- Page 1 User Guide Yoga 7 2-in-1 (14″, 9), Yoga 7i 2-in-1 (14″, 9), Yoga 7 2-in-1 (16″, 9), and Yoga 7i 2-in-1 (16″, 9)
- Page 2 • Setup Guide First Edition (February 2024) © Copyright Lenovo 2024. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-...
-
Page 3: Table Of Contents
Frequently asked questions ..Unique Lenovo apps ... . . How do I partition my storage drive .. - Page 4 What should I do if my computer stops Call Lenovo ....responding ....
-
Page 5: About This Guide
About this guide • This guide applies to Lenovo product model(s) listed below. Illustrations in this guide may look slightly different from your product model. Model name Machine type (MT) Yoga 7 2-in-1 14AHP9 83DK Yoga 7 2-in-1 14AHP9 1... - Page 6 User Guide...
-
Page 7: Chapter 1. Meet Your Computer
Microphones are essential components when you use your PC for video conferencing or voice recording. Infrared LED The infrared LED generates and emits near-infrared waves that are received and used by a camera (or a dedicated infrared camera) for facial recognition. © Copyright Lenovo 2024... -
Page 8: Camera
Camera The built-in camera captures visible light and converts it to digital signals. It is used for video recording and video conferencing. This camera also receives near-infrared waves emitted by an infrared LED and reflected by a human face, so it can also be used for facial recognition. -
Page 9: Base
Base Description Antennas Speakers Keyboard Fingerprint sensor* Touchpad * for selected models Antennas ® The antennas transmit and receive radio waves to allow data to be transferred between your PC and a Wi-Fi network device or a Bluetooth device. Note: The antennas are hidden inside the PC. Speakers The speakers are the PC's built-in sound output devices. -
Page 10: Fingerprint Sensor
Related topics “Hotkeys” on page 24 Appendix A “Function descriptions for Lenovo hotkeys” on page 47 Fingerprint sensor The fingerprint sensor scans your finger to unlock your PC or verify your identity. -
Page 11: Left
Left Yoga 7 2-in-1 14AHP9 and Yoga 7 2-in-1 16AHP9 Yoga 7 2-in-1 14IML9 and Yoga 7 2-in-1 16IML9 Description ™ HDMI connector ® Multi-purpose USB Type-C connector Charging light Multi-purpose USB Type-C connector Combo audio jack Note: Use the included power adapter and the USB Type-C connector (2) to supply power to the PC. Chapter 1 Meet your computer... -
Page 12: Hdmi Connector
HDMI connector The HDMI connector is used to connect an external display device, such as a television, a projector, or a monitor. Multi-purpose USB Type-C connector This multi-purpose USB Type-C connector is used to connect: • Storage or peripheral devices that follow the universal serial bus (USB) specification for data transfer and device interconnection •... -
Page 13: Right
Right Yoga 7 2-in-1 14AHP9 and Yoga 7 2-in-1 14IML9 Yoga 7 2-in-1 16AHP9 and Yoga 7 2-in-1 16IML9 Description Power light Power button microSD card slot USB Standard-A connector (always-on connector) USB Standard-A connector Chapter 1 Meet your computer... -
Page 14: Power Light
USB device connected to this type of connector even when the PC is powered off, in sleep mode, or in hibernation mode. The always-on function can be turned on and off in: • The PC's firmware setup utility, or • Lenovo Vantage or Lenovo PC Manager User Guide... -
Page 15: Rear
Rear Description Air vents (outlet) Air vents (outlet) The air vents allow hot air to be discharged out of the PC. Important: When the PC is operating, do not place it on a bed, sofa, carpet, or other flexible surfaces. Otherwise, the air vents will be blocked and the PC may overheat, reducing performance or causing the PC to be unresponsive or even shut down. -
Page 16: Bottom
Bottom Description Air vents (intake) Novo button hole Air vents (intake) The air vents allow air to be sucked inside of the PC to cool the internal components. Important: When the PC is operating, do not place it on a bed, sofa, carpet, or other flexible surfaces. Otherwise, the air vents will be blocked and the PC may overheat, reducing performance or causing the PC to be unresponsive or even shut down. -
Page 17: Features And Specifications
Features and specifications Yoga 7 2-in-1 14AHP9 and Yoga 7 2-in-1 14IML9 Dimensions Width 317.72 mm (12.51 inches) Depth 222.13 mm (8.75 inches) Thickness • Thinnest: 16.64 mm (0.66 inches) • Thickest: 18.19 mm (0.72 inches) ac power adapter Input 100 V ac–240 V ac, 50 Hz–60 Hz Output 20 V dc, 3.25 A... - Page 18 Keyboard Backlight color White Shortcut keys • Function keys • Hotkeys Modifier keys • Alt key • Ctrl key • Shift key • Windows key • Fn key Connectors and slots Combo audio jack • Diameter: 3.5 mm • Supported plugs: –...
- Page 19 USB Standard-A connector • Quantity: 1 • Maximum power output: – 5 V, 1.5 A • Supported signaling protocols: – USB 2.0 480 Mbps – SuperSpeed USB 5 Gbps Multi-purpose USB Type-C Yoga 7 2-in-1 14AHP9 connector • Quantity: 2 •...
- Page 20 Security Fingerprint reader* Location: Palm rest UEFI/BIOS passwords • Administrator password • User password • Master hard disk password • User hard disk password Network Wi-Fi • Wi-Fi 6E, or • Wi-Fi 6 Bluetooth Bluetooth 5.2 * for selected models User Guide...
-
Page 21: Features And Specifications
Features and specifications Yoga 7 2-in-1 16AHP9 and Yoga 7 2-in-1 16IML9 Dimensions Width 361.79 mm (14.24 inches) Depth 249.95 mm (9.84 inches) Thickness • Thinnest: 16.99 mm (0.69 inches) • Thickest: 18.99 mm (0.75 inches) ac power adapter Input 100 V ac–240 V ac, 50 Hz–60 Hz Output 20 V dc, 3.25 A... - Page 22 Keyboard Backlight color White Shortcut keys • Function keys • Hotkeys Modifier keys • Alt key • Ctrl key • Shift key • Windows key • Fn key Special keys or key group Numeric keypad Connectors and slots Combo audio jack •...
- Page 23 USB Standard-A connector • Quantity: 2 • Maximum power output: – 5 V, 0.9 A – 5 V, 1.5 A (for always-on connector) • Supported signaling protocols: – USB 2.0 480 Mbps – SuperSpeed USB 5 Gbps Multi-purpose USB Type-C Yoga 7 2-in-1 16AHP9 connector •...
-
Page 24: Statement On Usb Transfer Rate
Network Wi-Fi • Wi-Fi 6E, or • Wi-Fi 6 Bluetooth Bluetooth 5.2 * for selected models Statement on USB transfer rate Depending on many factors such as the processing capability of the host and peripheral devices, file attributes, and other factors related to system configuration and operating environments, the actual transfer rate using the various USB connectors on this device will vary and will be slower than the data rate listed below for each corresponding device. -
Page 25: Chapter 2. Get Started With Your Computer
Plug the other end of the Ethernet cable into a network wall jack or a router. Note: If your computer does not include an Ethernet connector, you can purchase a USB-C to Ethernet adapter from Lenovo at https://www.lenovo.com/accessories © Copyright Lenovo 2024... -
Page 26: Unique Lenovo Apps
Lenovo Vantage Lenovo Vantage is a one-stop solution to help you update your computer, configure hardware settings, and access personalized support. If your computer is pre-installed with Lenovo Vantage, type Vantage in the Windows search box to launch this app. Notes: •... - Page 27 Mode Suitable for Notebook mode • Entering text • Drag and drop operations using the touchpad Stand mode • Giving a presentation • Viewing a slide show Chapter 2 Get started with your computer...
-
Page 28: Interact With Your Computer
Interact with your computer Lenovo Digital Pen (for selected models) Selected models are equipped with Lenovo Digital Pen. The pen is not waterproof. Keep the pen away from water and excessive moisture. To purchase Lenovo Digital Pen, go to https://www.lenovo.com/accessories Before first use An insulation pad may be included in the Lenovo Digital Pen to prevent capacity loss during shipping. - Page 29 Lenovo Pen Settings is not accurate. Step 2. Open Lenovo Pen Settings. A battery icon is displayed in the upper right corner. Step 3. Move the mouse pointer on top of the battery icon to view the charge reading.
-
Page 30: Set Lenovo Digital Pen
Note: After you enable the near-screen click function, the pen buttons work as mouse buttons. Hotkeys Look at the top row of the keyboard of your Lenovo computer and you’ll find keys with printed icons. These keys are called hotkeys and they provide shortcuts to functions that you’ll use frequently. The function that each hotkey provides is denoted by the icon printed on the key. - Page 31 Figure 4. Locations of the FnLock key and the Fn key A Lenovo keyboard usually contains hotkeys in the top row. These hotkeys share keys with the function keys (F1–F12) and other keys. For these dual-function keys, the icons or characters denoting the primary functions are printed on top of the icons and characters denoting the secondary functions.
-
Page 32: The Copilot Key
Primary function The Copilot key The era of AI has arrived, and many Lenovo PCs now include a Copilot key on the keyboard. It is located either in the bottom or the top row of the keyboard and is marked with For Windows PCs with Copilot in Windows available and enabled, pressing the Copilot key opens Copilot in Windows. -
Page 33: Change Display Settings
Step 1. Press Windows key + K. The computer searches for wireless display devices and audio devices and lists the results. Step 2. Select the display you want to connect to, and then follow the on-screen instructions. Change display settings Step 1. -
Page 34: Dual-Function Keys Without Printed Icons
* for selected models Numeric keypad (for selected models) Some Lenovo computers include a dedicated numeric keypad on the far right of the keyboard. The keypad is used for entering numbers and operators quickly. Press the NumLock key to enable or disable the numeric keypad. - Page 35 Touch operation Used for Zooming out Pinch Zooming in Spread Opening the widgets panel Swipe in from the left edge Opening the notification center Swipe in from the right edge The Windows operating system also supports 3- and 4-finger gestures on the screen and the touchpad. You can set them up in Settings ➙...
- Page 36 User Guide...
-
Page 37: Chapter 3. Explore Your Computer
Intelligent features Your computer may be pre-installed with one of Lenovo Vantage or Lenovo PC Manager but not both. Most features described here can be enabled or disabled in one of these apps. Other features may be enabled in a standalone app. -
Page 38: Super Resolution
It works especially well in cases where the source video has poor resolution. For most players, Super Resolution can be enabled or disabled in Lenovo Vantage or Lenovo PC Manager, but for some specific players, you might need to enable this feature manually. -
Page 39: Manage Power
• Depending on its hardware, your computer may not support all the functions and options described above. • You can view and customize this feature under Device Settings in Lenovo Vantage or Lenovo PC Manager. * for Yoga 7 2-in-1 14IML9 and Yoga 7 2-in-1 16IML9 Manage power Use the information in this section to achieve the best balance between performance and power efficiency. - Page 40 If the battery pack of your computer supports overnight charge optimization, it can be enabled in Lenovo Vantage or Lenovo PC Manager.
-
Page 41: Set Power Button Behavior
You can switch the operation mode in the pre-installed app Lenovo Vantage or Lenovo PC Manager. As a shortcut, you can also use the key combination Fn + Q. Three modes are usually available for most Lenovo computers. The following table lists the operation modes and the recommended conditions for each mode. -
Page 42: Adjustable Display Refresh Rate (For Selected Models)
The displays of some Lenovo computers support dual refresh rates. For such a computer, you can manually switch its display to work at either the higher or lower refresh rate. For Windows operation systems, the manual settings are usually found in Settings ➙... -
Page 43: Change Hotkey Mode
Change the setting to Disabled or Enabled. Step 4. Select Exit ➙ Exit Saving Changes. Enable or disable always-on For some Lenovo computers with always-on connectors, the always-on function can be enabled or disabled in the UEFI/BIOS setup utility. Step 1. Open the UEFI/BIOS setup utility. -
Page 44: Set Administrator Password
Attention: If you forget the administrator password, a Lenovo authorized service personnel cannot reset your password. You must take your computer to a Lenovo authorized service personnel to have the system board replaced. Proof of purchase is required and a fee will be charged for parts and service. -
Page 45: Set Hard Disk Password
Lenovo authorized service personnel cannot reset your password or recover data from the hard disk. You must take your computer to a Lenovo authorized service personnel to have the hard disk drive replaced. Proof of purchase is required and a fee will be charged for parts and service. - Page 46 User Guide...
-
Page 47: Chapter 4. Help And Support
Why does my computer start automatically when I open the lid? Your computer may have Flip to Start enabled. Many Lenovo notebook computers include a sensor that can detect the angle at which the lid is opened. When you open the lid, the sensor can detect this behavior. If Flip to Start is enabled, the computer will respond by starting up automatically. -
Page 48: Self-Help Resources
3. Click Troubleshoot & Diagnose ➙ Custom Troubleshooting ➙ Operating System Diagnostics and then follow the on-screen instructions. Use Lenovo Vantage or Lenovo PC Manager to: • Download and install the latest drivers and firmware. • Configure hardware settings. Use Windows Search. -
Page 49: What Is A Cru
If you intend to install a CRU, Lenovo will ship the CRU to you. You might be required to return the defective part that is replaced by the CRU. When a return is required: (1) return instructions, a prepaid shipping label, and a container will be included with the replacement CRU;... -
Page 50: Call Lenovo
Call Lenovo If you have tried to correct the problem yourself and still need help, you can call Lenovo Customer Support Center. Before you contact Lenovo Record product information and problem details before you contact Lenovo. Product information Problem symptoms and details •... -
Page 51: Purchase Additional Services
Purchase additional services During and after the warranty period, you can purchase additional services from Lenovo at https:// pcsupport.lenovo.com/warrantyupgrade Service availability and service name might vary by country or region. Chapter 4 Help and support... - Page 52 User Guide...
-
Page 53: Appendix A. Function Descriptions For Lenovo Hotkeys
Appendix A. Function descriptions for Lenovo hotkeys Hotkey functions are denoted by the icons printed on the keys. The following table describes the functions for all Lenovo hotkeys. The keyboard of your Lenovo computer should only support a subset of the listed hotkeys. - Page 54 Table 7. Hotkey icons and denoted functions (continued) Hotkey icon Function description Plays the next audio or video in the playlist. Switches the computer’s active operation mode. Blurs the background for videoconferencing. Switches the computer’s active audio mode. Turns on/off night light mode. (Windows operating systems) Turns on/off the Eye Care mode.
-
Page 55: Appendix B. Notices And Trademarks
Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead. - Page 56 Actual results may vary. Users of this document should verify the applicable data for their specific environment. This document is copyrighted by Lenovo and is not covered by any open source license, including any Linux agreement(s) which may accompany software included with this product. Lenovo may update this document at any time without notice.
