Summary of Contents for Lenovo 83DF000CUS
- Page 1 User Guide Legion Pro 5i (16″, 9)
- Page 2 • Setup Guide Second Edition (January 2024) © Copyright Lenovo 2024. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-...
-
Page 3: Table Of Contents
Establish a wired connection ..Chapter 4. Help and support ..35 Unique Lenovo apps ... . . © Copyright Lenovo 2024... - Page 4 CRUs for your product model ..neither Copilot in Windows nor Windows Call Lenovo ....Search opened. What could be the potential Before you contact Lenovo .
-
Page 5: About This Guide
About this guide • This guide applies to Lenovo product model(s) listed below. Illustrations in this guide may look slightly different from your product model. Model name Machine type (MT) Legion Pro 5 16IRX9 83DF Lenovo Legion Pro 5 16IRX9 D1 •... - Page 6 User Guide...
-
Page 7: Chapter 1. Meet Your Computer
Camera The built-in camera captures visible light and converts it to digital signals. It is used for video recordings and video conferencing. Camera light The camera light indicates whether the camera is activated. © Copyright Lenovo 2024... -
Page 8: Screen
Table 1. Camera light statuses and descriptions Camera light status Description The camera is activated. The camera is not activated. Screen The screen of the built-in display is the area where text, graphics, and videos are displayed. User Guide... -
Page 9: Base
Base Description Power light Power button Keyboard Touchpad Antennas Power light The power light indicates the current power state of the PC: whether it is powered on, powered off, in sleep mode, or in hibernation mode. Table 2. Power light status and description Light status Power state Powered on... -
Page 10: Power Button
Related topics “Hotkeys” on page 20 Appendix A “Function descriptions for Lenovo hotkeys” on page 41 Touchpad The touchpad is the PC's built-in pointing device, which provides the basic functionality of an external mouse. -
Page 11: Antennas
Antennas ® The antennas transmit and receive radio waves to allow data to be transferred between your PC and a Wi-Fi network device or a Bluetooth device. Note: The antennas are hidden inside the PC. Chapter 1 Meet your computer... -
Page 12: Left
Left Description Air vents (outlet) USB Standard-A connector ® Multi-purpose USB Type-C connector Air vents (outlet) The air vents allow hot air to be discharged out of the PC. Important: When the PC is operating, do not place it on a bed, sofa, carpet, or other flexible surfaces. Otherwise, the air vents will be blocked and the PC may overheat, reducing performance or causing the PC to be unresponsive or even shut down. -
Page 13: Right
Right Description Combo audio jack Camera switch State light USB Standard-A connector Air vents (outlet) Combo audio jack The combo audio jack is used to connect single-plug headsets, headphones, or external speakers. Camera switch This toggle switch is used to enable or disable the built-in camera. Note: This switch is designed for privacy protection. -
Page 14: Usb Standard-A Connector
Table 5. State light status and description Light status Battery charge level Power state White (solid on) Powered on 21%–100% White (blinking rapidly) Powered on 1%–20% White (blinking slowly) In sleep mode Powered off or in hibernation mode USB Standard-A connector The USB Standard-A connector is used to connect storage or peripheral devices that follow the USB specification for data transfer and device interconnection. -
Page 15: Rear
Rear Description Air vents (outlet) Ethernet connector Multi-purpose USB Type-C connector ™ HDMI connector USB Standard-A connector USB Standard-A connector (always-on connector) Power connector Charging light Air vents (outlet) The air vents allow hot air to be discharged out of the PC. Important: When the PC is operating, do not place it on a bed, sofa, carpet, or other flexible surfaces. -
Page 16: Hdmi Connector
The always-on function can be turned on and off in: • The PC's firmware setup utility, or • Lenovo Vantage or Lenovo PC Manager Power connector Use this connector and the included ac power adapter to connect your PC to an electrical outlet. -
Page 17: Bottom
Bottom Description Air vents (intake) Speakers Air vents (intake) The air vents allow air to be sucked inside of the PC to cool the internal components. Important: When the PC is operating, do not place it on a bed, sofa, carpet, or other flexible surfaces. Otherwise, the air vents will be blocked and the PC may overheat, reducing performance or causing the PC to be unresponsive or even shut down. -
Page 18: Features And Specifications
Features and specifications Dimensions Width 363.4 mm (14.3 inches) Depth 260.35 mm (10.25 inches) Thickness • Thinnest: 21.99 mm (0.87 inches) • Thickest: 26.95 mm (1.06 inches) ac power adapter Input 100 V ac–240 V ac, 50 Hz–60 Hz Output 20 V dc, 15 A Power 300 W... - Page 19 Screen Size 406.4 mm (16 inches) Display resolution 2560 × 1600 pixels Keyboard Backlight color White, blue, or RGB Shortcut keys • Function keys • Hotkeys Modifier keys • Alt key • Ctrl key • Shift key • Windows key •...
-
Page 20: Statement On Usb Transfer Rate
Combo audio jack • Diameter: 3.5 mm • Supported plugs: – 3–pole,TRS – 4–pole, TRRS (CTIA and OMTP) Ethernet connector 8P8C jack Security UEFI/BIOS passwords • Administrator password • User password • Master hard disk password • User hard disk password Network Ethernet 2.5 Gbps... -
Page 21: Avoid Constant Body Contact With Specific Hot Sections
Relative humidity • Operating: 8% to 95% at wet-bulb temperature 23°C (73°F) • Storage: 5% to 95% at wet-bulb temperature 27°C (81°F) Avoid constant body contact with specific hot sections CAUTION: When the computer is operating, it should be placed on a hard and flat surface with its bottom area not in contact with user’s bare skin. - Page 22 User Guide...
-
Page 23: Chapter 2. Get Started With Your Computer
Plug the other end of the Ethernet cable into a network wall jack or a router. Note: If your computer does not include an Ethernet connector, you can purchase a USB-C to Ethernet adapter from Lenovo at https://www.lenovo.com/accessories © Copyright Lenovo 2024... -
Page 24: Unique Lenovo Apps
Lenovo Vantage Lenovo Vantage is a one-stop solution to help you update your computer, configure hardware settings, and access personalized support. If your computer is pre-installed with Lenovo Vantage, type Vantage in the Windows search box to launch this app. Notes: •... -
Page 25: Windows Help Information
Night light temperature screen. Note: Selected Lenovo computers are low blue light certified using night light mode and color temperature settings available in the pre-installed operating system. These computers are tested with night light turned on and color temperature set to 48 or greater. -
Page 26: The Fn Key And Hotkeys
The Fn key and hotkeys Hotkeys Look at the top row of the keyboard of your Lenovo computer and you’ll find keys with printed icons. These keys are called hotkeys and they provide shortcuts to functions that you’ll use frequently. The function that each hotkey provides is denoted by the icon printed on the key. -
Page 27: Dual-Function Keys Without Printed Icons
Figure 2. Locations of the FnLock key and the Fn key A Lenovo keyboard usually contains hotkeys in the top row. These hotkeys share keys with the function keys (F1–F12) and other keys. For these dual-function keys, the icons or characters denoting the primary functions are printed on top of the icons and characters denoting the secondary functions. -
Page 28: The Copilot Key
Show device information The Copilot key The era of AI has arrived, and many Lenovo PCs now include a Copilot key on the keyboard. It is located either in the bottom or the top row of the keyboard and is marked with For Windows PCs with Copilot in Windows available and enabled, pressing the Copilot key opens Copilot in Windows. -
Page 29: Change Display Settings
Step 1. Press Windows key + K. The computer searches for wireless display devices and audio devices and lists the results. Step 2. Select the display you want to connect to, and then follow the on-screen instructions. Change display settings Step 1. - Page 30 User Guide...
-
Page 31: Chapter 3. Explore Your Computer
Chapter 3. Explore your computer Intelligent features Your computer may be pre-installed with one of Lenovo Vantage, Lenovo PC Manager, or Legion Zone but not all. Most features described here can be enabled or disabled in one of these apps. Other features may be enabled in a standalone app. -
Page 32: Eye Care Mode
Notes: • Depending on its hardware, your computer may not support all the functions and options described above. • You can view and customize this feature under Device Settings in Lenovo Vantage or Lenovo PC Manager. Eye Care Mode Eye Care Mode intelligently adjusts the color temperature of the screen and can reduce the chances of developing eye fatigue or eye strain. -
Page 33: Normal Mode
You can charge the battery any time you want. The battery packs of Lenovo computers support multiple charging modes that are suitable for different power usage habits. You can switch the battery’s active charging mode in Lenovo Vantage, Lenovo PC Manager or Legion Zone. -
Page 34: Use A Power Delivery Compliant Usb Type-C Charger With The Computer
USB Type-C charger (purchased separately) that is also Power Delivery compliant to charge the computer in sleep or powered-off state. Lenovo branded USB Type-C chargers with the following listed maximum ratings are tested to work with the computer. Chargers of other brands with the same ratings should also work but are not thoroughly tested. -
Page 35: A Power Plan
The displays of some Lenovo computers support dual refresh rates. For such a computer, you can manually switch its display to work at either the higher or lower refresh rate. For Windows operation systems, the manual settings are usually found in Settings ➙... -
Page 36: Change Settings In Uefi/Bios Setup Utility
Open the UEFI/BIOS setup utility Step 1. Turn on or restart the computer. Step 2. When the Lenovo logo appears on the screen, press F2 repeatedly. Or enter Novo Button menu. Step 3. Select UEFI/BIOS Setup. Enable or disable Fool Proof Fn Ctrl Step 1. -
Page 37: Change Hotkey Mode
Change the setting to Disabled or Enabled. Step 4. Select Exit ➙ Exit Saving Changes. Enable or disable always-on For some Lenovo computers with always-on connectors, the always-on function can be enabled or disabled in the UEFI/BIOS setup utility. Step 1. Open the UEFI/BIOS setup utility. -
Page 38: Change Or Remove Administrator Password
Attention: If you forget the administrator password, a Lenovo authorized service personnel cannot reset your password. You must take your computer to a Lenovo authorized service personnel to have the system board replaced. Proof of purchase is required and a fee will be charged for parts and service. -
Page 39: Set Password For The Secondary Storage Device
Lenovo authorized service personnel cannot reset your password or recover data from the hard disk. You must take your computer to a Lenovo authorized service personnel to have the hard disk drive replaced. Proof of purchase is required and a fee will be charged for parts and service. - Page 40 User Guide...
-
Page 41: Chapter 4. Help And Support
Why does my computer start automatically when I open the lid? Your computer may have Flip to Start enabled. Many Lenovo notebook computers include a sensor that can detect the angle at which the lid is opened. When you open the lid, the sensor can detect this behavior. If Flip to Start is enabled, the computer will respond by starting up automatically. -
Page 42: Self-Help Resources
3. Click Troubleshoot & Diagnostics ➙ Custom Troubleshooting ➙ Operating System Diagnostics and then follow the on-screen instructions. Use Lenovo Vantage, Lenovo PC Manager or Legion Zone to: • Download and install the latest drivers and firmware. Use Windows Search. -
Page 43: What Is A Cru
If you intend to install a CRU, Lenovo will ship the CRU to you. You might be required to return the defective part that is replaced by the CRU. When return is required: (1) return instructions, a prepaid shipping label, and a container will be included with the replacement CRU;... -
Page 44: Call Lenovo
Call Lenovo If you have tried to correct the problem yourself and still need help, you can call Lenovo Customer Support Center. Before you contact Lenovo Record product information and problem details before you contact Lenovo. -
Page 45: Purchase Additional Services
For the terms and conditions of the Lenovo Limited Warranty that apply to your Lenovo hardware product, see “Warranty information” in the Safety and Warranty Guide that comes with your computer. Purchase additional services During and after the warranty period, you can purchase additional services from Lenovo at https:// pcsupport.lenovo.com/warrantyupgrade... - Page 46 User Guide...
-
Page 47: Appendix A. Function Descriptions For Lenovo Hotkeys
Appendix A. Function descriptions for Lenovo hotkeys Hotkey functions are denoted by the icons printed on the keys. The following table describes the functions for all Lenovo hotkeys. The keyboard of your Lenovo computer should only support a subset of the listed hotkeys. - Page 48 Table 11. Hotkey icons and denoted functions (continued) Hotkey icon Function description Plays the next audio or video in the playlist. Switches the computer’s active operation mode. Blurs the background for videoconferencing. Switches the computer’s active audio mode. Turns on/off night light mode. (Windows operating systems) Turns on/off the Eye Care mode.
-
Page 49: Appendix B. Notices And Trademarks
Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead. - Page 50 Actual results may vary. Users of this document should verify the applicable data for their specific environment. This document is copyrighted by Lenovo and is not covered by any open source license, including any Linux agreement(s) which may accompany software included with this product. Lenovo may update this document at any time without notice.
