  • Page 1 KIP522-EUK KIP522-S-EUK 21.5" 20 lb (55 cm) (9.1 kg)
  • Page 2 WARNING ENG - Do not begin to install product until you have read and understood the instructions and warnings contained in this user guide. Before installing make sure the supporting surface will support the combined load of the equipment and hardware. Screws must be tightly secured. Do not overtighten screws or damage can occur and product may fail.
  • Page 3 This page intentionally left blank.

  • Page 4: Parts List

    Parts (Before beginning, make sure you have all parts shown below). Parts List KIP522-EUK KIP522-S-EUK Description Part # kiosk 10005358-SLV-EUK 10005358-BLK-EUK loop clamp 10000739 M4 x 10mm 521-1050 cable tie 560-9711 hex nut 530-9041 M6 x 12mm 520-1128 M8 x 12mm...
  • Page 5 Remove 2021-09-20 #:150-9279-3 (2025-02-14)
  • Page 6 3/4" ENG Remove bolts to disengage kiosk from pallet before installing product. (19mm) 2021-09-20 #:150-9279-3 (2025-02-14)
  • Page 7 ENG Not included. 2021-09-20 #:150-9279-3 (2025-02-14)
  • Page 8 VESA: 200X200 VESA: 200X200 4a-1 4b-1 VESA: 100X100 VESA: 100X100 4c-1 4d-1 2021-09-20 #:150-9279-3 (2025-02-14)
  • Page 9 This page intentionally left blank. 2021-09-20 #:150-9279-3 (2025-02-14)
  • Page 10 4a-1 4a-2 1/8" (3mm) F,G,H,I ENG Not included. 4a-3 F,G,H,I Tighten. 2021-09-20 #:150-9279-3 (2025-02-14)
  • Page 11 4b-1 4b-2 1/8" (3mm) F,G,H,I ENG Not included. 4b-3 F,G,H,I Tighten. 2021-09-20 #:150-9279-3 (2025-02-14)
  • Page 12 4c-1 4c-2 1/8" (3mm) ENG Slots for M4 screws only. ENG Not included. 4c-3 Tighten. ENG For M4 screws only. 2021-09-20 #:150-9279-3 (2025-02-14)
  • Page 13 4d-1 4d-2 1/8" (3mm) ENG Slots for M4 screws only. ENG Not included. 4d-3 Tighten. ENG For M4 screws only. 2021-09-20 #:150-9279-3 (2025-02-14)
  • Page 14 Cable management. ENG Not included. 2021-09-20 #:150-9279-3 (2025-02-14)
  • Page 15 Replace ENG Not included. 2021-09-20 #:150-9279-3 (2025-02-14)
  • Page 16 Záruka TÜR Garanti̇ Garanzia Záruka www.peerless-av.com/warranty Peerless-AV Peerless-AV Europe Peerless-AV América Latina 2300 White Oak Circle Unit 3 Watford Interchange, Av. de las Industrias 413 Aurora, IL 60502 Colonial Way, Watford, Herts, Parque Industrial Escobedo Email: tech@peerlessmounts.com WD24 4WP, United Kingdom General Escobedo N.L., México 66062...
