Installing a Mortice Lock
To fit a Mortice lock you will require the following tools:
- Drill
- Drill bits for morticing of timber
- Chisel
- Mallet
- Posidriv screwdriver
- Pencil
- Ruler
Note: It is recommended that suitable pilot holes are drilled before fitting fixing screws (especially in hardwood).
Reversing the sashbolt (latch)
1
Lift latch bolt release up to disengage latch bolt
2
Rotate latch bolt 180˚
3
Depress latch bolt fully to re-engage latch bolt
DSPC
Valiant Mortice Lock
Fitting Instructions
1
2
3
