  • Page 1 INVERTER Plug-in option FR-A7AR E kit-SC INSTRUCTION MANUAL Relay output function PRE-OPERATION INSTRUCTIONS INSTALLATION AND WIRING RELAY OUTPUT...
  • Page 2 Thank you for choosing this Mitsubishi Electric inverter plug-in SAFETY INSTRUCTIONS option. This Instruction Manual provides handling information and precautions for use of this product. Incorrect handling might 1. Electric shock prevention cause an unexpected fault. Before using this product, read all WARNING relevant instruction manuals carefully to ensure proper use.
  • Page 3 3. Additional instructions 3) Usage The following instructions must be also followed. If this product is WARNING handled incorrectly, it may cause unexpected fault, an injury, or an electric shock.  Do not modify this product. 1) Transportation and installation ...
  • Page 4: Table Of Contents

    — CONTENTS — 1 PRE-OPERATION INSTRUCTIONS Unpacking and Product Confirmation .....................1 1.1.1 Product confirmation............................1 Parts ..............................2 Specifications.............................3 2 INSTALLATION AND WIRING Pre-Installation Instructions ......................4 Installation Procedure ........................4 Wiring..............................9 3 RELAY OUTPUT Internal Block Diagram........................12 Terminals ............................13 Parameter List ..........................13 Output Signal List ..........................14 APPENDIX Appendix 1 Instructions for compliance with the EU Directives ............15...
  • Page 5: Pre-Operation Instructions Unpacking And Product Confirmation

    PRE-OPERATION INSTRUCTIONS Unpacking and Product Confirmation Take the plug-in option out of the package, check the product name, and confirm that the product is as you ordered and intact. This product is a plug-in option dedicated for the FR-E700-SC series (safety stop function model). 1.1.1 Product confirmation Check the enclosed items.
  • Page 6: Parts

    PRE-OPERATION INSTRUCTIONS Parts Terminal Mounting Front view Rear view hole block Mounting hole Connector Mounting hole Connect to the inverter option connector 5, 7 (Refer to page Terminal layout...
  • Page 7: Specifications

    PRE-OPERATION INSTRUCTIONS Specifications (1) Types of output signal 1 changeover contact output (three relays are provided) (2) Contact capacity 230VAC ..0.3A 30VDC .... 0.3A CAUTION • The contacts should be used within the rated capacity to prevent contacts weld resulting from faster contacts wearing.
  • Page 8: Installation And Wiring Pre-Installation Instructions

    INSTALLATION AND WIRING Pre-Installation Instructions Make sure that the input power of the inverter is off. CAUTION With input power on, do not install or remove the plug-in option. Otherwise, the inverter and plug-in option may be damaged. For prevention of damage due to static electricity, touch nearby metal before touching this product to eliminate static electricity from your body.
  • Page 9 INSTALLATION AND WIRING  Inverter with one front cover (1) Remove the front cover from the inverter. (For removing the front cover, refer to the FR-E700 series instruction manual.) (2) Remove the PU cover from the front cover. Open the PU cover with a driver, etc. and remove it in the direction of arrow as shown below.
  • Page 10 INSTALLATION AND WIRING Remove the PU cover provided on the front cover for plug-in option and mount the other PU cover, which was removed in (2). (7) Loosen the terminal screws and insert the wires into the terminals. After that, fasten the terminal screws to the recommended tightening torque.
  • Page 11 INSTALLATION AND WIRING  Inverter with front covers 1 and 2 (1) Remove the front cover 1 and 2 from the inverter. (For removing the front cover, refer to the FR-E700 series instruction manual.) (2) Remove the PU cover from the front cover 2. For removing the PU cover, refer to page 5.
  • Page 12 INSTALLATION AND WIRING (4) Junction (4) Hexagon connector spacer (4) Plug-in option connector of inverter Front cover for plug-in option Replace Installation completed (4) Spacer for (6) Mounting screws plug-in option (short) mounting (6) Mounting screw (long)
  • Page 13: Wiring

    INSTALLATION AND WIRING Wiring (1) Wire the shielded twisted pair cable after stripping its sheath to make its Shield cables loose. (perform protective treatment) Sheath Also, protect the shielded cable of the shielded twisted pair cable to ensure that it will not make contact with the conductive area. Shielded twisted pair cable Strip the signal wires as shown below.
  • Page 14 INSTALLATION AND WIRING REMARKS • Information on crimp terminals Commercially available product examples (as of Jan. 2017) Wire gauge Ferrule part No. Terminal Maker screw size With insulation sleeve Without insulation sleeve AI 0,34-6TQ A 0,34-7 Phoenix Contact AI 0,5-6WH A 0,5-6 Co.,Ltd.
  • Page 15 INSTALLATION AND WIRING POINT If a hook of the front cover for plug-in option impedes wiring, cut the hooks off and perform wiring. Cut off hooks at the bottom of the Cut off with a option cover. nipper, etc. (Cut off so that no portion is left.) REMARKS The protective structure (JEM1030) is the open type (IP00).
  • Page 16: Relay Output Internal Block Diagram

    RELAY OUTPUT Internal Block Diagram You can select any three output signals (RUN, SU, FU, etc.) available with an inverter as standard, and output them as relay contact signals. Refer to page 14 of the Instruction Manual (detailed) for details. The following is the internal block diagram of the FR-A7AR.
  • Page 17: Terminals

    RELAY OUTPUT Terminals Terminal Symbol Description Relay RA1's normally open contact terminal Relay RA1's normally closed contact terminal Relay RA1's contact common terminal Relay RA2's normally open contact terminal Relay RA2's normally closed contact terminal Relay RA2's contact common terminal Relay RA3's normally open contact terminal Relay RA3's normally closed contact terminal Relay RA3's contact common terminal...
  • Page 18: Output Signal List

    RELAY OUTPUT Output Signal List For details of signal definitions, refer to Pr. 190 to Pr. 192 (Output terminal function selection) of the inverter instruction manual. Setting Setting Signal Signal Function Positive Function Positive Name Name logic logic Heatsink overheat pre-alarm Inverter running During deceleration at occurrence of Up to frequency...
  • Page 19: Appendix

    CE marking.  The authorized representative in the EU The authorized representative in the EU is shown below. Name: Mitsubishi Electric Europe B.V. Address: Mitsubishi-Electric-Platz 1, 40882 Ratingen, Germany  Note • To use this product in the EU, the operating capacity of the relay outputs should be 30 VDC, 0.3 A. (Relay output has basic isolation from the inverter internal circuit.)
  • Page 20: Appendix 2 Instructions For Eac

    9, X (October), Y (November), or Z (December). • Authorized sales representative (importer) in the CU area The authorized sales representative (importer) in the CU area is shown below. Name: Mitsubishi Electric (Russia) LLC Address: 52, bld 1 Kosmodamianskaya Nab 115054, Moscow, Russia Phone: +7 (495) 721-2070...
  • Page 21: Appendix 3 Restricted Use Of Hazardous Substances In Electronic And Electrical Products

    APPENDIX Appendix 3 Restricted Use of Hazardous Substances in Electronic and Electrical Products The mark of restricted use of hazardous substances in electronic and electrical products is applied to the product as follows based on the “Management Methods for the Restriction of the Use of Hazardous Substances in Electrical and Electronic Products”...
  • Page 22: Appendix 4 Referenced Standard (Requirement Of Chinese Standardized Law)

    APPENDIX Appendix 4 Referenced Standard (Requirement of Chinese standardized law) This Product is designed and manufactured accordance with following Chinese standards. EMC: GB/T 12668.3 IB(NA)-0600468ENG-B...
  • Page 23 REVISIONS *The manual number is given on the bottom left of the back cover. Revision date *Manual number Revision Aug. 2011 IB(NA)-0600468ENG-A First edition Addition • Appendix 1 Instructions for compliance with the EU Directives • Appendix 2 Instructions for EAC Mar.
  • Page 24 INVERTER HEAD OFFICE: TOKYO BUILDING 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN IB(NA)-0600468ENG-B (1903) MEE Printed in Japan Specifications subject to change without notice.
