QUICK SETUP GUIDE
PMC-1000, PMC-1001, PMM-1000, PMB-1960, PMMC-1000
PM Series Power Meter
Safety Information
DANGER!
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
Follow safe electrical work practices. See NFPA 70E in the USA, or applicable local codes.
This equipment must only be installed and serviced by qualified electrical personnel.
Read, understand and follow the instructions before installing this product.
Turn off all power supplying equipment before working on or inside the equipment.
Any covers that may be displaced during the installation must be reinstalled before powering the unit.
Use a properly rated voltage sensing device to confirm power is off.
DO NOT DEPEND ON THIS PRODUCT FOR VOLTAGE INDICATION
Failure to follow these instructions will result in death or serious injury.
NOTICE
This product is not intended for life or safety applications.
Do not install this product in hazardous or classified locations.
The installer is responsible for conformance to all applicable codes.
Mount this product inside a suitable fire and electrical enclosure.
CAUTION
RISK OF EQUIPMENT DAMAGE
This product is designed only for use with 0.33V output current transducers (CTs).
DO NOT USE CURRENT OUTPUT (e.g. 5A) CTs ON THIS PRODUCT.
Failure to follow these instructions can result in overheating and permanent equipment damage.
For use in a Pollution Degree 2 or better environment only. A Pollution Degree 2 environment must control conductive pollution and the
possibility of condensation or high humidity. Consider the enclosure, the correct use of ventilation, thermal properties of the equipment, and the
relationship with the environment. Installation category: CAT II or CAT III
Provide a disconnect device to disconnect the meter from the supply source. Place this device in close proximity to the equipment and within
easy reach of the operator, and mark it as the disconnecting device. The disconnecting device shall meet the relevant requirements of IEC
60947-1 and IEC 60947-3 and shall be suitable for the application. Disconnecting fuse holders can be used in the USA and Canada. Provide
overcurrent protection and disconnecting device for supply conductors with approved current limiting devices suitable for protecting the wiring.
If the equipment is used in a manner not specified by the manufacturer, the protection provided by the device may be impaired.
This symbol indicates an electrical shock hazard exists.
Documentation must be consulted where this symbol is used on the product.
Equipment Maintenance and Service
WARNING! This equipment must only be installed by qualified electrical personnel. This product contains no user serviceable parts. Do not open,
alter or disassemble this product. All repairs and servicing must be performed by Raritan authorized service personnel. Failure to comply with this
warning may result in electric shock, personal injury and death.
Raritan
400 Cottontail Lane, Somerset, NJ 08873 USA
Power Meter Quick Setup Guide
1
QSG-PMM-A1-v4.0.10-E  255-64-0004-00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Raritan PM Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LEGRAND Raritan PM Series

  • Page 1 QUICK SETUP GUIDE PMC-1000, PMC-1001, PMM-1000, PMB-1960, PMMC-1000 PM Series Power Meter Safety Information DANGER! HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH Follow safe electrical work practices. See NFPA 70E in the USA, or applicable local codes. This equipment must only be installed and serviced by qualified electrical personnel. Read, understand and follow the instructions before installing this product.
  • Page 2: Product Overview - Pm Series Power Meters

    Product Overview - PM Series Power Meters Raritan PM series power meters is a modular power metering solution that is a flexible alternative to the all-in-one BCM2 hardware. All solutions support Xerus technology platform. The PM series includes controllers, power meters, and branch circuit monitor modules.
  • Page 3: Current Measurement Inputs

    *Ratings for models with field wiring terminals. For models with factory installed line-cords, rating is limited by plug and ratings are labeled on back on unit. Current Measurement Inputs: Input Range 0-333mV Input Impedance 10kΩ CT Type Voltage Output = 333mV at rated current CT Rated Current 1-1200A Meter Measurement Accuracy:...
  • Page 4: Power Meter (Pmm) Connectors And Controls

    Environmental: Operating Temperature 0-60°C Operating Humidity 5-85%RH Operating Elevation 0-3000m Conformance: Safety UL/EN 61010-1 EMC/EMI EN61326-1, FCC Part 15 Class A Power Meter (PMM) Connectors and Controls Voltage Measurement. Power Factory Use (Do not connect.) Meter Bus Terminator Switch Meter Bus Connectors. Connects PMM to Controller.
  • Page 5: Power Meter With Controller (Pmmc)

    Multi-conductor cable CT 1 connector. Multi-conductor cable CT 2 connector. Multi-conductor cable CT 3 connector. Multi-conductor cable CT 4 connector. Multi-conductor cable CT 5 connector. Multi-conductor cable CT 6 connector. Multi-conductor cable CT 7 connector. Multi-conductor cable CT 8 connector. BOTTOM Expansion port.
  • Page 6: Power Meter Controller (Pmc) Ix6/Ix7

    Voltage Measurement Expansion Port is on bottom side of unit. Connects PMMC to PMB. Power Meter Controller (PMC) iX6/iX7 MODBUS RTU isolated RS-485 Meter bus connector (to PMM) Meter bus terminator switch 10/100 base-t Ethernet. Feature port (Raritan asset strip) Sensor port (temperature, humidity, etc.) USB A &...
  • Page 7: Voltage And Current Measurement Wiring

    35mm DIN rail Modules snap into rail. Pull white tab here to remove. Voltage and Current Measurement Wiring Protect phase lines with fused disconnects rated for available short circuit current at connection point. All wiring: 14-22 AWG, 75°C, solid or stranded. Do not solder tin wire ends.
  • Page 8: Pmb Branch Circuit Wiring

    Split-Phase North American 120/240V Panel, 2L+N circuit Three-Phase 3L, 3-phase without neutral 3L+N, 3-phase with neutral Note: X: Selection, Blank: Non-selection PMB Branch Circuit Wiring CT plugs into 2-pin locking connector (Molex 43640-0201) Branch Circuits have two labels: Red labels for odd/even numbered panels.
  • Page 9: Pmm Power Wiring

    PMM Power Wiring PMM can be powered from the voltage measurement inputs or from an auxiliary AC power source. Powering from the voltage measurement inputs minimizes circuitry, but the meter may stop functioning if the voltage turns off. Powering from an auxiliary single phase circuit is required when the voltage measurement circuit exceeds 240V, or when continued operation is required if the voltage measurement inputs turn off.
  • Page 10: Controller Wiring To Meters

    Powering from an auxiliary single phase circuit is required when the voltage measurement circuit exceeds 240V, or when continued operation is required if the voltage measurement inputs turn off. Controller Wiring to Meters The PMC controller supports up to 70 power meters (PMM) OR eight branch circuit meters (PMM+PMB) using daisy-chain wiring with shielded cat 5 Ethernet cable.
  • Page 11: Panel Layout

    Panel Layout Login and Configuration Connect your PC directly to the PM-Series Power Meter/Branch Circuit Monitor to complete the initial configuration.  To access the web interface at the rack: 1. Disable the wireless interface of the PC. 2. Connect a cat 5 cable between the PC and PM-Series Power Meter/Branch Circuit Monitor network ports. 3.
  • Page 12  To configure with the product web interface: Make a network connection to the product. See Login and Configuration (on page 11). Follow the instructions in this guide, starting with: Scan Power Meters. Configure Using the Web Interface Scan Power Meters Click Power Meters.
  • Page 13 Configure Panel Mains Circuit Enter a name. Select the circuit type: Single Phase Split Phase 3-phase Enter the number of circuit positions in the panel. Select the panel layout: one or two columns. Select the circuit position numbering style: sequential or odd/even. Enter the current rating (circuit breaker rating) of the circuit.
  • Page 14 Click Create Circuit. The Create Circuit dialog opens. Enter a name for the Click the Phase or CT# to edit circuit. the automatic labels. Select the circuit type: Click Create. One-Phase LN, One-Phase LL, One-Phase LLN, or Three-Phase. Circuit type cannot be changed later.
  • Page 15 The details page opens. In the details page, click the actions icon, then choose Edit Thresholds. The sensor list displays. Click a sensor to open the Edit Threshold dialog. Select the checkbox for the level, and enter the threshold current in amps. Click OK.
  • Page 16: Manual Mode

    Using the PM-Series Power Meter/Branch Circuit Monitor's Display  Automatic Mode: The PM-Series Power Meter/Branch Circuit Monitor has a display with automatic and manual modes. In automatic mode, the display scrolls through readings.  Manual Mode: In manual mode, you can select readings and settings to view.
  • Page 17 ▪ https://itunes.apple.com/app/raritan-pdview/id780382738 ▪ https://play.google.com/store/apps/details?id=com.raritan.android.pdview 2. Install PDView. Step 2: Connect the Mobile Device to PM-Series Power Meter/Branch Circuit Monitor The USB cable and USB port to connect are determined by your mobile operating system.  To connect your mobile device to PM-Series Power Meter/Branch Circuit Monitor: 1.
