Simfer SR-2515 Instruction Manual page 28

1. Dismantle the screw, sleeve pipe and stopper from the refrigerating door and
freezer door, and the support on the lower cover of the refrigerating door is
also removed.
2. Then install them on the other side of the doors in order.
3. Exchange the position of sleeve pipe and hole cap at the top cover of
refrigerating door, and install the upper hinge sleeve on the freezer door to
the hole on the other side of axis sleeve.
4. Put the cold door on the lower hinge , install the middle hinge, cover, screw
and screw cap.
middle hinge
5. Put the refrigerating door on the middle hinge , install the upper hinge, hinge
cover and hole cap.
hinge cover
hi ng e
28
sleeve pipe
stopper
stopper screw
support
screw cover
ho le cap
ho le c ap
