Q: When playing 4Kx2K source, screen is back without any
content?
A: Make sure both TV and HDMI cable support HDMI1.4.
Q: Display not fluent, not stable?
A: 1) Please check the cable length between the TX to switch, the
switch to the RX and the connection between each level is within
the required range.
2) Click the "reset" button on the TX/RX front panel, reset and
reconnect.
SPECIFICATION
HDMI signal
Support resolutions
Network cable
Transmission distance
IR Signal
Working temperature
Power Supply
Power consumption
Dimensions
Input POE
Weight
Color
Maintenance: clean only with a dry cloth. Do not use cleaning
solvents or abrasives.
Warranty: no guarantee or liability can be accepted for any changes
and modifications of the product or damage caused due to incorrect
use of this product.
In compliance with EU Directive WEEE this product is marked
with this symbol. It means that used electrical and electronic
products should not be mixed with general household waste.
There is a separate collections system for these products
in compliance with WEEE directive, otherwise contaminative and
hazardous substances can pollute the environment.
With the CE sign, Techly
conformed to the basic European standards and directives.
WWW.TECHLY.COM
Compatible with HDCP
480i@60Hz, 480p@60Hz, 576i@50Hz,
576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz,
1080p@50/60Hz, 4Kx2K@24/25/30Hz
UTP/STP Cat5E/6
Up to 120m transmission distance for 1080p
60Hz Full HD over single CAT6
Supports 20-60KHz IR devices
0°C – 60°C
DC5V/2A (adapter not included)
TX: 4.5W; RX: 3.5W
107.3 (L) x 94 (W) x 23.7 (H) mm * 2pcs
Support IEEE802.3af (Input power 10W)
TX: 275g RX: 275g
Black
ensures that the product is
®
4K@30HZ HDMI
EXTENDER WITH POE
