  • Page 1 Operating Instructions EKS2 programming station...

  • Page 2: Table Of Contents

    8.1. LED displays ..........................6 8.2. Status and error messages ......................7 Technical data ...................... 8 9.1. Technical data for EKS2 programming station ...................8 9.2. Dimension drawing for EKS2 programming station ................8 9.3. Radio frequency approvals.......................9 Inspection and service ..................10 Disposal ......................10 Service ......................

  • Page 3: About This Document

    1. About this document 1.1. Scope These operating instructions are valid for the programming station EKS2-P-USB-N-I1B0-C1-172018. The operating instruc- tions, the supplementary documents and any enclosed data sheets form the complete user information for your device. They apply to: Product version (hardware version)

  • Page 4: Correct Use

    EKS and EKS2 Electronic-Keys on a standard PC. The device is only allowed to be operated using Electronic-Keys and connection components that meet EUCHNER requirements. If unsuitable Electronic-Keys or other connection components are used, EUCHNER provides no warranty for correct function.

  • Page 5: Function

    There must only be one transponder on the read surface. 7. Updating firmware The firmware in the programming station can be updated via the related EUCHNER application software. You will find further information in the related software manuals. MAN20001744-01-08/24 (translation of the original operating instructions)

  • Page 6: Status And Error Messages

    LED displays Color red, green, yellow STATE red, green, yellow The LED displays on the EKS2 programming station indicate the individual status and error messages. LED not illuminated LED illuminated 1x inverse LED illuminated, briefly goes off 1 x Key to symbols...

  • Page 7: Status And Error Messages

    1 Hz Updating the firmware. green 2 Hz yellow Error during firmware update Resettable error: error can be acknowledged by briefly disconnecting the USB connection. yellow Non-resettable error: contact the EUCHNER support team. MAN20001744-01-08/24 (translation of the original operating instructions)

  • Page 8: Technical Data

    Operating Instructions EKS2 programming station 9. Technical data NOTICE If a data sheet is available for the product, the information on the data sheet applies. 9.1. Technical data for EKS2 programming station Value Parameter Unit min. typ. max. General Material...

  • Page 9: Radio Frequency Approvals

    Operating Instructions EKS2 programming station 9.3. Radio frequency approvals FCC ID: 2AJ58 - 22 22052 - 22 FCC/IC-Requirements This device complies with part 15 of the FCC Rules and with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 10: Inspection And Service

    13. Declaration of conformity The product complies with the requirements according to Machinery Directive 2006/42/EC. The EU declaration of conformity can be found at www.euchner.com. Enter the order number of your device in the search box. The document is available under Downloads.
  • Page 11 Operating Instructions EKS2 programming station MAN20001744-01-08/24 (translation of the original operating instructions)
  • Page 12 70771 Leinfelden-Echterdingen info@euchner.de www.euchner.com Edition: MAN20001744-01-08/24 Title: Operating Instructions EKS2 programming station (translation of the original operating instructions) Copyright: © EUCHNER GmbH + Co. KG, 08/2024 Subject to technical modifications; no responsibility is accept- ed for the accuracy of this information.
