- Page 1 De’Longhi Dishwasher Model DEDW60156S2 USER GUIDE Please read this user guide carefully and retain for future reference...
-
Page 2: Table Of Contents
Contents Parts and Features ..........De’Longhi Safety Precautions . -
Page 3: Parts And Features
Parts and Features Model: DEDW60156S2 Components: 1. Knife rack 2. Upper Basket 3. Top Spray Arm 4. Lower Basket 5. Lower Spray Arm 6. Dispenser 7. Filter Assembly Dimensions: Height 850mm Width 598mm Depth 600mm (with door closed) Voltage connected Load: see rating label Water pressure: 0.03-1.0MPa... -
Page 4: De'longhi Safety Precautions
De’Longhi’s Safety Precautions De’Longhi pride themselves on their innovative range This appliance is designed exclusively for of the highest quality consumer products. household use. All other uses are strictly forbidden. De’Longhi ensures all of its products are 100% safe The appliance is not intended for use by persons through quality design and manufacture. -
Page 5: Dishwasher Safety Precautions
Dishwasher Safety Precautions Your safety and the safety of others is very important. Safety messages are displayed in this manual and on your appliance. Read and obey these safety messages as they will alert you to potential hazards and tell you how to reduce the chance of injury. - Page 6 Dishwasher Safety Precautions Before the appliance is used, it must WARNING be properly positioned and installed as described in this manual, so read the manual carefully. To reduce the When using your dishwasher, you should prevent risk of fire, electrical shock or injury plastic items from coming into contact with the when using the appliance, follow heating element (This instruction is only applicable...
-
Page 7: Installation Safety Precautions
Installation Safety Precautions Electrical Connection Extension Cord This appliance should be properly grounded for your safety. The power cord of this appliance is DO NOT USE AN EXTENSION CORD OR AN equipped with a three-prong plug which mates ADAPTER PLUG WITH THIS APPLIANCE. with standard three prong wall outlets to minimise the possibility of electrical shock. -
Page 8: Installation
Installation Any installation may be carried out only by a qualitied technician refer to section SAFETY. Free Standing Installation Install the appliance on solid ground. Adjust accurately all feet to get a firm, horizontal position. Only with a correct level the appliance door closes and seals correctly. Installation under Worktop 1.Optional:Remove the work top of the appliance. -
Page 9: Drain Water Connection
Installation The incoming water temperature should not exceed 60°C. 2.Take note of the permitted water pressure extremes. Lowest: 0.3 bar = 3 N/cm = 30kPa Where pressure is below 1 bar, contact a qualified plumber. Highest: 10 bar = 100 N/cm = 1MPa Where pressure is above 10 bar, a pressure reduction valve must be installed. -
Page 10: Power Connection
Installation Power connection As shown in the figure, the power supply is plugged into an externally accessible place through the service hole for easy plugging. CAUTION! Ensure always that all connections (power supply, drain and fresh water hose) are firm, dry and leak free. Take care these parts are never to be crushed, kinked, or twisted If the supply cord is damaged, it must be replaced by the service agent (see warranty card) in order to avoid a hazard. -
Page 11: Using Your Dishwasher
Using Your Dishwasher QUICK START GUIDE For detailed operating method read the corresponding content on the instruction manual. Switch on the appliance Press the On/Off button to switch on the appliance, Open the door. Compartment A: For each wash cycle. Fill the detergent dispenser For programmes with pre-wash only. -
Page 12: Before Starting The Dishwasher
Using Your Dishwasher The use of “normal” washing programs in BEFORE STARTING THE DISHWASHER combination with concentrated detergents reduces The following things should be checked before pollution and is good for your dishes; these wash starting the dishwasher: programs are specifically matched to the dirt- 1. -
Page 13: Different Settings For Rinse Aid
Using Your Dishwasher Fill the Rinse Aid Dispenser 1. Press the button （A）to snap the dispenser cover open. 2. Pour rinse aid into the circular（B）opening, making sure not to fill beyond the MAX marking. 3. Close the cover, making sure it clicks shut. Different Settings for Rinse Aid Rinse aid is added during the last rinsing phase to dry the dishes without streaks and stains. - Page 14 Using Your Dishwasher Close the Detergent compartment WARNING! Dishwasher detergent is poisonous! Take care to keep it out of reach of children. If your dishes are only moderately dirty. You may be able to use less detergent Proper Use of Detergent 1.
-
Page 15: Loading The Dishwasher Basket
Using Your Dishwasher LOADING THE DISHWASHER BASKET It is not necessary to rinse the dishes under running water. Place objects in the dishwasher in following Recommendation way: Consider buying utensils which are identified as 1. Items such as cups, glasses, pots/pans, etc. are dishwasher-proof. - Page 16 Using Your Dishwasher Loading the Upper Basket The upper basket is designed to hold more delicate Lift the basket and lighter dishware such as glasses, coffee and tea cup and saucers, as well as plates, small bowls and shallow pans (as long as they are not too dirty). Position the dishes and cookware so that they do not get moved by the spray of water.
- Page 17 Using Your Dishwasher Loading the Lower Basket Place heavily soiled items (like pots and pans or dinner plates) in the bottom basket. The more powerful spray jet provides a better dishwashing result. Place the largest items here:pots, pans, lids, serving dishes and bowls. Fold down the tines to place pots and pans flat on the bottom.
-
Page 18: Damage To Glassware And Other Dishes
Using Your Dishwasher Standards Test Cutlery Basket Cutlery should be placed in the cutlery rack During the Dry phase, the door will separately from each other in the appropriate Wash programme automatically open about 100mm positions. Make sure the utensils do not nest to help with drying. -
Page 19: Starting A Washing Program
Using Your Dishwasher Starting a washing program Wash Cycle Table NOTE: Star ( ) means the need to fill rinse aid into the Rinse Aid Dispenser. Rinse Aid Detergent pre/main Program Cycle Selection Information 6/25g Soups, eggs, sauces, potatoes, Medium pasta, rice, roasted or fried food or 1 piece For heavily soiled loads,... -
Page 20: Control Panel
Using Your Dishwasher Control panel Dry- In the last stage of rinsing, the washing ower button: Press this button to turn on your temperature is increased and the drying time is dishwasher. prolonged to enhance the drying effect of Program：Select the appropriate washing tableware. - Page 21 Using Your Dishwasher Please note that not all sales models comes with Start a Programme with Delay identical features and options. So pictures of that Set a start time by the following procedure in order chapter are sometimes different to your dishwasher to delay a programmestart: model.
-
Page 22: Care And Cleaning
Care and Cleaning Filtering System STEP 2. To disassemble the filter A pull apart A1 and A2, The filter prevents larger remnants of food or other Wash the filters A and B with water. objects from getting inside the pump. The residue may block the filter, in this case they must be removed. -
Page 23: Protect Against Freezing
Care and Cleaning Protect against Freezing How to keep your Dishwasher in shape Please take frost protection measures on the After every wash, turn off the water supply to the dishwasher in winter. After washing cycles, please appliance and leave the door slightly open so that operate as follows: moisture and odours are not trapped inside. -
Page 24: Troubleshooting
Troubleshooting Problem Possible cause Possible solution Appliance door is open. Close the appliance door. Delay start is set. Refer to displayed time. The programme Power plug is not connected does not start. Connect the power plug. in the power socket. Fuse in the house circuit is Replace the fuse. -
Page 25: Error Codes
Troubleshooting Problem Possible cause Possible solution Released quantity of rinse aid is Decrease the re leased quantity of rin se aid. Refer to section too much. DIFFERENT SETTINGS FOR RINSE AID. Whitish streaks, stains or bluish Quantity of detergent was too Make sure that you add the correct quantity of detergent in the layers on glasses much. -
Page 26: Help Us Help You
Help us Help You Read this guide carefully, it is intended to help you operate and maintain your new Dishwasher properly. Keep it handy to answer your questions. If you don't understand something or you need more assistance, please call the De’Longhi Helpline. To help us provide prompt answers to your queries, please record your Dishwasher model and serial numbers. -
Page 27: Warranty Information
The De’Longhi Dishwasher is warranted against faults How to contact us about a warranty claim resulting from manufacturing or material defects. The warranty period for normal domestic installation and use is Talk to a De’Longhi representative for further warranty two years from the date of purchase. In non-domestic use or product information please call the number in your De’Longhi limits the voluntary warranty to 6 months. - Page 28 Australia Elba Appliances Australia Suite 1, 1107 Botany Road Mascot NSW 2020 Phone 1300 186 709 www.delonghicookingappliances.com.au Head Office Fisher & Paykel Appliances Italy S.p.A. Via Fabbian Matteo, 7 31030 Borso del Grappa (TV) ITALY © 2020 De’Longhi Australia Pty Ltd.
