- Page 1 DR SERIES PROFESSIONAL POWER AMPILIFIER USER MANUAL DR6000 DR4800 CLIP SIGNAL FAULT POWER/BRIDGE CH-A CH-B DR4800 CLIP SIGNAL FAULT POWER/BRIDGE CH-A CH-B DR6000 www.wharfedalepro.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS ....................1 IMPORTANT WARNINGS & SAFETY INSTRUCTIONS ..........2 INTRODUCTION ......................3 FEATURES ........................3 FRONT PANEL INFORMATION ..................4 REAR PANEL INSTRUCTION ..................5 POWER CONNECTION WARNINGS ................5 INPUT CONNECTIONS ....................6 .................... -
Page 3: Important Warnings & Safety Instructions
IMPORTANT WARNINGS & SAFETY INSTRUCTIONS 1. Read these instructions 2. Follow all instructions 3. Keep these instructions 4. Heed all warnings 5. Do not use this apparatus near water 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. -
Page 4: Introduction
INTRODUCTION The DR series are robust and durable amplification solutions for installation or for live sound. Anywhere where ‘bang for buck’ reliable power is needed. The DR4800 and DR6000 deliver powerful performance and exceptional durability, housed in a robust 2U steel chassis. -
Page 5: Front Panel Information
FRONT PANEL INFORMATION CLIP SIGNAL FAULT POWER/BRIDGE CH-A CH-B 1. CLIP LED: Each channel is indicated separately. When the input signal is too high to cause the amplifier output clipping, the CLIP indicator will flash and light up. With short flickers, clip distortion is almost not felt, but too large and continuous clipping may damage the connected loudspeakers and will cause sound quality deterioration. -
Page 6: Rear Panel Instruction
1.5 times the power supply margin. - The power input of the DR Series power amplifier does not use a fuse, but instead uses an overload circuit breaker. This avoid difficulties in replacing the fuse after abnormal operation. If the circuit breaks automatically when working, please turn off... -
Page 7: Input Connections
- WARNING: In PARALLEL mode, avoid inputting signals into both channel input sockets simultaneously. OUTPUT CONNECTIONS The DR Series use speakON output connectors. Ensure that only heavy gauge two conductor speaker cables with professionally wired speakON connectors are used for connection from amplifier to loudspeaker. -
Page 8: Amplifier Cooling
AMPLIFIER COOLING DR Series keep cool by sucking cold air from the front and pushing hot air out of the rear. Always leave suffient space around the amplifier to allow for smooth airflow, and ensure that it is used in the temperature range of -10 °... -
Page 9: Wiring Diagrams
WIRING DIAGRAM STEREO CONNECTIONS Switches Selection MODE PARALLEL AC XXXV~50/60Hz XXXXW STEREO BRIDGE Speaker: + to PIN 1+ SENSITIVITY Speaker: - to PIN 1- SPEAKER POWER OUTPUTS 35dB 0.775V OUT CH B IN CH 2 IN CH 1 OUT CH A INPUT Balanced XLR PARALLEL CONNECTIONS... -
Page 10: Specification
SPECIFICATION Model Name DR4800 DR6000 Rated Power per Ch. 1450 W 1900 W Rated Power per Ch. 2500 W 3150 W 2900 W 3900 W 3500 W 4700 W THD+N 43.5 dB 42.5 dB > 300 Class D Crosstalk 0.775 V / 1 V / 35 dB Input Impedance Input Connecter 2 balanced XLRs per channel... -
Page 11: Warranty
WHARFEDALE PRO LIMITED WARRANTY Wharfedale Pro products are warranted of manufacturing or material defects for a period of one year from the original date of purchase. In the event of malfunction, contact your authorized Wharfedale Pro dealer or distributor for information. - Page 12 IAG House, 13/14 Glebe Road, Huntingdon, Cambridgeshire, PE29 7DL, UK www.wharfedalepro.com Wharfedale Pro reserves the right to alter or improve specifications without notice. All rights reserved © 2024 Wharfedale Pro. Wharfedale Pro is a member of the IAG Group.
