphone settings screen. Pairing with the camera is not possible from the smartphone's Bluetooth settings screen. Install the dedicated app Camera Connect (free of charge) on the smartphone ( Pairing with a previously paired smartphone is not possible if pairing information registered for another camera remains on the smartphone.
  • Page 788 Operation problems Settings change when I switch from still photo shooting to movie recording or vice versa. Separate settings are retained for use when shooting still photos and recording movies. Touch operation is not possible. Make sure [ : Touch control] is set to [Standard] or [Sensitive] ( A camera button or dial does not work as expected.
  • Page 789 Display problems The menu screen shows fewer tabs and items. Tabs and items on the menu screen vary for still photos and movies. The display starts with [ ] My Menu, or the [ ] tab alone is displayed. [Menu display] on the [ ] tab is set to [Display from My Menu tab] or [Display only My Menu tab].
  • Page 790 Playback problems A red box is displayed on the image. : AF point disp.] is set to [Enable] ( During image playback, the AF points are not displayed. AF points are not displayed when the following types of images are played back: •...
  • Page 791 Movie playback stops by itself. Extended movie playback or movie playback under high ambient temperature may cause the camera's internal temperature to rise, and movie playback may stop automatically. If this happens, playback is disabled until the camera's internal temperature decreases, so turn off the power and let the camera cool down a while.
  • Page 792 Computer connection problems I cannot import images to a computer. Install EOS Utility (EOS software) on the computer ( Make sure the main EOS Utility window is displayed. If the camera is already connected via Wi-Fi, it cannot communicate with any computer connected with an interface cable.
  • Page 793 If you cannot remove the dirt or moisture, contact a Canon Service Center. If [Accessory unavailable status] is displayed, check the terminals of the multi-function shoe and accessory and make sure the accessory is not damaged.

  • Page 794: Error Codes

    Error Codes (1) Error number (2) Cause and countermeasures If there is a problem with the camera, an error message will appear. Follow the on-screen instructions. If the problem persists, write down the error code (Err xx) and request service.

  • Page 795: Information Display

    Information Display Still Photo Shooting Screen Movie Recording Screen Scene Icons Playback Screen Still Photo Shooting Screen Each time you press the < > button, the information display will change. The display will show only the settings currently applied.
  • Page 796 Maximum burst Number of available shots/Sec. until self-timer shoots Shooting mode AF area AF operation Subject to detect Image quality Still image aspect ratio Electronic level (10) AF point (1-point AF) (11) Battery level (12) Quick Control button (13) Anti-flicker shooting (14) White balance/White balance correction (15)
  • Page 797 (20) Drive mode (21) Touch Shutter (22) Shutter speed (23) Aperture value (24) Wi-Fi function (25) Wi-Fi signal strength (26) Bluetooth function (27) ISO speed (28) Highlight tone priority (29) Exposure compensation Note You can specify the information displayed in response to pressing the < >...
  • Page 798 Movie Recording Screen Each time you press the < > button, the information display will change. The display will show only the settings currently applied. Battery level Movie recording time available/Elapsed recording time Shooting mode AF area Subject to detect Movie recording size Electronic level AF point (1-point AF)
  • Page 799 (17) Audio recording level indicator (18) Movie Servo AF (19) Shutter speed (20) Overheat control (21) Aperture value (22) Wi-Fi function (23) Wi-Fi signal strength (24) Magnify button (25) Bluetooth function (26) ISO speed (27) Highlight tone priority (28) Exposure compensation (29) Exposure level indicator (metering levels) Caution...
  • Page 800 Scene Icons In < > or [ ] recording mode, the camera detects the type of scene and configures all settings accordingly. The detected scene type is indicated in the upper left of the screen. People Subjects Other Than People Subject Background Color Nature/...

  • Page 801: Playback Screen

    Playback Screen Basic information display for still photos Bluetooth function Wi-Fi signal strength Wi-Fi function Battery level Current image no./Total images/No. of images found Shutter speed Aperture value Exposure compensation amount Rating (10) Image protection (11) Folder no.-File no. (12) Image quality/Edited image/Cropping/Frame Grab (13) ISO speed...
  • Page 802 Caution If the image was taken by another camera, certain shooting information may not be displayed. It may not be possible to play back images taken with this camera on other cameras.
  • Page 803 Detailed information display for still photos 1 Aperture value Picture Style/Settings Shutter speed WB correction Shooting mode/Frame Grab White balance Flash exposure compensation amount/Bounce First image of scene Image quality/Edited image/Cropping (10) HDR shooting (11) Exposure compensation amount (12) Shooting date and time (13) Histogram (Brightness/RGB) (14)
  • Page 804 Detailed information display for still photos 2 Auto Lighting Optimizer * For simplicity, explanations are omitted for items that are also included in Basic information display for still photos Detailed information display for still photos 1, which are not shown here.
  • Page 805 Basic information display for movies Movie playback Vertical information display for movies Reel and clip numbers Recording time/Time code * For simplicity, explanations are omitted for items also included in Basic information display for still photos, which are not shown here.
  • Page 806 Detailed information display for movies 1 Movie recording mode Movie recording size Frame rate Compression method Picture Style (image characteristics/setting details)/Color filter/Custom Picture Recording time/Time code Bit rate * For simplicity, explanations are omitted for items that are also included in Basic information display for still photos, Detailed...
  • Page 807 Detailed information display for movies 2 Movie file name Movie auto level Image Stabilizer (Movie digital IS) Movie recording format * For simplicity, explanations are omitted for items that are also included in Basic information display for still photos, Detailed information display for still photos Basic information display for movies, and...

  • Page 808: Specifications

    Lens mount: Canon RF mount Compatible lenses: Canon RF lens group (including RF-S lenses) * Canon EF or EF-S lenses (excluding EF-M lenses) also compatible, using Mount Adapter EF-EOS R Lens focal length: Approx. 1.6 times the focal length indicated on the lens...

  • Page 809: Recording Media

    Recording media Recording media Single slot: SDXC/SDHC/SD memory card * UHS-II/UHS-I/UHS speed class/SD speed class supported Still photo recording Recording pixel count Resolution (Pixels) Image size Still photo aspect ratio 16:9 Approx. 21.3 Approx. 20.2 24.0 megapixels 16.0 megapixels megapixels* megapixels* (6000×4000) (4000×4000)
  • Page 810 3140 RAW+HEIF* 16.9 + 9.0 4730 * 1: Maximum burst applies to 128 GB UHS-II cards conforming to Canon testing standards. * 2: When [ HDR shooting (PQ): Disable] is set. * 3: When [ HDR shooting (PQ): HDR PQ] is set.

  • Page 811: Movie Recording

    Movie recording Movie recording format Movie recording Color sampling Video codec Bit depth File extension format method XF-HEVC S YCC422 H.265 / HEVC YCbCr 4:2:2 10 bits 10 bit XF-HEVC S YCC420 H.265 / HEVC YCbCr 4:2:0 10 bits 10 bit XF-AVC S YCC422 H.264 / MPEG-4 AVC YCbCr 4:2:2...
  • Page 812 Movie recording size Frame rate Compres- Recording sion Resolution format method 119.88 100.00 59.94 50.00 29.97 25.00 23.98 HEVC S YCC422 4K Crop 10 bit HEVC S YCC420 10 bit Standard XF-AVC LGOP Full HD Yes* Yes* YCC422 10 bit XF-AVC YCC420 8 bit...
  • Page 813 Movie recording angle of view Recording angle of view (Approx. %) Resolution Horizontal Vertical 84.4 4K Crop 64.0 54.0 Full HD 84.3 * The above values are based on the angle of view of still photo (JPEG/HEIF) being 100%. Built-in microphone: Stereo microphones External microphone (External microphone IN terminal): 3.5 mm diameter stereo mini jack (3-pin) * Stereo Microphone DM-E100 is recommended if plug-in power will be used.
  • Page 814 Estimated recording time, video bit rate, file size, and card performance requirements Total recording time per card Card Video bit Compres- (approx.) File size perfor- Recording Frame rate rate sion (Approx. mance format (fps) (Approx. method MB/min.) require- 64 GB 128 GB 512 GB Mbps)
  • Page 815 4K Crop Total recording time per card Card Video bit Compres- (approx.) File size perfor- Recording Frame rate rate sion (Approx. mance format (fps) (Approx. method MB/min.) require- 64 GB 128 GB 512 GB Mbps) ments XF-HEVC Video 59.94 Standard 1 hr.
  • Page 816 Full HD Total recording time per card Card Video bit Compres- (approx.) File size perfor- Recording Frame rate rate sion (Approx. mance format (fps) (Approx. method MB/min.) require- 64 GB 128 GB 512 GB Mbps) ments 119.88 1 hr. 25 2 hr.
  • Page 817 119.88 SD Speed 2 hr. 1 4 hr. 2 16 hr. 11 Class 10 min. min. min. or higher 100.00 59.94 XF-AVC S Standard YCC420 8 50.00 LGOP SD Speed 4 hr. 2 8 hr. 4 32 hr. 15 29.97 Class 6 or min.
  • Page 818 S&F movies (PAL) Rec time Maximum: 1 hr. 50.00 50 / 25 / 12 / 6 / 3 / 2 / 1 Maximum: 2 hr. Maximum: 30 min. 25.00 Maximum: 1 hr. 25 / 12 / 6 / 3 / 2 / 1 Maximum: 2 hr.

  • Page 819: Autofocus (Af)

    * Applies when an RF or RF-S lens without a focus mode switch is used. * When lenses with a focus mode switch are used, the setting on the lens takes precedence. Lens compatibility based on AF area: Refer to the Canon website ( Number of AF area available for automatic selection Horizontal: Approx.

  • Page 820: Hdmi Output

    Screen Type: TFT color LCD screen Screen size: Approx. 7.5 cm (3.0-inch) (aspect ratio of 3:2) Dot count: Approx. 1,040,000 dots Angle of view: Approx. 150° vertically and horizontally Coverage: Approx. 100% vertically and horizontally (at L image size and an aspect ratio of 3:2) Touch-screen: Capacitive sensing HDMI output...
  • Page 821 ISO speed (recommended exposure index) in still photo shooting Manual ISO speed setting for still photos ISO speed Normal ISO speed ISO 100–32000 (in 1/3-stop increments) Expanded ISO speeds* H (equivalent to ISO 51200) * 1: Expanded ISO speeds available when C.Fn [ISO expansion: Enable] is set. * When set to [Highlight tone priority], the available manual setting range is ISO 200–32000.
  • Page 822 ISO speed setting (when M mode is set) Custom Picture ISO speed Off* ISO 100–12800 Canon 709 / PQ / HLG / Canon Log Normal ISO speed ISO 400–12800 BT.709 Standard* ISO 160–12800 H (equivalent to ISO 16000, 20000, or...
  • Page 823 Setting range Electronic 1st-curtain 1/4000–30 sec., bulb Electronic shutter 1/8000–30 sec., bulb Flash sync speed EL/EX Speedlite Non-Canon flash unit Electronic 1st-curtain 1/250 sec. 1/250 sec. Movie recording Type: Rolling shutter, using the image sensor Shutter speed: 1/4000–1/8 sec. * The minimum value varies by shooting mode and frame rate.

  • Page 824: External Flash

    Drive Drive mode and continuous shooting speed [Max. approx.] Drive mode AF operation Electronic 1st-curtain Electronic shutter Single shooting One-Shot AF High-speed continuous AI Focus AF 12 shots/sec. 15 shots/sec. shooting + Servo AF One-Shot AF High-speed continuous AI Focus AF 7.6 shots/sec.

  • Page 825: External Interface

    +23°C / 73°F * 1: Based on CIPA standards. * 2: According to Canon measurement conditions, which are based on CIPA standards. * With a new, fully charged LP-E17 * The number of shots available may vary greatly depending on the shooting environment.
  • Page 826 Available operating time Available operating Conditions of use Temperature time Time available for bulb exposure +23°C / 73°F Approx. 3 hr. Time available for Live View shooting +23°C / 73°F Approx. 3 hr. 10 min. +23°C / 73°F Approx. 1 hr. 10 min. 29.97 / 25.00 fps 0°C / 32°F Approx.

  • Page 827: Dimensions And Weight

    Dimensions and weight Dimensions Exterior color Dimensions (W) × (H) × (D) Black / White Approx. 119.3 × 73.7 × 45.2 mm / 4.70 × 2.90 × 1.78 in. * Based on CIPA guidelines. Weight Exterior color Measurement conditions Weight Body (including battery and card)* Approx.

  • Page 828: Wi-Fi (Wireless Lan)

    Wi-Fi (wireless LAN) Supported standards (equivalent to IEEE 802.11b/g/n/a/ac standards) Maximum link speed Wi-Fi standards Transmission method (equivalent) 5 GHz band 2.4 GHz band IEEE 802.11ac 433 Mbps IEEE 802.11n 150 Mbps 72 Mbps OFDM modulation (CSMA / CA) IEEE 802.11a 54 Mbps IEEE 802.11g 54 Mbps...
  • Page 829 Standards compliance: Bluetooth Specification Version 5.1 compliant (Bluetooth Low Energy technology) Transmission method: GFSK modulation All data above is based on Canon testing standards and CIPA (Camera & Imaging Products Association) testing standards and guidelines. Dimensions and weight listed above are based on CIPA Guidelines (except weight for camera body only).

  • Page 830: Trademarks And Licensing

    The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Canon Inc. is under license. Other trademarks and trade names are those of their respective owners. USB Type-C™ and USB-C™ are trademarks of USB Implementers Forum.
  • Page 831 About MPEG-4 Licensing "This product is licensed under AT&T patents for the MPEG-4 standard and may be used for encoding MPEG-4 compliant video and/or decoding MPEG-4 compliant video that was encoded only (1) for a personal and non-commercial purpose or (2) by a video provider licensed under the AT&T patents to provide MPEG-4 compliant video.
  • Page 832 This product is designed to achieve optimum performance when used with genuine Canon accessories. Therefore, using this product with genuine accessories is highly recommended. Canon shall not be liable for any damage to this product and/or accidents such as malfunction, fire, etc. caused by the failure of non-genuine Canon accessories (e.g., a leakage and/or explosion of a battery).

Table of Contents

Save PDF
