  • Page 1 CRITICAL POWER MONITOR User Manual...

  • Page 2: Table Of Contents

    Critical Power Monitor Contents Changelog ................................5 Introduction ................................6 Hazards ................................6 Electrical specifications ............................. 6 Parameters ..............................6 M40 Series ................................ 7 Input Ratings ..............................7 Connector Pinout ............................7 CPM Temperature Monitor ..........................8 Input Rating ..............................8 Accuracy ...............................
  • Page 3 Critical Power Monitor M40/M50 Identification ..........................14 LEDs ................................15 Liquid Crystal Display ............................15 3-Digit LED Display ............................17 Feed Temperature Monitoring ........................19 Breaker Monitoring ............................19 Networking ..............................20 Security ............................... 20 Ethernet ..............................21 Daisy-Chain Ethernet ..........................21 Ring-Mode Ethernet ...........................
  • Page 4 Critical Power Monitor Outlet Alarm Status Register 1 ........................47 Temperature Monitor Alarm Status Register ..................... 48 Breaker Status Alarm Register ........................49 Group Reset Register ............................49 Troubleshooting.............................. 50 Current Transformers ..........................50 Privacy Policy ..............................51 Appendix A: Quick Start Guides .......................... 51 Quick Start Guide: Ethernet ..........................

  • Page 5: Changelog

    12. Added more information about CPM Alarms. 13. Added the TCP & UDP ports that the CPM utilizes for the various protocols. 14. Added Legrand privacy policy link. 15. Added more information about the CPM’s Wi-Fi capabilities. 16. Added details on the FCC/CE product ratings.

  • Page 6: Introduction

    Critical Power Monitor Introduction The STARLINE CPM M40 and M50 series are electrical energy meters compatible with three phase delta or wye power distribution systems. The STARLINE CPM is integrated into plug-in units for the STARLINE Track Busway electrical distribution system, and provides an easy, effective way to monitor electrical parameters throughout the system.

  • Page 7: M40 Series

    Critical Power Monitor • Outlet neutral current • Outlet total active power Outlet total apparent power • • Outlet power factor Outlet total energy • M40 Series Input Ratings • Control input (J1 input): 110Vac-240Vac, 50/60Hz, 20VA. • Current measuring input (J2 input): +/-0.25Vpeak (To be customized according to Current Transformer rating and selected burden resistor) Voltage measuring input (J3 input): Maximum 600Vac for CAT III.

  • Page 8: Cpm Temperature Monitor

    Critical Power Monitor J2.4, CT4P J2.5, CT5P J2.6, CT6P J2.7, Reference J2.8, Reference (CT1N, CT4N) J2.9, Reference (CT2N, CT5N) J2.10, Reference (CT3N, CT6N) • Voltage measuring input: J3.1, Line 1 J3.2, NC J3.3, Line 2 J3.4, NC J3.5, Line 3 J3.6, NC J3.7, Neutral CPM Temperature Monitor...

  • Page 9: Connector Pinout

    Critical Power Monitor • Pollution Degree 2 Connector Pinout Voltage Input: • J1, Line 1 J2, Line 2 J3, Line 3 J4, Neutral J5, Earth Ground • Current Transformer Input: J6, CT1P J7, CT2P J8, CT3P J9, CT4P J10, CT5P J116, CT6P J12-J17, Reference Accuracy...

  • Page 10: Operating Conditions

    Critical Power Monitor • Current: 0.5% reading • Power factor: 1.0% reading Power and energy measurements: (kW, kVA, kVAR, kWh) ANSI C12.20 Class 0.5 • Operating Conditions • Operating temperature range : 0 °C – 75 °C (32 °F – 167 °F) •...

  • Page 11: Meter Certification

    Critical Power Monitor J2, N Meter Certification The STARLINE CPM bears the following certification marks and is in compliance with all requirements required to bear them. FCC Compliance Statement The STARLINE CPM complies with part 15 of the Federal Communication Commission (FCC) rules. Operation is subject to the following two conditions: 1.

  • Page 12: Warranty Information

    Critical Power Monitor • STARLINE CPM is a UL Recognized Component • Busway devices that utilize the STARLINE CPM are ETL Listed. Warranty Information The following warranty is provided for the STARLINE CPM. Statement Starline hereby represents and warrants that original items manufactured by Starline and supplied to Customer for use, hereafter known as “Product,”...

  • Page 13: Contact And Support

    Critical Power Monitor Contact and support Any questions or concerns about your STARLINE CPM should be directed to Starline below: Starline 168 Georgetown Rd. Canonsburg, PA 15317 Phone: (724) 597-7800 Toll free: (800) 245-6378 Fax: (724) 926-2221 info@starlinepower.com 7/14/2022 Firmware v4.24, v4.24A, or v5.05 Page 13 of 131...

  • Page 14: Feature Guide

    Critical Power Monitor Feature Guide This section describes the basic features of the STARLINE CPM. The meters have several features which are useful for automated monitoring and alerting for electrical distribution systems. M40/M50 Identification The M40 and M50 series provide a variety of features and communication interfaces dependent on customer needs.

  • Page 15: Leds

    Critical Power Monitor The difference between the ‘M’ configuration of a meter and the ‘V’ configuration is the internal wiring of the box. ‘M’ meters only use current transformers (CTs) at the infeed of the box, while ‘V’ meters will have CTs on every outlet line.

  • Page 16: Adjusting Settings

    Critical Power Monitor Buttons The buttons are used exclusively for working with the LCD and therefore are exclusive to the M40 series meters. There are four buttons along the right side of the panel front face. These buttons change function depending on the screen being displayed.

  • Page 17: 3-Digit Led Display

    Critical Power Monitor 1. Press the button until the display reads Settings – Brightness. 2. Use the buttons to adjust the brightness of the display (default 90%). 3. Press the button to return to the main screen. Adjusting the backlight timeout 1.
  • Page 18 Critical Power Monitor Name Label Display Unit L1 to Neutral Voltage “L1n” Volts (V) L2 to Neutral Voltage “L2n” Volts (V) L3 to Neutral Voltage “L3n” Volts (V) L1 to L2 Voltage “PhA” Volts (V) L2 to L3 Voltage “Phb” Volts (V) L3 to L1 Voltage “PhC”...

  • Page 19: Feed Temperature Monitoring

    Critical Power Monitor Feed Temperature Monitoring The Feed Temperature Monitoring system is available as an option exclusively for the M40 series meters built into feeds. The temperature monitor adds real time temperature data for the mechanical connections inside of the feed units to allow for better planning and control of maintenance cycles.

  • Page 20: Networking

    Critical Power Monitor Networking The STARLINE CPM has a variety of networking options which allow for metering over a network. This section describes the types of networking available, as well as the configuration and monitoring web page. Security Starline M40 and M50 series meters comply with California (US) state law SB 327 and Oregon (US) state law HB 2395 for cyber security through the following features: Unique, strong passwords for each meter •...

  • Page 21: Default Usernames And Passwords

    Critical Power Monitor Default Usernames and Passwords The STARLINE CPM has the following Administrator defaults: • Username: admin Password • Unique, randomly generated 15-characters from the ASCII table, case sensitive Password is logged at the factory in secure data location factory as well as on the label on the front of the CPM This password is recommended to be changed upon initial log-in and configuration, and can be defaulted back to on a hard reset of the CPM...
  • Page 22 Critical Power Monitor The User Configuration Register, discussed further down in the document, contains a settable bit to enable ring- mode on the CPM. This will allow the first and last unit of a daisy-chain to be connected to the same network switch without creating routing issues or broadcast storms.

  • Page 23: Wireless

    Critical Power Monitor Important Details Each dual Ethernet CPM has a three-port switch on the unit, which means all communication is true point-to-point Ethernet. The normal limitations for cable distance apply, but the number of units is only limited by what the network can tolerate in propagation delay as each unit will have to re-route a packet until it gets to its destination.
  • Page 24 Critical Power Monitor Note: Energy values rollover at 9000000.000 kilowatt-hours. If Modbus is being used, and the data type is set to float and not double, you must read and reset the energy before it exceeds 6 significant digits, 999.999 kilowatt- hours.
  • Page 25 Critical Power Monitor 4. Click Save Changes. If prompted, enter your username and password and click OK. Modbus register map explained • "Base 0" and "Base 1" refer to the mode of the Modbus Master, the host processor connected to the meter.

  • Page 26: Communication Protocols

    Critical Power Monitor Communication Protocols This section contains information on how to communicate over the network with your STARLINE CPM. Since the M40 and M50 series meters utilize the same communication protocols the entirety of this section will pertain to all STARLINE CPM.

  • Page 27: Http/Https (Web

    Critical Power Monitor HTTP/HTTPS (Web Pages) Monitoring and configuring can be done through the embedded webserver in the STARLINE CPM. To conduct online monitoring, connect to the IP address of the STARLINE CPM using a computer with a web browser on the same network as the meter.
  • Page 28 Critical Power Monitor Viewing connectivity information On the configuration and monitoring web page, click Comm. Info. Viewing feed parameters On the configuration and monitoring web page, click Feed. Select Voltage, Current, or Energy/Power to view a live summary of these parameters. Viewing outlet parameters On the configuration and monitoring web page, click Outlet.
  • Page 29 Critical Power Monitor This step is recommended after initial log-in. 1. On the configuration web page, click Config. 2. Using the text boxes, enter the new Admin Password or User Password. 3. Click Save Changes. If prompted, enter your username and password and click OK. Setting up email alerts Note: This procedure requires that you know the IP address for your email (SMTP) server.
  • Page 30 Critical Power Monitor 4. Click Save Changes. If prompted, enter your username and password and click OK. Setting wired Ethernet configuration Note: Perform this procedure last, as changing network settings will disconnect the host PC from the STARLINE CPM. This procedure requires you to know the network configuration of the local area network to which the STARLINE CPM will be connected.
  • Page 31 Critical Power Monitor 4. If your network uses static IP addresses, click the Static radio button, and enter the Ethernet IP Address, Ethernet Netmask, and Ethernet Gateway for the meter. 5. Click Save Changes. If prompted, enter your username and password and click OK. Setting wireless configuration Note: This procedure requires you to know the network configuration of the local area network to which the STARLINE CPM will be connected.
  • Page 32 Critical Power Monitor 5. Click Save Changes. If prompted, enter your username and password and click OK. Alarm The STARLINE CPM has a configurable alarm feature which can alert the user in several ways. On the device, the STATUS LED will be lit red and the display will illustrate an exclamation point. An email alert can be sent to a preconfigured address as well as an SNMP trap.

  • Page 33: Telnet/Ssh

    Critical Power Monitor 3. Using the text boxes, set the alarm threshold for minimum voltage and maximum voltage for Phase L1-L2, Phase L2-L3, and Phase L3-L1. 4. Click Save Current Settings. If prompted, enter your username and password and click OK. 5.
  • Page 34 Critical Power Monitor The following table describes the elements of the standard command syntax for the meter: Variable Description NAME The command name is 2-10 ASCII characters which is descriptive of the action to perform or the parameters to get, set, or reset. This field is case sensitive. INDEX There are 1 or 2 indices for each command.
  • Page 35 Critical Power Monitor • $LOGIN,monitor • $LOGIN,user,user • $LOGIN,admin,admin Note: No password is required to login at the monitor level. This level cannot set any values in the meter. It is possible to use the LOGIN command to return to a lower privilege level by issuing it with the desired level. Examples The following examples are provided to demonstrate common procedures for the STARLINE CPM.
  • Page 36 Critical Power Monitor $MODP,S,2 Parity = None $MODM20BA,S,1 Don't shift registers 1-40 to 0-39 $MODAAC,S,2570 Admin Access Code = 2570 dec = 0A0A hex $MODUAC,S,0 User Access Code = 0 dec = 0000 hex $REBOOT Changing informative text strings $LOGIN,admin,admin $DEVLO,S,Row1 Col3 $ID,S,Tap Box 5 $OTLID,1,S,Device 1...
  • Page 37 Critical Power Monitor Resetting demand values $LOGIN,user,user $INFLCD,A,R $INFLCPD,A,R $INFCD,R $INFCPD,R $INFTACPD,R $INFPTACPD,R $INFTRACPD,R $INFTAPPD,R $OTLLCD,1,A,R $OTLLCD,2,A,R $OTLLCD,3,A,R $OTLLCD,4,A,R OTLTLCD ,A,R Resetting peak demand values $LOGIN,user,user $INFPTACPD,R $INFPTRACPD,R $INFPTAPPD,R $OTLLCPD,1,A,R $OTLLCPD,2,A,R $OTLLCPD,3,A,R $OTLLCPD,4,A,R OTLTLCPD ,A,R Examples of changing the User Configuration Register (UCR) $LOGIN,user,user $UCR,G Returns the current value of the UCR...

  • Page 38: Snmp

    Critical Power Monitor Examples of command and response $LOGIN,user,user $LOGIN,user,OK*56 $ID,S,Tap Box 5 $ID,S,Tap Box 5,ERR07*15 Not logged in with proper access rights $LOGIN,admin,admin $LOGIN,admin,OK*28 $ID,S,Tap Box 5 $ID,S,Tap Box 5,OK*53 $AAAA $AAAA,ERR09*60 Invalid command $LNV,1 $LNV,1,118.84,OK*57 $LNV,4 $LNV,4,ERR04*21 Index out of range; must be less than 4 SNMP The STARLINE CPM supports Simple Network Management Protocol (SNMP).

  • Page 39: General Information

    Critical Power Monitor through a BACnet discovery tool. The STARLINE CPM contains all BACnet objects necessary for establishing reliable communication with a BACnet browser. A list of BACnet objects may be found in the BACNet object list document. Note: BACnet discovery may not work properly if the STARLINE CPM and BACnet computer are on different networks or subnets.

  • Page 40: Maximum Number Of Instances Per Protocol

    Critical Power Monitor Modbus TCP BACnet UDP 47808 47809 47810 47811 47812 47813 47814 47815 47816 47817 Maximum Number of Instances Per Protocol Below is a table which shows the maximum number of parallel sessions that can be established per protocol. For example, a maximum of 4 Modbus TCP sessions can be established simultaneously.

  • Page 41: Meter Information

    Critical Power Monitor Meter Information This section describes any procedures which may be performed as part of the daily operation and maintenance of the power meter. The M40 and M50 series meters have been designed to utilize the same meter maintenance techniques, therefore this entire section will contain information relevant to both meter series.
  • Page 42 Critical Power Monitor 4. On the software update page, browse to the firmware which you intended to upload. 5. Select the file on your hard drive in the file dialog that appears. 6. Click Upload to upload the new firmware to the meter. 7.

  • Page 43: Configuration Registers

    Critical Power Monitor Configuration Registers This section contains all information related to the configuration registers on the CPM. Every configuration register is comprised of a 32-bit binary number which uses a single bit to enable/disable each independent feature. These flags can be summed up to generate a single integer value which represents all the selected settings. Interpretation Using Table 1 below as an example, let’s assume a user wanted to generate a configuration register with the following settings:...

  • Page 44: User Configuration Register

    Critical Power Monitor Table 1 – Breakout of the User Configuration Register (UCR) Options Setting Name Setting Description Disabled Enabled SNMPv3 Enable/Disable SNMPv3 (may require a different firmware version) Disabled Enabled SSL and SSH Enable/Disable replacement of Telnet with SSH and HTTP with HTTPS Enabled Disabled Modbus/SNMP Disable...

  • Page 45: Display Configuration Register

    Critical Power Monitor Display Configuration Register The display configuration register (DCR) is a register that allows a user to enable/disable which types of data points are displayed on the 7-segment, LED display for M50 CPM. Table 2 shows the complete breakout of data points that can be displayed.

  • Page 46: Alarm Registers

    Critical Power Monitor Alarm Registers This section contains all information related to the alarm registers on the CPM. Every alarm register is comprised of a 32-bit binary number which uses a single bit to indicate an alarm condition. These flags can be summed up to generate a single integer value which represents all active alarms.

  • Page 47: Outlet Alarm Status Register 1

    Critical Power Monitor Outlet Alarm Status Register 1 The Alarm Status Register Solver also works for outlet alarms. $OUTALM is used for outlets 1-4 and $OUTALM2 is used for outlets 5-6. Again, enter the values that the CPM provides into the solver and it will output which alarms are going off.

  • Page 48: Temperature Monitor Alarm Status Register

    Critical Power Monitor Temperature Monitor Alarm Status Register The temperature monitor system has several unique alarms that can be monitored with the telnet command $TMPALM. Starline provides an “alarm solver” which will automatically decode the value from $TMPALM and show which alarms are being triggered. Below is an example of the solver. The CPM responded with 1000 when $TMPALM was sent to the device.

  • Page 49: Breaker Status Alarm Register

    Critical Power Monitor Breaker Status Alarm Register The breaker status alarm register will indicate when a breaker is off/non-conducting. This register is a means of providing an alert that power has been lost, either intentionally (i.e. manually turning off the breaker) or unintentionally (i.e.

  • Page 50: Troubleshooting

    Critical Power Monitor Troubleshooting This section contains some basic information on troubleshooting issues on the CPM. Current Transformers One of the most common issues during an installation is reversing the polarity of the current transformation (CT) or placing the CT on the incorrect phase. A CT placed with the incorrect polarity will result in a negative active power on that individual line.

  • Page 51: Privacy Policy

    Critical Power Monitor Privacy Policy Starline privacy policy can be found here: https://www.legrand.us/privacy Appendix A: Quick Start Guides The guides contained in this section are provided to show the most common or default setup for the STARLINE CPM. They are designed to be broad overviews of the installation process and may not necessarily meet all your needs.

  • Page 52: Quick Start Guide: Ethernet

    Critical Power Monitor Quick Start Guide: Ethernet Please read this entire guide before you begin. Using this guide, you will install a STARLINE Plug-in Unit or Feed Unit with integrated STARLINE CPM, and configure the meter using the embedded web page. Materials Required The following materials and equipment are required for this procedure: •...
  • Page 53 Critical Power Monitor d. Identify the Ethernet adapter to which the STARLINE CPM Meter is connected, and make sure it is marked Enabled. Right click the adapter and select Properties. In the Properties window, scroll through the list and highlight Internet Protocol Version 4 (TCP/IPv4).
  • Page 54 Critical Power Monitor 3. Click Save Changes. If prompted, enter your username and password and click OK. Changing the admin or user account password 1. On the configuration web page, click Config. 2. Using the text boxes, enter the new Admin Password or User Password. 7/14/2022 Firmware v4.24, v4.24A, or v5.05 Page 54 of 131...
  • Page 55 Critical Power Monitor 3. Click Save Changes. If prompted, enter your username and password and click OK. Setting up email alerts Note: This procedure requires that you know the IP address for your email (SMTP) server. 1. On the configuration web page, click Config. 2.
  • Page 56 Critical Power Monitor 4. Click Save Changes. If prompted, enter your username and password and click OK. Setting final network configuration Note: Perform this procedure last, as changing network settings will disconnect the host PC from the STARLINE CPM. This procedure requires you to know the network configuration of the local area network to which the STARLINE CPM will be connected.
  • Page 57 Critical Power Monitor 4. Click Save Changes. If prompted, enter your username and password and click OK. 5. A reset or reboot will be required upon completion of step 4. 7/14/2022 Firmware v4.24, v4.24A, or v5.05 Page 57 of 131...

  • Page 58: Quick Start Guide: Daisy-Chain Ethernet

    Critical Power Monitor Quick Start Guide: Daisy-Chain Ethernet Please read this entire guide before you begin. Using this guide, you will set up a daisy-chain connection between two or more STARLINE M58/M59 meters. This guide will contain information only relevant for the M58 and M59 meter configurations. No device limit has been discovered based on meter hardware, unlike Modbus RTU and was functionally tested with over 150 meters in a single daisy-chain.
  • Page 59 Critical Power Monitor Installation Instructions In this section, you will install, energize, and connect to the STARLINE CPM via the configuration web page. The daisy-chain configuration utilizes device IP address for finding devices; if all devices in a chain have the same IP address communication errors will be the result.
  • Page 60 Critical Power Monitor Use the command “ping” with the meter’s IP address and push the enter key Note: It is possible to ping a series of meters if the IP Addresses are sequenced and share a subnet (i.e. 192.168.1.99, 192.168.1.100, 192.168.1.101, 192.168.1.102, …) using the following command: for /l %i in (99,1,254) do @ping 192.168.1.%i -n 1 -w 100 | find "Reply"...
  • Page 61 Critical Power Monitor Troubleshooting This section contains a list of common issues that may cause communication problems with one or more of the meters in a daisy-chain. Verifying the meters are turned on An M50 meter with power will have a PWR LED blinking green. If the PWR LED is not lit, the meter is not powered on.
  • Page 62 Critical Power Monitor Materials Required The following materials and equipment are required for this procedure: • STARLINE Busway System STARLINE Plug-In Unit or Feed Unit with integrated STARLINE CPM • • CAT-5e or CAT-6 standard Ethernet cable Host PC with web browser to connect to STARLINE CPM (Firefox, Chrome, or Internet Explorer •...
  • Page 63 Critical Power Monitor b. Click Network and Sharing Center. On the left pane in the window, click Change Adapter Settings. d. Identify the Ethernet adapter to which the STARLINE CPM Meter is connected, and make sure it is marked Enabled. Right click the adapter and select Properties. In the Properties window, scroll through the list and highlight Internet Protocol Version 4 (TCP/IPv4).
  • Page 64 Critical Power Monitor 3. Click Save Changes. If prompted, enter your username and password and click OK. Changing the admin or user account password 1. On the configuration web page, click Config. 2. Using the text boxes, enter the new Admin Password or User Password. 7/14/2022 Firmware v4.24, v4.24A, or v5.05 Page 64 of 131...
  • Page 65 Critical Power Monitor 3. Click Save Changes. If prompted, enter your username and password and click OK. Setting up email alerts Note: This procedure requires that you know the IP address for your email (SMTP) server. 1. On the configuration web page, click Config. 2.
  • Page 66 Critical Power Monitor 4. Click Save Changes. If prompted, enter your username and password and click OK. Setting final wireless configuration Note: This procedure requires you to know the network configuration of the local area network to which the STARLINE CPM will be connected. 1.
  • Page 67 Critical Power Monitor 4. Click Save Changes. If prompted, enter your username and password and click OK. 7/14/2022 Firmware v4.24, v4.24A, or v5.05 Page 67 of 131...

  • Page 68: Quick Start Guide: Wireless

    Critical Power Monitor Quick Start Guide: Wireless Please read this entire guide before you begin. Using this guide, you will install a STARLINE Plug-in Unit or Feed Unit with integrated STARLINE CPM, and configure the meter using the embedded web page. Materials Required The following materials and equipment are required for this procedure: •...
  • Page 69 Critical Power Monitor 3. Configure the host PC to connect to the STARLINE CPM by setting the host PC to a static IP in the 192.168.1.XX range, with a subnet mask of 255.255.255.0: Go to the Control Panel. b. Click Network and Sharing Center. On the left pane in the window, click Change Adapter Settings.
  • Page 70 Critical Power Monitor 3. Click Save Changes. If prompted, enter your username and password and click OK. Changing the admin or user account password 1. On the configuration web page, click Config. 2. Using the text boxes, enter the new Admin Password or User Password. 7/14/2022 Firmware v4.24, v4.24A, or v5.05 Page 70 of 131...
  • Page 71 Critical Power Monitor 3. Click Save Changes. If prompted, enter your username and password and click OK. Setting up email alerts Note: This procedure requires that you know the IP address for your email (SMTP) server. 1. On the configuration web page, click Config. 2.
  • Page 72 Critical Power Monitor 4. Click Save Changes. If prompted, enter your username and password and click OK. Setting final wireless configuration Note: This procedure requires you to know the network configuration of the local area network to which the STARLINE CPM will be connected. 1.
  • Page 73 Critical Power Monitor 4. Click Save Changes. If prompted, enter your username and password and click OK. 7/14/2022 Firmware v4.24, v4.24A, or v5.05 Page 73 of 131...

  • Page 74: Quick Start Guide: Modbus Rtu

    Critical Power Monitor Quick Start Guide: Modbus RTU Please read this entire guide before you begin. Using this guide, you will install a STARLINE Plug-in Unit or Feed Unit with integrated STARLINE CPM, and configure the meter using Modbus RTU. Note: The STARLINE CPM also supports Modbus TCP.
  • Page 75 Critical Power Monitor Default Settings The STARLINE CPM has the following default Modbus settings: • Baud: 19200 Parity: None • • Stop bits: 1 Address: 001 • The STARLINE CPM has the following default wired Ethernet settings: • IP Configuration: Static IP Address: 192.168.1.99 •...

  • Page 76: Appendix B: Modbus Register

    Critical Power Monitor 7. Using your Modbus controller and Appendix B: Modbus register map, connect to the meter and verify that it is working. Setting up a STARLINE CPM without a front panel display 1. Connect RS-485 cable to either of the two RS-485 ports on the front of the device. Both ports are connected in parallel as defined by an RS-485 bus definition.
  • Page 77 Critical Power Monitor 8. Using the text box and radio buttons, enter the Modbus Serial Address, Modbus Baud Rate, Modbus Stop Bits, and Modbus Parity. 9. Click Save Changes. If prompted, enter your username and password and click OK. 10. Click Reboot. Note: you may have to reload the webpage in the web browser. 11.

  • Page 78: Modbus Security

    Critical Power Monitor Modbus Security The CPM has an optional proprietary password feature that can be used with Modbus. This feature is linked to the following commands: 1. Default Admin Access Code: 2570 The default value shown above is in decimal format. b.

  • Page 79: Quick Start Guide: Bacnet

    Critical Power Monitor Quick Start Guide: BACnet Please read this entire guide before you begin. This guide may be used to set up a BACnet connection to the STARLINE CPM. A BACnet connection will require an existing Ethernet or wireless connection to the meter. To establish these connections please refer to Quick Start Guide: Ethernet Quick Start Guide:...
  • Page 80 Critical Power Monitor • Gateway: 192.168.1.1 Installation Instructions This section will describe the step by step instructions for establishing the BACnet connection. 1. Create the connection to the meter via a wired Ethernet or wireless connection. If the host PC has a usable web browser (i.e. Firefox, Chrome, or Internet Explorer), verify the connection by typing the CPM’s IP address into the browser’s URL bar.
  • Page 81 Critical Power Monitor b. After typing “cmd” and pushing the enter key the command prompt will appear and should look like the figure below. In the command prompt window type “ipconfig /all” and push enter. This will cause a large scroll of information in the command prompt window.
  • Page 82 Critical Power Monitor 3. Open the BACnet browser or software that will be used. YABE is depicted below. 7/14/2022 Firmware v4.24, v4.24A, or v5.05 Page 82 of 131...
  • Page 83 Critical Power Monitor Use the Add Device feature, the green plus towards the top left of the window. Clicking the button will pull up a window as seen in the figure below. 7/14/2022 Firmware v4.24, v4.24A, or v5.05 Page 83 of 131...
  • Page 84 Critical Power Monitor 5. The connection will be made using BACnet/IP over UDP. Enter the Host PC’s IP address, as was found in the previous steps, into the ‘Local endpoint’ field of the Search window. By default, the ‘Port’ field should be populated with BAC0 (this is also the default port setting for the STARLINE CPM).
  • Page 85 Critical Power Monitor 8. BACnet is now fully functional and communicating with the device. If information needs to be updated, simply clicking the object a second time will send a request for new data from the STARLINE CPM. In this way, data may be constantly read and updated from the meter.

  • Page 86: Troubleshooting

    Critical Power Monitor BACnet Security The CPM has an optional proprietary password feature that can be used with BACnet. This feature utilizes the user and admin passwords of the CPM which can be changed via telnet/SSH ($PWA for admin or $PWU for user). This feature requires the user to login before a write can be performed.
  • Page 87 Critical Power Monitor Enable BACnet capability It is possible to enable the BACnet functionality of the STARLINE CPM through the User Configuration Register (UCR). By setting the “BACnet” bit to 0, BACnet becomes enabled on the meter and will respond to BACnet broadcasts (Who-Is requests).
  • Page 88 Critical Power Monitor 7/14/2022 Firmware v4.24, v4.24A, or v5.05 Page 88 of 131...

  • Page 89: Quick Start Guide: Snmpv1/V2C

    Critical Power Monitor Quick Start Guide: SNMPv1/v2c Please read this entire guide before you begin. This guide may be used to set up an SNMPv1/v2c connection to the STARLINE CPM. An SNMPv1/v2 connection will require an existing Ethernet or wireless connection to the meter. To establish these connections please refer to Quick Start Guide: Ethernet Quick Start Guide: Wireless.
  • Page 90 Critical Power Monitor Password: 15-characters from the ASCII table, case sensitive, randomly generated  Password is logged at the factory in secure data location factory as well as on the label  on the front of the CPM This password is recommended to be changed upon initial log-in and configuration, and ...
  • Page 91 Critical Power Monitor 2. Open the SNMP browser or software that will be used. iReasoning is depicted below. 3. Load the MIB file into the software. 4. Enter the IP address into the “Address:” field and then select “Advanced…”. Again, every software may do this a bit differently but the process should be the same: 5.
  • Page 92 Critical Power Monitor The MIB Tree can now be used to pull information from the CPM: 7. To change a parameter right click on the “value” and select “set”. A new prompt will show up which will allow you to change the parameter: Once you change a parameter you must “get”...
  • Page 93 Critical Power Monitor Traps SNMP traps can be used once the trap destination for the CPM is set. 1. In iReasoning Select Tools>Trap Receiver. This will cause a Trap Receiver tab to open: 2. In the Trap Receiver pane Select Tools>Options. This is where the trap community name and host PC IP address can be entered.
  • Page 94 Critical Power Monitor 3. Find the host PC’s IP address that is being used to connect to the STARLINE CPM This may be done through windows command prompt, which is reached by typing “cmd” into the search bar of the start menu as seen in the figure below. b.
  • Page 95 Critical Power Monitor 7/14/2022 Firmware v4.24, v4.24A, or v5.05 Page 95 of 131...
  • Page 96 Critical Power Monitor 4. The IP address shown above is the one that should be selected in the “BIND IP Address Section of iReasoning”: 5. Traps will be received once all these settings have been correctly entered. Troubleshooting This section lists common issues while using SNMPv1/v2 and possible solutions. Enable SNMPv1/v2 capability It is possible to enable SNMPv1/v2 functionality of the STARLINE CPM through the User Configuration Register (UCR).

  • Page 97: Quick Start Guide: Snmpv3

    Critical Power Monitor Quick Start Guide: SNMPv3 Please read this entire guide before you begin. This guide may be used to set up an SNMPv3 connection to the STARLINE CPM. An SNMPv3 connection will require an existing Ethernet or wireless connection to the meter. To establish these connections please refer to Quick Start Guide: Ethernet Quick Start Guide:...
  • Page 98 Critical Power Monitor There are multiple credentials that may be used to access the meter with SNMPv3, all of which are outlined below. The Starline CPM embedded webpage does not contain any settings for SNMPv3, therefore, all the settings below must be changed via Telnet/SSH.
  • Page 99 Critical Power Monitor SNMPv3 Default Trap Settings: Trap Destination Address 1: 0.0.0.0 • Telnet Command: $SNMPTD1 • Trap Destination Address 2: 0.0.0.0 Telnet Command: $SNMPTD2 • SNMPv3 Trap Username: TrapUsm Telnet Command: $SNMPTUU If $SNMPTAA = $SNMPAUU then the CPM will use these commands for the authentication mechanisms: Telnet Command: $SNMPAA ...
  • Page 100 Critical Power Monitor The CPM will auto-generate a unique SNMPv3 Engine ID if the user does not change this parameter. Telnet Command: $SNMPEID Engine IDs must be specified as semicolon separated octets, for example: 00:01:02:03:04:05:06:07:08:09:0a:0b • SNMPv3 Engine Boot Counter This keeps track of the number of times SNMPv3 has been restarted.
  • Page 101 Critical Power Monitor 4. In Advanced, select SNMP Version 3 and then select the security level. There are three different security levels and the commands associated with each are listed in the Default Settings section of this QuickStart guide. Auth, Priv was used in the example below but here are the 3 options: No Auth, No Priv b.
  • Page 102 Critical Power Monitor 5. Once the login credentials are correctly entered, the MIB Tree can be used to read and write to the CPM: 6. To change a parameter right click on the “value” and select “set”. A new prompt will show up which will allow you to change the parameter: Once you change a parameter you must “get”...
  • Page 103 Critical Power Monitor Traps SNMPv3 traps can be used once the default Trap settings listed in the “Default Settings” section have been set. 1. In iReasoning Select Tools>Trap Receiver. This will cause a Trap Receiver tab to open: 2. In the Trap Receiver pane Select Tools>Options. This is where the host PC IP address must be selected from the “Bind IP”...
  • Page 104 Critical Power Monitor 3. Find the host PC’s IP address that is being used to connect to the STARLINE CPM This may be done through windows command prompt, which is reached by typing “cmd” into the search bar of the start menu as seen in the figure below. b.
  • Page 105 Critical Power Monitor d. Use the slide bar on the right side of the window to scroll back through the information to locate the adapter that is being used to connect to the STARLINE CPM. The name of the adapter and brief description should appear like the first yellow box in the figure.
  • Page 106 Critical Power Monitor 4. The IP address shown above is the one that should be selected in the “BIND IP” dropdown in iReasoning”: 5. Next open the SNMPv3 Trap Receiver tab and select “Add”. A new UI will appear. This is where the trap credentials that were outlined in the “Default Settings”...
  • Page 107 Critical Power Monitor 6. Optional: To disable the privacy algorithm, change the $SNMPTPA to a “-“ (without the quotation marks): $SNMPTPA,S,- b. This will allow the user to use the auth/no priv Security Level when setting up the trap. 7. Optional: To disable the authentication algorithm, change $SNMPTAA to a “–“ (without the quotation marks): $SNMPTAA,S,- b.
  • Page 108 Critical Power Monitor 8. Traps will now appear whenever an alarm is triggered on the CPM: Troubleshooting This section lists common issues while using SNMPv3 and possible solutions. 7/14/2022 Firmware v4.24, v4.24A, or v5.05 Page 108 of 131...

  • Page 109: Quick Start Guide: Replacing Battery For Temperature Monitor

    Critical Power Monitor Quick Start Guide: Replacing Battery for Temperature Monitor Please read this entire guide before you begin. Using this guide, you will replace the battery on a wireless node as part of the temperature monitor system. Note that this product is no longer offered by Starline and is obsolete. Starline now offers a wired temperature monitoring solution that does not use batteries.
  • Page 110 Critical Power Monitor 3. Remove the screw from the housing (yellow box in previous image). Caution: This step and subsequent steps should only be done in an ESD safe area! 4. Remove the PCBA from the housing. 7/14/2022 Firmware v4.24, v4.24A, or v5.05 Page 110 of 131...
  • Page 111 Critical Power Monitor 5. Remove the old battery and place the new battery into the holder (yellow box in the previous image). Ensure that the + side of the battery and + side of the battery holder are lined up! 6.
  • Page 112 Critical Power Monitor 8. Put the screw back into place to hold the PCBA firmly in place. 9. Place the node back onto the bracket in the feed unit. 7/14/2022 Firmware v4.24, v4.24A, or v5.05 Page 112 of 131...

  • Page 113: Quick Start Guide: Perl Script - Mass Firmware Updates

    Critical Power Monitor Quick Start Guide: Perl Script – Mass Firmware Updates Please read this entire guide before you begin. This guide may be used to perform a firmware update on multiple units without having to go to the STARLINE CPM embedded webpage.
  • Page 114 Critical Power Monitor Selecting the Correct Perl script Package from the Starline Website Starline offers multiple pre-packaged folders with all the files necessary for performing firmware updates. The CPM has multiple versions of firmware which is why there are multiple pre-packaged folders. Below are the descriptions of what each folder should be used for.
  • Page 115 Critical Power Monitor Ubuntu v20 or Later (Linux) If Ubuntu v20 or later is being used, then the following files must be changed on the machine for the Perl Scripts to function correctly: 1. Edit openssl.conf file by sending the following command in command prompt: sudo nano /etc/ssl/openssl.cnf 2.
  • Page 116 Critical Power Monitor Creating a List of CPMs to Update 1. Open the upload_list.txt file that is in the Perl Script subfolder 2. Enter the IP Address, username, password, and host-key of every unit that is to be updated. The following format must be followed: <IP_Address>,<username>,<password>,<host-key>...
  • Page 117 Critical Power Monitor 3. PuTTY (plink) can be used to acquire the host-key of the unit. The host-key is associated with the Certificate that is uploaded to the unit. Most likely the host-key will be the same for every unit, so this only needs to be done one time.
  • Page 118 Critical Power Monitor 6. Another way to acquire the host-key is to open Command Prompt (after PuTTY has been installed) and type “plink <IP_ADDRESS>”. An example is shown below where “plink 192.168.2.123” was used (without the quotations). The host-key in this example is 57:1f:b0:11:41:b8:e3:8f:e6:81:1a:5f:2e:f0:03:6a: 7.
  • Page 119 Critical Power Monitor Uploading Firmware to the CPM 1. Open the command prompt shortcut from the CPM Perl Script folder. Command prompt can be opened without the shortcut, but you must be in the directory with all the files in it for the Perl Scripts to work. The shortcut puts you right into the directory with all the files.
  • Page 120 Critical Power Monitor Verifying Firmware Version of Each Unit 1. Once the firmware has been uploaded on all the units it is a good idea to make sure no errors occurred. 2. A Perl Script was created to get the firmware version of each unit. Open command prompt from the shortcut inside of the CPM Perl Scripts folder and enter the following command: perl mu_webgetfwv.pl upload_list.txt This command will get the firmware version of every unit listed in the upload_list.txt file.

  • Page 121: Quick Start Guide: Perl Script - Mass Parameter Changes

    Critical Power Monitor Quick Start Guide: Perl Script – Mass Parameter Changes Please read this entire guide before you begin. This guide may be used to change one or more parameters on multiple units without having to go to the STARLINE CPM embedded webpage.
  • Page 122 Critical Power Monitor Ubuntu v20 or Later (Linux) If Ubuntu v20 or later is being used, then the following files must be changed on the machine for the Perl Scripts to function correctly: 1. Edit openssl.conf file by sending the following command in command prompt: sudo nano /etc/ssl/openssl.cnf 2.
  • Page 123 Critical Power Monitor Creating a List of CPMs to Update 1. Open the upload_list.txt file that is in the Perl Script subfolder 2. Enter the IP Address, username, password, and host-key of every unit that is to be updated. The following format must be followed: <IP_Address>,<username>,<password>,<host-key>...
  • Page 124 Critical Power Monitor 3. PuTTY (plink) can be used to acquire the host-key of the unit. The host-key is associated with the Certificate that is uploaded to the unit. Most likely the host-key will be the same for every unit, so this only needs to be done one time.
  • Page 125 Critical Power Monitor 6. Another way to acquire the host-key is to open Command Prompt (after PuTTY has been installed) and type “plink <IP_ADDRESS>”. An example is shown below where “plink 192.168.2.123” was used (without the quotations). The host-key in this example is 57:1f:b0:11:41:b8:e3:8f:e6:81:1a:5f:2e:f0:03:6a: 7.
  • Page 126 Critical Power Monitor Creating a Text File with the Parameters 1. The next step is to create a text file with the parameters that need to be changed. Keep in mind that any settings that are put into this file will be changed on all units. 2.
  • Page 127 Critical Power Monitor Verifying Firmware Version of Each Unit 1. Firmware version 4.21 or 5.02 (or greater) must be installed on the CPM to use these perl scripts. The first thing to do before trying to send telnet commands via the perl scripts is to make sure that all of the units have the correct firmware version.
  • Page 128 Critical Power Monitor Sending the Parameters to the CPMs 1. Open the command prompt shortcut from the CPM Perl Script folder. Command prompt can be opened without the shortcut, but you must be in the directory with all the files in it for the Perl Scripts to work. The shortcut puts you right into the directory with all the files.
  • Page 129 Critical Power Monitor 5. To verify that the changes all worked, modify the “parameter_get_script.txt” file. This file can be used to “get” parameters from multiple units. See the telnet command list for more information on “get” vs. “set”. b. In the example shown below we are “getting” the UCR and Device ID of all the CPMs listed in the “upload_list.txt”...

  • Page 130: Appendix B: Ascii Table

    Critical Power Monitor Appendix B: ASCII Table Char Char Char Char (null) Space (start of heading) (start of text) " (end of text) (end of transmission) (enquiry) (acknowledge) & (bell) (backspace) (horizontal tab) (NL line feed, new line) (vertical tab) (NP form feed, new page) (carriage return) (shift out)

  • Page 131: Compliance

    Critical Power Monitor Compliance Satisfying RF exposure compliance and Radio compliance FCCID: PPD-AR4100 FCCID: 2AA9B07 (Wireless Temperature Monitor Only) This device generates and radiates radio-frequency energy in compliance with FCC radio frequency radiation exposure guidelines for an uncontrolled environment. This equipment must be installed and operated while maintaining a minimum body-to-antenna distance of 1.1 cm for PIFA antenna. This device complies with Part 15 of the FCC Rules.
  • Page 132 7/14/2022 Firmware v4.24, v4.24A, or v5.05 Page 132 of 131...

This manual is also suitable for:

Starline m50 seriesStarline m41Starline m43Starline m45Starline m47Starline v41 ... Show all

Table of Contents
