INSTALLATION INSTRUCTIONS
BAH7V-01
IMPORTANT
Every working procedure that affects safety means shall
only be carried out by competent persons. This appliance
is not to be used by persons (including children) with
reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
Children should be supervised to ensure they do not
play with the appliance.
IMPORTANT
If installing in an R454B application, R454B air handler
sensor kit (27J27), Refrigerant Detection System
Control (27A05) and R454B TXV (26Z70, 26Z71, or
26Z72) must be ordered.
If installing in an R454B application, use installation
instructions provided in R454B air handler sensor kit
(27J27).
For sensor maintenance recommendations, refer to the
instructions in kit 27J27.
508475-01
This manual must be left with the homeowner for future reference.
One-Piece Variable Speed

Table of Contents

Shipping and Packing List ...........................................2
General ........................................................................2
Wiring diagram ............................................................3
BDC3 Blower Control ..................................................5
Adjusting the Blower Speed ........................................5
Blower Performance ....................................................6
Electrical Connections ...............................................11
Requirements ............................................................13
Nameplate Marking ...................................................13
Checkout Procedures ................................................15
Installation Clearances ..............................................15
Installation .................................................................15
Condensate Drain......................................................18
Duct System and Filters ...........................................20
Brazing Refrigerant Lines ..........................................22
Sealing the Unit .........................................................22
Homeowner Maintenance..........................................23
Professional Maintenance .........................................23
Decommissioning ......................................................24
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, personal
injury or loss of life. Installation and service must be
performed by a licensed professional HVAC installer or
equivalent, service agency, or the gas supplier.
*P508475-01*
Issue 0624
Air Handler R410A
WARNING
Blue Summit LLC 8201 C
National Turnpike Louisville,
KY 40214
(P) 508475-01
Page 1 of 26
