Model Number
101A03
Performance
Measurement Range(for ±5V output)
Sensitivity(± 0.05 mV/psi)
Maximum Pressure
Resolution
Resonant Frequency
Rise Time(Reflected)
Low Frequency Response(- 5 %)
Non-Linearity
Environmental
Acceleration Sensitivity
Temperature Range(Operating)
Temperature Coefficient of Sensitivity
Maximum Flash Temperature
Maximum Vibration
Maximum Shock
Electrical
Output Polarity(Positive Pressure)
Discharge Time Constant(at room temp)
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Electrical Isolation
Physical
Sensing Geometry
Sensing Element
Housing Material
Diaphragm
Sealing
Electrical Connector 10-32 Coaxial Jack
Weight
[3]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Piezotronics, Inc.
ICP® PRESSURE SENSOR
EN GLISH SI
10,000 psi 69,000 kPa
0.5 mV/psi 0.07 mV/kPa
15,000 psi 103,420 kPa
0.2 psi 1.38 kPa
≥ 400 kHz ≥ 400 kHz
≤ 1.5 µ sec ≤ 1.5 µ sec
0.0005 Hz 0.0005 Hz
≤ 2 % FS ≤ 2 % FS
0.002 psi/g 0.0014 kPa/(m/s²)
-100 to +275 °F -73 to +135 °C
≤ 0.03 %/°F ≤ 0.054 %/°C
3,000 °F 1,650 °C
2,000 g pk 19,600 m/s² pk
20,000 g pk 196,000 m/s² pk
Positive Positive
≥ 1,000 sec ≥ 1,000 sec
20 to 30 VDC 20 to 30 VDC
2 to 20 mA 2 to 20 mA
≤ 100 Ohm ≤ 100 Ohm
8 to 14 VDC 8 to 14 VDC
8 8
10 Ohm 10 Ohm
Compression Compression
Quartz Quartz
Stainless Steel Stainless Steel
Invar Invar
Welded Hermetic Welded Hermetic
10-32 Coaxial Jack
0.44 oz 12.5 gm
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
- Ablative Coating
CA
[1]
M - Metric Mount
Supplied Accessory: Model 065A40 Seal ring 0.435" OD x 0.397" ID x 0.030" thk brass (3) replaces
Model 065A03
N - Negative Output Polarity
[2]
- Stainless Steel Diaphragm
S
[1]
Diaphragm
- Water Resistant Cable
W
N OTES:
[1]Typical.
[2]Zero-based, least-squares, straight line method.
[3]See PCB Declaration of Conformance PS023 for details.
SUPPLIED ACCESSORIES:
Model 065A03 Seal ring 0.435" OD x 0.377" ID x 0.030" thk brass (3)
Model PCS-1AZ Sensitivity calibration at 100% and 10% of sensor range
Entered: ND Engineer: AJA
Date: 06/25/2024 Date: 06/25/2024 Date: 06/25/2024 Date: 06/25/2024 5955
3425 Walden Avenue, Depew, NY 14043
Revision: H
ECN #: 54949
OPTION AL VERSION S
316L Stainless Steel 316L Stainless Steel
Sales: RWM Approved: RPF Spec Number:
Phone: 716-684-0001
Fax: 716-684-0987
E-M ail: info@ pcb.com
