Cherry AK-PMH12OB Series User Manual

User Manual
AK-PMH12OB series
The medical mouse AK-PMH12OB series is a high quality and highly reliable hygiene mouse with 3-Button-
Scroll-Wheel emulation. It is particularly designed for the use at hospitals and by practitioners. The mouse
is sealed with a silicon membrane. Please follow the instructions provided by your authorities for standard
disinfection of surfaces for reprocessing of the mouse.
Delivery Content:
1x Corded mouse
1x User manual
Manufacturer:
Cherry Digital Health GmbH Web: www.cherry.de
Cherrystraße 2 Tel.: +49 (0) 9643-2061-100
D-91275 Auerbach/OPf.
Legal information:
The product complies with the EMC directive 2014/30/EU. The full text of the EU declaration of conformity
is available at the following internet address:
http://www.cherry.de/compliance
Electrical and electronic equipment (EEE) is marked with the symbol of the crossed-out wheeled bin
indicating the requirement not to dispose of waste electrical and electronic equipment (WEEE) as
unsorted municipal waste and to collect such WEEE separately.
Final users of WEEE from private households shall be able to return WEEE as per
EU country local regulations into established collection facilities free of charge.
Please consult your municipal waste department for detailed advice on separate
collection of WEEE.
The packaging material used with this product is identified as PAP-20 and LDPE-04. Please follow the
rules of your local community on collection of used packaging.
User Manual
AK-PMH12OB series
The medical mouse AK-PMH12OB series is a high quality and highly reliable hygiene mouse with 3-Button-
Scroll-Wheel emulation. It is particularly designed for the use at hospitals and by practitioners. The mouse
is sealed with a silicon membrane. Please follow the instructions provided by your authorities for standard
disinfection of surfaces for reprocessing of the mouse.
Delivery Content:
1x Corded mouse
1x User manual
Manufacturer:
Cherry Digital Health GmbH Web: www.cherry.de
Cherrystraße 2 Tel.: +49 (0) 9643-2061-100
D-91275 Auerbach/OPf.
Legal information:
The product complies with the EMC directive 2014/30/EU. The full text of the EU declaration of conformity
is available at the following internet address:
http://www.cherry.de/compliance
Electrical and electronic equipment (EEE) is marked with the symbol of the crossed-out wheeled bin
indicating the requirement not to dispose of waste electrical and electronic equipment (WEEE) as
unsorted municipal waste and to collect such WEEE separately.
Final users of WEEE from private households shall be able to return WEEE as per
EU country local regulations into established collection facilities free of charge. Please
consult your municipal waste department for detailed advice on separate collection of
WEEE.
The packaging material used with this product is identified as PAP-20 and LDPE-04. Please follow the
rules of your local community on collection of used packaging.
Supplier's Declaration of Conformity
FCC 47 CFR Part 15 Subpart B
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
Modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
U.S. Responsible Party: Cherry Americas
5732 95th Ave., Suite 850
Kenosha, WI 53144, United States
Product Name: Hygiene USB-mouse
Model Number: HM801C
CAN ICES-3 (B)/NMB-3(B)
Supplier's Declaration of Conformity
FCC 47 CFR Part 15 Subpart B
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
Modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
U.S. Responsible Party: Cherry Americas
5732 95th Ave., Suite 850
Kenosha, WI 53144, United States
Product Name: Hygiene USB-mouse
Model Number(s): HM801C
CAN ICES-3 (B)/NMB-3(B)
Frequently Asked Questions (FAQ):
Usage of Medical protective gloves!
Nitrile gloves reduce the risk of allergic reactions and help prevent discoloration caused by latex wear.
The mouse does not work reliably on the application areas!
The following questions must be considered:
•
Is the mouse used on a glossy or on a glass surface?
•
Is the surface made of mineral composites (e.g. Corian®)?
For reasons of hygiene, the mouse uses an optical sensor with a cover window. This limits the range
of supported surfaces. Please contact our customer support in case of further questions.
Middle mouse button activates auto-scrolling feature!
You can use this feature to make "scrolling" easier, for example by clicking on the middle mouse
button and then moving the mouse up/down to scroll. It works in programs such as Web Browsers,
Microsoft programs, etc..
Plug & Play:
As soon as you use the mouse and connect it to the PC for the first time, it registers itself as an USB-
HID-Mouse and uses the standard Windows drivers. You don't have to install any additional drivers
to use the mouse. Please note that it may take a moment for your PC to recognize the device.
Specification:
Compatibility All Operating Systems Supporting Standard USB Mouse
Interface USB 2.0 Full-Speed; USB Type A
Power Supply / Current Consumption 5 V +/- 10 % through USB port, Max. 24 mA
Sensing Technology Optical scanning, 1000 CPI
Dimensions Approx. 113 x 62 x 35 mm
Temperature Range Operating: 0 °C to +50 °C, Storage: -20 °C to +60 °C
Keys / Key travel 2 Mouse Keys, 3 Scroll Buttons / Approx. 1 mm
Agency Approvals CE, RoHS, FCC, IC, EN 60601-1-2:2015*
*No Medical Device acc.to Regulation (EU) 2017/745
All rights reserved. Copy or duplication, except for personal use, not permissible without specific prior
written consent by Cherry Digital Health GmbH. Contents are subject to change without notice. Errors
excepted.
Copyright by Cherry Digital Health GmbH.
Version 20240628
Frequently Asked Questions (FAQ):
Usage of Medical protective gloves!
Nitrile gloves reduce the risk of allergic reactions and help prevent discoloration caused by latex wear.
The mouse does not work reliably on the application areas!
The following questions must be considered:
•
Is the mouse used on a glossy or on a glass surface?
•
Is the surface made of mineral composites (e.g., Corian)?
For reasons of hygiene, the mouse uses an optical sensor with a cover window. This results in
limitation of the supported surfaces. Please contact support if you have problems with the insert
surfaces.
Middle mouse button activates auto-scrolling feature!
You can use this feature to make "scrolling" easier, for example by clicking on the middle mouse
button and then moving the mouse up/down to scroll. It works in programs such as Web Browsers,
Microsoft programs, etc..
Plug & Play:
As soon as you use the mouse and connect it to the PC for the first time, it registers itself as an USB-
HID-Mouse and uses the standard Windows drivers. You don't have to install any additional drivers
to use the mouse. Please note that it may take a moment for your PC to recognize the device. The
keyboard has no function during this time.
Specification:
Compatibility All Operating Systems Supporting Standard USB Mouse
Interface USB 2.0 Full-Speed, USB Type A
Power Supply / Current Consumption 5 V +/- 10 % through USB port; Max. 24 mA
Sensing Technology Optical scanning, 1000 CPI
Dimensions Approx. 113 x 62 x 35 mm
Temperature Range Operating: 0 °C to +50 °C, Storage: -20 °C to +60 °C
Keys / Key travel 2 Mouse Keys, 3 Scroll Buttons / Approx. 1 mm
Agency Approvals CE, RoHS, FCC, IC, EN 60601-1-2:2015*
*No Medical Device acc.to Regulation (EU) 2017/745
All rights reserved. Copy or duplication, except for personal use, not permissible without specific prior
written consent by Cherry Digital Health GmbH. Contents are subject to change without notice. Errors
excepted.
Copyright by Cherry Digital Health GmbH.
Version 20240628
