- Page 1 ČEŠ TÜR 2017-03-22 #:150-9085-4 (2020-04-01)
- Page 2 WARNING ENG - Do not begin to install product until you have read and understood the instructions and warnings contained in this user guide. Before installing make sure the supporting surface will support the combined load of the equipment and hardware. Screws must be tightly secured. Do not overtighten screws or damage can occur and product may fail.
- Page 3 ACHTUNG DEU - Lesen Sie zuerst die Anleitungen und Sicherheitshinweise in diesem Handbuch bevor Sie mit der Montage des Produktes beginnen. Vergewissern Sie sich vor der Anbringung, dass die tragende Fläche das Gesamtgewicht der Geräte und der Befestigungsteile tragen kann. Die Schrauben müssen sicher angezogen werden.
- Page 4 VÝSTRAHA ČEŠ - Nezačínejte s instalací výrobku dříve, než si přečtete pokyny a varování obsažená v tomto návodu k použití a porozumíte jim. Před instalací se ujistěte, že podpůrný povrch udrží součet zatížení zařízení a hard- waru. Šrouby je třeba dotáhnout napevno. Nedotahujte šrouby nadměrně, jinak by mohlo dojít ke škodám a selhání...
- Page 5 UYARI TUR - Bu kullanıcı kılavuzunda yer alan talimatları ve uyarıları okuyup anlamadan ürünü kurmaya başlamayın. Montaja başlamadan önce taşıyıcı yüzeyin hem takacağınız ekipmanı hem e aksamı birlikte taşıyacağından emin olun. Vidalar sağlam bir şekilde sıkıştırılmalıdır. Vidaları aşırı sıkıştırırsanız vidalara hasar verebilirsiniz ve ürün düşebilir.
- Page 6 Symbols Símbolos Symboles Symbole Symbolen WARNING Simboli ADVERTENCIA ČEŠ Symboly Skip to step. ADVERTISSEMENT Symboly Continúe con el ACHTUNG Screws must get at least three Símbolos paso. WAARSCHUWING full turns and fit snug. Semboller TÜR Passez à l’étape. AVVERTENZA Los tornillos tienen que dar, Weiter mit Schritt.
- Page 7 Tools Needed for Assembly. Herramientas necesarias para el ensamblaje. Outils nécessaires au montage. To properly tighten screws: Tighten until screw Für den Zusammenbau erforderliche Werkzeuge. head makes contact, then tighten another 1/2 Voor montage benodigd gereedschap. turn. Do not overtighten screws. Attrezzi necessari per l’assemblaggio.
-
Page 8: Parts List
J key 565-0049A 565-0049A 565-0049A 565-0049A 565-0049A K t-wrench 560-1718 560-1718 560-1718 560-1718 560-1718 Parts List KIPC2548 KIPC2549 KIPC2550 KIPC2555 KIPC2565 KIPC2548-S KIPC2549-S KIPC2550-S KIPC2555-S KIPC2565-S Description Part# Part# Part# Part# Part# A kiosk BLK 151-P1671-48 151-P1671-49 151-P1671-50 151-P1671-55 151-P1671-65... - Page 9 B (4) C (4) A ( 1 ) kiosk M6 x 12 mm M6 x 25 mm D (4) E (4) M8 x 12 mm M8 x 25 mm F (8) G (8) washer spacer H (1) I (6) power strip cable tie J ( 2 ) K ( 1 )
- Page 10 J ( 2 ) 2017-03-22 #:150-9085-4 (2020-04-01)
- Page 11 Remove Remove quite quite retirez retirez entfernen entfernen verwijderen verwijderen rimuovere rimuovere odstranit odstranit ČEŠ ČEŠ odstrániť odstrániť remova remova çıkartın çıkartın TÜR TÜR Remove Remove quite quite retirez retirez entfernen entfernen verwijderen verwijderen rimuovere rimuovere odstranit odstranit ČEŠ ČEŠ odstrániť...
- Page 12 ENG Caution: Remove bolts to disengage kiosk from pallet before installing product. 3/4" (19mm) 7/16" Remove (11mm) quite retirez entfernen verwijderen rimuovere odstranit ČEŠ odstrániť remova çıkartın TÜR 2017-03-22 #:150-9085-4 (2020-04-01)
- Page 13 40" - 48" 49" - 55" 65" 2017-03-22 #:150-9085-4 (2020-04-01)
- Page 14 VESA PATTERN 200mm 300mm 400mm 600mm ENG If adapter brackets interfere with display peripherals (plugs, etc.), use spacers provided. Consider the depth of the display and spacer when determining if the display will fit within the kiosk. 2017-03-22 #:150-9085-4 (2020-04-01)
- Page 15 VESA PATTERN 200mm 300mm 400mm 600mm 800mm ENG If adapter brackets interfere with display peripherals (plugs, etc.), use spacers provided. Consider the depth of the display and spacer when determining if the display will fit within the kiosk. 2017-03-22 #:150-9085-4 (2020-04-01)
- Page 16 VESA PATTERN 200mm 300mm 400mm 600mm 800mm 1000mm ENG If adapter brackets interfere with display peripherals (plugs, etc.), use spacers provided. Consider the depth of the display and spacer when determining if the display will fit within the kiosk. 2017-03-22 #:150-9085-4 (2020-04-01)
- Page 17 7/16" (11mm) 2017-03-22 #:150-9085-4 (2020-04-01)
- Page 18 Adjust Ajuste Réglez Einstellen Aanpassen Regolare Nastavit ČEŠ Nastaviť Ajuste Ayarlayın TÜR 2017-03-22 #:150-9085-4 (2020-04-01)
- Page 19 J ( 2 ) 2017-03-22 #:150-9085-4 (2020-04-01)
- Page 20 Cable management manejo de cables gestion des câbles Kabelführung kabelbeheer gestione dei cavi vedení kabelů ČEŠ vedenie káblov gestão de cabos kablo yönetimi TÜR I ( 6 ) 2017-03-22 #:150-9085-4 (2020-04-01)
- Page 21 10a-1 10b-1 10c-1 2017-03-22 #:150-9085-4 (2020-04-01)
- Page 22 10a-1 10a-2 2017-03-22 #:150-9085-4 (2020-04-01)
- Page 23 10b-1 Remove quite retirez entfernen verwijderen rimuovere odstranit ČEŠ odstrániť remova çıkartın TÜR 10b-2 2017-03-22 #:150-9085-4 (2020-04-01)
- Page 24 10b-3 10b-4 2017-03-22 #:150-9085-4 (2020-04-01)
- Page 25 10c-1 Remove quite retirez entfernen verwijderen rimuovere odstranit ČEŠ odstrániť remova çıkartın TÜR 10c-2 2017-03-22 #:150-9085-4 (2020-04-01)
- Page 26 10c-3 10c-4 2017-03-22 #:150-9085-4 (2020-04-01)
- Page 27 J ( 2 ) KIPC2540, KIPC2540-S, KIPC2542, KIPC2542-S, KIPC2543, KIPC2543-S, KIPC2546, KIPC2546-S, KIPC2547, KIPC2547-S, KIPC2548, KIPC2548-S, KIPC2549, KIPC2549-S, KIPC2550, KIPC2550-S, KIPC2555, KIPC2555-S, KIPC2565, KIPC2565-S 2017-03-22 #:150-9085-4 (2020-04-01)
