PCB Piezotronics ICP M101A03 Installation And Operating Manual page 10

4
PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
B
3 4 ABLATIVE COATING
A
5 ADAPTOR MAY BE PURCHASED SEPARATELY: 061A01 (17-4PH) OR 061A09 (316L)
4 BLACK VINYL ELECTRICIANS TAPE HAS BEEN FOUND TO BE AN EFFECTIVE ABLATIVE
MATERIAL, AS IS DC-4 SILICON GREASE
3 "CA" OPTION ONLY
2 MOUNTING TORQUE ON 7/16" HEX: 5-8 FT-LBS [6.78-10.85 Nm]
1 ABOVE INSTALLATION SHOWN FOR WALL THICKNESS OF .34 [8.6].
WALLS n .75 [19.1] TO CLEAR 7/16" HEX AND ALLOW FOR SOCKET WRENCH
4
3
ABLATIVE INSTALLATION
[ ]
.020 .51
.015 .38
v THICKER
3
2
ELECTRICAL CONNECTOR
10-32 UNF - 2A
MODEL 061A01
5 ADAPTOR BODY
MATERIAL: 17-4 PH
2 7/16" HEX
MODEL 065A03
BRASS SEAL (SUPPLIED)
MODEL 065A44
COPPER SEAL (OPTIONAL)
MODEL 065M29
316L ST STL (OPTIONAL)
3/8-24 UNF - 2A
MOUNTING HOLE PREPARATION:
3/8-24 UNF - 2B THRU
vn .437± .001 [11.10± .03] x .030 [.76]
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES DIMENSIONS IN MILLIMETERS
[ IN BRACKETS ]
DECIMALS XX ±.01 DECIMALS X ± 0.3
XXX ±.005
XX ± 0.13
` `
ANGLES 2 DEGREES ANGLES 2 DEGREES
CABLE TOLERANCES IN ENGLISH CABLE TOLERANCES IN METRIC
1"≤ LENGTH < 1' = +1"/ - 0
2.54cm ≤ LENGTH < 30.5cm = +2.54cm/ - 0
1'≤ LENGTH < 5' = +2"/ - 0
30.5cm ≤ LENGTH < 1.5m = +5.1cm/ - 0
5'≤ LENGTH < 100' = +6"/ - 0 1.5m ≤ LENGTH < 30.5m = +15.2cm/ - 0
30.5m ≤ LENGTH = +30.5cm/ - 0
100'≤ LENGTH = +1'/ - 0
FILLETS AND RADII FILLETS AND RADII
.003 - .005 0.07 - 0.13
2
1
REVISIONS
REV DESCRIPTION
G UPDATED NOTES
MODEL 060A03
CLAMP NUT
LENGTH
CHARGE 1.33± .05 [33.8]
®
1.47± .05 [37.3]
ICP
.34 [8.6]
.31 [7.9]
.34 [8.6] 1
DRAWN CHECKED ENGINEER
NJF 02/02/24 JDM 02/02/24 MJB 02/02/24
3425 WALDEN AVE. DEPEW, NY 14043
TITLE
INSTALLATION DRAWING
(716) 684-0001 E-MAIL: sales@pcb.com
MODELS 101A, 102A, 102B,
SHEET
CODE
102M, 061A01, & 061A09 IDENT. NO.
52681
PRESSURE SENSOR
SCALE: 3X
1
DIN
54569
B
A
DWG. NO.
6450
B
SHEET 1 OF 1
