  • Page 1 Hardware Maintenance Manual IdeaPad Pro 5i (16″, 9) and IdeaPad Pro 5 (16″, 9)
  • Page 2 First Edition (October 2023) © Copyright Lenovo 2023.

  • Page 3: Table Of Contents

    Remove the solid-state drive (SSD) ..Trademarks ....xlix Remove the Wi-Fi card ... . © Copyright Lenovo 2023...
  • Page 4 Hardware Maintenance Manual...

  • Page 5: About This Manual

    Important: • This manual is intended only for trained service technicians who are familiar with Lenovo products. • Before servicing a Lenovo product, be sure to read all the information under Chapter 1 “Safety information” on page 1. © Copyright Lenovo 2023...
  • Page 6 Hardware Maintenance Manual...

  • Page 7: Chapter 1. Safety Information

    • Do not work alone under hazardous conditions or near equipment that has hazardous voltages. • Disconnect all power before: – Performing a mechanical inspection – Working near power supplies © Copyright Lenovo 2023...

  • Page 8: Safety Inspection Guide

    This guide addresses only those items. You should use good judgment to identify potential safety hazards due to attachment of non-Lenovo features or options not covered by this inspection guide.

  • Page 9: Handling Devices That Are Sensitive To Electrostatic Discharge

    4. Check for cracked or bulging batteries. 5. Remove the cover. 6. Check for any obvious non-Lenovo alterations. Use good judgment as to the safety of any non-Lenovo alterations. 7. Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or other liquids, or signs of fire or smoke damage.

  • Page 10: Grounding Requirements

    Grounding requirements Electrical grounding of the computer is required for operator safety and correct system function. Proper grounding of the electrical outlet can be verified by a certified electrician. Safety notices (multilingual translations) The safety notices in this section are provided in the following languages: •...
  • Page 11 DANGER DANGER DANGER DANGER Chapter 1 Safety information...
  • Page 12 Hardware Maintenance Manual...
  • Page 13 PERIGO PERIGO PERIGO PERIGO PERIGO Chapter 1 Safety information...
  • Page 14 PERIGO PERIGO PERIGO DANGER DANGER DANGER Hardware Maintenance Manual...
  • Page 15 DANGER DANGER DANGER DANGER DANGER VORSICHT Chapter 1 Safety information...
  • Page 16 VORSICHT VORSICHT VORSICHT VORSICHT VORSICHT Hardware Maintenance Manual...
  • Page 17 VORSICHT VORSICHT Chapter 1 Safety information...
  • Page 18 Hardware Maintenance Manual...
  • Page 19 Chapter 1 Safety information...
  • Page 20 Hardware Maintenance Manual...
  • Page 21 Chapter 1 Safety information...
  • Page 22 Hardware Maintenance Manual...
  • Page 23 Chapter 1 Safety information...
  • Page 24 Hardware Maintenance Manual...

  • Page 25: Chapter 2. General Checkout

    • LCD panel cracked from the application of excessive force or from being dropped • Scratched (cosmetic) parts • Distortion, deformation, or discoloration of the cosmetic parts • Plastic parts, latches, pins, or connectors that have been cracked or broken by excessive force © Copyright Lenovo 2023...

  • Page 26: Cru List

    • Damage caused by liquid spilled into the system • Damage caused by the improper insertion of a personal-computer card (PC card) or the installation of an incompatible card • Improper disc insertion or use of an external optical drive •...

  • Page 27: Chapter 3. Identifying Frus (Crus)

    Chapter 3. Identifying FRUs (CRUs) Locate FRUs and CRUs The exploded illustrations help Lenovo service technicians identify FRUs or CRUs that they may need to replace when servicing a customer’s computer. © Copyright Lenovo 2023...
  • Page 28 Figure 1. Exploded view Hardware Maintenance Manual...
  • Page 29 Table 3. FRU (CRU) categories FRU (CRU) category LCD module Notes: • For LCD panel, the LCD module as a whole is not a FRU, it contains FRUs as its components. • For OLED panel, the LCD module is a FRU and it cannot be disassembled. Upper case System board System board conduction mylar...
  • Page 30 Figure 2. LCD module - exploded view (for LCD panels only) Table 4. FRU categories for the LCD module FRU (CRU) category Hinge cover LCD bezel LCD panel Microphone rubber Camera board ToF rubber Camera cable Removable tape LCD cover EDP cable Hardware Maintenance Manual...

  • Page 31: Chapter 4. Removing A Fru Or Cru

    Chapter 4. Removing a FRU or CRU Service tools The following table lists tools for servicing Lenovo computers. Tools with a cross mark are needed for serving the product models as described by this publication. Prepare them before you service the product.

  • Page 32: Remove The Lower Case

    2. Begin by removing any FRUs that have to be removed before replacing the failing FRU. Any such FRUs are listed at the beginning of each FRU replacement procedure. Remove them in the order in which they are listed. 3. Follow the correct sequence in the steps for removing an FRU, as shown in the illustrations by the numbers in square callouts.

  • Page 33: Remove The Battery Pack And Battery Pack Cable

    Step 3. Pry up the latches and then remove the lower case. Figure 4. Remove the lower case Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: Lower case Remove the battery pack and battery pack cable Make sure the following FRU (or CRU) has been removed.

  • Page 34: Remove The Solid-State Drive (Ssd) Plate

    Remove one screw and then remove the SSD plate. Figure 7. Remove the SSD plate Screw specifications Number of screws M2 x L3.5 Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: Solid-state drive (SSD) plate Hardware Maintenance Manual...

  • Page 35: Remove The Solid-State Drive (Ssd)

    Screw specifications Number of screws M2 x L2.5 Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following replacement parts: Solid-state drive (SSD) Remove the Wi-Fi card Make sure the following FRU (or CRU) has been removed.

  • Page 36: Remove The Type-C Bracket

    Figure 9. Remove the Wi-Fi card Screw specifications Number of screws M2 x L3.5 Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: Wi-Fi card Remove the Type-C bracket Make sure the following FRU (CRU) has been removed.

  • Page 37: Remove The Heat Sink

    Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: Type-C bracket Remove the heat sink Make sure the following FRU (or CRU) has been removed. “Remove the lower case” on page 26 Step 1.

  • Page 38: Apply The Thermal Interface Material (Tim) On The Cpu/Gpu Contact Area Of The Heat Sink (For Dis)

    Figure 12. The area where the thermal interface material should be applied Apply the thermal interface material (TIM) on the CPU/GPU contact area of the heat sink (for DIS) Step 1. Clean off the old thermal interface material from the CPU/GPU contact area of the heat sink. Step 2.

  • Page 39: Remove The I/O Board

    Figure 15. Remove the fans Number of screws Screw specifications M2 x L3.5 Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: Fans Remove the I/O board Make sure the following FRUs (or CRUs) have been removed.
  • Page 40 Figure 16. Remove two screws and then open the hinge Screw specifications Number of screws M2.5 x L5 Step 3. Peel back the I/O board mylar. Figure 17. Peel back the I/O board mylar Step 4. Disconnect cables connected to the I/O board. Hardware Maintenance Manual...
  • Page 41 Figure 18. Disconnect cables connected to the I/O board Step 5. Remove one screw and then remove the I/O board. Figure 19. Remove the I/O board Screw specifications Number of screws M2 x L3.5 Step 6. Remove the I/O board mylar. Figure 20.

  • Page 42: Remove The System Board And The I/O Board Cable

    Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: I/O board I/O board mylar Remove the system board and the I/O board cable Make sure the following FRUs (or CRUs) have been removed. “Remove the lower case” on page 26 “Remove the battery pack and battery pack cable”...
  • Page 43 Figure 22. Peel back the I/O board mylar Step 3. Disconnect cables connected to the system board and then remove the system board. Figure 23. Remove the system board Step 4. Remove the I/O board cable from the system board. Figure 24.

  • Page 44: Use A Golden Key U1 Tool To Flash-Write Key Id Information

    Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: System board I/O board cable Use a Golden Key U1 tool to flash-write key id information After replacing the system board and re-assembling the computer, use a pre-made Golden Key U1 tool to start the computer and flash-write the serial number (SN), machine type (MT), product name (PN), and UUID to the new system board.

  • Page 45: Remove The Upper Case

    “Remove the I/O board” on page 33 “Remove the system board and the I/O board cable” on page 36 “Remove the LCD module” on page 38 Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: Upper case Disassemble the LCD module (for LCD panels only) The LCD module as a whole is not a FRU.

  • Page 46: Remove The Hinge Cover

    Remove the hinge cover. Figure 27. Remove the hinge cover Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement part: Hinge cover Remove the LCD bezel Make sure the following FRUs (or CRUs) have been removed.

  • Page 47: Remove The Lcd Panel

    Screw specifications Number of screws M1.6 x L2.9 Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement part: LCD bezel Remove the LCD panel Make sure the following FRUs (CRUs) have been removed. “Remove the LCD module” on page 38 “Remove the hinge cover”...

  • Page 48: Remove The Microphone Rubber

    Step 2. Remove the EDP cable from the LCD panel. Figure 31. Remove the EDP cable Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: LCD panel EDP cable Removable tape Remove the microphone rubber Make sure the following FRUs (CRUs) have been removed.

  • Page 49: Remove The Tof Rubber

    Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: Microphone rubber Removable tape Remove the ToF rubber Make sure the following FRUs (CRUs) have been removed. “Remove the LCD module” on page 38 “Remove the hinge cover” on page 40 “Remove the LCD bezel”...

  • Page 50: Remove The Camera Board

    Figure 34. Remove the camera cable Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: Camera cable Removable tape Remove the camera board Make sure the following FRUs (CRUs) have been removed. “Remove the LCD module” on page 38 “Remove the hinge cover”...

  • Page 51: Remove The Lcd Cover

    “Remove the ToF rubber” on page 43 “Remove the camera cable” on page 43 “Remove the camera board” on page 44 Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement part: LCD cover Chapter 4 Removing a FRU or CRU...
  • Page 52 Hardware Maintenance Manual...

  • Page 53: Appendix A. Label Locations

    Indonesia label 26 mm x 10 mm KCC label 50 mm x 16 mm Belarus label 40 mm x 8 mm BIS label 22 mm x 30 mm Vietnam MEPS label 10 mm x 9 mm © Copyright Lenovo 2023...
  • Page 54 Hardware Maintenance Manual...

  • Page 55: Trademarks

    Trademarks LENOVO and the LENOVO logo are trademarks of Lenovo. All other trademarks are the property of their respective owners. © 2023 Lenovo.
