Samsung HW-LS60D Simple User Manual

Simple User Guide
HW-LS60D
You can access the User guide on Samsung's on-line customer support center by scanning the QR code on
the left. To see the manual on your PC or mobile device, download the manual in document format from
Samsung's website. (http://www.samsung.com/support)
QUESTIONS OR COMMENTS?
Samsung Service Center 
1-800-SAMSUNG (726-7864) www.samsung.com/us/support
© 2024 Samsung Electronics Co., Ltd. All rights reserved.
SAFETY INFORMATION
SAFETY WARNINGS
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE THE COVER (OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
Refer to the table below for an explanation of symbols
which may be on your Samsung product.
CAUTION
RISK OF ELECTRIC SHOCK. DO NOT
OPEN.
This symbol indicates that high voltage is
present inside. It is dangerous to make any
kind of contact with any internal part of this
product.
This symbol indicates that this product has
included important literature concerning
operation and maintenance.
Class II product : This symbol indicates that a
safety connection to electrical earth (ground)
is not required.
If this symbol is not present on a product
with a power cord, the product MUST have
a reliable connection to protective earth
(ground).
AC voltage : Rated voltage marked with this
symbol is AC voltage.
01 CHECKING THE
COMPONENTS
• Wireless Speaker main • Wallmount Component
unit ‒ Wallmount Guide
• Stand ‒ Bracket-Wall Rear
• AC/DC Adapter x 1
• Power Cord ‒ Screw (M5 X L55) x 2
• Photo Frame ‒ Anchor x 2
• Component for Art ‒ Holder-Screw x 1
Panel (sold separately) ‒ Spacer x 2
‒ Holder-Plate x 4
‒ Holder-Guide x 1
NOTE
• To purchase additional components or optional
cables, contact a Samsung Service Center or Samsung
Customer Care.
02 PRODUCT OVERVIEW
Front
Volume
1
(Multi Function) Button
In standby mode, press the (Multi Function)
button to turn on the Wireless Speaker.
Press the (Multi Function) button to change the
mode.
(Mic On/Off) Button
Press the button to turn the microphone on or off.
When the microphone is off, the LED indicator will
light red.
To switch to Bluetooth Pairing state, press and
hold the (Mic On/Off) button on the side of the
Wireless Speaker for more than 5 seconds.
LED indicator
1
The LED Indicator flashes, glows, or changes color
depending on the Wireless Speaker's current mode
or status.
AH81-17454A-01
Web Site Address
Samsung Electronics America, Inc.
85 Challenger Road Ridgefield Park,
NJ 07660
DC voltage : Rated voltage marked with this
symbol is DC voltage.
Caution. Consult Instructions for use : This
symbol instructs the user to consult the user
manual for further safety related information.
WARNING
• To reduce the risk of fire or electric shock, do not expose
this appliance to rain or moisture.
• To prevent injury, this apparatus must be securely
attached to the floor/wall in accordance with the
installation instructions.
• This product contains chemicals known to the State of
California to cause cancer and birth defects or other
reproductive harm.
• Do not use liquid fumigators containing chemicals,
such as mosquito repellent or air freshener, around the
product. If steam comes in contact with the product
surface or enters the product, it may cause stains or
malfunction.
CAUTION
• Do not expose this apparatus to dripping or splashing.
Do not put objects filled with liquids, such as vases, on
the apparatus.
• To turn this apparatus off completely, you must pull the
power plug out of the wall socket. Consequently, the
power plug must be easily and readily accessible at all
times.
Rear
D.IN SMARTTHINGS
DC 19V
(OPTICAL) DONGLE
D. IN (OPTICAL)
Connect to the digital (optical) output of an external
device.
SMARTTHINGS DONGLE
Connect the SmartThings dongle(Purchase separately) to
use the SmartThings Hub function.
DC 19V
Connect the AC/DC power adapter.
(Power Supply In)
03 CONNECTING THE
POWER
Connecting the power and units
DC 19V
AC/DC Adapter
Power Cord
• For more information about the required electrical
power and power consumption, refer to the label
attached to the product. (Label: Rear of the Wireless
Speaker Main Unit)
Important Safety Instructions
Read these operating instructions carefully before using
the unit. Follow all the safety instructions listed below.
Keep these operating instructions handy for future
reference.
1. Read these instructions.
2. Keep these Instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer's
instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug.
A polarized plug has two blades with one wider than the
other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit
into your outlet, consult an electrician for replacement
of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
04 CONNECTING THE
SMARTTHINGS APP
1 - Installation
• The SmartThings app allows you to
1
control the functionality of and adjust
the settings of the Wireless Speaker.
• Download the SmartThings app from
the app store of your mobile device, or
simply scan the provided QR code and 2
download the app.
• QR 1: Video Guide for SmartThings
App Connection
• QR 2: Download SmartThings App
2 - Device registration
1. Run the SmartThings app on your mobile device.
2. Follow the on screen instructions and add the product
to your mobile device.
• If the automatic pop-up window does not appear, press
( ) on the Home screen to register the product.
3 - Control with SmartThings
1. With the SmartThings app open on your device, select
the Wireless Speaker that you have added.
2. The settings menu of the Wireless Speaker appears,
where you can adjust the various settings including
volume, sound mode or fine-tuning.
• For other users who want to control the Music Frame,
tap Menu ( ) on the SmartThing app of their mobile
device and go to 'How to use' > 'Share control of devices'
for reference.
NOTE
The illustration below may differ with the app version.
Sound Mode
Equalizer
Advanced Sound Settings
SmartThings Hub
PRECAUTIONS
1. Ensure that the AC power supply in your house complies
with the power requirements listed on the identification
sticker located on the bottom of your product. Install
your product horizontally, on a suitable base (furniture),
with enough space around it for ventilation (3~4
inches). Make sure the ventilation slots are not covered.
Do not place the unit on amplifiers or other equipment
which may become hot. This unit is designed for
continuous use.
To fully turn off the unit, disconnect the AC plug from
the wall outlet. Unplug the unit if you intend to leave it
unused for a long period of time.
2. During thunderstorms, disconnect the AC plug from
the wall outlet. Voltage peaks due to lightning could
damage the unit.
3. Do not expose the unit to direct sunlight or other heat
sources. This could lead to overheating and cause the
unit to malfunction.
4. Protect the product from moisture (i.e. vases), and
excess heat (e.g. a fireplace) or equipment creating
strong magnetic or electric fields. Unplug the power
cable from the AC wall socket if the unit malfunctions.
Your product is not intended for industrial use. It
is for personal use only. Condensation may occur if
your product has been stored in cold temperatures.
If transporting the unit during the winter, wait
approximately 2 hours until the unit has reached room
temperature before using.
5. Make sure to rest the AC/DC Adapter flat on a table or
the floor. If you place the AC/DC Adapter so that it is
hanging with the AC cord input facing upwards, water
or other foreign substances could enter the Adapter and
cause the Adapter to malfunction.
05 CONNECTING VIA WIFI
WITH TV
• Wi-Fi connection is available only on Samsung TV.
• The TV and Wireless Speaker must be connected to the
same wireless network (Wi-Fi).
• The menus may differ depending on the year of
manufacture, refer to your TV manual.
1. Change the input source of the TV by using the Audio
menu to Wireless Speaker.
‒ Samsung TVs released in 2017 or later
: ( ) → Sound → Sound Output → Music Frame
(Wi-Fi)
06 USING THE
Q-SYMPHONY
FUNCTION
• This function is supported only when both the wireless
speaker and the TV are connected to the same Wi-Fi
network.
• It is available with new Samsung TV models to be
released 2024.
When the Wireless Speaker connects to a Samsung TV that
supports the Q-Symphony function, you can play the sound
simultaneously through the Wireless Speaker and the TV.
If you use the Q-Symphony function, the surround sound
played on the Wireless speaker allows you to enjoy a richer,
more three-dimensional surround sound effect.
When the Wireless Speaker is connected, "Q-Symphony"
menu appears on the TV. (The message displayed may
differ with the TV model.)
(Settings ( ) → All Settings ( ) → Sound → Sound Output)
07 CONNECTING VIA
BLUETOOTH WITH
MOBILE
5 sec 5 Sec
1. Press (Mic On/Off) button for 5 seconds for pairing.
• It is also available to pair by pressing [ ] on the
SmartThings App screen of your mobile device.
