- Page 1 Wharfedale Pro DP-8015i User Manual DP-8015i Multi-channel Amplifier DP-8015i X dB X dB BRIDGE X dB X dB X dB X dB STEREO 100V X dB X dB...
- Page 3 IMPORTANT WARNINGS & SAFETY INSTRUCTIONS 1. Read these instructions 2. Follow all instructions 3. Keep these instructions 4. Heed all warnings 5. Do not use this apparatus near water 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8.
-
Page 4: Warning Sign
With the DNA from our DP series, the new DP-8015i has the dedicated hardware features for installation. Joining the established DP-4035i in the series, the new DP-8015i delivers 8 x 150 W across low-impedance (2-8 Ω) and highimpedance (70 V/100 V) systems, and also supports Bridge mode for up to 4 x 300 W at 4-16 Ω, making it incredibly adaptable to a wide range of applications. -
Page 5: Packing List
10 pcs Power cord 1 pc 4P Plug-in connector, pitch: 7.62 mm 4 pcs User manual 1 pc Rubber feet 4 pcs Outline dimensions DP-8015i X dB X dB BRIDGE X dB X dB X dB X dB STEREO 100V... -
Page 6: Power Cord
Cooling instructions The cooling mode of the equipment is as follows: Cold air is sucked through the ventilation holes of the front panel and the heat is expelled from the rear panel. To ensure good heat dissipation, please keep the equipment in the 0-~40 degrees range and ensure that the front and rear panel airways are clear. - Page 7 Low-Z Bridge Mode Low-Z MONO Mode...
- Page 8 High-Z 100 V Mode High-Z 70 V Mode...
-
Page 9: Speaker Protection
Operating instructions Before installation, make sure that the power cord is not connected to the power outlet; the power switch is turned off; the volume knob is completely closed (counterclockwise to the limit). Speaker protection Clipping not only distorts the sound, but it also damages the transducers (drivers) of your loudspeakers. If clipping occurs, reduce the input signal level to avoid clipping. -
Page 10: Operating Panel
Operating Panel DP-8015i X dB X dB BRIDGE X dB X dB X dB X dB STEREO 100V X dB X dB DP-8015i X dB X dB BRIDGE X dB X dB X dB X dB STEREO 100V X dB... - Page 11 Operating Panel Icon Function Illustration Power Input IEC 10 A Connector, 3 x 1.0 mm2 Power cord. Ultra quiet variable speed fans. Plug-in connector (pitch: 7.62 mm): When the amplifier is in Stereo or Mono mode, Loudspeaker A is connected to A+ and A-, Loudspeaker B is connected to B+ and B-, Output Connector and so on;...
-
Page 12: Specifications
Specifications Model DP-8015i Stereo Power Output 8 ohms 4 ohms 2 ohms 8 x 150 W Bridge Power Output 8 ohms 4 ohms 2 ohms 4 x 300 W Hi-Z Power Output 100V 70V 8 x 150 W Rear panel Input Connectors Plug-in connector pitch: 3.81 mm... -
Page 13: Power Consumption And Heat
Power consumption and heat Test signal: Pink Noise, bandwidth limited from 22 Hz to 22 kHz 1/8 power is typical of program material with occasional clipping. Refer to these figures for most applications. 1/3 power represents program material with extremely heavy clipping. 8 x 150 W Line Current (A) Power (W) -
Page 14: System Example
Mixer XC-44N / XC-44F GPL-5T GPL-5T GPL-28B GPL-8T GPL-8T Level * Control Level Control Remote ON/OFF switch DP-8015i DP-8015i Level Front Display Control DP-8015i X dB X dB BRIDGE X dB X dB X dB X dB 3 x GPL-5T... -
Page 16: Wharfedale Pro Limited Warranty
WHARFEDALE PRO LIMITED WARRANTY Wharfedale Pro products are warranted of manufacturing or material defects for a period of three years from the original date of purchase. In the event of malfunction, contact your authorised Wharfedale Pro dealer or distributor for information.
