  • Page 1 U S E R M A N U A L...
  • Page 2 Thank you FANTIC WANTS TO THANK YOU for choosing one of its products. We recommend that you read this manual before driving your vehicle. It contains information, advice and warnings on the vehicle maintenance and use. The instructions in this manual have been prepared to give you a simple and clear guide for use.

  • Page 4: Table Of Contents

    Table of conTenTs InTRoDucTIon ........................6 GeneRal InfoRMaTIon ....................... 7 Symbols used ................................7 General warnings ................................8 Vehicle identification..............................11 Rules of use ........................13 Behaviour and driving .............................. 13 Running-in rules ............................... 16 Turning the vehicle on and off ..........................17 Starting and using the gearshift ..........................20 Braking and the ABS system ............................
  • Page 5 Table of conTenTs Steering lock engagement ............................35 Horn button ................................35 Turn signal switch ..............................36 High beam/low beam light button ..........................36 High beam flashing button ............................37 Starter button ................................37 Engine stop button ..............................38 Emergency light switch ............................38 Suspensions (Scrambler/Deluxe versions) ......................39 Suspensions (Rally/explorer versions) ........................42 Regolazione del gioco della leva della frizione ......................47 Lights and turn signals .............................49...
  • Page 6 Table of conTenTs Operation and Maintenance ............................60 Engine oil ...................................62 Tires ...................................64 Coolant ..................................67 Braking system .................................69 Chain..................................72 Front brake lever clearance check ..........................75 Rear brake pedal clearance check ...........................75 Troubleshooting and errors .............................76 Seat opening ................................78 Battery ..................................79 Fuses and relays ............................... 81 Vehicle inactivity ...............................83 Vehicle washing ................................84 Recommended products table ..........................86...

  • Page 7: Introduction

    This manual is an integral part of the vehicle and if the vehicle should be resold, it must be delivered together with the vehicle. Fantic Motor reserves the right to modify and make changes, at any time and without notice, to the models described, specifications and design data, guaranteeing the essential characteristics described and illustrated herein.

  • Page 8: General Information

    GeneRal InfoRMaTIon syMbols useD The symbols indicated in the booklet are very important. They are used to highlight parts of text to which it is necessary to pay more attention. Read this manual carefully before starting the engine. Your safety and that of others does not depend only on your quickness of reflexes and agility, but also on your knowledge of the vehicle, its condition and your knowledge of the rules for safe driving.

  • Page 9: General Warnings

    GeneRal WaRnInGs Motorcycle care Fantic Motor recommends using appropriate vehicle care products. Using products that contain alcohol, nitro diluents, cold detergents, fuels or similar can ruin and/or damage vehicle components. Regular care preserves the aesthetic and functional quality of your vehicle for a long time.
  • Page 10 GeneRal InfoRMaTIon used engine and gearbox oil Used engine and gearbox oil is harmful to health, whether it is inhaled or swallowed. It is also irritating and can cause serious consequences if it comes into contact with the skin. Spreading and dispersion into the environment is prohibited. If swallowed, do not induce vomiting, but go urgently to a first aid centre, indicating the cause and how the accident occurred.
  • Page 11 GeneRal InfoRMaTIon electrolyte and hydrogen gas from the battery The electrolyte of the battery is toxic and caustic. In contact with skin it can cause burns, as it contains sulphuric acid. Wear gloves and protective clothing. If the electrolyte liquid comes into contact with the skin, wash it thoroughly with fresh water. Protect your eyes, as battery fluid can cause blindness.

  • Page 12: Vehicle Identification

    Frame number Engine number fantic Motor vehicles are equipped with frame and engine identification numbers. It is advisable to write down the identification numbers in the spaces indicated above, in order to remind them in case of loss or damage.
  • Page 13 GeneRal InfoRMaTIon Frame number The frame number is punched on the steering tube on the right side. The image shown is for information only. for the original spare parts supply this identification number to your dealer. Engine number The engine number is punched on the left side of the crankcase.

  • Page 14: Rules Of Use

    Rules of use behaVIouR anD DRIVInG Some safety tips are given below to avoid damage to people and/or things and to use your vehicle with an easier and safer drive. Vehicle use To use the vehicle it is necessary to meet all the law requirements. It is advisable, in order to acquire a good knowledge of the vehicle, to use the vehicle in areas without traffic or unpopulated stretches of road.
  • Page 15 Rules of use The getting on and off from the vehicle must be in complete freedom of movement and without impediments. Go up and down only from the left side of the vehicle and with the kickstand down to prevent unbalancing or loss of balance, causing falls or overturns.
  • Page 16 Rules of use The rider must instruct the passenger on how to get off the vehicle. The passenger must get off with the utmost caution, avoiding unbalancing the rider and the vehicle. Do not get off the vehicle jumping or by stretching the leg to touch the ground. The stability and balance of the vehicle would be compromised.

  • Page 17: Running-In Rules

    “scheduled maintenance plan” on page 89: at the scheduled mileage, carry out servicing at an authorised fantic Motor center. comply with the deadlines for these checks and operations in order to avoid damage to the vehicle, to others and to yourself.

  • Page 18: Turning The Vehicle On And Off

    Rules of use TuRnInG The VehIcle on anD off Starting Release the steering lock turning the key clockwise and get on the vehicle assuming the correct posture, making sure that the kickstand is completely retracted. If the kickstand is lowered, the vehicle can be started only with the gearbox in neutral.
  • Page 19 Rules of use Turn the key to “ON” and wait a few seconds to load the standard parameters on the dashboard display. Deactivate the engine stop function by pressing the “A” button and then pressing the “B” start button once. It is advisable to warm up the engine well, proceeding for the first kilometres at reduced speed.
  • Page 20 Rules of use Engine stop To stop the vehicle and the engine, apply the front and/or rear brake until the vehicle is stopped. Set the shift lever to neutral. Do not intervene on the engine stop switch when the vehicle is running, this would cause the engine to stop;...

  • Page 21: Starting And Using The Gearshift

    Rules of use sTaRTInG anD usInG The GeaRshIfT Starting After starting the vehicle and warming the engine well, operate the clutch lever and engage the first gear pressing the gear lever downwards. The neutral indicator light will go off on the dashboard. Releasing the clutch slowly, gradually accelerate to allow the vehicle to move forward.

  • Page 22: Braking And The Abs System

    Rules of use Gearshift use To change gears, release the throttle control knob, operate the clutch lever and raise the gearbox pedal upward to shift up and/or down to shift down. If you are a beginner in driving the vehicle, it is important to familiarize yourself with the vehicle controls and its functions.

  • Page 23: Abs System

    It is important to always check that the phonic wheels are clean and periodically check that the distance from the sensor is fully constant. for verification and adjustment, contact an authorized fantic Motor center.

  • Page 24: Parking

    Moderate the speed and go to an authorized fantic Motor center. at low speed the abs system is not active: pay particular attention to the braking situations in conditions of low grip at low speed.

  • Page 25: Side Kickstand

    The kickstand sensor is part of the ignition circuit interruption system. This system allows you to stop the ignition. It is necessary to check the operation of the kickstand interruption system and the kickstand itself regularly. In case of failure or malfunction contact a fantic dealer to repair it.

  • Page 26: Silencer

    Check that there are no holes and signs of rust or wear on the exhaust system. Check that the exhaust system always works correctly. In case of increased or abnormal noise, contact a Authorized Fantic Motor Center as soon as possible. for maintenance, repair or replacement work, contact an authorized fantic Motor center.

  • Page 27: Clothing

    Rules of use cloThInG Always wear and fasten the helmet before starting to ride the vehicle. The helmet must be approved, intact and with the visor intact and clean. Wear appropriate protective clothing and no hanging accessories that could create problems when riding the vehicle.

  • Page 28: Refuelling

    Rules of use RefuellInG To refuel, lift the cover “A”. Insert the key “B” and turn it anticlockwise. Lift the cap “C” and refuel. When refuelling, do not smoke or use open flames, avoid using electrical devices or any source that can trigger sparks or ignition.
  • Page 29 Rules of use Fuel reserve indicator light If the fuel reserve indicator light comes on, refuel as soon as possible. STREET ALL - TERRAIN GEAR km/h miles TRIPAB BATT...

  • Page 30: Main Elements And Devices

    MaIn eleMenTs anD DeVIces MaIn conTRols (scRaMbleR/DeluXe VeRsIons) 12 11 1. Headlight 10. Rear handle 19. Gear shift lever 2. Left front turn indicator 11. Rear fender 20. Left radiator cover 3. Dashboard 12. Tail light 21. Front brake calliper 4.
  • Page 31 MaIn eleMenTs anD DeVIces 24. Right rear-view mirror 33. Right rider footrest 25. Right light stalk 34. Rear brake master cylinder 26. Gas command 35. Right passenger footrest 27. Front brake master cylinder 36. Rear brake calliper 28. Front brake lever 37.

  • Page 32: Main Controls (Rally Version)

    MaIn eleMenTs anD DeVIces MaIn conTRols (Rally VeRsIon) 12 11 1. Headlight 10. Rear handle 19. Gear shift lever 2. Left front turn indicator 11. Rear fender 20. Left radiator cover 3. Dashboard 12. Tail light 21. Front brake calliper 4.
  • Page 33 MaIn eleMenTs anD DeVIces 24. Right rear-view mirror 33. Right rider footrest 25. Right light stalk 34. Rear brake master cylinder 26. Gas command 35. Right passenger footrest 27. Front brake master cylinder 36. Rear brake calliper 28. Front brake lever 37.

  • Page 34: Panel Commands

    MaIn eleMenTs anD DeVIces Panel coMManDs 1. Mode button 10. Turn signals indicator light switch 2. Selection button 11. Starter button 3. Ignition switch 4. Engine stop button 5. High beam flasher button 6. Horn button 7. Turn signal switch 8.

  • Page 35: Driving Controls And Adjustments

    DRIVInG conTRols anD aDJusTMenTs IGnITIon sWITch The ignition switch is located at the front of the vehicle near the dashboard. The functions of the ignition switch are the following: A. The handlebar is locked and the vehicle cannot be started and the lights cannot be switched on. The key can be removed.

  • Page 36: Steering Lock Engagement

    DRIVInG conTRols anD aDJusTMenTs sTeeRInG lock enGaGeMenT To insert the steering lock, turn the handlebar completely to the left and turn the key to position “A”. Press and turn the key anticlockwise and slowly turn the handlebar until the key is positioned on “B”. hoRn buTTon Press to activate the horn.

  • Page 37: Turn Signal Switch

    DRIVInG conTRols anD aDJusTMenTs TuRn sIGnal sWITch Press the switch to the left or right to indicate the turn. Press the switch, bringing it to the center position to deactivate the indicators. hIGh beaM/loW beaM lIGhT buTTon Press the light button to activate the high beam Press the light button again to return to the low beam.

  • Page 38: High Beam Flashing Button

    DRIVInG conTRols anD aDJusTMenTs hIGh beaM flashInG buTTon Pressing it activates the flashing of the high beam. It is usually used to indicate danger or emergency situations. When the button is released, the high beam flashing is deactivated. sTaRTeR buTTon When the key is inserted and set to ‘ON’, with the engine stop button deactivated, the engine will start when the start button is pressed.

  • Page 39: Engine Stop Button

    DRIVInG conTRols anD aDJusTMenTs enGIne sToP buTTon Pressing it stops the engine. It has the function of a safety or emergency switch. Do not intervene on the switch when the vehicle is running, this would cause the engine to stop. This could result in loss of control of the vehicle, increasing the risk of accidents and damaging things and/or people.

  • Page 40: Suspensions (Scrambler/Deluxe Versions)

    DRIVInG conTRols anD aDJusTMenTs susPensIons (scRaMbleR/DeluXe VeRsIons) Front wheel suspension for the replacement of the front suspension oil, go to an authorized fantic Motor service center. For maintenance intervals, refer to the section “Scheduled maintenance plan” on page 89 under “Fork”. Check Apply the front brake lever, push repeatedly on the handlebars, making the fork compress.
  • Page 41 If the user does not have the necessary technical skills and does not feel confident in performing this adjustment, it is recommended to contact a fantic Motor authorized center directly. To perform this procedure, it is necessary to have : no.
  • Page 42 When adjusting the adjustment ring nuts, take particular care when handling the hook wrenches, in order to avoid the risk of injuring yourself by hitting other parts of the motorcycle. Do not force the rotation of the adjusters beyond the limits set by fantic Motor, to avoid possible damage.

  • Page 43: Suspensions (Rally/Explorer Versions)

    (Rally/eXPloReR VeRsIons) Front suspension for the replacement of the front suspension oil, go to an authorized fantic Motor service center. For maintenance intervals, please refer to the section “Scheduled maintenance plan” on page 89 under “Fork”. for good vehicle stability, make sure that the suspensions are adjusted equally between the front and the rear.
  • Page 44 DRIVInG conTRols anD aDJusTMenTs The standard adjustment of the front fork is designed to adapt to most driving styles and situations, however it is possible to make custom adjustments. The left stem adjustment is divided into two types: – COMPRESSION; –...
  • Page 45 DRIVInG conTRols anD aDJusTMenTs The adjustment of the right stem consists only in the adjustment of the spring preload. To adjust the right stem spring preload it is necessary, initially, to turn the adjustment screw “C” completely counter-clockwise (“-”). Turn the adjustment screw “C” clockwise (“+”), counting 5 turns.
  • Page 46 If the user does not have the necessary technical skills and does not feel confident in performing this adjustment, it is recommended to contact a fantic Motor authorized center directly. To adjust the rear shock absorber spring extension it is necessary, initially, to fully close the adjustment screw “B”...
  • Page 47 DRIVInG conTRols anD aDJusTMenTs Adjust the rear shock absorber preload as follows: – Unscrew the locking ring nut “C”; – Use the adjustment ring nut “D” to adjust the shock absorber spring preload “E”; – Screw in to increase the preload, vice versa, unscrew to decrease it;...

  • Page 48: Regolazione Del Gioco Della Leva Della Frizione

    (“D”): 2 mm (0.08 in). clutch lever clearance must comply with the value indicated by fantic Motor in order to avoid malfunctions, slipping and permanent damage to the engine. a lack of clutch lever clearance can cause permanent engine damage.
  • Page 49 Motor center. If the adjustments made and the resulting clearance are not within the prescribed parameters, there is a risk of serious damage to the vehicle’s engine and clutch.

  • Page 50: Lights And Turn Signals

    DRIVInG conTRols anD aDJusTMenTs lIGhTs anD TuRn sIGnals for disassembling, checking and/or replacing the headlight, tail light and license plate light, contact an authorized fantic Motor service center. headlight adjustment To check the correct direction of the headlight beam, proceed as follows: –...

  • Page 51: Rear-View Mirrors

    DRIVInG conTRols anD aDJusTMenTs ReaR-VIeW MIRRoRs The operations described below apply to both rear- view mirrors. Place the vehicle on the kickstand and on a flat and stable surface. Loosen the lock nut “A”, turn the left-hand mirror counter-clockwise and remove it, then turn the right-hand mirror clockwise and remove it.

  • Page 52: Dashboard

    DashboaRD DIsPlay unIT STREET ALL - TERRAIN GEAR km/h miles TRIPAB RANGE BATT 1. Coolant temperature 10. Neutral 2. Gear indicator 11. ABS status 3. Tachometer 12. Main information window 4. Side kickstand 13. Malfunction indicator light 5. Speedometer 14. Fuel reserve indicator light 6.

  • Page 53: Basic Information Window

    DashboaRD After turning the key to "ON", all indicator lights are shown on the display. STREET ALL - TERRAIN GEAR km/h miles TRIPAB RANGE BATT basIc InfoRMaTIon WInDoW When the display is switched on, basic information is shown in window "12". It is possible to navigate through the menu STREET ALL - TERRAIN by briefly pressing the "MODE"...

  • Page 54: Low Fuel Level Warning

    DashboaRD loW fuel leVel WaRnInG When the fuel level is below the "low level" threshold, the corresponding warning light comes on (amber colour), until STREET ALL - TERRAIN the fuel level returns above the "low level" threshold. GEAR km/h miles TRIPAB RANGE BATT...

  • Page 55: Abs Disable Logic

    DashboaRD When the motorcycle is switched off and on again with the naMe Icon key, the display must reset to the default riding mode. The riding mode affects the ability to disable the ABS. STREET ON or OFF ALL-TERRAIN (if required) abs DIsable loGIc Disabling the ABS is only permitted under the following circumstances:...

  • Page 56: Accessing The Settings Menu

    DashboaRD At any time while the ABS is in the "OFF" status, briefly pressing the "ABS" button "C" will reactivate the "ON" status. Reactivation turns the ABS warning light off. STREET ALL - TERRAIN STREET ALL - TERRAIN GEAR GEAR at each key off - key on cycle, the abs returns to km/h km/h...

  • Page 57: Clock And Time Settings

    DashboaRD clock anD TIMe seTTInGs In this menu screen the user can set: – Time (Hours/minutes). STREET ALL - TERRAIN STREET ALL - TERRAIN – Time format (12/24H). GEAR GEAR km/h km/h By holding down the "MODE" button "A", it is possible to miles miles automatically adjust the hours until the button is released.

  • Page 58: Unit Settings

    DashboaRD unIT seTTInGs In this menu screen the user can set: – Unit (miles/km). STREET ALL - TERRAIN STREET ALL - TERRAIN GEAR GEAR With each short press of the "MODE" button "A", the units km/h km/h (miles/km) can be changed. miles miles By briefly pressing the "SET"...

  • Page 59: Connectivity System

    Through the "Connectivity" system, you have the possibility of connecting your smartphone to your Fantic vehicle, via Bluetooth® . To do so, it is necessary to download the Fantic Garage app from the App Store (IOS® system) or the Google Play Store (Android® system).

  • Page 60: Main Maintenance Operations

    Replacing components Refer only to an authorised fantic Motor centre, so that only original fantic Motor components are used for a guarantee of reliability and safety.

  • Page 61: Operation And Maintenance

    If the user is not interested in performing certain routine maintenance operations, we recommend going to an authorized fantic Motor service center. If it is necessary to have technical advice or request service, contact the authorized fantic Motor center.
  • Page 62 MaIn MaInTenance oPeRaTIons Verification operations to be carried out by the customer The proposed mileage intervals are purely indicative. In the case of heavy and/or special use, carry out visual and functional checks on the vehicle before further use. component Intervention before every...

  • Page 63: Engine Oil

    MaIn MaInTenance oPeRaTIons enGIne oIl Engine oil consumption and quality deteriorate with riding conditions and over time. Check the oil level regularly and, if necessary, top up with the recommended engine oil. Dirty or exhausted oil must be changed as soon as possible. check the engine oil level every 500 km (300 mi).
  • Page 64 Engine oil replacement The operations for filter and engine oil replacement are complicated for an inexperienced operator. It is advisable to contact an authorized fantic Motor center if you need to remove and replace the filter and the engine oil.

  • Page 65: Tires

    MaIn MaInTenance oPeRaTIons TIRes SCRAMBLER DELUXE For tyre pressure values, brand, type and dimensions refer to the chapter “Technical data” on page 94. EXPLORER check the tire pressure at room temperature, because if the tires are warm, the measurement will not be correct.
  • Page 66 MaIn MaInTenance oPeRaTIons The sticker indicates the inflation pressure of the front and rear tires. It can be positioned on the chain guard, left side of the vehicle. Find the position where the chain is most taut. Misurare la tensione della catena nel punto medio Measure chain tension in the middle point of the del ramo inferiore, con la motocicletta sul cavalletto lower branch, with the motorcycle on the side stand...
  • Page 67 Replacement, repair and maintenance are very important and must be performed with appropriate tools and by an operator with the necessary experience. For this reason, it is advisable to contact an authorized Fantic Motor Center or a tire specialist for the execution of certain operations.

  • Page 68: Coolant

    Check that the coolant is between the levels shown in the figure. If the coolant level steadily decreases or the tank remains empty, it is probable that there are major leaks in the system: contact an authorised fantic Motor centre immediately.
  • Page 69 – Remove the cap from the coolant tank; Recommended product: antifreeze liquid based on ethylene glycol with organic additives. If there is no antifreeze fluid available, add distilled water and go to an authorised fantic Motor centre as soon as possible to purchase new coolant.

  • Page 70: Braking System

    If the brake disc and the brake pads are not to be replaced, contact an authorized fantic Motor service center. Refilling the brake system To top up the brake fluid, do to an authorized fantic Motor service centre.
  • Page 71 MaIn MaInTenance oPeRaTIons Pads wear check It is recommended to check the consumption of the pads at least every 1500 km (900 mi). If there is a reduction in the vehicle’s braking capacity, carry out an inspection of the brake pads and brake discs.
  • Page 72 MaIn MaInTenance oPeRaTIons check the wear condition of the front brake pads from the back of the calliper, where it is possible to see the ends of the pads which must have at least a 2 mm (0.08 in) layer of lining, if the layer is lower, replace them immediately.

  • Page 73: Chain

    • teeth excessively worn (see example “D”); • damaged teeth (see example “E”). If one of these components is damaged or excessively worn, contact your authorised fantic Motor workshop to request replacement of the entire chain assembly (sprocket, chain and chainring).
  • Page 74 “Recommended products table” on page 86. If the right products are not available and if the user does not feel confident in cleaning and lubricating the chain, it is advisable to contact a fantic Motor authorised centre directly.
  • Page 75 If there is a higher clearance in certain positions, it means that there are crushed or seized meshes, in this case contact an authorized fantic Motor center. To prevent the risk of seizure, it is recommended to lubricate the chain correctly.

  • Page 76: Front Brake Lever Clearance Check

    Check that the rear brake light works properly when the brake lever is pressed. If the lever clearance is excessive, contact an authorised fantic Motor workshop. ReaR bRake PeDal cleaRance check Check the clearance of the rear brake pedal. The free clearance “b” on the rear brake pedal for operating the brake master cylinder must be : 2 mm (0.08 in).

  • Page 77: Troubleshooting And Errors

    If the procedure indicated does not solve the problem, contact an authorised fantic Motor centre as soon as possible. If a fuse or relay is to be replaced, inform a fantic Motor authorised centre: any solution may not be definitive and may be related to a more extensive problem with the vehicle.
  • Page 78 69 The braking pattern is smooth. Do not use the vehicle, park it properly and contact an Authorized Fantic Motor Center. Significant increase in braking distance. Check the brake fluid level. The brake controls do not present a consistent Poor and/or absent brake fluid.

  • Page 79: Seat Opening

    MaIn MaInTenance oPeRaTIons seaT oPenInG To open the seat, unscrew and remove knob “A” located under the rear mudguard. Lift up and remove the saddle “B”. before reassembling the saddle make sure you have not forgotten the key in the area under the saddle. before riding, check that the saddle has been correctly fixed.

  • Page 80: Battery

    Install components in the reverse order of removal. Always connect the positive terminal first and then the negative terminal. Do not remove the protections and always install the battery respecting the polarities, protecting the terminals with vaseline grease.In tal caso si consiglia di rivolgersi presso una concessionaria autorizzata fantic Motor.
  • Page 81 The procedure for cleaning the battery terminals may not be suitable for less experienced persons. In this case, it is advisable to contact an authorised fantic Motor dealer. – Remove the battery; – If the terminals begin to corrode and are coated with a whitish substance, they have to be washed with warm water and cleaned;...

  • Page 82: Fuses And Relays

    If a fuse frequently blows, there may be an electrical problem. It is therefore advisable to take the vehicle to an authorized fantic Motor dealership for inspection. Do not repair faulty fuses and never use a fuse of a...
  • Page 83 MaIn MaInTenance oPeRaTIons fuse removal Set the ignition switch to “OFF”. – Remove the seat and the fuse box cover from the vehicle. – Remove one fuse at a time and check if the filament is broken. – Replace the fuse, if damaged, with a type of the same amperage.

  • Page 84: Vehicle Inactivity

    MaIn MaInTenance oPeRaTIons VehIcle InacTIVITy If the vehicle should remain inactive for months it is advisable to take some precautions: – Empty the tank completely. – Remove the battery and charge it with a suitable battery charger every two weeks. The battery must be kept in a dry place and at a temperature between 5-35 °c (41-95 °f).

  • Page 85: Vehicle Washing

    The use of high-pressure washing systems (or steam cleaners) can damage the seals, the oil seals, brake system, electrical system, dashboard and seat. fantic Motor does not recommend the use of steam or pressure washing systems to clean the vehicle.
  • Page 86 MaIn MaInTenance oPeRaTIons – Steering lock; – Fuel tank cap or similar; – Headlight and tail light; – Electrical components; – Decals. Use a jet of warm water at low pressure, rinse the vehicle thoroughly and in particular the dirtiest parts. With a soft sponge rub all parts of the vehicle.

  • Page 87: Recommended Products Table

    MaIn MaInTenance oPeRaTIons RecoMMenDeD PRoDucTs Table use lubricating and fluid products that meet the equivalent specifications, or higher than those prescribed. These same indications are also valid for topping up. Product characteristics Remarks SAE 10W40, API service type SG or greater, 4-stroke gear engine oil Do not use mineral oils.
  • Page 88 MaIn MaInTenance oPeRaTIons Product characteristics Remarks Safety lock strong tightening Strong threadlocker Lubricant for bolts unlocking Unblocking protective lubricant Anti-friction lubricant screw Generic engine oil tightening torques Lubricant for rubber oil seals and OR Lithium soap grease parts Battery poles White vaseline grease Low pressure water at room temperature Vehicle wash...

  • Page 89: Maintenance Plan

    Motor declines all civil and criminal liability for damage to the vehicle, property and/or persons due to maintenance operations performed by the user.

  • Page 90: Scheduled Maintenance Plan

    Motor authorised workshops. The scheduled maintenance for this fantic Motor vehicle involves a regular frequency of a service every 5,000 km or 3,000 miles (with the exception of the first service at 1,000 km or 600 miles, scheduled at the end of running-in).
  • Page 91 MaInTenance Plan service (x 1.000 km / 600 mi) specific specific Item operation period distance – Check the clearance on the rear sprocket flexible every 500 km coupling. – (300 mi) Transmission chain – Adjust if necessary. – Replace if necessary. –...
  • Page 92 MaInTenance Plan service (x 1.000 km / 600 mi) specific specific Item operation period distance – Check the bearing clearance and the handlebar      hardness. handlebar bearings – Lubricate with lithium soap based grease.   –...
  • Page 93 MaInTenance Plan Drive chain : replace only in the following cases: – worn and/or deformed chain – difficulty or impossibility of adjusting tension; – excessive elongation beyond the limit (greater than 2% of the maximum permitted length); – lack of alignment between chainring and sprocket. Fastening elements and moving parts : check the following components: –...

  • Page 95: Technical Data

    TechnIcal DaTa TechnIcal DaTa Technical Data Scrambler/Deluxe 2158 mm (84.96 in) Maximum length Rally/Explorer 2179 mm (85.79 in) Maximum width 873 mm (34.37 in) Scrambler/Deluxe 1135 mm (44.68 in) Maximum heigth Rally/Explorer 1183 mm (46.57 in) Scrambler/Deluxe 1423 mm (56.02 in) Wheel base Rally/Explorer 1432 mm (56.38 in)
  • Page 96 TechnIcal DaTa Technical Data 6-speed mechanical Type of gearbox Pedal control on the left side of the engine Primary transmission: 2.286 1st gear ratio: 2.357 2nd gear ratio: 1.824 3rd gear ratio: 1.747 Transmission ratios Scrambler/Deluxe 4th gear ratio: 1.182 5th gear ratio: 1.000 6th gear ratio: 0.846 Secondary transmission: 45/14...
  • Page 97 TechnIcal DaTa Technical Data Capacity of the fuel reserve only 3.5 l (0.76 UK gal, 0.92 US gal) Quantity (disassembled) : 1.8 l (0.4 UK gal, 0.48 US gal) Engine oil Without oil filter change : 1.15 l (0.25 UK gal, 0.3 US gal) With oil filter change : 1.2 l (0.26 UK gal, 0.32 US gal) Seats Maximum allowable weight...
  • Page 98 TechnIcal DaTa Technical Data Mono-shock absorber in adjustable compression and Scrambler/Deluxe progressive linkage Stroke 56 ± 2 mm (2.20 ± 0.07 in) Rear suspension Gas mono-shock absorber with tank positioned outside Rally/Explorer for convenient adjustment Stroke 76 ± 2 mm (2.99 ± 0.07 in) Four-piston calliper 28 mm (1.10 in) Front brake 320 mm floating disk (12.59 in)
  • Page 99 TechnIcal DaTa Technical Data Spark plug NGK ER9EH-6N Battery 12 V - 8 Ah Main fuse : 30 A Fuses Secondary fuses : 30 A (1), 10 A (1), 7.5 A (1), 5 A (3), 2 A (1) Generator 12 V - 300 W Turn signals High/low beam light Position/brake light...
  • Page 100 TechnIcal DaTa...

  • Page 101: Declaration Of Conformity

    Your vehicle is equipped with a range of radio equipment. The manufacturers of this radio equipment declare that these equipment complies with Directive 2014/53/EU where required by law. The complete text of the EU declaration of conformity is available at the following web address: www.Fantic.com/RED Addresses of radio component manufacturers: All radio components must carry the manufacturer’s address according to the provisions of directive 2014/53/EU.
  • Page 102 FANTIC MOTOR S.P.A. www.fantic.com - info@fanticmotor.it...
