- Page 1 Serving Quality on Demand CrispyMax™ Crisp and Ready Serving Station Service Manual This manual is updated as new information and models are released. Visit our website for the latest manual. *8197929* Part Number: MER_SM_8197929 05/2023...
- Page 2 Safety Notices Warning Use caution when handling metal surface edges of all Warning equipment. Read this manual thoroughly before operating, installing or performing maintenance on the equipment. Failure Warning to follow instructions in this manual can cause property This appliance is not intended for use by persons damage, injury or death.
-
Page 3: Table Of Contents
Table of Contents Section 1 General Information Overview ......................1-1 Component Identification ................1-1 Service Personnel ....................1-1 Section 2 Troubleshooting Troubleshooting Chart ..................2-1 Sequence of Operation ..................2-1 LED Troubleshooting Chart ................2-2 Measuring Air Temperature ................2-4 Section 3 Wiring Diagrams Wiring Diagrams .................... -
Page 4: Section 1 General Information
In 3 lane units the primary and secondary boards are set with a jumper. Below The Merco Crispy Max is designed to warm prepared fried foods with a flow of heated air. is a board with a jumper in the secondary position. - Page 5 General Information Section 1 Thermocouple Heater Heat Sink (Cools Triacs) Thermocouple Heater DC Fan Line Switch, LED, Jumper Voltage daisy chain Position between boards Heater Thermocouple High Limit Opens 275F ±6F...
- Page 6 Section 1 General Information Steps For Component Removal 5. Ensure the food tray is inserted correctly. The front edge should be flush with the cabinet. 1. Remove divider(s) if present. Correct placement of the food tray. 2. Remove food tray. Incorrect placement of the food tray.
-
Page 7: Section 2 Troubleshooting
Section 2 Troubleshooting Troubleshooting Chart Problem Probable Cause Corrective Action Machine doesn’t operate. No power. Check power source. Verify voltage. Call for service. Excessive time to reach Improper food tray installation / Install food tray properly / Remove temperature. Blocked airflow at rear of unit / any airflow blockages / Clean and Dirty or plugged air filter dry air filter then reinstall. -
Page 8: Led Troubleshooting Chart
Troubleshooting Section 2 LED Troubleshooting Chart Front LED Indicator Control Board LED Indicators Front LED Control Board Description Probable Possible Parts Service Cause Required Procedure Status Solid Green Orange flashes Normal -IO COMM (2 & 3 Operation Lane only) Flashing Green Preheating Flashing Yellow Filter Clog... - Page 9 Section 2 Troubleshooting Front LED Control Board Description Probable Possible Parts Service Cause Required Procedure Status Three (3)- Red One (1) -Zone 1 Thermocouple Open Thermocouple/ Check flashes and a or 2 error flash error Thermocouple Control Board thermocouple Three (3) second and a Three (3) or Control Board and control...
-
Page 10: Measuring Air Temperature
Troubleshooting Section 2 Measuring Air Temperature To determine if the CrispyMax is delivering the correct air temperature, use a thermocouple to measure the air temperature. Remove the holding pan to access the air grill. Tape a thermocouple over the air grill as shown, ensuring that the thermocouple does not touch the grill. -
Page 11: Section 3 Wiring Diagrams
Section 3 Wiring Diagrams CrispyMax Wiring Non-CE... - Page 12 Wiring Diagrams Section 3 CrispyMax Wiring with voltages...
- Page 13 Section 3 Wiring Diagrams CrispyMax Wiring CE...
- Page 14 THIS PAGE INTENTIONALLY LEFT BLANK...
- Page 15 Cleveland™, Convotherm®, Crystal Tips®, Dean®, Delfield®, Fabristeel®, Frymaster®, Garland®, Inducs®, Koldtech®, Kolpak®, Lincoln®, McCann’s™, Merco®, Merrychef®, Multiplex®, RDI®, SerVend™, SunFire®, U.S. Range™ and WMaxx™. These product brands are supported by these service brands: FitKitchen®, our fully-integrated kitchen systems brand, and KitchenConnect®, our cloud-based digital platform brand.
