Summary of Contents for Monport ONYX-R
- Page 2 PREFACE Welcome to the Monport Laser Family! We are very excited to have you as one of our valued customers. To save time in the future, it is recommended that you print this manual and keep it close to your machine or computer for easy access when designing files or operating the machine.
- Page 3 DEFINITIONS OF PROCEDURES The Monport ONYX-R laser, the machine you're about to explore, utilizes a carbon dioxide laser for cutting or engraving. Inside the protective housing, the laser beam travels through three mirrors on a two-axis moving frame and is then reflected into the focusing optics for irradiation of the workpiece.
-
Page 4: Fire Warning
Be prepared with a fire extinguisher. Always keep a properly maintained and inspected fire extinguisher at hand. Monport recommends a Halotron fire extinguisher or a multi-purpose dry chemical fire extinguisher. Although the Halotron extinguisher is more expensive than a dry chemical one, it offers certain advantages when used. For example, the Halotron extinguisher discharges a clean and easily removable substance that is not harmful to the mechanics or wiring of the laser system. -
Page 5: Table Of Contents
CONTENT 1. Introduction .............................. 6 1.1 General Information ......................... 6 1.2 Designated Use ..........................6 1.3 Technical Specifications ........................7 1.4 Components ............................8 2. Safety Information .............................9 2.1 Disclaimer ............................9 2.2 General Safety ..........................9 2.3 Laser Safety ............................ 11 2.4 Electrical Safety ..........................12 2.5 Material Safety .......................... -
Page 6: Introduction
Installation, Operation, Maintenance, and Contact Information. 1.2 Designated Use The ONYX-R is designed for engraving signs and other consumer products on applicable substrates. Its laser can process a wide variety of materials, including wood and cork, paper and cardboard, most plastics, glass, cloth and leather, and stone. -
Page 7: Technical Specifications
1.3 Technical Specifications Model ONYX-R Input Voltage 110-120V Power Consumption 550W Rated Power Expected Service Life 8,000 / 6,000 / 4,000 hrs (at<40% / 40-70% / >70% Power) Laser Wavelength 10,600 nm Diameter 2.2 in 55 mm Laser Tube Length 34.6 in... -
Page 8: Components
1.4 Components Here's a quick tour of the parts you need to know: Top View Button Color Status Standby Green Blue Working Error or Malfunction Front View Fireproof PE Rear View... -
Page 9: Safety Information
SAFETY INFORMATION 2.1 Disclaimer Your ONYX-R may differ slightly from those shown in this manual due to options, updates, etc. Please contact us if your engraving machine was supplied with an outdated manual or if you have any other questions. - Page 10 Your ONYX-R should come with warning labels in the following locations: If any of these labels is missing, illegible, or damaged, it must be replaced. Use this laser engraving device only in accordance with all applicable local and national laws and regulations.
-
Page 11: Laser Safety
2.3 Laser Safety Instructions The ONYX-R utilizes an invisible CLASS 4 LASER, the most powerful and dangerous class of laser available for public application. If used or modified carelessly, it can cause serious property damage and severe personal injury, including but not limited to the following:... -
Page 12: Electrical Safety
• Ensure that the area is kept free of airborne pollutants, as these might pose a similar risk of reflection, combustion, etc. 2.4 Electrical Safety Instructions ONLY use this device with a compatible, stable and grounded power supply with a voltage fluctuation of less than 5%. - Page 13 This machine can be safely used with the following materials: Plastics • Acrylonitrile Butadiene Styrene (ABS) • Nylon (Polyamide, PA, etc.) • Polyethylene (PE) • High-Density Polyethylene (HDPE, PEHD, etc.) • Biaxially-Oriented Polyethylene Terephthalate (BoPET, Mylar, Polyester, etc.) • Polyethylene Terephthalate Glycol (PETG, PET-G, etc.) •...
-
Page 14: Installation
INSTALLATION 3.1 Installation Overview • A complete working system consists of the laser engraving cabinet, its vent, a water tank (not included) with a pump (included), all applicable connecting cables, the laser and access keys. • The cabinet can is compatible with designs provided by the enclosed engraving software via a direct or internet connection to your computer;... -
Page 15: Unpacking
3.3 Unpacking Your Engraver Your new ONYX-R arrives in a wooden crate with its accessories (including this manual) packaged inside the main bay. You should place the crate in a spacious and flat area for unpacking, ideally where you plan to operate the machine permanently. At least two people are required to move and adjust the engraver's position to keep it level and avoid any sharp or sudden movement. -
Page 16: Main Power
3.5 Main Power Connection Confirm that the voltage on the label above the laser's power socket matches your local power supply. Connect one end of the power cord to the socket at the back of the machine. (If the interlock connector does not fit, pull back its outer casing, align its holes with the pins, and try again.) Connect the other end of the power cord directly to a grounded outlet or to a surge protector rated over 2000J that is connected to a grounded outlet. -
Page 17: Initial Testing
7. In the system work platform at the top right of the main screen, change the tab from Work to User and select Open. Go to the USB flash drive or your folder and load the file User_parameters.RDUSet. 8. Configure the camera by going to Laser Work at the bottom right and changing the Position from "Current Position"... -
Page 18: Operation
Information above), the separate software manual, and all warnings on the machine itself. The ONYX-R works by emitting a powerful laser beam from a glass tube filled with carbon dioxide ), nitrogen, and insulating gases, reflecting this beam with three mirrors and through a lens, and using this focused light to etch designs onto certain substrates. - Page 19 Step 6. Focus your laser using the Offset parameter in your software, located on the Test tab of the system workplate at the top right of the main interface. For the 2 inch focus lens, set the Offset value accordingly. Step 7.
-
Page 20: Rotary Instructions
Step 10. Open the cover and remove any dust or debris that has built up on the workbed and the various surfaces in the bay. Remove the debris tray to empty and clean it, and replace it. 4.3 Rotary Operation Instructions Step 1. -
Page 21: Maintenance
MAINTENANCE 5.1 Maintenance Overview Use of procedures other than those specified here may result in hazardous exposure to laser radiation. Before any cleaning or maintenance, always switch off the device and disconnect its power supply. Always keep the system clean, as flammable debris in the working and exhaust areas could cause a fire hazard. -
Page 22: Cooling System
Cleaning the Main Bay and Engraver Check whether dust has accumulated in the main engraving bay at least once a day. If so, remove the dust. The exact cleaning interval and requirements greatly depend on the material being processed and the operating time of the device. -
Page 23: Laser Alignment
5.4 Laser Path Alignment The ONYX-R has undergone a complete beam alignment prior to shipment and its design should keep your mirrors in their proper positions at all times. If you wish to test the alignment by using the laser to... -
Page 24: Contact Information
CONTACT US Thank you for choosing the ONYX-R! MONPORT PROVIDES US-BASED TECH SUPPORT. Please rest assured that machines purchased from any platform are eligible for comprehensive and professional technical support from Monport's official after-sales support department. TEl: (812)351-0217 System: https://app.helpdesk.com/tickets/all Note: Please submit to the Helpdesk with your order number and a description of the issue if you have any questions about the machine. -
Page 25: Attachment 1
Attachment 1 Material Acrylic Basswood Canvas Cardboard Leather Power (W) Engraving Speed (mm/s) 100% 100% 100% 100% 100% 100% Power (W) Cutting Speed (mm/s) Rec. Thickness (mm) Resolution (dpi) Ceramics When engraving ceramics, generally use moderate to high power. Using more loops rather than higher power and lower speed can help avoid cracking the material during operation. - Page 26 from those that burn through the substrate. As with leather, pay particular attention to the possibility of fire, as well as the dust produced in repetitive applications. Plastics Plastics for engraving are available in many different colors and thicknesses and with many different coatings and surfaces.
- Page 27 Attachment 2 Symbol Guide The following symbols are used on the labeling of this machine or in this manual: These items present a risk of serious property damage or personal injury. These items address similarly serious concerns with regard to the laser beam. These items address similarly serious concerns with regard to electricity.
